BioLAB BSFLS-101 User manual

Operation Manual
Floor Standing Shaking Incubator
BSFLS-101
Thank you for Choosing Biolab products. Please read the “Operating Instructions” and
“Warranty” before operating this unit to assure proper operation.

Index
. Product Drawing............................................................................................................................3
2. Structure and Working Principle..............................................................................................4
3. Technical Parameter.......................................................................................................................4
4. Panel Instruction.............................................................................................................................5
5. Operation..........................................................................................................................................5
6. Temperature and its parameter setting.................................................................................6
7. Trouble Shooting.......................................................................................................................... 6
8. The Wiring Diagram..................................................................................................................... 7
9. After Sales Services...................................................................................................................... 8
www.biolabscientific.co
2
Floor Standing Shaking Incubator BSFLS-101

0 Product Drawing
Sectional view Front view Back view
. Oscillator
2. Driving wheel
3. Printer
4. USB Port
5. Controller
6. Power Switch
7. Observation window
8. Door Handle
9. Universal caster
0. Fan
. Heating Tube
2. Evaporator
www.biolabscientific.co 3
Floor Standing Shaking Incubator BSFLS-101

02 Structure and Working Principle
The shaking incubator is composed of a microcomputer temperature control system
with LCD Display, Stainless steel inner material, The Body is Composed of environmental
protection foam , transparent glass door, stainless steel oscillation car and rack, stainless steel
inner chamber and refrigeration system
Transparent glass door is good for insulation and observing the platelet preservation
condition.
stainless steel material is easy to clean and disinfect, oscillating frame divided lots of layers,
each layer can put numbers of platelet bags, frame grid can be taken out independently, easy
to operate, oscillation frame was working by a constant speed motor for horizontal shaking
The machine is equipped with multiple axial flow fans to keep temperature evenly in the box.
03 Technical Parameter
. Temperature range: RT+5-60°C
2. Shake frequency: 20-300 rpm
3. Amplitude: 26mm
4. Plate size: 500x350 mm
5. Working Mode: continuous
6. Voltage: 220V, 50/60Hz
7. Power: 720 W
8. Overall Size: 700x665x 350 mm
www.biolabscientific.co
4
Floor Standing Shaking Incubator BSFLS-101

04 Panel Instruction
05 Operation
. Controller is powered on, the temperature display window showing "HY - 2", speed
display window showing"8888", the time display window showing "8888", all identifiers
is lighting, the machine into the normal display status after 4 seconds.
2. Prohibit temperature and speed control function
Temperature value is less than the set temperature value, temperature display window
showing "OFF", said the ban on temperature control function. Speed value is less then
set speed value, speed display widow showing “OFF”,said the ban on speed control
function .
3. Timing function
When total timing set to "0", said there was no timing function, the controller run
continuously; When timing setting is not "0", after the time stop running (see the ndt
parameters: the internal parameter table 7), the time display shows "End", buzzer call
for minute. Click the run/stop "button, can restart the controller.
4. Start and Stop
Long press the "run/stop" key for second can start or stop the controller . Runtime
identifier light "RUN", "STOP" when to STOP identifier to light.
5. Refrigeration function
Compressor works can choose (intermittent type, balanced type and open type),
www.biolabscientific.co 5
Floor Standing Shaking Incubator BSFLS-101

intermittent work can choose manual or automatic start-stop compressor (see the
NDC, CP, Htd, Crc, Cnp parameters: the internal parameter table – 2).
6. Memory function when power off
By modifying off electrical parameter values (see the "rES" parameters: the internal
parameter table - 2) can choose whether to have memory function when power supply
drop.
7. Lighting and sterilization function (see the Lt, St parameters: the internal parameters of
table )
Note: click on lighting lighting function work; Sterilization function long press for 3
seconds sterilization work.
8. In the condition of setting if without any key pressed for minute, the controller will
automatically return to normal display state.
9. Over temperature alarm, "ALM identifier" light, buzzer, buzzer can press any key when
it sound.
0. When the controller (Er - ) power module fault occurring, locked-rotor (Er - 2), hall
error (Er - 3), busbar undervoltage (Er - 4), bus over-voltage (Er - 5), communication
failure (Er - 6), "ALM2 identifier to light," speed controller automatically stop running.
. If the temperature controller display window "-", said temperature sensor failures or the
controller itself, please carefully check the temperature sensor and its wiring.
06 Temperature and its parameter setting
．Click on the "temperature" button, enter the temperature setting state, flashing
temperature display area, can be modified by shift, increase and decrease key to the desired
set point; Then click on "temperature", exit temperature setting state, the value is
automatically saved.
2．Long press "temperature" button for 3 seconds temperature display area to show the
password prompt "Lc", speed display area shows the password value, enter the password
value into the temperature internal parameters setting state, then click on "temperature" can
modify the parameters. Long press "temperature" button for 3 seconds, exit this state, the
parameter value automatically saved.
www.biolabscientific.co
6
Floor Standing Shaking Incubator BSFLS-101

