Organomation Associates MICROVAP 11803 User manual

MICROVAP®
Nitrogen Evaporation System
Models
INSTRUCTION MANUAL
ORGANOMATION ASSOCIATES INC.
266 RIVER ROAD WEST
BERLIN, MA 01503
U. S. A.
Tel: [phone] Fax: [phone]
11803 ( Triple Plate )
MICROVAP®
Nitrogen Evaporation System
Models
INSTRUCTION MANUAL

1
4
6
8
7
1
13
15
8
18
14
15
19
23
24
28
8
28
29
30
TABLE OF CONTENTSMICROVAP®
Introduction
Instrument Items Shipped ………………………….
Instrument Description …………………………….
Instrument Part Identification ……………………...
Safety Considerations - Read before operation …………
Installation
Location …………………………………………….
Bath Setup …………………………………………..
Instrument Setup ……………………………………
Operation
Instrument Control Identification …………………..
Planning and Preparation …………………………...
Bath Operation ……………………………………...
Instrument Operation ……………………………….
Maintenance and Cleaning ………………………………
Trouble Shooting …………………………………………
Technical Information …………………………………...
Parts List ……………………………………………
Service and Returns ………………………………...
Shipping - Claims for damage or shortage …………
Specifications ……………………………………….
Product designs are subject to change without notice
Printed in U. S. A.

V18.1 - 4 -
INTRODUCTIONMICROVAP®
Items Shipped
Carefully check the contents of all cartons received for damage which may have
occurred in transit. Retain all cartons and packaging materials until all components have
been checked against the packing slip, the component list below, and the equipment has been
assembled and tested. Contact Organomation immediately if any damage or discrepancies
are found.
Your shipment should contain one or more of the instruments shown below. Option codes
are listed on the next page.
Instrument Size
Triple Plate N-EVAP Nitrogen evaporation system
Flowmeter Assembly with Mounting Bracket & Connector Tube
0-100 LPM for triple plate MICROVAP
19ga x 2” Stainless Steel Needles, blunt end
24 dz for 3 Position MICROVAP (pre-installed)
OA-HEAT heater 540W, for triple plate MICROVAP
ID #
11803
NA1804
NA1807
B1803
MICROVAP and OA-HEAT are Registered Trademarks of Organomation

V18.1 - 5 -
INTRODUCTIONMICROVAP®
Option Codes and additional items shipped
The following list contains option codes and items which may have been shipped in
conjunction with the standard parts shown on the previous page. Please check your packing
list and order information carefully to determine if these items are included in your shipment.
For a complete list of available accessories, please refer to the Accessories Section.
Your shipment may contain the following optional items:
Description
OA-HEAT heating unit has been modified for the Type-Z Purge
Intrinsically Safe bath option (passive operation). Additional parts
include: differential pressure gauge, mounting bracket, and tubing.
OA-HEAT heating unit is wired as a 240 Volt unit.
Option
-Z
-2
