Accessories & Optional PartsOverview
Dimensions (H) 295 × (W) 106 × (D) 146 mm Max
(H) 11.6 × (W) 5.75 × (D) 4.17 in. Max
Weight 385g Max (13.58 oz / 0.85 lb)
Color Black or White
Quick Start Guide
• Read this quick start guide carefully before installing or/and using the stand.
• Keep this quick start guide for future reference and store in a safe place.
Introduction
CAUTION
• This quick start guide may be revised or withdrawn at any time without prior notice.
• This quick start guide may not, in whole or in part, be copied, photocopied, reproduced, translated or
converted to any electronic or machine readable form without prior written consent of Opticon.
• Trademarks used are property of their respective owners.
• Under no circumstances shall Opticon be held responsible for any special, incidental, consequential or
indirect damages howsoever caused.
Handling Instructions
• The STD-3201 is the designated stand for the OPR-3201 handheld laser scanner.
• Do not dismantle the stand.
• Do not drop the stand.
• Do not install the stand on unstable surfaces.
• Do not place heavy objects on top of the stand.
• Do not expose the scanner to intense heat.
• Do not hold the Scanner Cradle when adjusting the Stand Arm.
STD
-
3201
Using the Stand
5J0081
Copyright 2007, Opticon All rights reserved.
STEP1
Use the Adjusting Screw to connect the
Stand Arm with the Scanner Cradle as
shown in the diagram.
STEP 1
Scanner
Cradle
Adjusting Screw
Stand Base
Stand Arm
STEP2
Adjust the angle of the Scanner Cradle
by first loosening the Adjusting Screw
and then tightening it once the Scanner
Cradle has been placed in the desired
position.
STEP 2
Adjusting Screw
STEP3
Make sure to place one hand on the Stand
Base and hold the Stand Arm with the
other hand when adjusting the height and
the angle of the stand.
STEP 3
Do not hold the Scanner Cradle when adjusting
the Stand Arm.
No te
Please use commercially
available M3 or M4 screws
to mount the stand.
Over-tightening the screws may cause
the stand to break.
No te
146mm 106mm
295mm
