1. Open the package and check every
accessory:
Main Unit
with Stylus
Quick GuideQuick Guide
(Not Shown)(Not Shown)
CAUTION:
!
The device will be powered on when you install Battery Pack.
Power off device after touch screen calibration and charge batteries
for at least hours. Do not turn on the device for the first time until
batteries are charged for at least hours. Always charge batteries
at 0 ~45 (32 ~113 ) environment temperature. The Charger
LED will be turned to green color when battery charging is finished.
℃℃℉ ℉
6
6
2. Installing the Battery Pack
1) Detach the Hand Strap.
2) Turn the battery cover latches downwards and lift
the battery cover away.
3) Insert the Battery Pack into the battery compartment with the
label facing out, and make sure the battery fits into place.
4) Place the battery cover by inserting the top first, and then press
the bottom in firmly. Turn the battery cover latches upwards to
secure the cover to the PDT.
3. Connect Power Adapter to charge the PDT
1) Insert DC connector into bottom case of the PDT.
2) Connect Power Cord to power adapter.
3) Insert power cord to AC Outlet.
USING THE KEYPADUSING THE KEYPAD
The keypad comprises 25 keys (numeric, arrow,
functional and Fn) and 3 scan buttons.
Lithium-ion Battery Packs might get hot, explode, ignite
and/ or cause serious injury in case of misuse.
Please follow the safety warnings listed below:
BATTERY PRODUCT SAFETY
Special Characters Special Functions
Sequence of Keys Description Sequence of Keys Description
@
’
＋
－
Copy
&
＊
Space
Start Menu
/
PHL-8100
A.Do not throw the battery into fire. Do not expose the battery to
high temperatures.
B.
C.
D.
E.
F.
G.
H.
I. In the event the Battery Pack leaks and the fluid gets into one's
eye, do not rub the eye.
Rinse well with water and immediately seek medical care.
If left untreated,the battery fluid could cause damage to the eye.
Do not connect the positive Battery Pack with negative
Battery Pack to each other with any metal object (like wire).
Do not carry or store Battery Pack together with metal objects.
Do not pierce the Battery Pack with nails or drills, strike the battery
pack with a hammer, step on the Battery Pack or otherwise expose
it to strong impacts, shocks or excessive force.
Do not solder directly onto the Battery Pack.
Do not expose Battery Pack to liquid or allow the battery contacts
to get wet.
Do not disassemble or modify the Battery Pack.The Battery Pack
contains safety and protection measures, which, if damaged,
may cause the Battery Pack to generate heat, explode or ignite.
Do not discharge the batteries outside the PDT. Do not use the
battery in another device then the PDT or series battery chargers.
Otherwise, the Battery Pack can be damaged, the Battery Pack
can be damaged or its life expectancy reduced. If the device
causes any abnormal current to flow, it may cause the Battery
Pack to become hot, explode or ignite and cause serious injury.
USB Client
Cable for Terminal
USB Client
Cable for Terminal
Battery Pack
(2200mAh)
Battery Pack
(2200mAh)
Ear/Microphone SetEar/Microphone Set
Power Adapter
(5VDC/2.6A)
Power Adapter
(5VDC/2.6A)
Power CordPower Cord
Special Characters Special Functions
Sequence of Keys Description Sequence of Keys Description
:\
=%
Launch of Application 1
Launch of Application 2
Launch of Application 3
Launch of Application 4
，
Battery Cover
Battery Cover Latch
Stylus
Hand Strap
Earphone Jack Connector
Scan Window
Speaker
Scanner LED Indicator
Right Scan Key
USB/Serial/
Synchronization Port
DC Power Jack
Enter Key
F4 Key
F3 Key
Power Key
Fn Key
F2 Key
F1 Key
Charger LED Indicator
LCD Touchscreen
Scan Key
Alpha Key
Alpha-Numeric Key
MIC
Receiver
Reset
1) Key toggle between the Numeric and Alpha modes.
2) Key
3) Press to toggle Function Mode.
allows the toggle between upper-case letters and
lower-case ones. When enable Caps Lock Mode, the Icon A
shows at Task bar
“”
.
；
.
