ORFELD ST69A User manual

INSTRUCTION MANUAL
Sandwich maker
ST69A
IMPORTANT: Read Before Using
[e-mail]
www.orfeldtech.com

2
CONTENTS
SPECIFICATIONS---------------------------------------------------------- 3
SAFETY PRECAUTIONS-------------------------------------------------4
IMPORTANT INFORMATION------------------------------------------- 6
NAME OF EACH PART--------------------------------------------------- 6
INSTALLATION AND DISASSEMBLY OF PRODUCT------------7
METHOD OF USE---------------------------------------------------------- 7
METHOD OF CLEANING-------------------------------------------------8

3
SPECIFICATIONS
MODEL
ST69A
Voltage
120V~60HZ
Power
750W
Size
9.8 X 9.3 X 3.5 inches
Plate Size
9.3 X 5.3 X 0.4 inches
Net Weight
1.8KG
Plate Weight
0.16KG
Power Cord Length
0.8m
Name and Content of Harmful Substances in Product
Part Name
Harmful
Substances
Pb Hg Cd Cr(M) PB
B
PBD
E
Plastic parts
O
O O O O O
Metal fittings
O
O O O O O
Power cord,
internal
O O O O O O
Electrical circuit
O O O O O O
Heating
component
O O O O O O
This form has been formulated in accordance with S J/T 11364.
O: indicates that the content of the harmful substance in all homogeneous
materials of the component is below the limit requirements specified in GB/T
26572.
X: indicates that the content of the harmful substance in at least one homogeneous
material of the component exceeds the limit specified in GB/T 26572.
Thank you very much for purchasing ORFELD products.
To ensure the correct and safe use of this product,please read this instruction
manual carefully.
Please read the "Safety Precautions" (page 4-6) and "Important
Information" carefully (page 6) before using.
This product is only for home use.
Please keep the warranty certificate with this instruction manual for future use.
ORFELD will not take any responsibility for improper use or failure to follow
relevant instructions of this product.

4
Warning: Events that may lead to serious injury or death.
Attention: Personal injury or damage to property may occur.
Means prohibited matters.
Means matters that must be implemented.
SAFETY PRECAUTIONS
In order to reduce the risk of personal injury, electric shock and fire. Please be sure
to observe the following.
The harm caused by wrong operation and the degree of loss shall be
distinguished and explained.
Symbol classification and description are as follows.
Warning
In order to avoid the risk of electric
shock, fire, burns, scalds or injuries.

Do not let babies or children play
with packaging materials. (May
cause suffocation.)

Do not disassemble, repair or
modify this product. Please consult
ORFELD Service Center for repair
matters.
 Please do not damage the power
cord or plug. It is strictly prohibited
to: process, touch or place it near
the heating assembly, forcibly bend,
twist, pull, hang or pull the power
cord from sharp edges, place heavy
objects on the power cord, bundle
the power cord and use the power
cord to pull the product.

Do not use this product when the
power cord or plug is damaged or
the socket is loose.

Do not plug and unplug the power
plug with wet hands.

Please do not soak this product in
water or let it be splashed by water
and other liquids.
 Ingredients may burn during
baking, and please do not use this
product near or under flammable
materials such as curtains.
Warning
Please do not pour cooking oil on
the baking tray. When necessary,
please dip a brush in a proper
amount of cooking oil and gently
brush it on the baking tray.
 Please do not insert anything into
the gap.

This product will emit water vapor
from the gap of the machine body
during use. Please do not touch or
bring your face close to this
product.

During use, please do not block
the machine body gap or cover the
machine body.
power cord
power plug

5

This product is not intended to be
used by children or people with
physical, sensory or mental
defects or people lacking
experience and knowledge,
unless there are people
responsible for their safety to
supervise and guide them in
relation to the use of the
product.Children should be taken
care of to ensure that they do not
play with this product.
Please be sure to keep children
away from this product and its
power cord.
Please be sure that the voltage
indicated on the label of this
product is consistent with the
local power supply voltage. To
avoid overheating of the current,
inserting other equipment into the
same power socket should also
be avoided. if multiple power
plugs are connected, the total
power does not exceed the rated
power of the power outlet should
be ensured.
The power plug shall be inserted
into the socket fully.
Regularly clean dust from the
power plug. Remove the power
plug first and wipe it with a dry
cloth.
If this product operates
abnormally, please stop using this
product immediately and unplug
the power plug. Examples of
abnormalities or malfunctions:
The power plug and power cord
are abnormally hot.
1. The power cord is damaged or the
power supply of this product is faulty.
2. The machine body is deformed, with
obvious damage or abnormal
heating.
3. There are abnormal sounds during
use.
4. There is an unpleasant smell during
use.
5. Other abnormalities or malfunctions
occur.
-Please consult ORFELD Service Center
for inspection and repair.
Attention
In order to avoid the risk of electric
shock, fire, smoke, burns, scalds,
injuries or property damage.
Please do not use this product in the
following places.
1. Uneven surfaces, above refrigerators
and other electrical appliances, on
carpets, non-heat-resistant surfaces or
tablecloths.
2. Where it may have watersplash or near
a heat source.
3. Near a wall or furniture. Please place
this product on a stable, dry, clean, flat
and heat-resistant workbench.
Please do not place anything above
or below the machine body.
Please do not use when the baking
tray is not properly installed.
Under no circumstances it is
allowed to fry and bake ingredient
with the upper cover open.
In addition to the original parts of
this product, please do not use other
parts to replace any parts on this
product.
Please do not touch hot surfaces
such as the machine body, upper
cover, baking tray release button and
baking tray when using this product
or just after using it. The contactable
parts of this product may become
hot during use. Please be careful
about the waste heat after use.
Please wait for it to cool before
processing.
Please do not use external timers,
etc. This product cannot be operated in
the mode of external timer or external
independent remote control system.
Do not leave when using this
product, please turn off the power
when you leave.

