Oregon Scientific BBM211 User manual

EN
1
TABLE OF CONTENTS
Introduction ........................................................ 2
Warnings ............................................................. 2
Limitation of Warranty and Liability ................. 2
Overview ............................................................. 2
Front View - Parent Unit ................................... 2
Back View - Parent Unit ................................... 3
LCD - Parent Unit ............................................. 3
Front View - Baby Unit ..................................... 3
Back View - Baby Unit ...................................... 4
Getting Started ................................................... 4
Power ............................................................... 4
Neck String - Parent Unit ................................. 5
Turn On / Off .................................................... 5
Set Up .............................................................. 5
Select Channels - Baby Unit ............................ 6
Nightlight - Baby Unit ....................................... 6
Change Volume......... ....................................... 6
Sound Light Indicators ..................................... 6
Connection Signal Status ................................. 6
Lost-Link Alarm ................................................ 6
Temperature Display .......................................... 6
Clock / Alarm ...................................................... 6
Set Clock / Voice Activation Sensitivity Level ... 7
Set Alarm ......................................................... 7
Feeding Timer ..................................................... 7
Backlight ............................................................. 7
Reset ................................................................... 8
Precautions ......................................................... 8
Specifications ..................................................... 8
About Oregon Scientific .................................... 9
EU-Declaration of Conformity ........................... 9
FCC Statement .................................................... 9
Declaration of Conformity ............................... 10
Baby Monitor
with Indoor Temperature
Model: BBM211/BBR211
USER MANUAL
%00B%%5(15 11/28/2005, 12:05 PM1

EN
2
mentioned in this Manual; used inconsistently with the
technical or safety standards in force in the country where
this product is used, or damaged due to leaky or defective
batteries; used by children as a toy or placed less than 1 meter
away from and within the reach of the child, is not subject to
warranty/liability.
OVERVIEW
FRONT VIEW – PARENT UNIT
1. :Turns unit ON / OFF; activates backlight
2. Sound light indicators: Shows sound level received
from the baby unit
3. / :Increases / decreases volume; changes setting
value; enables / disables alarm
4. :Displays or sets the clock / alarm / voice
activation sensitivity level
5. :Sets and operates the feeding timer
6. Speaker
INTRODUCTION
Thank you for selecting the Oregon Scientific™ Baby Monitor
with Indoor Temperature (BBM211 – parent unit / BBR211 –
baby unit).
NOTE Please keep this manual handy as you use your new
product. It contains practical step-by-step instructions, as well
as technical specifications and warnings you should know.
WARNINGS
•This product should only be operated by an adult
and should not to be used as a toy for children.
•This product is not intended and should not be used as a
replacement for responsible adult supervision; it only acts
as a support for your child-caring purpose. Any type of
liability beyond statutory warranty regulations or resulting
from improper use of this product and/or use not in
accordance with product warnings, precautions and
instructions is excluded.
•Please ensure that this product and adapter cable
are always kept out of the reach of your child and at
least 1 meter away.
•Never place the baby unit inside the baby crib or
near water (e.g. bathtub, wet basement, etc.)
•For indoor use only.
LIMITATION OF WARRANTY AND LIABILITY
Oregon Scientific provides warranty for products with
manufacturing defects. A product which is: damaged, misused,
abused, improperly used by user; used not in accordance
with any product warnings, precautions or instructions
13
4
5
6
2
%00B%%5(15 11/28/2005, 12:05 PM2

EN
3
1
2
3
5
4
BACK VIEW – PARENT UNIT
1. AC adapter hole
2. Table stand
3. RESET: Resets the unit
4. Neck-string holes
5. °C / °F: Selects temperature unit
LCD – PARENT UNIT
1. Connection signal icon
2. Low battery on baby unit
3. Battery status on parent unit
4. Voice activation sensitivity level
5. Alarm icon
6. Feeding timer icon
7. Indoor temperature
8. Clock / alarm / timer area
9. Volume level
FRONT VIEW – BABY UNIT
1. Microphone
2. :Turns unit ON / OFF; searches for channel
3. :Turns nightlight ON / OFF
4. Nightlight
5. LED indicator : Flashes during data transmission
%00B%%5(15 11/28/2005, 12:05 PM3

EN
4
BACK VIEW – BABY UNIT
1. AC adapter hole
2. Table stand
3. Battery compartment
4. RESET: Resets the unit
GETTING STARTED
POWER
BABY UNIT
We recommend you use the adapter for continuous use.
However, the unit can be powered by alkaline batteries.
Insert batteries (3 x AAA / UM-4 1.5V) matching the polarity
(+ and -).
PARENT UNIT
The unit uses a rechargeable battery pack (3 x AAA / UM-4
Ni-MH). Insert the rechargeable battery by putting the piece
at the end of the wire into the indentation at the bottom right
of the battery compartment:
%00B%%5(15 11/28/2005, 12:05 PM4

