ORIGO AF7024F User manual

使用說明書
Instruction Manual
AF7024F
使用本產品前，請先細閱使用說明，並請妥善保存以便將來翻閱。
本說明書可於本公司網站下載 www.origin.hk。
Read all instructions carefully before using the appliance, and keep this
instruction for furture reference when necessary.
This instruction manual can be acquired at www.origin.hk.
*
**
*
**
Healthy Air Fryer Oven
健康氣炸烤爐

Important Safety Information
重要安全提示
2
切勿於水源或易燃物品附近使用。
DO NOT OPERATE this appliance near
water sources or flammable liquids.
切勿於高溫表面上或附近使用本產品。
DO NOT OPERATE this appliance on or
near any hot surface.
為防止損害電源線，請勿把電源線掛
放在檯邊上或接觸發熱的物體。
Do not hang the power cord on the edge
of table or touch the surface with high
temperature in order to avoid damage to
the power cord.
在氣炸過程中，熱蒸汽通過排氣口釋
放
，請 將手和臉與排氣口保持安全距
離。從設備上取下配件時，還應注意
防止熱蒸汽溢出。
During hot air frying, hot steam is
released through the air outlet openings,
keep your hands and face at a safe
distance from the steam and from the air
outlet. Also be careful of hot steam
overflow when you remove the
accessories from the appliance.
在本機運行期間，請勿覆蓋進氣口和
排氣口。請勿讓本機空燒超過10分鐘
，以免造成故障或火災。
Do not cover the air inlet and air outlet
openings while the appliance is
operating. Do not let the appliance empty
burn for more than 10 minutes.
請勿將異物如針、鐵絲等金屬物體黏
在電源插頭上，以免造成觸電、短路
或火災。
Do not stick foreign objects such as
needles, iron wires and other metal
objects to the power plug to avoid
electric shock, short circuit or fire.
所有未開封的密封包裝食品(例如:罐頭
)，不可使用本產品直接進行加熱，避
免發生危險。
To avoid any danger of explosion,
please do not heat the canned goods
before remove their cover.
請勿將產品放在桌布或窗簾等可燃物
料上或附近上使用。使用時不應靠近
牆角，其周圍10cm內不應放置其他易
燃物品，免溫度過高引起爆裂、變形
、變色等。
In order to prevent any accident, do not
place the appliance on or near
combustible materials such as a
tablecloth or curtains. Do not operate
this appliance near water sources or
flammable liquids within 10cm.
請勿在炸籃、網籃、烤網及盛油盤中
注油，否則可能引起火災。
Do not fill the frying basket, mesh
basket, wire rack and grease tray with oil
as this may cause a fire hazard.
在操作或清潔設備之前，讓氣炸烤爐
冷卻約30分鐘。
Let the Air Fryer Oven cool down for
approximately 30 minutes before handle
or clean it.
使用中的玻璃門表面會產生高溫。
The glass window surfacemay get hot
when the oven operating.
Healthy Air Fryer Oven
本產品含有可回收材料，不可把本
產品作為未分類廢物。請聯繫當地
就近指定回收點。
This product contains recyclable
materials. Do not dispose this
product as unsorted municipal
waste. Please contact your local
municipality for the nearest collection.
健康氣炸烤爐

Main Parts
各部名稱 Healthy Air Fryer Oven
健康氣炸烤爐
3
圖片只供參考 ， 一切以實物為準
調溫旋鈕
Temperature
Knob
定時旋鈕
Timer Knob
烤盤/盛油盤
Grill/Grease Tray
插頭
Plug
玻璃門
Glass Door
燒烤叉把手
Split Handle
旋轉燒烤叉
Turnspit Mount
旋轉網籃
Rotating Mesh Basket
網籃
Mesh Basket
玻璃門把手
Glass Door Handle
旋轉軸
功能旋鈕
Function
Knob
The picture is for reference only,
everything in kind shall prevail.
Rotisserie Shaft