6
Baking tray
release button
n
Handle
Before moving or cleaning this product, please remove the power plug to cool it
down.
When not using this product, please remove the power plug.
Be sure to hold the power plug when unplugging it. Pull the power cord hard is
prohibited.
IMPORTANT INFORMATION
Please do not use this product for other purposes than those shown in this manual.
Do not let this product fall to avoid damage.
Please do not use metal objects to touch the baking tray, such as knives and forks or
similar utensils, so as not to damage the baking tray.
When storing this product, the handle must be placed upward.
To avoid overflow of ingredients or poor baking effect, please make according to the
portions shown in the recipe.
This symbol means: the surface of the product is high in temperature, please be
careful when touching it.
NAME OF EACH PART
Baking tray
release button
Lock catch Upper cover
Heating tube
Sandwich baking tray
Temperature indicator
Power Indicator
Body
Barbecue tray
Waffle baking tray
Bakingtray
Power cord
Power plug

7
Attention: Please make sure the release button has cooled before
removing the baking tray.
INSTALLATION AND DISASSEMBLY OF PRODUCT
INSTALLATION
Insert the upper and lower baking trays into the small holes respectively, and
press to insert the baking trays into the grooves, until a"click" sound is heard.
DISASSEMBLY
After pulling the baking tray release button outward, the baking tray can be
unlocked and taken out. (When unloading the upper baking tray, please
connect the baking tray by hand to prevent the baking tray from falling.)
METHOD OF USE
Prepare materials.
Prepare the materials needed for
baking.
Open the upper cover.
Pull the lock catch on the handle
first and lift the upper cover
upward.

8
Install the baking tray.
Install the baking tray in the
direction of inserting the baking
tray. (page 7)
Preheat
Make sure there is no food in the
machine, cover the upper cover, then
plug in the power supply, the power
indicator light is on (red), and the
preheating is completed when the
temperature indicator light is on
(green), and it is ready for the next
step.
At the beginning of use, it will releas
e
odor, which is a normal phenomeno
n
and is not a fault, which will graduall
y
disappear during use.
Put ingredients inside
Open the upper cover, gently brush a
layer of edible oil on the baking tray
with a brush if necessary※, then add
the prepared ingredients, cover the
upper cover and fasten the lock catch.
※To prevent oil dripping, causing
cleaning troubles,please do not dip
too much edible oil.
After the ingredients are put in, the
temperature indicator may go out and
then light up again due to temperature
change, which is not a fault.
If it is difficult to fasten the lock catch,
it may be that too much stuffing is put
in, too thick, or the bread is too thick.
Do not fasten the lock catch with force.
Start baking
Bake according to the time required for
each recipe. The side or top of the
machine body may touch the hot air,
please pay attention carefully.
After baking, unplug the power plug.
If continuous baking is needed, please
wait for the temperature indicator to be
on before repeating steps 5-7.
METHOD OF CLEANING
Please unplug the power plug before
cleaning, and make sure the product has
completely cooled before taking out the
baking tray.
Attention
Do not use gasoline, alcohol, bleach,
polishing powder, metal brush or nylon
brush, etc., otherwise the surface of the
product will be damaged.
Please do not use metal objects, which
may scratch and damage the non-stick
coating of the baking tray.
Do not use the dishwasher for cleaning.

9
Wipe with a wrung dry soft cloth
Wipe with a wrung dry soft cloth
Wipe with a wrung dry soft cloth

10
Facebook
Website
Instagram
Twitter
Shenzhen Xiaosi Technology Co., Ltd.
ADD: 5A17,Bldg B,WePark,Road 1,China South City,Pinghu,Longgang,
Shenzhen,China
MADE IN CHINA
