Optoma 4K500 User manual

User manual
DLP®Projector

English
2
TABLE OF CONTENTS
SAFETY ............................................................................................... 4
Important Safety Instruction....................................................................................................... 4
Copyright ................................................................................................................................... 5
Disclaimer.................................................................................................................................. 5
Trademark Recognition ............................................................................................................. 6
FCC ........................................................................................................................................... 6
Declaration of Conformity for EU countries ............................................................................... 7
WEEE........................................................................................................................................ 7
INTRODUCTION.................................................................................. 8
Package overview ..................................................................................................................... 8
Standard accessories................................................................................................................ 8
Optional accessories ................................................................................................................. 8
Product overview....................................................................................................................... 9
Connections.............................................................................................................................. 10
Keypad ..................................................................................................................................... 11
LED status indicators................................................................................................................ 11
Remote control ......................................................................................................................... 12
SETUP AND INSTALLATION ............................................................. 14
Installing the projector .............................................................................................................. 14
Connecting sources to the projector......................................................................................... 15
Adjusting the projector image................................................................................................... 16
Remote setup ........................................................................................................................... 17
USING THE PROJECTOR.................................................................. 19
Powering on / off the projector.................................................................................................. 19
Selecting an input source ......................................................................................................... 20
Menu navigation and features .................................................................................................. 21
OSD Menu tree......................................................................................................................... 22
Display image settings menu.................................................................................................... 30
Display aspect ratio menu ........................................................................................................ 32
Display edge mask menu ......................................................................................................... 33
Display digital zoom menu........................................................................................................ 33
Display image shift menu ......................................................................................................... 33
Setup projection menu.............................................................................................................. 34
Setup lamp settings menu........................................................................................................ 34
Setup lter settings menu......................................................................................................... 34
Setup lens function menu......................................................................................................... 34
Setup power settings menu...................................................................................................... 35
Setup security menu................................................................................................................. 35
Setup test pattern menu ........................................................................................................... 35
Setup remote settings menu..................................................................................................... 35

English 3
Setup projector ID menu........................................................................................................... 36
Setup 12V trigger menu............................................................................................................ 36
Setup options menu.................................................................................................................. 36
Setup reset menu ..................................................................................................................... 37
Network LAN menu .................................................................................................................. 37
Network control menu............................................................................................................... 38
Setup network control settings menu ....................................................................................... 39
Info menu.................................................................................................................................. 44
MAINTENANCE.................................................................................. 45
Replacing the lamp................................................................................................................... 45
Installing and cleaning the dust lter ........................................................................................ 47
ADDITIONAL INFORMATION ............................................................ 48
Compatible resolutions............................................................................................................. 48
Image size and projection distance .......................................................................................... 49
Projector dimensions and ceiling mount installation................................................................. 51
IR remote control codes ........................................................................................................... 52
Troubleshooting ........................................................................................................................ 54
Warning indicators.................................................................................................................... 55
Specications ........................................................................................................................... 58
Optoma global ofces............................................................................................................... 59