EN
5
To recharge the batteries connect the adapter.
The battery icon will animate to show it is charging.
appears with no animation when the battery is fully
recharged. Charge the batteries for 12 hours before 1st use
and press RESET. After the first charge, you only need to
charge the unit until the battery icon shows it is full.
LOW BATTERY
Flashes when the baby unit battery is low and
sounds warning beeps every minute until the
battery is dead
Flashes when the parent unit battery is low
and sounds warning beeps every minute until
the battery is dead
NOTE Press RESET after each battery change.
NECK STRING – PARENT UNIT
TURN ON / OFF
To turn a unit ON or OFF, press and hold .
SET UP
1. Insert batteries / adapters (as shown in the Power section).
2. Turn the baby unit ON and then the parent unit.
3. Place the 2 units close to each other for 5 seconds. This
allows the units to recognize each other as family.
4. Position the units no more than 300 meters (984 feet)
from each other.
For best results:
•Place the units away from electrical or mechanical objects,
direct sunlight and moisture.
•Do not exceed the 300-meter (984-foot) transmission
range of the units.
•Minimize obstructions such as doors, walls and furniture
as this will decrease the transmission range between the
2 units.
%00B%%5(15 11/28/2005, 12:05 PM5

EN
6
CONNECTION SIGNAL STATUS
The connection icon will show you the status of the
signal between the units.
LOST-LINK ALARM
When the parent unit cannot receive data from the baby unit
(due to interference or out-of-range distance), an alarm will
sound and will flash. The temperature reading will display
as “- - -”. The alarm sound will stop only when the connection
between the two units is linked again.
TEMPERATURE DISPLAY
The baby unit measures the surrounding temperature. If
“- - -” is displayed, the baby unit cannot transmit the
temperature reading.
Slide the °C / °Fswitch in the parent unit battery compartment
to your desired setting.
CLOCK / ALARM
Press to toggle between the clock and alarm display.
You may need to experiment with various locations to get
the best reception.
SELECT CHANNELS – BABY UNIT
You can change the channel (if there is interference or problem
linking the 2 units) by pressing on the baby unit.
NIGHTLIGHT – BABY UNIT
Press to turn the nightlight ON / OFF.
CHANGE VOLUME
To change the volume (0-5), press + / - on the parent unit. 0
= mute and 5 = high volume.
NOTE All alarm sounds are independent of the volume level.
NOTE You may hear a high pitched noise if the parent unit
is placed too closely to the baby unit. The noise will stop
sounding once the units are moved away from one another.
SOUND LIGHT INDICATORS
The sound light indicators on the parent unit can alert you
visually to a baby’s sound. The louder the sound received
from the baby unit, the more lights will be on.
LOST LINK NORMAL SIGNAL
(The graphics are animated
when the 2 units are linked.)
%00B%%5(15 11/28/2005, 12:05 PM6

EN
7
SET CLOCK / VOICE ACTIVATION SENSITIVITY LEVEL
1. Press and hold to enter the setting mode.
2. Press + or - to change the setting. To scroll through the
numbers quickly, press and hold + or -.
3. Press to confirm a setting and move on to the
next one. The setting sequence is: 12 / 24-hour format,
hour, minute and voice activation sensitivity level (0-3).
NOTE The voice activation sensitivity feature increases /
decreases the level of sound the parent unit emits. When
set to 0, all sounds, regardless of level, can be heard on the
parent unit.
SET ALARM
1. Press to view alarm display.
2. Press + or - to select alarm ON.
3. Press and hold to enter the setting mode.
4. Press + or - to change the setting. To scroll through the
numbers quickly, press and hold + or -.
5. Press to confirm a setting and move on to the
next one. The setting sequence is: hours and minutes.
To enable or disable the alarm:
Press + or - when in the alarm display. “- -” will display if the
alarm is OFF.
To stop the alarm sound:
Press any key except .
FEEDING TIMER
The feeding timer is useful to help you develop a feeding
routine for your baby.
To set the timer:
1. Press to view the feeding timer display.
2. Press and hold to enter the setting mode.
3. Press + or - to increase or decrease the time in 30 min
intervals. To scroll through the numbers quickly, press
and hold + or -.
4. Press to confirm.
Timer functions:
•To start / stop / retrieve last setting press .
•To reset the timer, press and hold or press RESET.
•To view the clock while the timer is running, press MODE.
will flash when the timer is in use.
•To turn OFF the 2-minute alarm that sounds when the
timer has reached 0, press any key except .
NOTE If no key is pressed after 1 minute when you are in
the timer display mode, it will go back to clock display mode.
BACKLIGHT
Press to turn the parent unit backlight ON for 8 seconds.
LEVEL SENSITIVITY
0Maximum
3High
2Medium
1Low
%00B%%5(15 11/28/2005, 12:05 PM7