Intrinsic parameter-1
Parameter
code
Parameter
name Parameter function factory default (range)
Lc Password “Lc=3”view and modify parameters 0
AL-
Over-
temperature
alarm margins
when “test temp. > set temp. +AL ”, alarm
light is on, alarm beeps, stop running,
heating output
(0~20.0 )℃
5.0
Ct- Compressor
delay start
Compressor startup time delay protection,
compressor minimum time interval from
stop to restart
(0~600s)
80
uP-
The
compressor
Start threshold
When compressor working in Continuous
way
If "temperature measured values ≥
temperature setting value + uP" and the
compressor start delay time is over, start the
compressor
Note: This parameter is only effective in
manual start-stop compressor mode, in the
automatic mode is invalid
(- 0.0~ 0.0 )℃
0.4
dn-
The
compressor
shut down
threshold
When compressor working in Continuous
way
If "temperature measured values ≤
temperature setting value + dn" and the
compressor is closed
Note: This parameter is only effective in
manual start-stop compressor mode, in the
automatic mode is invalid
(- 0.0~(uP-
0. ))
0.2
Lt- Lighting close
delay close
Open lamp, delay after Lt time automatically
shut down."Lt = 0", the time delay is invalid,
must manually close the lighting.
Lights, delay shut down automatically after
St time."St = 0", the time delay is invalid
must manually shut the sterilization lamp
(0~9999min)
0
St-
The
sterilization
lamp close
time delay
After sterilization lamp open, delay St time
shut down automatically."St = 0", the time
delay is invalid must manually shut the
sterilization lamp.
(0~9999min)
0
www.biolabscientific.co 7
Floor Standing Shaking Incubator BSFLS-101

T- Control cycle Heating Control cycle ( ~60s) 5
P- Proportional
band Time scale functional governing (0. ~50.0) 5.0
I- Integration
time Integration functional governing ( ~2000s) 380
d- Differential
time Differential functional governing (0~2000s) 00
Pb- Zero
adjustment
Correction (low temperature) generated
when the measuring error of the sensor.
Pb = actual temperature - meter
measurements
(-99.9~99.9 )℃
0
PK- Full
adjustment
Correction (high temperature) generated
when the measuring error of the sensor.
PK = 000 * (the actual temperature value -
instrument measurements)/instrument
measured values
(-999~999) 0
Intrinsic parameter-2
Parameter
code
Parameter
name Parameter function factory default (range)
Lc password "Lc = 9 to view and modify the parameter
values. 0
rES
power supply
drop memory
function
0: no memory function when power supply
drop
: power lost memory function
(0~ )
0
FAn fun style
chose
0：The fan is short axial fan
：The fan is long axial fan
(0~ )
0
ndc compressor
working way
0: compressor only intermittent work;
: compressor according to the CP (see
below) the value of the compressor balance
type or intermittent work;
2: compressor according to Htd (see below)
judging the value of the compressor balance
type or intermittent work;
(0~2) 0
CP-
The
compressor
works fixed
switching
points
When "NDC = ",
If the temperature set point or CP ", the
compressor work in intermittent way,
whereas work in balanced way
(0~ 00.0 )℃
30.0
www.biolabscientific.co
8
Floor Standing Shaking Incubator BSFLS-101

