Orbis HTSC-F02 User manual

HTSC-F02
In-Line Optic Splice Closure
Installation Guide

1
NOTES:
1. Please read the user’s guide before installation.
2. Please pay attention while sealing the cable ports, the inappropriate
installation would affect the performance.

2
List of Contents
1. General introduction ………………………………………………………….. Page 3
2. Basic structure and configuration ………………………………………. Page 3
3. Product illustration ………………………………………………………….. Page 3
4. Preparation for installation …………………………………….….………. Page 4
5. Application ……………………………………………………………………….. Page 6
6. FOSC inspecting and testing items ……………………………………. Page 6
7. Customer service ……………………………………………………………….. Page 8

3
1. General introduction
HTSC-F02 is fiber optic splice closure equipment for multiple uses, which can contact and branch cables. It
has 2 inlet port. Device can apply for wall mounting environments. The goods can use in different area and
come with perfect sealing, easy installation and indeed our cover made of super strength material and
temperature proof. This is our mission to dedicated perfect communication equipment and to ensure every
customer has best quality of goods
2. Basic structure and configuration
2.1 Dimension and capacity
Outside dimension (LxWxH, mm)
179x72x26
Weight (w/o packing box, kg)
0.17
Sealing method
Mechanical
Number of inlet/outlet ports
2
Diameter of fiber cable (mm)
Φ6
Max. splice capacity (single fiber)
4
Working temperature (℃)
-40~+65
Notice:
In case of slightly bigger diameter of optical cable, can apply proper force to squeeze cable into grommet,
and for smaller than 6mm diameter cable, using insulation tape to increase the diameter.
3. Product illustration

4
4. Preparation for installation
4.1 Preparation
4.1.1 Check the model of closure, accessories and specification of optical fiber cables before installation.
4.1.2 Keep all components and accessories dry and tidy for proper installation.
4.1.3 Keep the working place clean and flat for easy installation
4.1.4 Use the proper equipment and tools during the installation.
4.2 Cable installation
4.2.1 Stripping the cable in 60mm length
4.2.2 Cut the reinforced core (CSM).
Notice: Be sure not to damage the fiber. If the fibers are damaged, cut if off and stripping the new fibers.
4.3 Installation Process
4.3.1 Open the closure and release the screws on the splice tray.
4.3.2 Remove the cable block and use the proper grommet through the cable. Screw tight the cable block.
4.3.3 Remove the top of the aluminum cable clamp and then lead the stripped cable through, fasten the
cable on the cable clamp. Insert the CSM to the clamp and screw tight, also cut the remained CSM.

5
4.3.4 Insert the fiber to the splice protective sleeve and fasten with nylon tie.
4.4 Fibers spliced and protection with sleeve
4.4.1 Insert each fiber to each splice protective sleeve.
4.4.2 Splicing the fibers which have the same serial numbers
4.4.3 Heat shrink the fibers after all are spliced and then fix on the slot.
4.5 Routing the fibers
The diameter of the bending radius should be more than 30mm.
4.6 Sealing the Closure
4.6.1 Routing of optical fiber should be neat in optical splice tray, the bending radius should meet the
requirement.
4.6.2 Internal components should be fastened properly.
4.6.3 Plug the unused inlet/outlet drop cable ports.
4.6.4 The sealing tape should be used in proper volume.
4.6.5 Sealing tape should be placed in slot of base properly.

6
4.7 The installation of the Body
4.7.1 Put the Cover and the Bottom in alignment.
4.7.2 Screw the screws with wrench.
5. Application
Wall mounting application
6. FOSC inspecting and testing items
Inspecting
item
Technical Requirements
Inspecting type
Routine test
(Before leaving
factory)
Type test
Package
Each small package contains one fiber optic splice
closure, together with its accessories, tools,
installation manual and packing list.
full
At least 3 sets
sampled each
time
Appearance
Intact in shape, no burrs, bubbles, chaps, pores,
warps, impurities and other defects, all background
colors should be even and continual.
Sign
There is a clear sign on the housing, such as name
and model of the product, etc.

7
Fiber storage
device
The fibers reserved are to be winded in fiber optic
splice tray (FOST), the length of fibers housed in
FOST is >1.6m, the curved radius is >30mm. During
the installation and maintenance, there should be
no attenuation on fibers.
At least 3 sets
sampled each time
Electrical
jointing
device
Inside FOSC: metallic components of fiber cables
has the functions of electrical putting through,
earthing connection and disconnecting. It is
possible to install earthing deriving device outside
the housing
Sealing
performance
After sealing according to the stipulated operation
procedures, the injected air pressure is
100KPa±5Kpa, when immersed in clean water of
normal temperature for 15 minutes, there should
be no air bubbles, then observed for 24 hours,
there should be no change of air pressure.
Re-sealing
performance
After reopening and resealing according to the
stipulated operation procedures, the injected air
pressure is 100KPa±5Kpa, when immersed in clean
water of normal temperature for 15 minutes, there
should be no air bubbles, then observed for 24
hours, there should be no change of air pressure.
Pull
Bearing pull is ≧800N at axle orientation, there
should be no breakage on the housing.
Punching
Bearing pressure of 2000N/10cm for 1 minutes,
there should be no breakage on the housing
Impact
Bearing impact energy of 16N•m, 3 times of
impacts there should be not breakage on the
housing
Bending
The spot between the FOSC and seal fitting can
bear bending tension of 150N at bending angle of
±450for 10 circles, there should be no breakage on
the housing
Torsion
Bearing torsion 50N•m, 10 circle at torsion
angle±900,
There should be no breakage on the housing.

8
Temperature
circle
Injected air pressure of 60KPa±5 KPa, the
temperature circle ranging from -40℃~+65℃, 10
times of the circular tests (one circular consists of
high temperature for 2 hours + indoor temperature
for 2 hours + low temperature for 2 hours + indoor
temperature for 2 hours ) when the pressure
declines, the amplitude is ≦5Kpa, immerse the
swatch in clean water of normal temperature for
15 minutes, there should be no air bubbles.
Voltage
resistance
strength
After sealing the FOSC according to the stipulated
operation procedures, immerse it in clean water of
normal temperature in 1.5m depth for 24 hours,
there should be no breakdown or arc over between
the metallic components of the FOSC, between
metallic components and the ground at DC 15KV
for 1 minutes.
Isolating
resistance
After sealing the FOSC according to stipulated
operation procedure, immerse it in clean water in
1.5m depth for 24h, the isolating resistance
between the metallic components of the FOSC,
between the metallic components and the ground
should be ≧2×104MΩ.
7. Customer service
Should you have any questions or suggestions, please do not hesitate to contact your local supplier.
Maahantuoja / Imported by
Orbis Oy
www.orbis.fi
Tuotenumero / Orbis product code: 3010387
