Oracle Audio CD turntable User manual

Please note that your Oracle CD turntable does not
contain any user serviceable parts.
Always consult an Oracle qualified service technician.
WARNING
Table of Content
Unpacking 3, 4, 5
Installation Procedure 6
Suspension Fine Tuning 6, 7
Connection Procedure 8, 9, 10
Operating Instructions 11, 12, 13
Remote Control 14, 15, 16,17
Laser Lens Cleaning 18
Fuse Replacement 19
IMPORTANT WARNING CLASS 1 Laser Product. It is essential that the
protective top cover be installed and remains
in place until the « No Disc » message appears in the CD display.
This also applies should the unit be switched off during a listening
session, NEVER remove this cover until the « No Disc » or the disc
information message appears or re-appears after a new switch-on.

Unpacking your Oracle CD Turntable
We developed this packing material so that your
new Oracle CD turntable is afforded maximum protection.
It consist of :
- a double layer cardboard box,
- a module of foam packaging for the accessories,
- a wooden frame with internal foam packing, protecting the CD turntable
itself. It is very important to preserve this packaging material since it is
the only really safe method of transporting your Oracle CD turntable.
The Wooden Module
4 suspension covers
magnetic
disc clamp
aluminium
top cover
power supply
AC power cord
15 pin DC
signal cord
remote control
handset and
batteries
suspension
calibration tool
Brillance cleaner
and linth free blue cloth
1
Content
The Upper Foam Structure
1 CD turntable assembly
1 plinth assembly including :
- 4 suspension towers
- 1 display module assembly
1 main CD turntable chassis assembly
2 main chassis protective foam end caps
1 main chassis hold down « C » shape foam spacer block

- Phillips (cross head) or Pozidrive screw driver
- Small needle nose pliers
TOOL NEEDED
• Open the external box
• Carefully remove the 4 white foam protection corners
• Turn the brown box on its side so you can pull out the white internal
cardboard box
• Carefully slide the white box out and stand it flat with the arrows on the side
pointing up
• Open the box first by opening the end flaps then the front
• Remove the white foam layer to access the wooden box, set it aside
Unpacking
NOTE The suspension covers will be installed following the suspension
fine tuning should this be required.
Accessories Foam Block
• Remove the power supply, power cord and DC cord, put it aside
• Remove the aluminium top cover
and the Brillance cleaner
• Remove the remote control and
install the batteries
• Remove the magnetic disc clamp
• Remove the suspension covers
and put them to one side for
later installation
2

Unpacking
NOTE Place the inner bag, the 2 protective end caps and the «C»
shape hold down spacer blocks back in the wooden box thus
making sure they do not get lost. Put the wooden top cover back on.
NOTE When repackaging, it is important to use this inner protective
bag to prevent surface damage to the clear lacquer finish.
• Open the plastic bag at one end only and remove the foam protective end cap
• Hold the plinth and slide the CD turntable assembly out of the bag
• Remove the «C» shape, hold down spacer block
•␣ Remove the inner protective bag
•␣ Remove the wooden top cover using your Phillips screwdriver
• Grasp the plastic protective bag at each end using the handles and lift the
whole Oracle player unit out of the box
3

CAUTION
NOTE Before beginning this step, very carefully seat the aluminium
top cover above the compact disc in its specially machined
recess and position, so that the two finger slots match the one on
the player main chassis. The slightly curved section of the finger
slots should be facing the front of the unit. This will give a more
accurate operational mass of the main chassis.
Do not attempt to lift the main chassis from the suspension
towers as this could damage the connecting cable between
the display module and the main chassis. If the main chassis needs to
be removed, a special technical document is available from Agence
Commerciale A.C.I. Inc. or your local area distributor. This work should
always be carried out by an experienced and competent technician.
• Place your Oracle CD player on a flat surface to complete the set up procedure.
Suspension Fine Tuning
The suspension of your Oracle CD turntable has been calibrated at the factory
but it possibly might require minor fine-tuning before putting the player into
service. To help with this we have supplied a suspension calibration tool to
assist with accurate measurement and calibration of each suspension tower.
NOTE The reference to clockwise or counter-clockwise is
determined by viewing the spring module from above.
Suspension Fine Tuning
The tool supplied will help you determine if a suspension
fine tuning is required. If no or only minor changes
need to be performed, you might select
to leave the system as is.
At this point, the suspension top covers
can be installed and the player moved to
its final playing location.
To complete the final leveling of the
plinth, it will be necessary to use a spirit
level. The leveling will be achieved by
ajusting the height of the threaded feet
under the plinth.
This picture indicates the target setting of the suspension system.
4