[]
Laft
Rigth
Audio Mute
Esc
Paste
Del
Reserve Hotkey
Caps
Tab
1:\
2ABC
3DEF
4GHI
5JKL
6MNO
7PQRS
9WXYZ
8TUV
0
[]
F3
Fn
.,;
*
=%
#
F2
F1
F4
Alpha
Alpha
Caps
Fn
Alpha
Alpha
Alpha
1:\
0
[]
.,;
*
=%
#
Fn
Fn
Fn
Fn
Fn
Fn
Fn
Fn
Fn
Fn
Fn
Fn
Fn
GSM/GPRS/EDGE
indication (Availability
depends of PDT model)
GSM/GPRS/EDGE
indication (Availability
depends of PDT model)

RESETTING DEVICERESETTING DEVICE
SETTING DEVICESETTING DEVICE
1. Initial Boot Up
The initial boot up screen will be displayed
when you install battery pack at the first
time. Do not remove Battery Pack when
system is at initial boot up.
2. Calibrating Touch Screen
This calibration is already done by manufacturer.
If you want to calibrate the touch screen again,
please tap “Start” --- “Settings” --- “Control Panel
” --- “Stylus” --- “Calibration" --- "Recalibrate”,
then hold the stylus and press on the center of
each target as it moves around the screen.
3.Setting Up Wireless LAN
1) Press "Start" – "Programs" -- "Summit" –
"scu" to open SCU.
2) Into Main tab, tap "Enable/Disable Radio
" button to Enable or Disable the WLAN.
3) Into Profile tab, tap "Scan" button to
connect/refresh the network.
4) Select a network, tap the "Connect" button
or double tap it to create a new profile SSID.
5) And setting encryption of the network then
press "Commit" button to commit it.
6) Finally, you can view the SSID of the active
profile on Main tab and select it to use the
network.
availability depends of PDT model.
Note:
5. Brightness Setting
The device is equipped with backlight for both
sunlight-readable LCD display and keypad.
To adjust the LCD backlight brightness, press
the “Fn” key and then press navigation key
“>” or “<” to adjust display brightness.
Press “Start”---“Settings”---“Control Panel” ---
“Control Center” “Brightness” both LCD
and Keypad brightness.
Or
to set
6. Volume Adjusting
1) Press “Start”---“Settings”---“Control Panel”
-- “Volume & Sounds”.
2) Adjust the volume bar to meet your demand.
To mute the sound, press the “Fn” key and then
press “ESC” key to turn off and on the sound.
Note:
USING THE APPLICATIONS
1. Execute an “Application”
Tap an application icon on the desktop, or tap
“Start”---“Programs”. Select one of the applications.
2. Close an “Application”
Tap the tab of “X” to close the application.
3. Using the Software Input Panel
1) Tap the “Stylus” icon on the “task bar”.
2) Tap the “Keyboard” icon.
3) When Software Input Panel appears, input
characters with the Stylus.
4. Task Switch
Win CE can execute multiple applications
at the same time.
1) Press “Task Switch” icon in the task bar.
2) Select the task(s) you want in the task menu.
During the execution of applications, when you select the menu
“Desktop”, brings the selected application to the foreground.
It does not close the other applications.
BAR CODE READINGBAR CODE READING
Remove the protective film from the scan window before use.
1. Start your application
2. Aim the scan window at the bar code
3. Press one of the three bar code reader trigger
buttons
4. Aiming :
1D laser: aim the red laser beam on the center of the bar code
Bar codes can be read from 50 to 650 mm distance.
USING PERIPHERALSUSING PERIPHERALS
1. Using SD / MMC Type Card
To remove SD/MMC card, press the card again and slot
will pop out card automatically.
3) Put down the SD hold and re-place the battery and battery cover.
1) Remove the battery cover and battery then lift the SD hold.
2) Insert a correctly oriented SD/MMC card.
Note:
The SD/MMC slot support memory card only.
It does not support SD I/O peripherals.
The SD/MMC slot support memory card only.
It does not support SD I/O peripherals.
3. USB Connection
Connect the USB client cable to synchronize data with a computer.
Be sure the HRS mark on the connector of USB cable to be upward
when you insert cable to devices. To remove cable from device,
press both buttons on connector and then remove connector from
device.