Operations
使用方法 Healthy Air Fryer Oven
健康氣炸烤爐
4
使用前的準備:
1. 取出所有包裝物料。
2. 用熱水，一些溫和清潔液和非研磨性海綿徹底清潔轉籃和其他配件。
3. 用濕布擦拭氣炸烤爐的內部和外部。
注意: 這是一種可在熱空氣上工作的氣炸烤爐，請勿在爐中注油或炸油脂。
4. 將氣炸烤爐擺放於穩固的平面上。
5. 打開玻璃門，將盛油盤放在氣炸烤爐內的下方。
6. 將食材放在所需烹飪配件裡，然後將所需烹飪配件正確放入氣炸烤爐內。
7. 將定時旋鈕調至 "OFF"，再將插頭插入交流電壓220-240V ~ 50/60Hz的獨立插
座，電源指示燈亮起，氣炸烤爐已可使用。
PREPARATION BEFORE USE:
1. Remove all packaging material.
2. Thoroughly clean the rotating mesh basket and other accessories with hot
water, mild cleaner and a non-abrasive sponge.
3. Wipe the inside and outside of the appliance with a moist cloth.
Notice: This is an Air Fryer Oven that works on hot air. Do not fill the Oven
with oil or frying fat.
4. Place the Air Fryer Oven on a stable and flat surface.
5. Place the grease tray at the bottom of the Air Fryer Oven.
6. Put the ingredients in the required cooking accessories, and then put the
required cooking accessories into the Air Fryer Oven.
7. Set the "Timer" knob to "OFF" position, then plug the power plug into an
220-240V~ 50/60Hz electrical outlet, power indicator light on, the Air
Fryer Oven is ready for use.
注意:
- 切勿將氣炸烤爐放在非耐熱表面上。
- 切勿在氣炸烤爐中注油或任何其他液體。
- 切勿在氣炸烤爐頂部放置任何物品，這會擾亂氣流並影響氣炸的結果。
- 切勿在沒有配件的情況下使用氣炸烤爐。
- 本機只可使用附設提供的配件進行煮食。
- 配件只適用於本機使用。
Notice:
- Never place the Air Fryer Oven on non-heat-resistant surfaces.
- Never fill the Oven with oil or any other liquid.
- Never place anything on top of the Air Fryer Oven. This disrupts the airflow
and affects the hot air frying result.

Operations
使用方法 Healthy Air Fryer Oven
健康氣炸烤爐
5
- Never use the Air Fryer Oven without the accessories in it.
- This Air Fryer Oven can only use the supplied accessories for cooking.
- The accessories is only suitable for this Air Fryer Oven.
1. 旋轉"功能"旋鈕選擇相應的烹調模式(氣炸/烘焙/燒烤/薄餅/乾果)。
1. Set the "Function" knob to select the corresponding cooking mode (air fry/
toaster/grill/pizza/dry fruit).
2. 將"溫度"旋鈕從"min"設至到所需溫度:80℃-230℃。
2. Set the "Temperature" knob to the desired temperature setting from 80℃to
230℃.
3. 旋轉"定時"旋鈕選擇合適的操作時間(包括5分鐘的預熱時間)，此時電源指示燈亮起。
*注意: 在加熱過程中，電源指示燈會時亮時滅，此乃正常現象。
3. Set the "Timer" knob at required cooking time (including 5 minutes preheat
time), the power indicator will light on.
*Note: During heating process, the indicator light will be on or off automatically.
4. 如食物在設定時間前已完成，可自行把"定時"旋鈕回轉至"0"。
4. If cooking is completed before the end of the timer, please turn the "Timer"
knob to position "0" manually.
注意: 如果烹調時間少於20分鐘，請將"定時"旋鈕設至40分鐘或以上，然後再設回所
需時間。
Note: If the cooking time is less than 20 minutes, please set the "Timer" knob
to 40 minutes or more and then turn it back to the required time.
5. 烹飪完成後，將會發出"叮"聲。
5. When the cooking is complete, it will have a "Ding" sounds.
6. 完成後，打開玻璃門，將配件從氣炸烤爐中拉出並將其放在耐熱表面上，小心地將
食物從配件中倒到碟上。
6. After finished, open the glass door, pull the accessories out of the Air Fryer
Oven and place it on a heat-resistant surface, carefully pour the food out of
the accessories onto plate.
烹調/COOKING
圖片只供參考 ， 一切以實物為準
The picture is for reference only,
everything in kindshall prevail.
電源指示燈
Power
Indicator
溫度旋鈕
Temperature Knob 定時旋鈕 Timer Knob
功能旋鈕
Function Knob