In the unlikely event that your Oracle suspension system
may need to be completely recalibrated please refer to
the caution on the preceeding page.
Make the Suspension Housing Sit Lower
Make the Suspension Housing Sit Higher
If the suspension housing is sitting to high as on this picture
• With one hand apply a
light down pressure to
the main chassis while
holding the suspension
housing
• Rotate the spring counter-clockwise by very small
increments until the suspension housing lightly
rests against the step on the gauge
If the suspension housing is sitting to low as on this picture
Do not allow the pliers to contact the aluminium parts since
this could damage the clear lacquer finish.
• Gently raise the
suspension
housing
with one
hand
• While holding the spring to prevent it from turning, rotate by very small increments
the suspension housing, couter-clockwise. This will move the spring further out of
the spring calibration sleeve thus making the suspension housing sit higher.
NOTE
IMPORTANT
•␣ When all suspension towers are fine tuned, install the suspension covers
Suspension Fine Tuning
To proceed with minor changes to the suspension
fine tuning, please read the following information.
• Using needle nose pliers, insert the tip
of the pliers near the end of the spring
and hold it firmly
5

Connection Procedure
15 pin DC input BNC XLR Optical
NOTE We strongly suggest the use of the best possible Digital/Optical
Interconnect cable available, your dealer will help you make the
right choice.
CD Player
• BNC, output of 0,5 volt peak to peak @ 75 Ohms
• RCA analog output,
• Impedance < 100 Ohms
• Recommended impedance load 50 kOhms ( Minimum 5 kOhms )
• Maximum effective output level, 2.4 volts
• Digital to Analog converter type, Delta Sigma
• Resolution 24 Bits
Your Oracle CD Player is equipped with both an Analogue (pair) and a Digital output.
Use the desired output to transfer the signal to your Digital to Analog converter.
• BNC, (75 Ohms) output of 0,5 volt peak to peak
• XLR, AES/EBU (110 Ohms), balanced output of 4 volts peak to peak
• Optical, Hewlett Packard (ST, AT&T - glass) - HP-HFBR 1412
Your Oracle CD transport is equipped with three digital outputs :
CD Transport
THE ANALOGUE AND/OR DIGITAL CONNECTIONS
6

Simultaneous Connection of an External Digital
to Analogue Converter
• Plug your digital/optical interconnect to the rear of the player and connect it
to your stand alone D/A converter
• Connect the Analogue outputs to an « Auxiliary » input at the rear of your
pre-amplifier
• Balance the volume between the two D/A converters through the external
converter volume control... should this facility be available
• Switch from « CD » to « Auxiliary » so as to compare the two options
It is possible to simultaneously use the BNC (75 Ohms) Digital output to compare
the players internal Digital/Analogue converter, with that of an external (stand
alone) D/A converter
15 pin DC Input BNC
Digital Output
NOTE It is not necessary to use digital output unless connecting
to a separate stand alone DAC.
NOTE
Connection Procedure
We strongly suggest the use of the best possible Analogue
Interconnect cables available, your dealer will help you make
the right choice.
WARNING Lower the volume of the pre-amplifier as there could be a
major difference in gain, this could cause damage to your
loudspeakers.
Analogue RCA
Outputs
7
• Connect your pair of RCA terminated Analogue Interconnect cables from the
rear of the player to your pre-amplifier Digital input ( CD input )
Connection to the Pre-Amplifier, CD input

• Connect the 15 pin DC signal cable to the rear of the CD turntable and
secure it with the two locking thumb screws
• Connect the other end to the power supply and secure it as above
• Plug the AC power cord to the IEC socket at the power supply end,
and the other end to the line voltage wall socket
• Turn the power supply « ON », indicated by the line ( — ) on the rocker
switch above the IEC socket, the red « L.E.D. » at the front of the power
supply will now light up.
The « OFF » position is indicated by ( O ) on the rocker switch
Power Supply Connection
IMPORTANT WARNING CLASS 1 Laser product. It is essential that
the protective top cover be installed and
remains in place until the « No Disc » message appears in the CD
display. This also applies should the unit be switched off during
a listening session, NEVER remove this cover until the « No Disc »
or the disc information message appears or re-appears after a
new switch-on.
On/Off switch
IEC socket
15 pin DC Input
8