Htd
The
compressor
works
automatically
switching
points
When "NDC = 2"
If the temperature set point ≥ ambient
temperature + Htd", compressor work in
continuous way, otherwise work in balanced
way.
(-50.0~50.0 )℃
0.0
Crc
The
compressor
Start and Stop
mode
When the compressor work in continuous
way,
0: automatic start-stop compressor
(according to the environmental temperature
and set point);
: manual start-stop compressor (according
to the internal parameters in table of the
uP and dn value);
(0~ ) 0
Cnp
Ban on
compressor
Working
temperature
point
Setting Value ≥Cn when temperature is "p",
prohibit the compressor work.
Note: this way is the highest priority, the
controller to perform this command first,
then to judge compressor balance or
intermittent work.
(0~ 00.0 )℃
42.0
nP- Maximum
power output
The percentage of maximum power heating
output (0~ 00%) 00
Co-
Shut off the
heating output
deviation
When the temperature measured values
≥setting value + Co, shut off the heating
output.
(0.0~20.0 )℃
5.0
SPL
Temperature
setting min
value
temperature setting min value data
(-
50.0~ 00.0 )℃
0.0
SPH
temperature
setting max
value
temperature setting max value data (SPL~ 00.0 )℃
60.0
Adr address The machine factory produce address ( ~ 6)
www.biolabscientific.co 9
Floor Standing Shaking Incubator BSFLS-101

Intrinsic parameter-3
Parameter
code
Parameter
name Parameter function factory default (range)
Lc password "Lc = 8" to view the environment
temperature.
Ht Environment
temperature
the environment temperature of The
controller
Intrinsic parameter-4
Parameter
code
Parameter
name Parameter function factory default (range)
Lc- Password “Lc=27”to view or modify the parameter
value 0
CdS
apillary,
pressure
release
function
selection
0: relay for pressure relief function;
: relay for capillary function; (0~ ) 0
CAP
Capillary
switch Setting
value
When the temperature setting ≥ CAP ", start
relay;
When the temperature setting ＜ CAP ",
close the relay.
(-
50.0~ 00.0 )℃
0.0
dpL
Pressure
release
(cooling)
solenoid valve
start valve
When the compressor work in balanced way,
If the temperature measurement ≤
temperature setting value + dpL ", start the
electromagnetic valve;
When the compressor to off work, if the
compressor stop working, the starting
electromagnetic valve.
(- 0.0~0.0 )℃
0.0
www.biolabscientific.co
10
Floor Standing Shaking Incubator BSFLS-101

dpH
Pressure
release
(cooling)
solenoid valve
start valve
When the compressor work in balanced way,
If "temperature measured values ≥
temperature value + dpH, compressor work,
electromagnetic valve closed;
Note: when the compressor work in balanced
way, if the "dpL = 0" and "dpH = 0", the
electromagnetic valve is closed.
(0.0~ 0.0 )℃
0.0
ndF
The
evaporator
Frost way
0: no frost function;
: solenoid valve frost;
2: electric heat pipe frost;
(0~2) 0
dt
frost release
The time
interval
When the setting temperature ≤ 8.0 ℃the
frost time interval."Dt = 0" no frost.
(0~240h)
24
Ft frost release
The time
When the setting temperature ≤ 8.0 ℃
for solenoid valve frost, Ft for
electromagnetic valve conduction time;
for electric heat pipe frost, Ft to stop the
compressor working time.
Note: if frost electric heating tube, frost time
try try to less than the compressor started
delay time.
(0~600s)
80
ot
When frost full
power heating
time
When the setting temperature≤ 8.0 ℃
For electromagnetic valve, frost ot is
invalid;
If the frost electric heating tube, ot for frost
full power when the heating time.
(0~Ft )
60
dt2
frost release
The time
interval 2
When the "8.0 < temperature set℃ting
value ≤ 6.0 frost time interval.℃"Dt2 = 0"
no frost.
(0~240h)
48
Ft2 frost release
The time 2
When the "8.0 < temperature set℃ting
value≤ 6.0 ℃
If the solenoid valve frost, Ft2 for
electromagnetic valve conduction time;
If the electric heat pipe frost, Ft2 means stop
the compressor working time.
Note: if frost electric heating tube, frost time
try to less than the compressor started delay
time
(0~600s）
80
www.biolabscientific.co 11
Floor Standing Shaking Incubator BSFLS-101

