Orava MK-7 User manual

Portable insect killer with LED light
MK-7
MK-7
Instruction manual EN

2EN
Intended use of the device
The device is intended to serve exclusively as an insect repellent, to the
extent specified in the technical and operational parameters and functions,
safety and user instructions and external influences of the operating
environment.
ORAVA electrical equipment is manufactured in accordance with the
state of the art and recognized safety and technical rules. Nevertheless,
incorrect and unprofessional use or use contrary to the intended purpose
may create a risk of injury or endanger the life of the user or a third party,
resp. damage to equipment and other property.
GENERAL SAFETY INSTRUCTIONS AND WARNINGS
• Before putting the device into operation, we recommend that you carefully
read the operating instructions and operate the device in accordance with
the specified instructions! The insect killers are designed either for indoor
use or for outdoor use, depending on the type of product.
• By failing to observe the safety instructions and warnings, the
manufacturer is not responsible for any damage to health or property!
• Always keep the operating instructions with the appliance for future
reference and use by new users.
• Use the device only for the intended purpose and in the manner specified
by the manufacturer.
• The device is intended for use in the home and in similar indoor areas
intended for housing without special focus.
• The manufacturer is not responsible for damage caused during transport,
incorrect use, damage or destruction of the device due to adverse weather
conditions.
• Do not use the device in an industrial or outdoor environment!
• Do not expose the device to:
- sources of excessive heat or open flame
- animals and flora,
- aggressive and chemical substances.
• The operating environment of the device must always comply with the
specified basic characteristics.
CHARACTERISTICS OF THE OPERATING ENVIRONMENT
1. Ambient temperature: -10 to +65 ° C
2. Humidity: 15 ÷ 85%
3. Altitude: ≤ 2,000 m
4. Occurrence of water: occasional condensation of water or occurrence of
water steam
5 Occurrence of foreign objects: the amount and type of dust are
insignificant

3EN
ELECTRICAL SAFETY
• Before connecting the appliance to the mains for the first time, make sure
that the mains voltage indicated on the type plate corresponds to the
mains voltage in your home.
• The electrical appliance is designed for mains supply 1/N/PE ~ 230 V 50
Hz or USB 5 V depending on the product type.
• The electrical safety of the device is only guaranteed if it is connected
correctly to the mains.
• Always connect electrical equipment to an easily accessible power outlet.
In the event of an operating fault, the device must be switched off and
disconnected from the mains as soon as possible.
• Do not unplug the power cord / power cable by pulling on the cord / cable.
Disconnect by unplugging the power cord.
• If you use an extension power cord, make sure that the total ampere rating
of all the devices connected to the extension cord does not exceed the
max. extension cable current load.
• The plug of the device‘s power cord must be compatible with the power
outlet. Never use any adapters or modify the outlet in any other way. Do
not use unsuitable and damaged sockets!
• Do not bend, squeeze, or otherwise expose the device‘s power cord /
power cable to mechanical stress or external heat. Damage to the power
cord may result in electric shock.
• If the power cord is damaged, unplug the device and do not continue to
use it.
• If the supply cord / cable is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to
avoid a hazard.

4EN
PERSONAL SECURITY
• This device is intended for use and operation by persons without electrical
qualification, according to the instructions provided by the manufacturer.
• Operations of the equipment include activities such as turning the
equipment on and off, user manipulation and setting of operating
parameters, visual or auditory inspection of the equipment, and user
cleaning and maintenance.
• The appliance is not intended for use by persons, including children under
the age of 8, with reduced physical, mental or sensory capabilities, or lack
of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure that they do not play with the
appliance. The device is not a toy.
• Always keep the appliance out of the reach of children during use and
operation. Remember that the device can also be downloaded with a
freely accessible power cord.
• Always take extra care when operating electrical equipment! Do not use
the device if you are excessively tired, under the influence of drugs or
narcotics that reduce attention and concentration.
• Careless handling can lead to serious injuries.

