ORION TELESCOPES & BINOCULARS Tritech II-M User manual

IN 574 08/16
Orion®Tritech II-M Stabilized Monopod with 3-Way Pan Head
#40810
Figure 3. Attach the handle to the pan head with the
handle adjustment knob (A). To change the handle angle,
just loosen the handle adjustment knob until the handle
can be rotated, then retighten the knob when the desired
angle has been set. (B) Three adjustment knobs let you
rotate and lock the 3-way pan head’s azimuth (horizontal),
altitude (vertical), and lateral tilt (C).
Figure 1. Key features (Shown with retractable mini tripod
stand deployed.)
Figure 2. Fold the mini tripod legs down (A) until they click
into the locked position. To fold them back up, (B) press
the two spring pegs inward, then lift the leg up.
Quick-release plate
Handle angle
adjustment
Adjustable
handle
collar
Lateral tilt
adjustment
knob
Handle
angle
adjustment
knob
Handle
Handle
Hand strap
Mini tripod stand
Flip lever leg
locks
Foam grip
Bubble
level
3-way pan head
Altitude
adjustment
knob
Azimuth
adjustment
knob
A
A
B
B
INSTRUCTION MANUAL
CAUTION: While the mini tripod stand can help stabilize the monopod
while in use, it is not designed to support an unattended camera
or spotting scope. Always maintain a firm grip on your camera or
spotting scope with one hand – even when the mini tripod stand is
deployed – to prevent the monopod from tipping over.
C

2
1/4"-20 post
Dovetail
mounting
plate
Lock/
release
lever