NOTE To obtain optimal performance, keep the surface of the Ure-
thane vibration damping trap clean at all times using your
Brillance cleaner or denatured alcohol (methylated spirits).
To extend the cleaning cycle to a maximum, we recommend not setting the
magnetic disc clamp with the Urethane facing down as dust would very quickly
reduce the adhesion to the compact disc, thus lowering the vibration damping
trap efficiency.
CAUTION Since the adhesion will diminish as the Urethane picks up
dust, it is important to place your hand under the compact
disc to prevent it from falling.
Please read the recommended maintenance procedure below.
Operation
• Place the compact disc on your Oracle CD turntable
• Install the magnetic disc clamp
The Magnetic Disc Clamp
To Remove the Magnetic Disc Clamp
• Lift the compact disc
by holding it from the periphery
with the magnetic disc clamp
installed
RECOMMENDEDOption 1
CAUTIONOption 2
Maintenance
Your Oracle player is equipped with a very efficient magnetic clamp. One of the
key features of this clamp is the proprietary Urethane compound ring that acts
as a vibration damping trap.
• Peel the disc from the clamp, this will break the close seal between the
Urethane vibration damping trap and the compact disc
• Lift the magnetic disc clamp
straight up. The compact disc
will follow because of the adhesion
of the Urethane vibration damping
trap to the compact disc surface
9

Disc Reset Down (-) Up (+) Play Stop
Track Selector
Display Keyboard Function Selector
Please Follow these Important Safety Tips for
The Safe Operation of Your CD Player
Safe Operating Instructions
These instructions may seem extremely basic, but they must be
followed exactly to ensure safe operation of this product.
1. Before switching on your CD Player/Drive it is essential that the aluminium
top cover be correctly installed and remain in place until the CD display indi-
cates the «␣ No Disc␣ » message.
2. To start playing a CD : remove the aluminium top cover ; select the CD you
wish to play and place it on the CD turntable. Install the magnetic clamp and
replace the top cover.
3. Press the Reset button and wait for the disc information to appear in the
main CD display. The information will show the number of tracks on the CD
and the total playing time.
4. Press « Play »and adjust the volume control on your pre-amplifier,
sit back, and
ENJOY PURE MUSIC !
5. To change a CD, press Stop, the CD display will once again show the disc
information. Remove the aluminium top cover, lift your CD using one of the
methods described earlier. Gently peel the clamp from the CD. Select your
next CD and place it on the CD turntable as described above. Having placed
the disc on the turntable, the display will still show the details of the previ-
ous CD played until you press the Reset button, only then will the new disc
information be displayed.
Do not activate this switch until you have read the instructions listed below.
NOTE
The main Power On/Off switch for your CD Player/Drive is located on the rear of
the power supply.
10
The display module
is equipped with five
selector buttons

The performance of the
Oracle CD turntable is
significantly improved
by using the aluminium top
cover whenever the player is
in use. It provides a darker
environment for the laser
diode to more accurately
pick up signals from the
spinning compact disc.
IMPORTANT
• Press the « Disc Reset » function selector to initialize the selected disc. This
operation must be repeated every time a different compact disc is used
• Select the track to be played by pressing the « Up » or « Down » function
track selector
• Press « Play » and adjust the volume control on your pre-amplifier,
sit back, and
ENJOY PURE MUSIC !
• Press the « Stop » function selector and repeat the « To Play a Compact
Disc␣ » procedure
• Remove the aluminium top cover and put it to one side
Press the « Disc Reset » function selector every time a
new compact disc is placed on the CD turntable, so it
can be properly initialized.
To Play a Compact Disc
To Play a Different Compact Disc
11
• Place a compact disc over the centering device of your CD turntable
• Position the magnetic disc clamp over the centering device and make
sure it is well seated
• Very carefully seat the aluminium top cover over the compact disc in its
specially machined recess and position it so the two finger slots match
the ones on the player main chassis. The slightly curved section of the
finger slots should be facing the front of the unit
Operation Instructions

