Osaki OS4000T User manual

1
Rear clearance
Notes
Allow for at least 31.5” rear clearance behind and the
chair and 13.8” in font of the chair when installing.
Caution
1.Place a carpet under the chair to protect the floor and install on a flat even
surface only.
2.Be careful not to damage the floor surfaces when positioning the chair.
3.Do not install the chair in an area of high humidity such as a bathroom or
sauna, or where the ambient temperature is 104 ℉ or higher.
4.Install the chair at least 3 feet away from TVs,radios, and/or other audio or
video equipment to prevent signal interference
Accesscories
2* M6*40mm
2* M6 washer
2* M6 spring washer
31.5ȕ
13.8ȕ
ʽ
Installation of the backrest unit
Lift the backrest, then lower the backrest into the seat brackets. Securely lock
the flat head bolts into both sides of holder on the seat.
Note: Please do it carefully to avoid scratching during installation.
A: Flat Head bolt (on the backrest)
B: Holder (On the seat)
B
A
Step 1:

2
Use the diagonal pliers to cut off the cable tie
which binds the stopper of the backrest and
take down the packing material of the backrest
actuator, where both of them are located
underneath the seat pad.
Connect and lock backrest to bottom seat then secure position.
Step 2:
Connect the air hose connectors on the backrest.
(with Red&Yellow circle bands)
Step 3:

3
Step 5:
Step 4:
Step 6:
Take down the packing material of the plug, then insert the wire plugs into
the corresponding place in the seat according to the marks given, and make
sure the wire plugs are fully connected until you hear a “click” sound.
Insert black to black and gray to gray.
Unfold the backrest until you hear “ click” sound.
Attach the backrest pad and the pillow
Zipper Velcro

4
Connect side panel air hose of the side panel unit
Installation of the side panel unit
Step 1:
Insert the side panel to the chair at 30 degrees.Securely lock the flat head bolts into
the side holder on the seat.
Step 2:
30°

Use the cable tie to unfasten the seat pad from the chair
by the zipper, then lift up the seat pad.
Fasten the socket screw onto the corresponding holder.
Step 3:
5
Inserting the fixing lugs in to the cross bar completely

6
Fix the remote controller to the holder
by securing the screws.
Installation of remote comtroller
The back massage strength-control pad has been inserted into the
backseat cove
If strong massage is desired, remove the back massage
strength-control pad from the cover; this strengthens the massage.
If strong massae is desired, remover the back massage
strength-control pad from the cover; this strengthens the massage.
If milder massage are desired , insert the back massage
strength-control pad into the cover; this lessens the strength of
the massage.
You could remove the pillow(s) to engoy
deeper massage for the neck.
Note:

7