Use Microsoft ActiveSync version 3.7 or above.
Note:
1. Warm Reset
1) If an application hangs, initiate Warm Reset to terminate
the application.
2) Warm Reset will close all applications and clear the working
RAM, but all files will be preserved.
3) Only use stylus to press the Reset buttons.
CAUTION:
!
A. Do not stare into the laser beam directly or shine it
into eyes.
B. Never use strong pressure onto the screen or subject
it to severe impact, as the LCD panel could become
cracked and possibly cause personal injury. If the
LCD panel is broken, never touch the liquid inside,
because the liquid irritates the skin.
C. Use only the original approved AC adapter with the
PDT. Use of an unapproved AC Adapter could
result in electrical problems,or even cause a fire or
electrical shock to the user.
D. Do not disassemble the PDT. Servicing should
be done by Authorized Suppliers only. If the device
or accessories gets damaged due to wrong handling
or unauthorized repair, warranty is void.In case the
warranty seals are broken, warranty is void too.
E. Make regularly back-ups of all important data.
F. Under no circumstance will Manufacturer be liable
direct, indirect,consequential or incidental
arising out of use or inability to use both
and software and/or any data loss,
has been informed about the
damages.
for any
damages
the hardware
even if Manufacturer
possibility of such
c
o
m
m
u
n
i
c
a
t
i
o
n
PHL-8100
Quick Guide
humanization
ma
n
a
g
e
m
e
n
t
User and Product Safety
CAUTION:
!
CAUTION:
!
Start Button
Close Button
Keyboard input panel.
Task Switch
CAUTION:
Be sure to use the supplied stylus or plastic-
tipped pens for touch screen display. Don't use pencil, pen or any
sharp object on touch screen display.
4. Bluetooth Device Properties
Bluetooth Device Properties to enable
Bluetooth device.
2) Wait for 20 seconds in order to initialize the
Bluetooth hardware correctly.
) Press Scan device button to search for
Bluetooth devices.
availability depends of PDT model.
1) Press “Start”---“Settings”---“Control Panel”--
“”
3
Note :
PHL-8100
2. Cold Reset
PHL- 0081
Try before you initiate Cold Reset. All applications
will be closed, and working RAM as well as all files will be
cleared if you initiate the Cold Reset. It is strongly recommended
to back up your files to Flash ROM, Flash Card or PC.
Warm Reset
Stylus/Keyboard icon
1) You can use Cold Reset to initialize the device if the WinCE.NET
OS locks up or in case a Warm Reset has no effect.
2) To perform Cold Reset, press “Power” , and “Reset” buttons
simultaneously.
3) Device will boot up after Cold Reset.
5. Check the bar code reading result
You can verify the result of the bar code reading in your application,
by beep sound(s) or the LED indicator.
opticon
Opticon
opticon
Opticon
Good scanning positions
Bad scanning positions
opticon
Opticon
opticon
Opticon
opticon
Opticon
4680-810004-01
WPP
Reset button
This device complies With part 15 of the FCC rule Operation is subject to
the following two conditions. (1)This device may not cause harmful
interference. (2)This device must accept any interference received.
Including interference that may cause undesired operation. Complies with
21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser
Notice No. 50, July 26, 2001
Do not throw this product in the home waste bin.
For proper end-of-life treatment consult the
Environmental care section of www.sccltd.com.tw
For CE, FCC and other DoC's, consult the Regulatory
section of www.Opticon.com
2. Put in SIM Card
1) Remove the battery cover and battery
2) Pushes the iron stock to front unlock the slot and lifts the slot
3 Insert a correctly oriented SIM card.
4 Put down the slot and push the iron stock to back lock the slot).
5) Re-place the battery and battery cover.
Availability depends of PDT model
.
() .
)
)(
.
Note:
4. IrDA Connection
1) Generally it’s used for synchronized data transmission with a PC.
Aim both devices IR port at each other s.
As IrDA is very sensitive to the distance and the angles,
approach the two devices IR ports as close as possible
The maximum transfer distance is cm
Availability depends of PDT model
2) ' '
1.
'.
40 .
2. .
Note:
Loading OS ...Loading OS ...
opticon
Opticon