Operations
使用方法 Healthy Air Fryer Oven
健康氣炸烤爐
6
7. 使用後，請確保"定時"旋鈕處於"0"位置並拔除電源插頭。
7. After use, please make sure that the "Timer" knob is at the "0" position and
unplug the power plug.
旋轉式灸烤 / Grilling with the turnspit
1. 這個功能是最適合用於烤雞及其他肉類等食物。
1. This function is ideal for grill chicken and other type of meats.
2. 先用旋轉燒烤叉把食物固定(如欲得到更佳效果，可用廚繩把食物扎緊)。
2. Place the meat on the spit (for the best result, tie the meat by kitchen
string).
3. 把盛油盤放到最低位置及把旋轉燒烤叉固定在氣炸烤爐中間位置。
3. Place the grease tray to the bottom and the push the turnspit mount
inside the Air Fryer Oven.
4. 旋轉"功能"旋鈕選擇烹調模式(燒烤)。
4. Set the "Function" knob to select the cooking mode (grill).
5. 將"溫度"旋鈕從"min"設至到所需溫度:80℃-230℃。
5. Set the "Temperature" knob to the desired temperature setting from 80℃to
230℃.
6. 旋轉"定時"旋鈕選擇合適的操作時間(包括5分鐘的預熱時間)，此時電源指示燈亮
起。
6. Set the "Timer" knob at required cooking time (including 5 minutes
preheat time), the power indicator will light on.
7. 如食物在設定時間前已完成，可自行把"定時"旋鈕回轉至"0"。
7. If cooking is completed before the end of the timer, please turn the
"Timer" knob to position "0" manually.
8. 完成後，打開玻璃門，用燒烤叉把手將旋轉燒烤叉從氣炸烤爐中拉出並將其
放在耐熱表面上，小心地將食物從配件中倒到碟上。
8. After finished, open the glass door, use the split handle to pull the
turnspit mount out of the Air Fryer Oven and place it on a heat-resistant
surface, carefully pour the food out of the accessories onto plate.
烤盤 / Grill
1. 這個功能是最適合用於薄餅和曲奇等食物。
1. This function is ideal for pizza and cookie, etc.
2. 把烤盤放到最低位置。
2. Place the grill at the bottom of the Air Fryer Oven.
3. 旋轉"功能"旋鈕選擇烹調模式(烘焙/薄餅)。
3. Set the "Function"knob to select the cooking mode (toaster/pizza).