English
4
SAFETY
The lightning ash with arrow head within an equilateral triangle is
intended to alert the user to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may be of sufcient
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
Please follow all warnings, precautions and maintenance as recommended in this user's guide.
Important Safety Instruction
 Do not block any ventilation openings. To ensure reliable operation of the projector and to protect from
over heating, it is recommended to install the projector in a location that does not block ventilation.
As an example, do not place the projector on a crowded coffee table, sofa, bed, etc. Do not put the
projector in an enclosure such as a book case or a cabinet that restricts air ow.
 To reduce the risk of re and/or electric shock, do not expose the projector to rain or moisture. Do not
install near heat sources such as radiators, heaters, stoves or any other apparatus such as ampliers
that emits heat.
 Do not let objects or liquids enter the projector. They may touch dangerous voltage points and short
out parts that could result in re or electric shock.
 Do not use under the following conditions:
± In extremely hot, cold or humid environments.
(i) Ensure that the ambient room temperature is within 5°C ~ 40°C
(ii) Relative humidity is 10% ~ 85%
± In areas susceptible to excessive dust and dirt.
± Near any appliance generating a strong magnetic eld.
± In direct sunlight.
 Do not use the projector in places where ammable gases or explosives gases may be present in the
atmosphere. The lamp inside the projector becomes very hot during operation and the gases may
ignite and result in a re.
 Do not use the unit if it has been physically damaged or abused. Physical damage/abuse would be
(but not limited to):
± Unit has been dropped.
± Power supply cord or plug has been damaged.
± Liquid has been spilled on to the projector.
± Projector has been exposed to rain or moisture.
± Something has fallen in the projector or something is loose inside.
 Do not place the projector on an unstable surface. The projector may fall over resulting in injury or the
projector may become damaged.
 Do not block the light coming out of the projector lens when in operation. The light will heat the object
and my melt, cause burns or start a re.
 Please do not open or disassemble the projector as this may cause electric shock.
 Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous
voltages or other hazards. Please call Optoma before you send the unit for repair.
 See projector enclosure for safety related markings.
 The unit should only be repaired by appropriate service personnel.

English 5
 Only use attachments/accessories specied by the manufacturer.
 Do not look into straight into the projector lens during operation. The bright light may harm your eyes.
 When replacing the lamp, please allow the unit to cool down. Follow instructions as described on
pages 45-46.
 This projector will detect the life of the lamp itself. Please be sure to change the lamp when it shows
warning messages.
 Reset the "Lamp Reset" function from the on-screen display "Setup lamp settings" menu after
replacing the lamp module.
 When switching the projector off, please ensure the cooling cycle has been completed before
disconnecting power. Allow 90 seconds for the projector to cool down.
 When the lamp is approaching to the end of its life time, the message "Lamp life exceeded." will show
on the screen. Please contact your local reseller or service center to change the lamp as soon as
possible.
 Turn off and unplug the power plug from the AC outlet before cleaning the product.
 Use a soft dry cloth with mild detergent to clean the display housing. Do not use abrasive cleaners,
waxes or solvents to clean the unit.
 Disconnect the power plug from AC outlet if the product is not being used for a long period of time.
Note: When the lamp reaches the end of its life, the projector will not turn back on until the lamp module has been
replaced. To replace the lamp, follow the procedures listed under “Replacing the Lamp” section on pages
45-46.
Do not setup the projector in places where it might be subjected to vibration or shock.
Do not touch the lens with bare hands
Remove battery/batteries from remote control before storage. If the battery/batteries are left in the
remote for long periods, they may leak.
Do not use or store the projector in places where smoke from oil or cigarettes may be present, as it
can adversely affect the quality of the projector performance.
Please follow the correct projector orientation installation as non standard installation may affect the
projector performance.
Use a power strip and or surge protector. As power outages and brown-outs can KILL devices.
Copyright
This publication, including all photographs, illustrations and software, is protected under international copyright
laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced
without written consent of the author.
© Copyright 2017
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes no representations
or warranties with respect to the contents hereof and specically disclaims any implied warranties of
merchantability or tness for any particular purpose. The manufacturer reserves the right to revise this publication
and to make changes from time to time in the content hereof without obligation of the manufacturer to notify any
person of such revision or changes.

