Orion HP10D2 User manual

subwoofer
HP10D2
HP10D4
HP12D2
HP12D4

Recommended Enclosures
Directed Part Number 27202 27207 27212 27217
Model Number HP10D2 HP10D4 HP12D2 HP12D4
Fs (free-air resonance) 31.42 33.14 29.46 27.75
Vas (equivalent compliance, cu. ft.) 0.62 0.56 1.79 1.78
Vas (equivalent compliance, liters) 17.42 18 50.72 50.44
Qms (Q, mechanical) 5.57 5.31 5.24 4.99
Qes (Q, electrical) 0.59 0.63 0.58 0.63
Qts (total driver Q) 0.53 0.57 0.52 0.56
Re (DC resistance, ohms) 3.8 6.85 3.8 6.8
Z (nominal impedance, ohms) 4 8 4 8
Le (inductance, mh) 2.01 2.79 2.01 2.85
Efficiency (2.83v/1M, dB) 84.79 82.72 87.25 84.94
Xmax (one-way linear excursion, in.) 0.55 0.55 0.55 0.55
Xmax (one-way linear excursion, mm) 14 14 14 14
Power (continuous power handling)* 500 watts 500 watts 500 watts 500 watts
Peak power handling (music,)** 1000 watts 1000 watts 1000 watts 1000 watts
Mms (total moving mass, grams) 205 182 247 226
Cms (mechanical compliance, µM/N) 125 127 147 146
BI (motor strength, Tesla-M) 16.22 20.1 16.43 20.59
Sd (effective radiating area, sq. m.) 0.033 0.033 0.050 0.050
Sd (effective radiating area, sq. in.) 51.15 51.15 77.5 77.5
Frequency range (Hz) 40-2.5k 40-2.5k 30-2.5k 30-2.5k
Energy Bandwidth Product (EBP) 53 53 46 44
Typical Sealed Enclosure (cu. ft.) 0.55 0.65 1.25 1.35
SPL Sealed Enclosure (cu. ft.)** 0.35 0.35 0.65 0.55
Low Qtc Sealed Enclosure (cu. ft)* 0.65 0.65 2.05 2.15
Vented Enclosure (cu. ft.)*** 0.95 0.95 1.35 1.45
Port Tuning Frequency (Hz) 44 44 40 40
Port Diameter (inside in.) 3 3 4 4
Equivalent Square Port (in.) 2.65 x 2.65 2.65 x 2.65 3.54 x 3.54 3.54 x 3.54
Port Length (in.) 8 8 12.5 11.5
SPECIFICATIONS
1. Parameters listed are for conventional applications only, for further help please call Tech Audio Support *For SQ (sound quality applications) amps should be between
2. Recommend enclosure are NET Box Volumes, speaker and port displacement are NOT calculated into the Pe and Peak power ratings.
volume of the enclosure, you will need to add these volumes to calculate GROSS volume for the enclosure. ** SPL usage only! Not rated for continuous use at this level.
3. The approximate volume of air displaced by the port can be calculated by using the square port area (H x W) *** Sub-sonic filters should always be used and adjusted specifically
times the port length and then divide by 1728 to get cubic feet. for vented box designs.
4. Please call Technical Audio support for further specifications and information: 1-800-876-0800 ext. 2032
Specifications subject to change without notice © 2005 Directed Electronics, Vista, CA.—all rights reserved
Driver Physical Dimension
Speaker Displacement (cu. ft.) 0.077 0.077 0.096 0.096
Mounting hole diameter (in.) 9 9 11 11
Mounting depth (in.) 6.5 6.5 7 7
Basket diameter (in.) 10.25 10.25 12.35 12.35

Warranty
LIMITED TWO YEAR CONSUMER WARRANTY:
Directed Electronics promises to the original purchaser, to replace this product should it prove to
be defective in workmanship or material under normal use, for a period of two years from the date
of purchase by the dealer as indicated by the date code marking of the product PROVIDED the
product was installed by an authorized Directed dealer. During this two year period, there will be
no charge for this replacement PROVIDED the unit is returned to Directed, shipping pre-paid. If
the unit is installed by anyone other than an authorized Directed dealer, the warranty period will
be 1 year from date of purchase by the dealer as indicated by the date code marking of the
product. During this 1 year period, there will be no charge for this replacement PROVIDED the
unit is returned to Directed, shipping pre-paid. This warranty is non-transferable and does not
apply to any unit that has been modified or used in a manner contrary to its intended purpose,
and does not cover damage to the unit caused by installation or removal of the unit. This warranty
is void if the product has been damaged by accident or unreasonable use, neglect, improper service
or other causes not arising out of defects in materials or construction. ALL WARRANTIES
INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY
OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, AND WARRANTY OF NON-
INFRINGEMENT OF INTELLECTUAL PROPERTY ARE EXPRESSLY EXCLUDED TO THE
MAXIMUM EXTENT ALLOWED BY LAW, AND DIRECTED NEITHER ASSUMES NOR
AUTHORIZES ANY PERSON TO ASSUME FOR IT ANY LIABILITY IN CONNECTION WITH THE
SALE OF THE PRODUCT. DIRECTED HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS
OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS OR INSTALLERS. Unit must be
returned to Directed, postage pre-paid, with: consumer's name, telephone number, and address,
authorized dealer's name and address, and product description. IN ORDER FOR THIS WARRANTY
TO BE VALID, YOUR UNIT MUST BE SHIPPED WITH PROOF OF INSTALLATION BY AN
AUTHORIZED DIRECTED DEALER. ALL UNITS RECEIVED BY DIRECTED FOR WARRANTY
REPAIR WITHOUT PROOF OF DIRECTED DEALER INSTALLATION WILL BE COVERED BY THE
LIMITED 1 YEAR PARTS AND LABOR WARRANTY. Note: This warranty does not cover labor costs
for the removal and reinstallation of the unit.
BY PURCHASING THIS PRODUCT, THE CONSUMER AGREES AND CONSENTS THAT ALL
DISPUTES BETWEEN THE CONSUMER AND DIRECTED SHALL BE RESOLVED IN ACCORDANCE
WITH CALIFORNIA LAWS IN SAN DIEGO COUNTY, CALIFORNIA.
© 2005 Directed Electronics, All rights reserved. G27202.07.12.17 11-05