Operations
使用方法 Healthy Air Fryer Oven
健康氣炸烤爐
7
網籃 / Air Frying With Mesh Basket
1. 這個功能是最適合用於牛扒和乾果等食物。
1. This function is ideal for steak and dry fruit, etc.
2. 把網籃放進氣炸烤爐的最高位置，再把盛油盤放到最低位置。
2. Insert the mesh basket in the Air Fryer Oven, then place the grease
tray at the bottom of the Air Fryer Oven.
3. 旋轉"功能"旋鈕選擇烹調模式(氣炸/乾果)。
3. Set the "Function"knob to select the cooking mode (air fry / dry fruit).
4. 將"溫度"旋鈕從"min"設至到所需溫度:80℃-230℃。
4. Set the "Temperature"knob to the desired temperature setting from 80℃to
230℃.
5. 旋轉"定時"旋鈕選擇合適的操作時間(包括5分鐘的預熱時間)，此時電源指示燈亮
起。
5. Set the "Timer"knob at required cooking time (including 5 minutes
preheat time), the power indicator will light on.
6. 如食物在設定時間前已完成，可自行把"定時"旋鈕回轉至"0"。
6. If cooking is completed before the end of the timer, please turn the
"Timer" knob to position "0" manually.
7. 完成後，打開玻璃門，用耐熱手套將網籃從氣炸烤爐中拉出並將其放在耐
熱表面上，小心地將食物從配件中倒到碟上。
7. After finished, open the glass door, use the heat-resistant gloves to pull
the mesh basket out of the Air Fryer Oven and place it on a heat-resistant
surface, carefully pour the food out of the accessories onto plate.
4. 將"溫度"旋鈕從"min"設至到所需溫度:80℃-230℃。
4. Set the "Temperature"knob to the desired temperature setting from 80℃to
230℃.
5. 旋轉"定時"旋鈕選擇合適的操作時間(包括5分鐘的預熱時間)，此時電源指示燈亮
起。
5. Set the "Timer"knob at required cooking time (including 5 minutes
preheat time), the power indicator will light on.
6. 如食物在設定時間前已完成，可自行把"定時"旋鈕回轉至"0"。
6. If cooking is completed before the end of the timer, please turn the
"Timer" knob to position "0" manually.
7. 完成後，打開玻璃門，用耐熱手套將烤盤從氣炸烤爐中拉出並將其放在耐
熱表面上，小心地將食物從配件中倒到碟上。
7. After finished, open the glass door, use the heat-resistant gloves to pull
the grill out of the Air Fryer Oven and place it on a heat-resistant
surface, carefully pour the food out of the accessories onto plate.

Operations
使用方法 Healthy Air Fryer Oven
健康氣炸烤爐
8
旋轉網籃 / Air Frying With Rotating Mesh Basket
注意: 在烹飪過程中，旋轉網籃和其他配件會變得很熱。當將其卸下以檢查進度時，
請確保附近有矮腳架或耐熱表面將其放下。
切勿將旋轉網籃直接放在檯面或桌上。
Notice: During the cooking process, the Rotating Mesh Basket and other
accessories will become very hot. When you remove it to check
on the progress, make sure you have a trivet or a heat resistant
surface nearby to set it down on.
NEVER place the Rotating Mesh Basket directly on a counter top or
table.
1. 這個功能是最適合用於炸薯條及炸雞塊等食物。
1. This function is ideal for fries and chicken nuggets,etc.
2. 打開旋轉網籃的鎖扣，然後放入食材再將其鎖緊。
2. Open the lock of the rotating mesh basket and put in the
ingredients and then lock it tightly.
3. 然後用旋轉軸插入旋轉網籃連接槽把旋轉網籃固定。
3. Insert the rotisserie shaft into the rotating mesh basket's
connection slot to fix the rotating mesh basket
4. 把盛油盤放到最低位置，再用燒烤叉把手把旋轉網籃放進氣炸烤爐。
4. Place the grease tray at the bottom of the Air Fryer Oven, then use the
split handle to insert the rotating mesh basket in the Air Fryer Oven.
5. 旋轉"功能"旋鈕選擇烹調模式(氣炸)。
5. Set the "Function"knob to select the cooking mode (air fry).
6. 將"溫度旋鈕從"min"設至到所需溫度:80℃-230℃。
6. Set the "Temperature"knob to the desired temperature setting from 80℃to
230℃.
7. 旋轉"定時"旋鈕選擇合適的操作時間(包括5分鐘的預熱時間)，此時電源指示燈亮起。
7. Set the "Timer"knob at required cooking time (including 5 minutes
preheat time), the power indicator will light on.
8. 如食物在設定時間前已完成，可自行把"定時"旋鈕回轉至"0"。
8. If cooking is completed before the end of the timer, please turn the
"Timer"knob to position "0" manually.
9. 完成後，打開玻璃門，用燒烤叉把手將旋轉網籃從氣炸烤爐中拉出並將其
放在耐熱表面上，打開旋轉網籃的鎖扣，小心地將食物從配件中倒到碟上。
9. After finished, open the glass door, use the split handle to pull the
rotating mesh basket out of the Air Fryer Oven and place it on a
heat-resistant surface, open the lock of the rotating mesh basket then
carefully pour the food out of the accessories onto plate.