For your convenience and to increase ease
of use, your new Oracle CD Player/Drive is
supplied with an Infra-red remote control
facility. To enable you to reap the benefit of
this facility please spend a few minutes read-
ing these simple instructions.
Beginning at the top, or front of the handset
the various buttons (function keys) will be
described on the left of the page. What the
button does and how to do it is described on
the right of the page.
Remote Control Operation
FUNCTION KEY WHAT IS DOES & HOW TO DO IT
•Red Button•
( STBY )
This is the Standby button and this allows the display
screen to be turned off as if the unit was out of service.
Whilst the player looks as if it is switched off, the opti-
mum operating temperature is maintained. PRESS the
STBY button once and the display goes out. PRESS the
STBY button again and this will have a similar effect as
pressing the « Disc Reset » on the display keyboard func-
tion selector to initialize the selected disc. If the unit
was in a Standby mode after using the STBY button,
it must be pressed again so the player can resume the
operational mode.
•Numeric Buttons•
( 1 – 0 )
These buttons relate to the track numbers on your CD,
and run from 1 through 9, the 0 button becomes 10 by
pressing first 1 then 0. The player is able to play, merely
by pressing a combination of two buttons any track on a
CD that may contain anything up to 99 tracks.
12

•Programme Button•
( PROG )
This button allows you to select various tracks of a CD
and play them in your chosen order. To use this func-
tion you first select a track number using the numeric
buttons, having selected the track number pressPROG.
Move on using the numeric buttons to your next se-
lection and again press PROG. Repeat this operation
until you have programmed as many or as few tracks
as you want. The track selection will play in the order
in which you have entered the track numbers.The PROG
function is cancelled by pressing STOP.
•Time Button•
( TIME )
This button allows you to view various TIME options.
The default setting will indicate the number of tracks
and the total running time of the disc is displayed.
PRESS PLAY and the elapsed time of the track playing
will show. Press TIME once and the elapsed running
time of the disc will show. Press TIME again and the
remaining running time of the disc will show.
•Fast Button•
( FAST )
This button is located next to both, the track search
forward and track search back buttons. PRESS
the FAST button to double the search speed before
pressing the and buttons. The sound heard
in order to find a particular section of track will be
more difficult to identify using the FAST mode.
•Search Buttons•
( )
This function allows you to search forward or back-
wards through a track, or the complete CD at approxi-
mately 10 times normal speed. It is possible to hear
the track/CD whilst doing this enabling you to find a
specific part of a track/CD. PRESS and the search
runs back from where you are. PRESS and the
search runs forward from where you are.
•Scan Button•
( SCAN )
This button permits you to SCAN a CD to find a particu-
lar track. PRESS this button once and it plays the first
few seconds of every track in numeric order. Once you
have heard the track you want, press the button again
and your chosen track will play from the beginning.
FUNCTION KEY WHAT IS DOES & HOW TO DO IT
Remote Control Operation
13
▲ ▲
▲ ▲
▲ ▲
▲ ▲
▲ ▲
▲ ▲
▲ ▲
▲ ▲

•Shuffle Button•
( SHUF )
This command causes the track
playing order to be played non
numerically ascending. Instead of
the tracks being played from 1
through to say 10, it will play the
tracks in a random order.
The track play order cannot be
determined by the user when
using this function. This func-
tion must be chosen before
the PLAY button is pressed.
The disc information will
be displayed on the main
display screen. PRESS SHUF
and the random track play
order will be displayed along
the bottom of the main display screen. PRESS PLAY
and the randomly selected order will start playing.
•Previous Track•
( I )
This button has two functions, and is marked I. PRESS
once and the track being played will start playing from
the beginning again. PRESS I twice quickly and the
previous track on the CD will play from the beginning.
•Next Track•
(>(II)
This button only has one function, and is marked I.
PRESS this button once and the next track on the CD will
begin playing. Each time you press this button, the next
track on the CD will begin to play in the normal ascend-
ing numeric order, or the next programmed selection if
you have used the PROG option. If in the SHUF mode the
next randomly selected track will begin to play.
Remote Control Operation
•A/B Button•
( A / B )
This button allows you to repeat a section of a track or
the CD. To do this, listen for the starting point of the
section you want to repeat and PRESS the A/B button once.
Let the section run to where you want the repeated sec-
tion to end, then PRESS the A/B button once more. The
selected section will now continue to repeat just that
section until you cancel the command
by pressing STOP.
FUNCTION KEY WHAT IS DOES & HOW TO DO IT
14
▲
▲
▲
▲
▲