ot2
When frost full
power heating
time 2
When the "8.0 < temperature set℃ting
value≤ 6.0 ℃
If the solenoid valve frost, ot2 is invalid;
If the electric heat pipe frost, ot2 for frost full
power heating time
(0~Ft2)
60
Speed and parameter setting
. Click on the "speed" button, enter the speed setting state, speed display flashing, can
through shift, increase, decrease key set to the desired set point; Click on the "speed" button
again, exit speed setting state, the value is automatically saved.
2. According to the "speed" button for 3 seconds long temperature display area to show the
password prompt "Lc", speed display area shows the password value, input speed internal
parameters set password value into the state, then click on the "speed" button can modify the
parameters. Long press the "speed" button for 3 seconds, exit this state, the parameter value
automatically saved.
3. Note: the speed in the process of the parameters in the controller running from
modification, if you need modify, please stop controller to modify again
Intrinsic parameter-5
Parameter
code
Parameter
name Parameter function
factory
default
(range)
Lc password “Lc=3”to view and modify the parameter
value。0
Pd-
The
proportional
gain
Speed proportional gain. ( ~ 00) 0
Id- Integral
coefficient Speed integral coefficient ( ~ 00) 5
InT speed up time Motor speed up to the time needed for the
new Settings. ( ~60) 0
dET Speed down
time
Motor speed down to the time needed for
the new Settings. ( ~60) 0
SdL speed setting
min value speed setting min value date (20~6000) 20
SdH Speed setting
max value speed setting max value date (SdL~6000) 600
www.biolabscientific.co
12
Floor Standing Shaking Incubator BSFLS-101

Intrinsic parameter-6
Parameter
code
Parameter
name Parameter function
Factory
default(range
）
Lc- password “Lc=9”To view and modify parameter value 0
EAr The gear ratio Big Wheel diameter/ small wheel diameter. ( .0~ 0.0) .0
PoL Motor pole
logarithmic Brushless dc motor logarithmic ( ~32) 4
dIF
The motor
rotation
Reference
direction
DIF = 0: clockwise direction as positive
DIF = : rules for positive counterclockwise
direction
(0~ ) 0
FdS Speed value
feedback Speed feedback coefficient values (0. ~ 0.0) .0
FdC Current
feedback value Current feedback coefficient value (0. ~ 0.0) .0
FrE Carrier
frequency
Brushless motor carrier modulation
frequency
Note: change the carrier frequency, need to
restart the controller
(5~ 5) 5
Po- Motor power
Brushless motor power
Note: the user according to the actual motor
power to adjust the parameters
( ~400)
Low voltage
driver: 80
High voltage
driver: 200
CL- Flow ratio Motor over-current protection, allowing
multiple rated current ( .0~ 0.0) 5.0
Fr- Motor rotation
direction
o: the motor run only to forward;
: the motor run only in reverse;
2: the motor can be positive &negative
operation；
(0~2)
0
db- Show no
sensitive area Speed shows no sensitive area (0~ 00) 2
dF- False display
range
When speed set point ≥dF, the speed set
point display value and speed display values
are all false
(0~6000) 6000
www.biolabscientific.co 13
Floor Standing Shaking Incubator BSFLS-101

Time setting
. When the "Fr = 0" or "Fr = : motor in forward or only run only in reverse:
Click on the "time" button and enter the total timing time setting, time display flashing, can
through shift, increase, decrease the key changes to the desired setting point; Then click on
"time" from the total time setting status regularly, value is automatically saved.
2. When "Fr = 2" : the motor can be positive & negative operation: Click on the "time" button
and enter the total timing time setting, time display flashing, can through displacement,
increase, reduce the key changes to the desired set point; Then click on "time" in turn, are in
turn time setting, stop time setting, reverse time setting state, and then click on the "time"
button, the exit time setting state, the value is automatically saved.
When into the state of forward time setting, forward identifier "Fd" light, time display area;
When to stop time setting state, stop identifier "P -" light, time display area flicker;
When into the reverse time setting state, reverse identifier "Rd" light, time display area;
Note: total timing can choose minutes and hours; Forward, stop, reverse time timing for
minutes.
3. Long press "time" key about 3 seconds, the temperature display area shows the password
prompt "Lc", speed display area password value, by increasing, reducing, and the shift key,
modification to the required password value. Then click on "time", if the password value is not
correct, the controller automatically return to the normal display status, if the password value,
right into the time internal parameter set state, then click on "time" can modify the
parameters in turn. Long press "time" button for 3 seconds, can withdraw this state, the
parameter value automatically saved.
Intrinsic parameter-7
Parameter
code
Parameter
name Parameter function
Factory
default(range
）
Lc- Password “Lc=3”to view and modify parameter value 0
ndt Timing mode
chose
0: after running time, running time, only stop
speed, constant temperature
: after running time, running time, at the
same time to stop the speed and
temperature
Start the time after 2: temperature reach the
set value, to the running time, only stop
speed, constant temperature
(0~3)
www.biolabscientific.co
14
Floor Standing Shaking Incubator BSFLS-101