Cooking Time & Temperature
烘烤時間及溫度 Healthy Air Fryer Oven
健康氣炸烤爐
9
烹調時間及溫度需因應食物的重量及個人口味而作出調整，以上附表只供參考。
The cooking time and temperature are base on the quantity of food and cooking request.
The above table is only for your reference.
食品類別
Food 烹調時間(分鐘)
Timer(Mins)
o
烹調溫度( C)
Temperature( C)
o
18-25
18-25
30
230
230
230
功能旋鈕
Function Knob
氣炸/Air Fry
氣炸/Air Fry
氣炸/Air Fry
18
200
氣炸/Air Fry
12-15200烘焙/Toaster
30180烘焙/Toaster
18
160
烘焙/Toaster
30
180
燒烤/Grill
420
80
乾果/Dry Fruit
10-12
200
薄餅/Pizza
薯條
French Fries
雞翼
Chicken wings
豬排
Pork Chop
冷凍雞塊
Forzen Chicken
蛋糕
Cake
蛋撻
Egg Tart
曲奇
Cookie
烤雞
Rotisserie Chicken
乾果
Dehydrated Fruit
薄餅
Pizza

Maintenance
清理及維護 Healthy Air Fryer Oven
健康氣炸烤爐
10
注意:/CAUTION:
警告: 不使用氣炸烤爐時，經常保持拔除電源，及切勿將氣炸鍋浸於水或其他液體中。在清潔本氣炸烤爐
前，先將氣炸烤爐關掉及把電源線從插座拔出，然後讓氣炸烤爐冷卻。
*注意：打開玻璃門並卸下所有配件，使氣炸烤爐冷卻更快。
WARNING: ALWAYS UNPLUG THE POWER CORD BEFORE MOVING OR SERVICING. DO NOT
IMMERSE THE AIR FRYER OVEN IN WATER! BEFORE CLEANING, MAKE SURE THAT THE UNIT HAS
BEEN SWITCHED OFF AND IT IS UNPLUGGED FROM THE MAIN OUTLET AND LET THE AIR
FRYER COOL DOWN.
* Note: Open the Glass Door and remove all accessories to let the Air Fryer Oven cool
down more quickly.
外殼: 清理時切勿將氣炸烤爐浸於水或其他液體中。使用濕潤軟布抹擦清潔，頑固污垢可用軟布沾上含肥
皂的溫水抹擦。
Housing: Clean the outside and grille of the Air Fryer Oven with a soft cloth. To remove
presistent dirt, wipe down with a cloth that has been dampened with warm soapy water.
1. 每次使用後都要清潔氣炸烤爐。
1. Clean the appliance after every use.
2. 切勿使用研磨性、腐蝕性或易燃性清潔劑(例如漂白劑或酒精)清潔氣炸烤爐的任何部位。
2. Do NOT use abrasive, corrosive or flammable cleansers (such as bleach or alcohol) to clean
any part of the Air Fryer Oven.
3. 盛油盤具有不粘塗層。請勿使用金屬廚房用具或研磨性清潔材料來清潔盛油盤，因為這可能會損壞不
粘塗層。
3. The grease tray of the Air Fryer Oven have a non-stick coating. Do not use metal kitchen
utensils or abrasive cleaning materials to clean the grease tray, as this may damage the
non-stick coating.
4. 用濕布擦拭設備的外部。
4. Wipe the outside of the appliance with a moist cloth.
5. 用熱水，一些洗滌液和非研磨性海綿清潔所有配件。
5. Clean all accessories with hot water, mild cleaner and a non-abrasive sponge.
6. 用熱水和非研磨性海綿清潔設備內部。
6. Clean the inside of the appliance with hot water and a non-abrasive sponge.
7. 用清潔刷清潔加熱元件，以清除食物殘留物。
7. Clean the heating element with a cleaning brush to remove any food residues.
提示: 如果污垢粘在盛油盤底上，請在盛油盤中註入一些清洗液。讓盛油盤浸泡約10分鐘。
Tip: If dirt is stick to the grease tray, fill the grease tray with hot water and mild
cleaner. Let the grease tray soak for approximately 10 minutes.
儲存: 連同使用說明，把氣炸烤爐存放於清涼及乾爽的地方。
STORAGE: Store the Air Fryer Oven with these instructions in the original box in a cool and dry
place.

