opto engineering MCSM Series User manual

V 1.0 - eng
ACCESSORIES
INSTRUCTIONS MANUAL
MCSM series
Variable macro lens with Scheimpflug adjustment

V 1.0 - eng 2
CMHO series | INSTRUCTIONS MANUAL
1. MCSM Macro setup
Setting-up the Scheimpflug mount is easy.
First screw the lens into the camera C-mount, just like with any common lens.
Loosen the lens C-mount adaptor by unscrewing the set-screws. Tune the lens phase to the right
position, then tighten the set-screws.
Mount the lens to a secure fixture by means of the threaded holes. Once the lens is mounted,
adjust the focus until the image at the centre of the detector is sharp; you don’t need to tilt the
detector yet.

V 1.0 - eng 3
CMHO series | INSTRUCTIONS MANUAL
With the lens mounted and well focused, adjust the tilt control on the side of the Scheimpflug
mount by means of a screwdriver. It might be required to perform a second fine focusing of the
lens to achieve the perfect setting. Once the Scheimpflug angle is set, lock the mount in place by
tightening the lateral set-screws.
