CareCo UNIVERSAL ADJUSTABLE TABLE User manual

TO RAISE THE TABLE
Lift the table until the desired height is reached;
With hand squeezing the lever and table top
Lift the table until the desired height is reached;
it will automatically lock in position.
TO LOWER THE TABLE
Squeeze lever handle and table top together Plastic lever
(with one hand) and apply pressure down above
the column until the table top lowers to the
desired position. Release the lever and the table
top is locked.
NOTES
NOTES
Occasional application of light oil lubrication
between the inner and outer columns will
help your table operating smoothly.
The table top will rotate a full 360°around its base
to be used as a side table or lap tray as needed.
THIS TABLE IS DESIGNED TO BE
USED WITH HEAVIER RECLINER
CHAIRS SO INCORRECT USE OR
UNIVERSAL ADJUSTABLE TABLE
CHAIRS SO INCORRECT USE OR
POSITIONING MAY RESULT IN
CareCo (UK) Ltd
THE TABLE TIPPING OVER.
Hubert Road
(REF. ASSEMBLY STEP 1)
Brentwood
Essex
CAUTION--SPRING LOADED ASSEMBLY CM14 4JE
Do not remove the black shipping screw
before completing assembly steps 1-4.
Tel: [phone]
Removing the shipping screw before this
Removing the shipping screw before this
can result in personal injury and spring
damage.
www:careco.co.uk
Product is NOT to be used to assist in lifting
or hold more than 25lbs (11kgs).
Email: [email protected]

① Table Top
②Top Bracket
③M6*15 round head Allen bolts
Your new CareCo Universal Adjustable
Table is designed for use on either the left
or right-hand side of your recliner but must
be assembled to suit.
Column
⑦Small Square Base of the Column
⑥M6*12 countersunk Allen bolts
Decide which side of the recliner you want
the table. When seated in the chair, if you
want the table on the right follow the RH
instructions. For left Hand (LH) swap the
connections during assembly.
1
⑤ Floor Plate
④ Column
Assembly drawing
FIGURE 1
Take the Floor Plate(#5) and look
underneath to see the RH & LH labels. For a
Right Hand table use the RH holes. Use the
screw 4x M6x12 countersunk Allen bolts
from the underside of the Floor Plate (#5)
into the small Square Base of the Column
(#7) and tighten fully using the Allen Key
supplied. Fig.1
2
4
supplied. Fig.1
Use the 6xM6x15 round head Allen bolts to
connect the Table Top (#1) to the top of
the Column (#4) making sure to bolt into
the 6 predrilled holes marked RH.
3
Remove the black shipping screw from the
top of the Column and replace it with the
zinc plated screw, using a Phillips
screwdriver, to release the Spring Loading
Right Hand (RH)Left Hand (LH)
Tools Necessary For Assembly:
Phillips Screwdriver
Allen key
screwdriver, to release the Spring Loading
mechanism and the product is ready for
use. Fig. 2
FIGURE 2