產品保用証(一年自攜服務)
產品: 健康氣炸烤爐
型號: AF7024F
www.origo.hk
Item : Air Fryer Oven
Model : AF7024F
www.origo.hk
Warranty Card(1 year carry-in)
此產品由購買日期起計算，本公司將根據下列條款及細則，提供一年保養服務(商業用享為3個月):
1. 於購買後一年內，經本公司技術員判斷為正常運作下損壞之產品，可獲免費維修和/或零件更換。
2. 以下情況不被包括在保養範圍內：
- 若產品是因為濫用、錯誤使用、疏忽及/或意外而遭致損壞；
- 未經授權之自行處理、維修及/或改裝；
- 任何機殼、面蓋、燒烤叉把手、旋轉燒烤叉、旋轉網籃、網籃、盛油盤，以及配件。
3. 需要檢查或維修時，請將產品送往本公司服務中心，並於修理妥當後自行取回。
4. 更換後之任何損壞零件，均屬本公司所有。
5. 本保養服務只適用於香港特別行政區。
6. 顧客必須同時出示零售商之正式發票，方可得到免費維修服務。
*** 額外3個月保用: 凡於購買產品後10天內完成網上登記，即可免費延長保用期3個月，即15個月免費保用
(商業用途除外)。請即登入網站: www.origo.hk
服務中心
源澤市務有限公司
香港新界葵涌青山公路403號(近華星街12號)匯城集團大廈21樓H室
電話: 2156 8238
www.origo.hk
This product is warranted for 1year (commercial use for 3 months) from the date of purchase
under the following conditions:
1. For any defect, in the judgment of our technician, if it is caused under normal use, we are
responsible for repairing the product, and/or replacing parts at free of charge.
2. This warranty DOES NOT apply to:
- If the product has been damaged through abuse, misuse, negligence or accidents;
- Unauthorized repair, alteration/modification;
- The housing, cover, split handle, turnspit mount, rotating mesh basket, mesh basket,
grease tray, or accessories, is excluded from this warranty.
3. The customer is requested to bring the unit to and from our Service Centre whenever
service is needed.
4. Any defective parts, which had been replaced, shall be of our property.
5. This warranty is valid in H.K.S.A.R. only.
6. Please show the Invoice to get free service.
***Extra 3 months warranty: just complete Online Warranty Registration within 10 days from
the date of receipt, free warranty will be extended to 15 months (not applicable to commercial
use). Plaese enter our website: www.origo.hk
Service Centre
ORIGIN MARKETING LIMITED
Unit H, 21/F., Reason Group Tower (nearby 12 Wah Sing Street),
403 Castle Peak Road, Kwai Chung, N.T., Hong Kong.
Tel: [phone]
www.origo.hk
Healthy Air Fryer Oven
健康氣炸烤爐
