1
1. Abstract
This manual provides specifications for the OPI-3601 handheld 2D imager scanner.
2. Overview
The OPI-3601 is a handheld 2D imager scanner that enables high speed scanning of standard linear
(1D) and 2D symbologies. Main features of the OPI-3601 are as follows:
・High-speed scanning
Extremely high speed performance ensures stress free scanning and fast response without being
affected by hand movement and light conditions.
・Auto trigger, moving object scanning
With the use of a dedicated stand, the scanner is automatically triggered and a moving target can
be detected automatically and scanned instantaneously.
・Editing function
A new function “Data Editing Program” captures up to 16 codes on multiple images simultaneously
in one go. Output editing process, such as GS1 format, also can be set easily.
・World's most compact 2D scanner in its class
The OPI-3601 offers ultra-compact size and easy operation.
・LED aiming
A sharp single line of green LED makes it easy to aim the scanner while providing safety and long-
life.
・Antimicrobial coating
Special antimicrobial treatment is applied to the chassis, and alcohol can be used to clean the
scanner (except for the scanning window and the logo panel).
・Various interfaces
Four types of interfaces, RS-232C, Keyboard Wedge PS/2, USB-HID, and USB-COM, are
supported.
・RoHS compliance
The OPI-3601 is a RoHS compliant product, which is declared by Optoelectronics Co., Ltd.
* Refer to “OPI-3601 User’s Manual” for supported codes and commands.

OPI-3601
Specifications Manual
2
3. Basic Specifications
Item Specification Note
CPU CPU: ARM-926EJ-S
Core: 400 MHz
SDRAM 256 Mbits (2 M × 4 Banks × 32 Bits ) SDCLK: 133 MHz
Control
Section
Flash ROM 16 Mbits (1 M × 16 Bits) Flash Memory
RS-232C 300 bps ~ 115200 bps Default: 9600bps
USB USB2.0 Full-Speed 12 Mbps (HID/COM)
Interface
Wedge PS/2 Keyboard (selectable ‘with or without
keyboard connection’)
Scanning method WVGA (0.36 million-pixel) CMOS area sensor Frame rate: 60 fps
Scanning light source 2 red LEDs
Aiming light source 1 green LED
Effective pixels 0.36 million pixels (H: 752 x V: 480)
Optical Section
View angle Horizontal: about 40.6°
Vertical: about 26.4°
Symbologies
UPC-A, UPC-A Add-on, UPC-E, UPC-E Add-
on, EAN-13, EAN-13 Add-on, EAN-8, EAN-8
Add-on, JAN-8, JAN-13, Code 39, Tri-Optic,
Codabar (NW-7), Industrial 2 of 5, Interleaved
2 of 5, S-Code, IATA, Code 93, Code 128,
MSI/Plessey, UK/Plessey, TELEPEN, Matrix 2
of 5, Chinese Post Matrix 2 of 5, Code 11,
Korean Postal Authority code, Postal Code
Minimum resolution Code 39 : 0.127 mm PCS 0.9
Curvature Radius ≧16 mm (12-digit 0.15mm Codabar)
Radius ≧20 mm (13-digit UPC) PCS 0.9
Wide Bar Code Possible to read: Code 39 with 100 mm width
and resolution 0.2mm (DOF: 135 mm)
Motion tolerance Possible to read: UPC 100% moving at 2 m/s
(DOF: 100 mm)
Resolution (0.127) 65 ~ 105
Resolution (0.254) 45 ~ 185
Code 39
Resolution (0.508) 50~ 250
Code 128 Resolution (0.2) 65 ~ 150
Supported 1D Symbologies
Depth of field
(mm)
UPC Resolution (0.33) 45 ~ 175
Symbologies
GS1 DataBar, GS1 DataBar Limited, GS1
DataBar Expanded, Composite GS1-DataBar,
Composite GS1-128, Composite EAN,
Composite UPC
GS1 DataBar: formerly
called “RSS”
GS1/Composite
Minimum resolution GS1 DataBar : 0.169 mm
Composite Code: 0.169 mm