3: timing starts after the temperature reach
the set value, to the running time, at the
same time to stop the speed and
temperature
Timing at the beginning of the "m" or "h"
start flashing, End of the time, the time
display shows "End"
Note: this parameter in the operation of the
modification is prohibited
Hn- total timing
mode
0: timing time in minutes
: timing time by the hour
Note: this parameter in the operation of
the modification is prohibited
(0~ ) 0
rT-
Total timing
modify
total timing
mopd
Revision total timing timing error,
Revised = [running time (in seconds) - real
time (in seconds)] * 0 / real time (points)
(-999~999) 0
Note: the value internal parameter table factory has debugging confirmation, users do not
need to adjust themselves.
7. Matters need pay attention and maintenance
a．When moving the machine, Forbid Inversion and greater than 45° putting the Incubator.
b．Do not change the setting value frequently during using, in case to cause overload for the
compressor, and affect the equipment service life.
c．To ensure cooling condenser heat dissipation, machine backside and wall should keep a
distance of more than 20 cm, boxes both sides should keep more than 25 cm gas
d．In order to keep the nice appearance, Do not use The corrosion solution to clean machine.
Can use the dry cloth or alcohol to keep the chamber neat.
e．Every Six months should clean the machine and the chamber. To check the Oscillation car.
Make sure power off during cleaning equipment.
f．Should cut off power and keep equipment chamber dry when it is not using
g．To insure the temperature evenly inside, should often check if axial flow fan inside is
working normally.
h．Do not touch crash the probe，So as not to cause temperature abuse.
i．When the equipment not working, should contact with professional Maintenance
personnel or sale department.
j．If need move, repair or clean the machine, should keep the power off
k．The Equipment should place at Ventilated, dry and non-corrosive gases warehouse
www.biolabscientific.co 15
Floor Standing Shaking Incubator BSFLS-101

07 Trouble Shooting
Trouble shooting check/solution
Temperature display no values
Temperature setting have
values
Abnormal temperature sensor, check the temperature
sensor.
Temperature rise less than the
set value
whether the temperature set point temperature below
shows;
Check whether the electric heating tube is damaged:
Check the control board and related wiring.
The speed up rating is low
Check whether the studio fan stalling:
. The fan
2. Relevant connection line fault
check whether the use of voltage in ~ 220 v (voltage
fluctuation within 0%)
Low Temperature Warning Check the fan, heater is working correctly.
Over temperature alarm
Check the fan and compressor is working correctly (please
refrigeration compressor does not work should repair
personnel diagnosis maintenance).
Boot up without any display
Check whether the power switch is open
Check into line plug line, has ~ 220 v
Check whether the fuse is damaged
Please check the fault according to the wiring diagram
www.biolabscientific.co
16
Floor Standing Shaking Incubator BSFLS-101

08 The Wiring Diagram
www.biolabscientific.co 17
Floor Standing Shaking Incubator BSFLS-101

09 After Sales Services
( ) one year warranty, life-long service. Warranty period in the date of sales paper, customer.
(2) customer modification or repairing the product itself without permission, does not belong
to free warranty scope.
(3) due to the customer the fault or damage caused by improper use, do not belong to free
warranty scope.
(4) has a warranty and does not belong to free warranty range of products, service charge the
corresponding cost.
www.biolabscientific.co
18
Floor Standing Shaking Incubator BSFLS-101

BIOLAB SCIENTIFIC LTD.
3660 Midland Avenue, Suite 300, Toronto, Ontario M V 0B8 Canada
Email: [email protected] Tel: + 707 533 445
Website: www.biolabscientific.com
