OR STEEL light ALPHA ZENITH User manual

TECHNICAL MANUAL
The powerful ceiling recessed Alpha Zenith swivel spotlight can be flush
mounted in a straight or sloping suspended ceiling. This spotlight is used for
accent lighting in any room and provides excellent interior architectural lighting.
The aesthetic “Trimless” surround and its low luminance make it very popular
with designers. The added extra of Alpha Zenith: A perfect finish to the ceiling
after fitting, with no need to retouch the plasterwork.
T° max 55°C
AA+
A++
IP44 IK03
0,2
75 mm
ALPHA ZENITH
350mA-700mA
POWER 1x9W
SUPPLY 350mA-700mA
POWER
SUPPLY
Not included
WIRING Serial
AVERAGE LIFE OF THE
LED
60 000 hours
Certied L90 B10
COLOUR EMISSION 2700°K - 3000°K
4000°K - 6000°K
BEAM 13° /24°/44° /115°
INITIAL OUTFLOW 558lm at 3000k
Electrical features
TECHNICAL SHEMATICS
6161
SIZE Ø80x61mm
WEIGHT 0,2 kg
MATERIAL Solid aluminium
OPERATING
TEMPERATURE
- 20°c ~+ 60°
INGRESS PROTECTION IP44
IMPACT RESISTANCE IK03
APPLICANCE CLASS CLASS III
WALKOVER FIXTURE NO
DRIVE-OVER FIXTURE NO
Mechanical characteristics
INSTALLATION SCHEMATICS
Characteristics
lighting techniques
General characteristics
WIRES Supply wire 2x0,34
mm2 in IP68
PHOTOBIOLOGICAL
SAFETY
Risk group I
ENERGY CLASS A /A+/A++
All data are given for information purposes only. They do not constitute a contractual commitment on our part and are subject
to change at any time.
75
34
1 2
Serial wiring 350-700mA
Drill a hole with a hole saw.
Connector IP44
Not submerged
Air gap
Insulator
5 at
20mm

1. Use
Spotlight to flush mount in a suspended ceiling. Interior architectural lighting.
IP68 class watertight so it can be fitted in a damp atmosphere or a low-energy
building. Only an IP44 connection to the electricity network ensures the IP44
degree of the product Manufacturing/special applications available on request.
2. Technical data/Assembly
Round or square trim in different finishes, with one 9W LED cold white (6000
K), neutral white (4000 K), warm white (3000 K), fixed by two steel springs with
rubber protection. Delivered with a 2x0,34mm 30cm long cable
3. Installation/assembly
Please comply with the applicable national safety requirements We disclaim
all responsibility for non-compliant use or assembly Similarly, we reject any
responsibility for any modifications you may make to the light fittings.
For their use, constant current spotlights must always be connected in series
to the corresponding DC power supply (see power packs) 350-700mA. Do not
disassemble the projector casing, because the cables and the plate are sealed
Install the spotlight in a BA13 type or metal ceiling. We cannot supply universal
installation instructions because ground conditions and the location will vary for
each project. The pictograms show examples of typical installations
When installing, it is advisable not to put rock wool around the product to ensure
it is correctly ventilated. Use only the factory-connected cables. Please indicate
the required cable length when ordering. In the event of mechanical stress, the
cable must be installed in a protective conduit. The connection of the silicone
cable to the supply must be carried out in a dry environment and, in the event of
a direct connection in the ground, only connection units compatible with a joint
sealing compound should be used. Connect the various conductors to power
supplies in accordance with instructions. The maximum number of lights that can
be connected is indicated in the power pack manual
4. Connecting to the power packs/connection matrix
Constant current spotlights must only be connected in series. If applicable,
proceed with connection in series in separate load distribution units, the outside
of which must also be protected against humidity using a sealing compound.
5. General Maintenance Instructions
Do not use detergents which are harmful to metals when cleaning the spotlight.
The use of hydrochloric acid-based detergents on and around any parts of a
stainless steel light fitting is totally forbidden.
Regularly clean the spotlight and its mounting box to avoid any rust deposit.
Caution: Do not use a high pressure cleaner. Any lost screws should only be
replaced by V4A stainless steel screws.
According to conditions of use (power, environmental circumstances), it is
recommended to change the seals (on the glass, screw fittings and O-rings) and
the cable every 5 to 8 years.
6. Warranty conditions
The following time limits and provisions of the warranty shall apply from the date
of delivery: - 24 months for Orsteel spotlights
The warranty covers defects in materials, manufacturing defects and any
treatment which is proven to be attributable to the manufacturer.
Any damage resulting from the non-compliance with this user leaflet or any non-
compliant repair is excluded from the warranty.
We disclaim any guarantee where the installation has not been carried out
according to the instructions or where unsuitable bulbs or connection cables have
been used.
We reserve the right to make any modification corresponding to technical
advancement.
7. Important Notice
(The warranty becomes void in the event of non-compliance with the following
points)
The absence of damage during transport must be verified before installation.
Any assembling and installation, as well as any electrical work, must be carried
out by qualified personnel.
To avoid any rust deposits, only stainless steel tools should be used.
The cable length for lamps must be chosen to avoid extending it in water or in a
damp environment. Any subsequent claim for this reason will not be accepted.
A mounting distance of 10 cm between each device is strongly recommended to
avoid mutual heating.
Equipment must be connected without current, otherwise surges in the power
supply could damage the LEDS. There must be no primary voltage when changing
LEDs.
When connecting the lamps, please ensure that polarity matches! A polarity error
may damage the LED module.
The customer is advised to install protection against any over voltage compliant
with standards DIN VDE 0100-443, DIN VDE 0100-534 and En 62305.
Please observe the measures against electrostatic discharge during all work on
the spotlights, equipment and LEDs.
INSTALLATION GUIDE