5EN
2. Special safety instructions.
Read carefully!
• The electrical equipment is designed and manufactured in such a way
as to allow safe operation and use by unqualified persons. Despite all
the measures taken by the manufacturer for safe use, operation and use,
there are certain residual risks and the possible dangers associated with
them.
• The following symbols and their meanings have been used on the device
and in the accompanying documentation to warn of possible dangers:
This symbol alerts users that the device is operating on
hazardous voltage. Do not remove the protective covers on the
device.
Failure to observe the safety instructions when using and
operating the device may result in:
Danger of electric shock! Danger of serious injury or death!
This symbol alerts users to the fact that if the safety instructions
for the use and operation of the device are not observed, there
is a risk of:
Danger of serious injury or death! Danger of equipment damage
or other property damage!
This symbol means that the product is made with double
insulation between dangerous live parts (parts with dangerous
mains voltage) and parts that are accessible during normal use.
This symbol used on the product replaces the sentence: Do not
immerse in water or other liquids!
Dangerous voltage!
Unpacking/Packaging
• Unpack the device and accessories before putting them into operation
and dispose of all parts of the packaging materials, labels and tags. Store
packaging materials in a safe place, especially out of reach of children and
incompetent persons, or dispose of them safely. Risk of serious injury!
There is a risk of suffocation!

6EN
Inspection/Commissioning
• Never use the device if it is incomplete, damaged or its parts or
accessories have been damaged during use (eg due to a fall - tearing of
the cable).
There is a risk of electric shock! Risk of serious injury!
Warning!
• Prior to commissioning, make sure that the correct voltage is available.
• Before each use, check the power cord for damage.
• Do not use the appliance if you find any damage. Risk of serious injury!
There is a risk of equipment damage or other property damage!
• Do not use the device in potentially explosive atmospheres where
flammable liquids, gases or dust are present. Risk of serious injury! There
is a risk of equipment damage or other property damage!
Operation/Supervision
Warning!
• This device may only be used with original and undamaged parts and
accessories.
• Equipment that is not removed from the packaging must not be connected
to a power source. There is a risk of fire!
• Do not expose the device to high temperatures, direct sunlight, excessive
humidity or dust.
• Do not use or place the device near containers containing water. If the
appliance falls into water, take it to a specialist garage to check that it
is safe and working properly. There is a risk of electric shock! Danger of
electrical short circuit!
• The appliance is not suitable for use in barns, stables, garages or similar
places where dry or highly flammable material may be stored.
• Do not expose the device to rain or humid environments! If the device is
intended for outdoor use, it must be protected by a pergola or roof.
• Do not spray the device with water or any other liquid.
• Use and store the device away from flammable and volatile substances or
explosive dust.
• Do not place the appliance near heaters, open flames or other heat
sources.
• Do not place the device on an inclined surface.
• Install the device up to your reach (for proper maintenance and operation).
• The device is intended for domestic use, not for industrial use. Do not use
it for purposes other than the one for which it was made
• Do not repair or modify the device yourself - risk of electric shock. All
repairs must be carried out by a specialist company/service.
• Cracking that you hear after the insect comes in contact with the safety net
is a common phenomenon, not a device fault.
• Place the enclosure in a dark place where the insect comes from the
outside and will respond to light.

7EN
POWER SUPPLY SAFETY INSTRUCTIONS
• Do not grasp the AC adapter and cord and do not plug into an AC outlet
with wet hands or the AC adapter plug or cord or the device itself is wet.
Always wipe your hands, power cord, and device thoroughly with a dry
cloth. There is a risk of electric shock!
• Never insert any conductive objects (such as a screwdriver, etc.) into the
connector for connecting the AC adapter.
Danger of electrical short circuit! Danger of explosion!
• Do not use travel adapters (for foreign outlets) as the power cord.
There is a risk of electric shock! There is a risk of fire!
• To disconnect the device from the power supply by pulling the plug from
the socket, do not pull on the power cord.
MAINTENANCE AND CLEANING
• To clean the device, wipe it with a soft, dry cloth. Unplug the appliance
before cleaning.
• Do not use water to clean the device!
LIQUIDATION
• At the end of its service life, return the device for recycling of electrical and
electronic equipment.