OPI-3601
Specifications Manual
3
Item Specification Note
Symbologies
PDF417, MicroPDF417, Codablock F, QR
Code , Micro QR Code, DataMatrix (ECC 0 -
140 / ECC 200), MaxiCode (Modes 2 to 5),
Aztec Code, Chinese Sensible Code
Disable Code 128
when Codablock F is
enabled.
Minimum resolution (mm)
PDF417 : 0.169 mm
QR Code : 0.212 mm
DataMatrix : 0.212 mm
PCS 0.9
Resolution (0.169) 60~ 120
PDF417
Resolution (0.254) 45 ~ 185
Resolution (0.212) 70 ~ 95
QR Code
Resolution (0.381) 35 ~ 165
Supported 2D Symbologies
Depth of field
(mm)
DataMatrix Resolution (0.254) 65 ~ 120
PCS 0.9
Pitch : ±40°
Skew : ±50°
Scan angle
Tilt : ±180°
Common
Minimum PCS 0.3 or more MRD: 32% or more
Image data format Windows Bitmap, JPEG
Shades of gray 1024, 256, 16, 2
Range of output image Select top/bottom (column) and left/right (row)
Resolution of output image Full,1/2, 1/4
Interface of output image RS-232C, USB-COM
Black spot may appear
on images, however, it
does not affect the
scanning performance..
USB-COM
(full speed) About 3 sec
Imager
Baud rate RS-232C
(baud rate: 15.2 kbps) About 40 sec
Resolution: Full
Range of operating voltage
4.5 ~ 5.5 V: USB
5.4 ~ 6.6 V: RS-232C / Wedge PS/2
(external power supply )
RS-232C / Wedge
(external power
supply): Dedicated AC
adapter 6.0 V ±5%
Reading 300 mA (max)
Power
Current
consumption
(RS-232C) Standby 75 mA (max)
At 6.0 V, room
temperature/ humidity,
Operating -20~ 50°C AC adapter: 0 ~ 40°C
Temperature
Storage -20 ~ 60°C
Operating 5 ~ 90% (no condensing, no frost)
Humidity
Storage 5 ~ 90% (no condensing, no frost)
Fluorescent 10,000 lx or less
Ambient light
immunity Sunlight 100,000 lx or less
UPC 100%
Optical axis angle: 75°
Distance: 100 mm
Vibration
10 Hz ~ 100 Hz, acceleration of 19.6 m/s2,
60 minutes per cycle, repeat once in each X, Y
and Z-direction
Drop
Drop 3 times, at each 5 faces (right, left, front,
back and top), from a height of 150 cm onto a
concrete surface.
* Excluding the part
where the interface
cable is attached
Environmental Specifications
Dust and drip proof IP42

OPI-3601
Specifications Manual
4
Item Specification Note
This scanner is an Exempt Risk Group LED product.
LED safety IEC 62471-1:2006 Exempt Risk Group Peak Wavelength:
624 nm
EMI/RFI VCCI / EN55022 / FCC Class-B
For residential,
commercial and light-
industrial environments
Product safety CE Marking
Regulatory
Electromagnetic compatibility
(EMC) EN55024 (EN61000-6-1) Class-B
For residential,
commercial and light-
industrial environments
No destruction 15 kV (Apply static electricity 50 times to the
surface of the scanner)
ESD immunity
No malfunction Contact discharge (direct / indirect): ±6 kV
Air discharge (direct):±8 kV
Condition:
IEC:61000-4-2
compliant
Frequency 80 ~ 1000 MHz
Level 3 V/m
Radio-
frequency
electromagnetic
field. Amplitude
modulation AM 80% (AM)
Condition:
IEC61000-4-3
compliant
Voltage Alternating-current input cable: ±1 kV
Pulse 5 / 50 ns (Tr / Tw)
Fast transient
Frequency 5 kHz
Condition:
IEC61000-4-4
compliant
Pulse 1.2 / 50 ns (Tr / Th)
From L to P : ±2 kV (closed-loop voltage)
Surge
Voltage
From L to L : ±1 kV (closed-loop voltage)
Condition:
IEC61000-4-5
compliant
Frequency 0.15 ~ 80 MHz
Level 3 V
Radio-
frequency
common mode AM 80% (AM)
Condition:
IEC61000-4-6
compliant
Frequency 50 and 60 Hz
Power
frequency
magnetic field Level 3 A/m
Condition:
IEC61000-4-8
compliant
Dip 1 Drop 30%, 0.5 cycles
Dip 2 Drop 60%, 5 cycles
Immunity Test
Voltage dip,
momentary
voltage drop,
fluctuation Momentary
drop Drop > 95%, 250 cycles
Condition:
IEC61000-4-11
compliant
Dimensions Approx. 56.0 × 108.1 × 148.6
(WDH mm)
Physical
Features
Weight Approx. 85g Excluding the interface
cable
Model name SFP0602000P-PSE Accessories:
conversion plug
Voltage range AC 90 ~ 265 V
Input
Supply current 0.5 A (max)
Voltage range 5.7 ~ 6.3 V
External Power
Supply
Output Maximum
current 2.0 A (max)

