Opticon MDI 1000 Quick setup guide

MDI 1000
2D CMOS Imager
Integration Guide

Opticon
MDI 1000
Integration Guide
2
All information subject to change without notice.
Document History
Model Number: MDI 1000 Specification Number: TS06010
Edition: 5 Original Spec Number: TS06009
Date: 2007-07-19
Copyright 2007 Opticon. All rights reserved.
This manual may not, in whole or in part, be copied, photocopied, reproduced, translated or converted to any electronic or
machine readable form without prior written consent of Opticon.
Limited Warranty and Disclaimers
PLEASE READ THIS MANUAL CAREFULLY BEFORE INSTALLING OR USING THE PRODUCT.
Serial Number
A serial number appears on all Opticon products. This official registration number is directly related to the device
purchased. Do not remove the serial number from your Opticon device. Removing the serial number voids the warranty.
Warranty
Unless otherwise agreed in a written contract, all Opticon products are warranted against defects in materials and
workmanship for two years after purchase. Opticon will repair or, at its option, replace products that are defective in
materials or workmanship with proper use during the warranty period. Opticon is not liable for damages caused by
modifications made by a customer. In such cases, standard repair charges will apply. If a product is returned under
warranty and no defect is found, standard repair charges will apply. Opticon Inc. assumes no liability for any direct, indirect,
consequential or incidental damages arising out of use or inability to use both the hardware and software, even if Opticon
has been informed about the possibility of such damages.
Packaging
The packing materials are recyclable. We recommend that you save all packing material to use should you need to
transport your scanner or send it for service. Damage caused by improper packaging during shipment is not covered by
the warranty.
Trademarks
Trademarks used are the property of their respective owners.
Opticon Inc. and Opticon Sensors Europe B.V. are wholly owned subsidiaries of OPTOELECTRONICS Co., Ltd., 5-3,
Tsukagoshi 5-chome, Warabi-shi, Saitama, Japan 335-0002. TEL [phone]; FAX [phone]
SUPPORT
USA Europe
Phone: [phone]
Email: [e-mail] Email: [email protected]
Web: www.opticonusa.com Web: www.opticon.com

Opticon
MDI 1000
Integration Guide
3
Contents
1. Introduction .............................................................................................................................4
2. Integration Parameters...........................................................................................................4
2.1. Exit Window Materials .....................................................................................................4
2.2. Exit Window Design......................................................................................................... 5
3. Installation ...............................................................................................................................6
4. Cable Specifications...............................................................................................................7
4.1. Connection between the Camera Module and the Decoder Board ................................. 7
4.2. Connection between Decoder Board and Host................................................................8
5. Handling Requirements..........................................................................................................9
6. Mechanical Drawings............................................................................................................10
6.1. Camera Module ............................................................................................................. 10
6.2. Decoder Board (DBM 1000) ..........................................................................................11
Table of Figures
Figure 1: Exit window design.......................................................................................................5
Figure 2: Signal connection .........................................................................................................7
Figure 3: Connector between camera module and decoder board: Thickness: 0.2±0.03 ........... 7
Figure 4: Signal connection .........................................................................................................8
Figure 5: Connection between decoder board and host.............................................................. 8
Figure 6: Camera module..........................................................................................................10
Figure 7: Decoder board............................................................................................................ 11

Opticon
MDI 1000
Integration Guide
4
1. Introduction
The MDI 1000 CMOS two-dimensional (2D) imager consists of the MSI 1000 camera module
(referred to as the “camera module”) and the DBM 1000 decoder board developed specifically
for the MDI 1000 (referred to as the “decoder board”). This guide provides instructions for
installing the camera module and the decoder board.
2. Integration Parameters
2.1. Exit Window Materials
For best optical quality, use an acrylic material (cast or extruded) for the exit window.
Select a high-quality achromatic acrylic material with a smooth, flat surface and no
scratches or dents. The acrylic material should be 1 mm thick and have an anti-reflective
(AR) coating applied to both sides of the exit window.
You should also apply an anti-scratch coating to the surface of the exit window to protect
it from scratches during operation. Coated acrylic plates are readily available. Such a
coating greatly enhances anti-scratch properties without degrading the optical
characteristics of the acrylic material.
To protect the exit window from dust, stains, and scratches during assembly, a protective
sheet was attached. This should be removed before operation. After removing the
protective sheet, use an ion-blower or other method to remove any dust that may have
been attracted by static electricity.
Recommended acrylic material:
Nitto Jushi Kogyo Co., Ltd. “Clarex—Precision Thin Sheet”
MITSUBISHI RAYON CO., LTD. “Acrylite”