8EN
General information about the device
Portable insect trap with LED lamp MK-7
- Ecological disposal of insects using high voltage
- It does not produce any toxic substances, gases or other impurities
- Ultraviolet LED light
- Easy to use and maintain
- LED light
- Rechargeable via microUSB
- Powerbank function
Parts descriptions
A Hook for hanging
B Handle
C Ultraviolet LED light
D High voltage conductive grid
E LED lamp on/off button
F Removable bottom (turn to open)
G MicroUSB power connector
(connection of the supplied cable and a suitable AC power adapter)
H USB power connector (5 V OUT) - powerbank - phone charging, etc.
A
C
D
E
F
G
H
B

9EN
Operation
Follow the steps below to prepare the device and get it up and running.
Power supply
The device is powered by a built-in Li-ion battery 2,000 mAh, 3.7 V. The
battery is charged from a suitable AC adapter with DC output voltage
5 V, 1 000 - 2 000 mA using the supplied charging cable with USB
connector and mini-connector.
Connect the AC adapter to an electrical outlet, connect the USB connector
of the cable to the AC adapter, and connect the mini-connector to the mini-
connector on the device.
During charging, the red charging LED will flash, when the battery is fully
charged, the red LED will light up.
You can also power the device from a PC by connecting the PC and this
device with the supplied cable.
LED lantern function
1. Press button E for the first time to switch on the LED lantern at 100%
brightness (150 lm).
2. Press button E a second time to reduce the brightness of the LED lamp
to 50% (70 lm).
3. Press the E button a third time to turn on the LED flashing.
4. Press the E button a fourth time to turn off the LED.
Insect killer function
1. Firmly grasp the LED lamp by the white part of the shade and with the
other hand pull the insect trap upwards with the handle.
WARNING!
When closed, a slight negative pressure may be created, so that the
first pull-out of the insect trap may be more difficult.
2. The insect repellent will be put into operation automatically.
3. Push the insect killer
Powerbank function
The device has a USB connector with a 5 V DC output voltage for charging
a mobile phone, etc. Connect the classic USB connector with the charging
connector on your mobile phone/mp3 player/tablet and other digital devices
to it.
The device will then charge the battery in the connected digital
device with 5 V DC and the green LED will light up.

10EN
Cleaning and maintenance
Do not use solvents or harsh cleaners to clean any elements. Before each
cleaning, make sure that the appliance is no longer connected to the mains.
To increase the efficiency of fluorescent lamps, regularly remove insect
remnants.
Do not use chemical solvents. Do not immerse the device in water or any
other liquid.
Do not use harsh or aggressive cleaning agents that could damage the
surface of the device.
When not in use, the appliance should be stored in a safe and dry place out
of the reach of children.
Technical specifications
Power (charging): optional AC adapter with output
DC 5 V/5 V/1-2 A (not supplied)
Built-in rechargeable lithium battery
3.7 V, 2 000 mAh
charging time approx. 4 hours
High voltage: 500 V
Dimensions (W x H x D): 9.8 x 13.8 x 9.8 cm
Weight: 389 g
We reserve the right to make changes!

INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING
Dispose of used packaging material at a municipal waste disposal site.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on the products or in the accompanying documents means that used electrical
and electronic products should not be mixed with general household waste. For proper
disposal, recovery and recycling, please return these products to designated collection
points. Alternatively, in some countries of the European Union or other European countries,
you may return your products to your local retailer when purchasing an equivalent new
product. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment natural resources and help prevent potential
negative effects on environment and human health, which could be the consequences
of improper disposal waste. Contact your local authority or nearest office for more
detailscollection point. Improper disposal of this type of waste may result in penalties in
accordance with national regulations.
For business entities in the countries of the European Union
If you wish to discard electrical and electronic equipment, please request the necessary information from
your seller or supplier.
Disposal in other countries outside the European Union
This symbol is valid in the European Union. If you wish to discard this product, please request
obtain the necessary information on the correct method of disposal from the local authorities or from the
your supplier.
This product meets all the essential requirements of the EU directives that apply to it.
Producer:
Importer:
ORAVA retail 1, a.s.
Seberíniho 2
821 03 Bratislava
Slovenská republika
ORAVA distribution CZ, s.r.o.
Ostravská 494
739 25 Sviadnov
Česká republika
ORAVA retail 1, a.s.
Seberíniho 2
821 03 Bratislava
Slovenská republika