OPI-3601
Specifications Manual
5
4. Detailed View
Figure 1: Detailed View of OPI-3601
No Name Description
1 Trigger Key By pressing this key, the scanner starts taking an image from the scanning
window and LED illumination is emitted to read 1D/2D codes.
2 Scanning Window Light paths of the imager, LED illumination and LED aiming. Ensure that
the lens is not exposed to dust and dirt before scanning.
3 Status LED The operating statuses are indicated by different colors.
4 Buzzer Hole
A sound from a built-in buzzer comes out through these holes. When they
are covered, the buzzer sound may not be able to be heard. The sound
varies depending on the status. Buzzer settings can be configured in
various ways: enable or disable buzzer as well as change the loudness and
duration.
1
2
3
4

OPI-3601
Specifications Manual
6
5. Electrical Specifications
The OPI-3601 comprises ‘Camera Module Section’ with CMOS sensor, ‘Decoder Section’ for decoding
1D / 2D code data from a scanned image, ‘Communication Control Section’ to communicate with a host
and ‘Power Supply Section’ for the main power supply conversion.
The USB model is bus powered and no adapter is needed. The RS-232C and Wedge PS/2 models
need a dedicated adapter for DC 6.0 V power. Make sure not to insert and remove the power adapter
when PC is on. It may cause the PC to malfunction.
Figure 2: Configuration Diagram
5.1. AC Adapter Specifications
For RS-232C and Wedge PS/2 models
5.1.1. Input Specifications
Power supply voltage : AC 90 ~ 265 V
Power supply frequency : 47 ~ 63 Hz
Maximum current : 0.5 A (max)
5.1.2. Output Specifications
Output voltage : 6.0 V ±5% / Output current: 0 ~ 2.0 A (max)
Power ripple : 100 mVp-p (max, rated load)
5.2. Wedge PS/2 Power Supply (Host)
Input power supply voltage : DC 5.0 V
Range of working voltage : 4.5 ~ 5.5 V
Power ripple : 100 mVp-p max (10 ~ 100 kHz, power supply voltage 5.0 V)
Current consumption : 100 mA (max) without main power supply (AC adapter)
* Current consumption from the main power supply in standby state: 75 mA (max)
* Current consumption from the main power supply during reading operation: 300 mA (max)
* Keyboard operation is possible when the main power supply is off.
* The current consumption was measured at 25°C.
5.3. USB Power Supply
Bus-Power Class : Hi-Power (500 mA max)
Current consumption : 75 mA (max) in stand-by mode
: 300 mA (max) during reading operation
* The current consumption was measured at 25°C.
Power Supply Section
Camera Module & Decoder Section
CMOS sensor
Host
CPU +
FROM/SDRAM
3.3VÅ+5.0～6.0V
I/F
(RS-232C/USB
/Wedge)
Buzzer
+6.0/5.0V
AC adapter
/Host
Status LED
Illumination
Red LED (2)
Keyboard
(Wedge)
Imaging
Lens
1.3VÅ3.3V
Trigger
button
Magnet
sensor
Interface Section
Aimin
g
Green LED (1)
Communication Control Section