EN
8
CAUTION Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
Batteries are supplied by Rickbery, Ni-MH, 3.6V, 700mAh,
3 pcs AAA per pack with wire.
SPECIFICATIONS
TYPE DESCRIPTION
Clock time 12 or 24-hour format
Alarm 2 minutes
Feeding timer 30 minutes to 24 hrs
RF frequency 2.4GHz
Transmission range 300 meters (984 feet) open area
Temp. measuring -10°C to 50°C
range (14°F to 122°F)
Operating range 0°C to 50°C (32°F to 122°F)
Temp. unit °C / °F
POWER
Baby unit 6VDC 200mA AC adapter /
3 x 1.5V UM-4 / AAA batteries
Parent unit 6VDC 200mA AC adapter /
3.6V Ni-MH rechargeable
battery pack
MEASUREMENTS
Dimensions – both units 96 x 63 x 40 mm
(H x W x D) (3.8 x 2.5 x 1.6 inches)
Weight – parent unit 68 g (2.4 ounces) without battery
Weight – baby unit 62 g (2.2 ounces) without battery
RESET
To return either unit to the default settings, insert a blunt
stylus into the RESET hole in the battery compartment.
PRECAUTIONS
This unit is engineered to give you years of satisfactory service
if you handle it carefully. Here are a few precautions:
•Do not immerse the unit in water.
•Do not cover the ventilation holes. Make sure items that
are nearby such as newspapers, tablecloths, curtains,
blankets, beddings etc cannot accidentally cover the
ventilation holes.
•Use a soft, slightly moistened cloth to clean the unit. Do
not use abrasive or corrosive cleaning agents, as these
may cause damage.
•Do not subject the product to excessive force, shock,
dust, temperature changes, humidity and direct sunlight
for extended periods.
•Do not tamper with the internal components. Doing so
will terminate the product warranty and may cause
damage. The unit contains no user-serviceable parts.
•Remove the batteries when storing the product for a long
time. Do not mix new and old batteries.
NOTE The technical specifications for this product and the
contents of the user guide are subject to change without
notice.
CAUTION To reduce the risk of electric shock, do not
expose this appliance to rain or moisture.
%00B%%5(15 11/28/2005, 12:05 PM8

EN
9
ABOUT OREGON SCIENTIFIC
Visit our website (www.oregonscientific.com) to learn more
about Oregon Scientific products such as digital cameras;
MP3 players; children’s electronic learning products and
games; projection clocks; health and fitness gear; weather
stations; and digital and conference phones. The website
alsoincludes contact information for our Customer
Caredepartment in case you need to reach us, as well as
frequently asked questions and customer downloads.
We hope you will find all the information you need on our website,
however if you’re in the US and would like to contact the Oregon
Scientific Customer Care department directly, please visit:
www2.oregonscientific.com/service/support
OR Call 1-800-853-8883.
For international inquiries, please visit: www2.
oregonscientific.com/about/international
EU-DECLARATION OF CONFORMITY
Hereby, Oregon Scientific, declares that this Baby Monitor
with Indoor Temperature BBM211 / BBR211 is in compliance
with the essential requirements and other relevant provisions
of Directive 1999/5/EC. A copy of the signed and dated
Declaration of Conformity is available on request via our
Oregon Scientific Customer Service.
FCC STATEMENT
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) This
device must accept any interference received, including
interference that may cause undesired operation.
WARNING Changes or modifications not expressly
approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
NOTE This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
COUNTRIES RTTE APPROVED COMPLIED
All EU countries, Switzerland
and Norway
CH
N
%00B%%5(15 11/28/2005, 12:05 PM9

EN
10
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
•Consult the dealer or an experienced radio / TV technician
for help.
DECLARATION OF CONFORMITY
The following information is not to be used as contact for
support or sales. Please call our customer service number
(listed on our website at www.oregonscientific.com), or on
the warranty card for this product) for all inquiries instead.
We
Name : Oregon Scientific, Inc.
Address : 19861 SW 95th Ave., Tualatin, Oregon
97062 USA
Telephone No. : 1-800-853-8883
declare that the product
Product No. : BBM211 / BBR211
Product Name : Baby Monitor with Indoor Temperature
Manufacturer : IDT Technology Limited
Address: Block C, 9/F, Kaiser Estate,
Phase 1,41 Man Yue St.,
Hung Hom, Kowloon,
Hong Kong
is in conformity with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: 1) This device may not
cause harmful interference. 2) This device must accept any
interference received, including interference that may cause
undesired operation.
%00B%%5(15 11/28/2005, 12:05 PM10

EN
11
Baby Monitor with Indoor Temperature
Model: BBM211 / BBR211
USER MANUAL
%00B%%5(15 11/28/2005, 12:05 PM11

EN
12
©2005 Oregon Scientific. All rights reserved.
086L004171-018
%00B%%5(15 11/28/2005, 12:05 PM12