•Stop•
( STOP )
This function stops the CD turntable from spinning and
the laser from reading the digital information on the
disc. It also cancels all programmed functions and en-
ables the current disc to be removed. The CD turntable
is now ready to accept another disc, or to be switched
off at the end of the current listening session.
•Play•
( PLAY )
The PLAY function is used to start a new listening
programme. When a CD is placed on the turntable the
PLAY function will not operate until one of the two fol-
lowing funtion is activated :
a) The RESET button on the CD Player/Drive
has been pressed.
b) The STBY button on the remote control
handset is pressed twice.
Remote Control Operation
•Pause•
( PAUSE )
This function suspends the playing of the CD at the
exact point that the PAUSE button was pressed. This
mutes the sound completely. PRESS PAUSE again and
play resumes from the exact point it was originally
suspended.
•Repeat•
( REP )
This function permits continual repeat playing of the
track being played by pressing the REP button once.
PRESS the REP button twice and the WHOLE disc will
be repeated until the REP button is pressed again can-
celling the repeat function. The REP function can also
be used if PROG or SHUF modes have been selected,
and works in exactly the same way. PRESS once and
the track being played will repeat, PRESS twice and
ALL the programmed selections PROG, or the random
play order SHUF, will be repeated. PRESS REP again and
the selection will play as normal without repeating,
from the point at which the REP function was cancelled.
FUNCTION KEY WHAT IS DOES & HOW TO DO IT
This starts the turntable spinning and the disc infor-
mation is read by the laser. The disc information will
then appear on the main display screen. Once the disc
information is displayed, it is possible to play the CD by
pressing the PLAY button on the remote control handset.
15

Routine Cleaning of the Laser Lens
Routine Cleaning
Cleanliness is essential in order to maintain optimum performance.
Routine cleaning of the laser lens should be carried out weekly in
the following way␣ :
1. Turn off the power to the CD
Player using the switch on the
rear of
the power supply.
2. Unplug the supply power cord
from the wall socket.
3. Remove the aluminium top
cover and the magnetic disc
clamp.
4. Using a clean cotton bud/Q-tip
dampened with denatured
alcohol (methylated spirits)
very, very gently wipe the
laser lens.
WARNING
16
IMPORTANT WARNING CLASS 1 Laser Product. It is essential that the
protective top cover be installed and remains
in place until the « No Disc » message appears in the CD display.
This also applies should the unit be switched off during a listening
session, NEVER remove this cover until the « No Disc » or the disc
information message appears or re-appears after a new switch-on.
Extreme care is required when carrying out this
procedure, the drive and lens mechanisms are
extremely delicate.
WARNING Do not allow the spirit to drip into the mechanism).

Fuse Replacement
If the power supply is connected to the line source and the switch is in the ( ON␣ )
position the red «L.E.D. » located at the front of the unit will glow. If it does not
glow make sure the line signal coming from the wall outlet is operational.
If everything is normal, follow the procedure below to proceed to
the replacement of the line input fuse.
• Using a continuity tester check the fuse for
continuity. Continuity means « good fuse ».
No continuity means « fuse no good »
• Make sure to reinsert the fuse holder in the
same direction as the arrow inside the cover
There are 2 fuses inside the IEC socket, the one under the « O »
is the one in the signal path. The fuse under the ( – ) is a spare.
NOTE
• Close the flap until it snaps in a fully closed position
• Plug the AC power cord at the power supply end
• Switch the power supply to the « ON » position
If the fuse keeps blowing, it might be an indication of
a defective power supply unit, please contact your
dealer for advice. Do not use a different value fuse than recommended.
IMPORTANT NOTE
Fuse Types
CD Drive
- 100 to 120 volts fuse type - GMC 200ma @ 250v
- 220 to 240 volts fuse type - GMA 200ma @ 250v
CD Player
- 100 to 120 volts fuse type - GMC 2amps @ 250v
- 220 to 240 volts fuse type - GMC 1,25amp @ 250v
• Switch the power supply to the « OFF » position
• Unplug the AC power cord at the power supply end
• Use a flat blade screw driver and insert it in the
slot at the top of the IEC socket to open the
flap as shown on the picture
• Use the same flat blade screw driver to gently
extract the fuse holder
17

Agence Commerciale A.C.I. Inc.
4124, Boul. Industriel
Sherbrooke QC - Canada - J1L 2S6
Tel. : [phone]
Fax : [phone]
eMail : oracle.audio
@
sympatico.ca
Notes
Authorized Oracle Distributor