OPI-3601
Specifications Manual
7
6. Optical Specifications
6.1. Basic Optical Specifications
Item Characteristics
Scan method CMOS area sensor (white / black) -
Number of effective pixel (Column) × (Row) 752 × 480 dots
Image capture speed (*1) Frame rate 60 fps
Focal distance Distance from the front edge of scanner 104 mm
Horizontal Approx. 40.6°
View angle Vertical Approx. 26.4°
Red LED -
Peak wavelength 617 nm
Directivity angle: 2Φ1/2 (*2) 60°
Illumination light source
(LED × 2)
Maximum radiation output (*3) 15000 mcd
Green LED -
Peak wavelength 528 nm
Aiming light source
Maximum radiation output (*4) 18700 mcd
*1 The fastest seed of image capture
*2 Reference value extracted from the datasheet.
*3, *4 Reference value based on the datasheet (25°C, IF = 140 mA ).

OPI-3601
Specifications Manual
8
6.2. Aiming Pattern
The aiming is used for the following purpose:
1. Fill light to recognize the appropriate reading range.
2. Fill light when auto trigger is used.
The aiming specifications are as follows:
- An optical axis of imaging field of view and the center of horizontal aiming width coincide at a
distance of L=85±20 mm from the front edge of the scanner.
- The horizontal aiming width to the horizontal width of imaging filed of view at a distance of L=85
is 80%±10%.
Figure 3: Aiming Pattern and Imaging Range
6.3. Imaging Range
The range is ±5% from the following values.
L: Distance from the front edge of scanner [mm] 60 80 100 120 140 160
H: Horizontal imaging range [mm] 66 82 97 111 125 136
V: Vertical imaging range [mm] 42 52 62 72 82 93

OPI-3601
Specifications Manual
9
7. Technical Specifications
Aim the laser light at the center of a code to scan it. For long distance scanning, ambient light entering
the angle of view may affect the scanning performance. The conditions for technical specifications are
as follows, unless otherwise specified in each section.
<Conditions>
Ambient Temperature and Humidity Room temperature, room humidity
Ambient Light 100 ~200 lux (on the surface of a bar code)
Angles Pitch: α= 0°, Skew: β= 15°, Tilt: γ= 0°
Curvature R = ∞
Power Supply Voltage 5.0 V
PCS (1D and 2D) 0.9 or higher
Scanning Test Accept the performance with 70% or more success rate
for 10 tries of scan. One reading should be 2 seconds.
Barcode Test Sample (1D and 2D) Specified below.
< Test chart >
For 1D codes, OPTOELECTRONICS test samples
For GS1 Databar, stacked codes and 2D codes, printed by a dedicated printer for bar code

OPI-3601
Specifications Manual
10
7.1. Barcode Test Sample
1D Bar Codes
<Code 39>
Resolution Symbology PCS Size (mm) No. of Digits
0.127 mm (5 mil) 32 × 10 15
0.20 mm (7.9 mil) 100 × 10 31
0.254 mm (10 mil) 32.5 × 12 7
0.508 mm (20 mil)
Code 39 0.9
36 × 25 4
<Code 128>
Resolution Symbology PCS Size (mm) No. of Digits
0.20 mm (7.9 mil) Code 128 0.9 42 × 10 16
<UPC>
Resolution Symbology PCS Size (mm) No. of Digits
0.330 mm (13 mil) 12-digit UPC 0.9/0.3 31.5 × 25.0 12
<Codabar>
Resolution Symbology PCS Size (mm) No. of Digits
0.15 mm (6 mil) Codabar 0.9 20 × 10 10
GS1 Databar/Composite
<GS1-limited>
Resolution Symbology PCS Size (mm) No. of Digits
0.169 mm (6.7 mil) Limited 0.9 12 × 1.5 14
0.169 mm (6.7 mil) Limited-Composite 0.9 12 × 3.0 26
2D Codes
<PDF417>
Resolution Error Correction PCS Size (mm) No. of Character
0.169 mm (6.7 mil) 23 × 10
0.254 mm (10 mil) Level-3 0.9 35 × 15 58
<QR Code: Model-2>
Resolution Error Correction PCS Size (mm) No. of Character
0.212 mm (8.4 mil) 6 × 6
0.381 mm (15 mil) M 0.9 11 × 11 44
<Data Matrix>
Resolution Model PCS Size (mm) No. of Character
0.212 mm (8.4 mil) 5 × 5
0.254 mm (10 mil) ECC200 0.9 6 × 6 40
* The size is outline dimensions excluding the quiet zones.

