optrel Optray V5-250 User manual

Optray Sunglasses Owner’s Manual
V5-250
CH-
Dokument-Änderung
Dokument-Freigabe
Index / Version
Dokumentart / Nr.:
9615.001.01
Datum
Visum
Datum:
Visum:
Pfad Dokument:
Q:\F_E\50_Optrel_Sports\51 - Entwicklungsprojekte\51001 -
Optray\08_Marketing\Manuals\Manual Optray_v4.11_250um.docx
Erstellt:
25.06.2020
ROSC
00
Letzte Änderung:
19.02.2021
ROSC
06
Optrel AG - Industriestrasse 2 - CH-9630 Wattwil
Gedruckt: 24.02.2021 Seite 1 von 2
OPTRAY EYEWEAR
Congratulations on your purchase of premium OPTRAY LCD sunglasses. These are the first active and fully automatic
sunglasses with LCD technology, that don’t need any battery or maintenance. Your OPTRAY LCD sunglasses will work
reliably for years without the need to charge or change batteries. (LCD: liquid crystal display)
Every pair of OPTRAY sunglasses bears the CE mark that represents compliance with European guidelines 89/686/EEC
in connection with ISO 12312-1. All OPTRAY sunglasses are also in compliance with the US standard ANSI Z80.3 for
nonprescription sunglasses and fashion eyewear.
How do the sunglasses work?
The OPTRAY Sunglasses darken to adapt to the
brightness of your surroundings. Direct sunlight hitting
the sensors is efficiently converted by the sensor into
electricity, which darkens the LCD according to its
intensity faster than 0.1 seconds. Plenty of sunlight, dark
sunglasses, little sunlight, light sunglasses.
The LCD darkens more at the top than at the bottom,
creating a gentle darkening process to create the most
comfortable wearing experience possible, adapted to
the eye.
The sensors work in the infrared spectrum of sunlight. If the infrared radiation is reduced by filters, e.g. on car windows,
the LCD also darkens less.
The fully automatic adjusting OPTRAY Sunglasses offer a transmission from 30% in bright state to 8% in fully dark state
depending on the ambient sunlight.
Range of application and use restrictions
OPTRAY sunglasses guarantee protection from harmful UVA, UVB and UVC rays up to 400 nm.
Do not use for looking directly at the sun!
Do not use OPTRAY sunglasses while driving at night or in otherwise reduced lighting conditions.
OPTRAY sunglasses have a shock resistance in accordance with ISO 12312-1 and ANSI Z80.3, however they ARE NOT
unbreakable. Therefore, OPTRAY sunglasses are not to be used as safety glasses, as they do not protect against eye
injuries.
OPTREL Sports excludes any liability for possible damage occurring or having occurred from improper use.
General information
The LCD is pressure sensitive. Avoid bending or squeezing the LCD, it can be irreversibly damaged. Black dots in the
display are an indication that the LCD is overstressed.
Warning
Optray glasses can cause photosensitive epileptic seizures, especially with sensitive people. Unfavorable light-shadow
effects, Optray sunglasses can intensify and promote a seizure in sensitive individuals.
Filter
category
Transmission
Description
0
80 –100%
Transparent or slightly tinted
I
43 –80%
Light to medium filter
II
18 –43%
Dark universal filter
III
8 –18%
Very dark filter (high mountains)
IV
3 –8%
Extremely dark filter (glaciers). Not suitable for driving

Optray Sunglasses Owner’s Manual
V5-250
CH-
Dokument-Änderung
Dokument-Freigabe
Index / Version
Dokumentart / Nr.:
9615.001.01
Datum
Visum
Datum:
Visum:
Pfad Dokument:
Q:\F_E\50_Optrel_Sports\51 - Entwicklungsprojekte\51001 -
Optray\08_Marketing\Manuals\Manual Optray_v4.11_250um.docx
Erstellt:
25.06.2020
ROSC
00
Letzte Änderung:
19.02.2021
ROSC
06
Optrel AG - Industriestrasse 2 - CH-9630 Wattwil
Gedruckt: 24.02.2021 Seite 2 von 2
Cleaning
Be careful when cleaning your sunglasses! Remove any dirt by blowing softly on them. Clean only with the included
OPTREL microfiber bag. Do not use paper towels or other materials containing wood fiber or any other cleaning
material. The lens has an anti-scratch coating on the outside and on the inside.
Storage
To prevent the lenses from being scratched, it is best to store the sunglasses only in the microfiber bag and case
designed for them. The sunglasses must not be stored in direct sunlight or in locations where the temperature exceeds
50°C (122°F). If the sunglasses have become too hot, black dots may appear in the LCD. These usually disappear after
about 7 days.
Inspection
Inspect your glasses prior to use for possible damage. If the lenses show scratches, cracks or other blemishes, they
should be repaired or replaced; otherwise sufficient protection from harmful UVA and UVB rays cannot be guaranteed.
Lens removal
Remove nosepiece by bending it gently to the center and
pull it out. Hold the lens at the edge; bend out carefully
the frame to the side until the lens is released.
Lens installation
Hold the top frame of the glasses with one hand while
grasping in the center and one end of the lens with the
other hand. Gently insert the lens into one end by
inserting the lens mounting tab into the frame.
Install the nosepiece by centering it on the lens and applying slight, even pressure in the center to seat it onto the lens.
Limited Warranty
Optray glasses are covered by a two-year manufacturer's warranty against manufacturing defects from the date of
purchase. The guarantee is only valid for the original purchaser on presentation of a valid proof of purchase from an
authorized Optray dealer, on which the date of purchase is clearly stated. The serial number engraved on the lens at
the top edge is the unique identification of the glasses. The Optray warranty does not cover scratching, crushing or
breaking of the lenses. This warranty is void if lenses are modified, misused or fitted. The customer's right of recourse
in the event of a breach of warranty is limited, at Optray's discretion, exclusively to repair or replacement of the part in
question. Customer's statutory rights under applicable national or state laws governing the sale of consumer products
are not affected by this warranty.
Development, homologation and distribution in the EU and worldwide outside North America:
OPTREL Sports AG, Industriestrasse 2, CH-9630 Wattwil, Switzerland
Distribution North America:
Cyber Optic Shades LLC, 7931 E. Pecos Rd., Suite 209, Mesa AZ 85212, United States of America
Warranty Card
In case of a problem with your sunglasses, please contact Cyber Optic Shades LLC.
Art. No. 1500.001 OPTRAY neon
Art. No. 1500.002 OPTRAY onyx
Serial number: note the sticker on the packaging and the upper edge of the lens
https://www.cyberopticshades.com