Opticon
MDI 1000
Integration Guide
5
2.2. Exit Window Design
The exit window must be positioned to accommodate limitations of distance and
inclination, as well as the range of the window itself. Design the layout within the range
specified in the following diagram and associated table.
Figure 1: Exit window design
L (mm) 3 4 5 6 7 9 12
A (mm) >25 >27 >29 >30 >32 >34 >38
Yt (mm) >9 >10 >11 >12 >13 >14 >15
Yb (mm) >7 >8 >8 >8 >9 >9 >10
θcw (deg) >19° >23° >25° >27° >28° >29° >29°
θccw (deg) >19° >23° >25° >27° >28° >29° >29°
* When installing the exit window close to the scan engine, use the following range (including the tolerance).
Ｌ=1.5 ±0.5, θcw and θccw ＜2°(deg)
*The maximum exit window inclination is up to 40 degrees in both directions, θcw and θccw.
During the design phase, check for image eclipse caused by insufficient exit window size and
LED illumination entering the central part, due to improper angle settings. The check can be
done by acquiring images from the camera module.

Opticon
MDI 1000
Integration Guide
6
3. Installation
When installing a camera module, use the tapping screw holes on the bottom surface. Do not
over-tighten the screw. Only the bottom surface of the camera module should be attached to a
chassis for installation. Keep enough clearance to avoid damage to the camera module in case
the host instrument is dropped and damaged. The anti-shock capabilities of the camera module
apply only when acceleration is applied via the bottom surface. In case of direct shock, the
camera module will almost certainly be damaged, since it consists of precise optical elements.
Use the mounting hole with screw cramp to install the decoder board. The size of the screw
head must not exceed the diameter of the mounting land (φ3.6).
Installation conditions—camera module side
Recommended screw: M2 B tight
Tightening torque: up to 20 N_cm
The screwing depth should be within 4.5 mm from the contact surface of the camera
module.
Installation conditions—decoder board side
Recommended screw: M1.7 (Do not use a countersunk screw)
Tightening torque: 20N_cm or less

Opticon
MDI 1000
Integration Guide
7
4. Cable Specifications
Note: Connector mechanical drawings published by the manufacturer may be revised. Please
refer to the latest mechanical drawings from the manufacturer for further details.
4.1. Connection between the Camera Module and the Decoder Board
Connector: 54809-3375 (33 pins), manufactured by MOLEX
Cable Length: 70 mm (max.)
Signal Connection: Use single-sided FPC to connect pin number 1 of camera module to
pin number 33 of decoder board.
Figure 2: Signal connection
Figure 3: Connector between camera module and decoder board: Thickness: 0.2±0.03

Opticon
MDI 1000
Integration Guide
8
4.2. Connection between Decoder Board and Host
Connector: 52437-3071 (30 pins), manufactured by MOLEX
Cable Length: 70 mm (max.)
Figure 4: Signal connection
Figure 5: Connection between decoder board and host
About FPC:
•When producing the FPC, punch out the FPCs from the conductor side.
•Use polyimide as the material of the reinforcing board.
•Use thermoset adhesive.

Opticon
MDI 1000
Integration Guide
9
5. Handling Requirements
Use anti-static measures such as a grounding strap before handling the scan engine in order to
avoid damage to the electronic components from electrostatic discharge. Hold the scan engine
only by the metal case. Do not touch the circuit board or the front side of the scan engine when
handling it. Do not touch the electronic elements or the terminals of the circuit board.
Installation in a clean environment is recommended in order to protect the imaging lens from
dust. Operators should wear a mask to avoid contaminating the optical elements.

Opticon
MDI 1000
Integration Guide
10
6. Mechanical Drawings
6.1. Camera Module
Figure 6: Camera module
Do not touch the circuitry when inserting the scan engine into the scanner. Only the black
casing on the back side (0.9 mm thick) can touch the scanner case.

Opticon
MDI 1000
Integration Guide
11
6.2. Decoder Board (DBM 1000)
Figure 7: Decoder board