OPI-3601
Specifications Manual
11
7.2. Scan Area and Depth of Field
The scan area is measured from the front edge of the scanner.
250
65 150
175
12060
16540
70 95
35 165
65 120
Code 128
UPC 100%
PDF417
QR Code
Data Matrix
0.508(20mil)
0.20(7.9mil)
0.33(1.3mil)
0.169(6.7mil)
0.254(10mil)
0.212(8.4mil)
0.381(15mil)
0.254(10mil)
45
50
50 100 150 200 250 300
0.127(5mil)
65 105
45 185 [ Unit ：mm ]
0.254mm(10mil)
Code 39
Figure 4: Scan Area and Depth of Field

OPI-3601
Specifications Manual
12
7.3. Printed Contrast Signal (PCS)
0.3 or higher
<Conditions>
MRD : 32% and higher
(70% or higher reflectivity of space and quiet zone)
Distance : 105mm from the front edge of the scanner
Bar Code Sample : UPC specified in Chapter 8. (Resolution: 0.33 mm, PCS: 0.3)
MRD = Minimum reflectance of white bar - Maximum reflectance of black bar
PCS = Reflectance of white bar－Reflectance of black bar
Reflectance of white bar
7.4. Minimum Resolution
1D Code : 0.127 mm (5 mil) Code 39 specified in Chapter 7.1
GS1-Databar : 0.169 mm (6.7 mil) GS1 Databar Limited specified in Chapter 7.1
Stacked Code : 0.169 mm (6.7 mil) PDF417, GS1 Databar Limited Composite specified in Chapter 7.1
2D Code : 0.212 mm (8.4 mil) QR Code and Data Matrix specified in Chapter 7.1
<Conditions>
Bar Code Sample : The above codes specified in Chapter 7.1
Distance : 75 mm from the front edge of the scanner
Angle : α= 0°, β=＋15°, γ= 0°
Curvature : R = ∞
7.5. Wide Bar Code
Code 39 with width of 100 mm and resolution of 0.2 mm can be read
<Conditions>
Bar Code Sample : 0.20 mm Code 39 / PCS 0.9 specified in Chapter 7.1
Distance : 135 mm from the front edge of the scanner
Angle : α= 0°, β=＋15°, γ= 0°
Curvature : R = ∞
Figure 5: Wide Bar Code

OPI-3601
Specifications Manual
13
7.6. Pitch, Skew and Tilt
Pitch : α= ±50°
Skew : β= ±50°
Tilt : γ= ±180°
<Conditions>
Bar Code Sample : 0.33 mm UPC specified in Chapter 7.1
Distance : 105 mm from the front edge of the scanner
Curvature : R = ∞
* For the pitch angle and tilt angle measurement, set the skew angle β= +15°
Figure 6: Pitch, Skew and Tilt
7.7. Curvature
0.33 mm 12-digit UPC : R ≧20 mm
0.15 mm 10-digit Codabar : R ≧16 mm
<Conditions>
Bar Code Sample : 0.33 mm UPC, 0.15 mm Codabar specified in Chapter 7.1
Distance : 85 mm from the front edge of the scanner
Angle : α= 0°, β=＋15°, γ= 0°
Figure 7: Curvature
Note: Scanning may fail due to the specular reflection of LED illumination when the reflectivity is high.

OPI-3601
Specifications Manual
14
7.8. Auto Trigger
A dedicated stand contains a magnet and when the OPI-3601 is placed into this stand, it can
detect this magnet and enters auto trigger mode. The scanner starts scanning automatically when
it detects a change in brightness that occurs when a bar code label is presented in front of it.
7.8.1. Stand Detection
“Stand detection - Auto trigger Flow”
Figure 8: Stand Detection Flow
* The dedicated stand needs to be purchased separately if auto trigger is used.
* Auto trigger is disabled by default and needs to be enabled if it is used.