English
6
Trademark Recognition
Kensington is a U.S. registered trademark of ACCO Brand Corporation with issued registrations and pending
applications in other countries throughout the world.
HDMI, the HDMI Logo, and High-Denition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other countries.
DLP®, DLP Link and the DLP logo are registered trademarks of Texas Instruments and BrilliantColorTM is a
trademark of Texas Instruments.
All other product names used in this manual are the properties of their respective owners and are
Acknowledged.
DARBEE is a trademark by Darbee Products, Inc.
MHL, Mobile High-Denition Link and the MHL Logo are trademarks or registered trademarks of MHL Licensing,
LLC.
FCC
This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15
of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this device does cause
harmful interference to radio or television reception, which can be determined by turning the device off and on is
encouraged to try to correct the interference by one or more of the following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the device and receiver.
 Connect the device into an outlet on a circuit different from that to which the receiver is connected.
 Consult the dealer or an experienced radio/television technician for help.
Notice: Shielded cables
All connections to other computing devices must be made using shielded cables to maintain compliance with FCC
regulations.
Caution
Changes or modications not expressly approved by the manufacturer could void the user's authority, which is
granted by the Federal Communications Commission, to operate this projector.
Operation Conditions
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference and
2. This device must accept any interference received, including interference that may cause undesired operation.
Notice: Canadian users
This Class B digital apparatus complies with Canadian ICES-003.
Remarque à l'intention des utilisateurs canadiens
Cet appareil numerique de la classe B est conforme a la norme NMB-003 du Canada.

English 7
Declaration of Conformity for EU countries
 EMC Directive 2014/30/EC (including amendments)
 Low Voltage Directive 2014/35/EC
 R & TTE Directive 1999/5/EC (if product has RF function)
WEEE
Disposal instructions
Do not throw this electronic device into the trash when discarding. To minimize pollution and ensure
utmost protection of the global environment, please recycle it.

English
8
INTRODUCTION
Package overview
Carefully unpack and verify that you have the items listed below under standard accessories. Some of the items
under optional accessories may not be available depending on the model, specication and your region of
purchase. Please check with your place of purchase. Some accessories may vary from region to region.
The warranty card is only supplied in some specic regions. Please consult your dealer for detailed information.
Standard accessories
Optional accessories
Note: Optional accessories vary depending on model, specication and region.
Projector Power lead *(2) Documentation

CD User Manual

Warranty Card*(1)

Basic User Manual
VGA cable
Note:
The remote control is shipped with the battery.
*(1) For European warranty information please visit www.optomaeurope.com.
*(2) Power lead is depending on the region.
Remote control
On
Geometric
Mode
Correction PIP/PBP
Off
F1 F2
AVMute
ENTER
Source
Volume DZoom
Info.
F3
VGA
1
S-Video
2
HDMI1
3
HDMI2
HDMI3
Format Freeze Remote
ID All
HDBaseT
4
Video
5
DVI
6
BNC
7
YPbPr
8
DisplayPort
9
3D
0
Re-Sync
Menu

English 9
INTRODUCTION
Product overview
12
2
6
8910 7
3
11
4
1
5
Note: Keep a minimum distance of 20 cm between the "inlet" and "outlet" labels.
No Item No Item
1. Lens 7. Keypad
2. IR Receiver 8. KensingtonTM Lock Port
3. Lamp Cover 9. Security Bar
4. Tilt-Adjustment Feet 10. Power Socket
5. LED Status Indicators 11. Ventilation (outlet)
6. Ventilation (inlet) 12. Input / Output

English
10
INTRODUCTION
Connections
USB Power
Out(5V-1.5A)
Service
RS-232 12V Out
A12V Out B
HDMI 1 HDMI 2
(HDCP2.2)
HDMI 3 HDMI Out
DisplayPort
VGA/YPbPr RJ-45
Wired Remote
101 2 3 4 5 67 8 9
111213
No Item No Item
1. USB Power Out (5V 1.5A)/Service
Connector
8. VGA/YPbPr Connector
2. RS-232 Connector 9. RJ-45 Connector
3. 12V Out A Connector 10. Wired Remote Connector
4. 12V Out B Connector 11. Power Socket
5. HDMI 1 Connector 12. HDMI Out Connector
6. HDMI 2 (HDCP2.2) Connector(*) 13. HDMI 3 Connector
7. DisplayPort
Note:
Remote mouse requires special remote control.
This model supports mouse / service capability.
(*)Only HDMI 2 (HDCP2.2) connector supports 4K (Ultra HD) at 60Hz refresh rate.
