OSEPP DIY-001 User manual

OSEPP USA, INC.
2105 S Hardy Dr., Unit # 19
Tempe, Arizona, 85282
USA
www.osepp.com
Hourglass DIY Solder Kit
Cat #: DIY-001
Learn to solder with easy-to-follow instructions. Idea for hobbyists and education institutes.
Kit Contents:
Component
Name
Value
Qty
Designator
Important Info
Image Reference
LED 5mm
5mm
42
LED1…. LED42
Watch for
polarity. Long leg
is positive (+)
Mini Push Button
6x6mm
2
KEY1, KEY2
No polarity
Pin Header
2.54mm 1x8
2
P1, P2
No polarity
Female Header
2.54mm 1x8
2
U1, U3
No polarity

42 LEDs (extras included)
Sound Indicator
Push-button time selection
Rotate to reset (tilt sensor)
2xAAA battery power (not Incl.)
Microprocessor technology
On/Off switch

OSEPP USA, INC.
2105 S Hardy Dr., Unit # 19
Tempe, Arizona, 85282
USA
www.osepp.com
Resistors
330 ohms
7
R1…. R7
No polarity
Resistors
1K ohms
3
R8, R9, R10
No polarity
Buzzer
3V
1
BUZZER1
Watch the
polarity
Tilt Sensor
SW-52D
1
SW1
No polarity
On/Off Switch
3.7 x 8.5 mm
1
SW2
No polarity but
pay attention to
placement
position
Integrated Circuit
(IC)
STC15W204S
1
U1
Match the ‘notch’
on the silkscreen
to the notch on
the IC.
Battery Clip
AAA
4
BT1, BT2, BT3,
BT4
Pay attention to
the placement
direction.
Capacitor
100nF
1
C1
No polarity
Desoldering Braid
6” long (2.5mm
width)
1
n/a
Use to remove
solder when
correcting
mistakes

OSEPP USA, INC.
2105 S Hardy Dr., Unit # 19
Tempe, Arizona, 85282
USA
www.osepp.com
100 ohms
Brown/Black/Brown/Gold
300 ohms
Orange/Orange/Brown/Gold
1 MEG
Brown/Black/Green/Gold
1K ohms
Brown/Black/Red/Gold
10K ohms
Brown/Black/Orange/Gold

OSEPP USA, INC.
2105 S Hardy Dr., Unit # 19
Tempe, Arizona, 85282
USA
www.osepp.com
Step-by-Step Instruction
STEP 1: LED placement (x42)
The kit comes with extra LEDs in case of defects or misplacement. When placing components with longer leads, it is helpful
to bend the lead to hold the component in place while soldering.
•The ‘longer’ lead from the LED is positive (+)
•Finish all 42 required LEDs before moving to step 2.
•Use a diagonal clipper to cut off the lead once soldering has been completed.

OSEPP USA, INC.
2105 S Hardy Dr., Unit # 19
Tempe, Arizona, 85282
USA
www.osepp.com
STEP 2: Place and solder the two Mini Push Buttons (x2)
•There is no polarity with the push buttons.

OSEPP USA, INC.
2105 S Hardy Dr., Unit # 19
Tempe, Arizona, 85282
USA
www.osepp.com
Step 3: Solder the Female Header (x2) to the BACK of the PCB.
•Please note that this completes the first PCB

OSEPP USA, INC.
2105 S Hardy Dr., Unit # 19
Tempe, Arizona, 85282
USA
www.osepp.com
Step 4: Place and solder the 330-ohm resistors (x7)
•Start of second PCB
•Resistors do not have polarity
Step 5: Place and solder the 1K resistors (x3)
•No polarity

OSEPP USA, INC.
2105 S Hardy Dr., Unit # 19
Tempe, Arizona, 85282
USA
www.osepp.com
Step 6: Place and solder the capacitor (x1)
•Capacitors do not have polarity
Step 7: Place and solder the On/Off switch
•Make sure the switch is pointing outward from the PCB

OSEPP USA, INC.
2105 S Hardy Dr., Unit # 19
Tempe, Arizona, 85282
USA
www.osepp.com
Step 8: Place and solder IC into place.
•Match the ‘notch’ on the IC to the notch on the silkscreen image.
Step 9: Place and solder the tilt sensor.
•No polarity

OSEPP USA, INC.
2105 S Hardy Dr., Unit # 19
Tempe, Arizona, 85282
USA
www.osepp.com
Step 10: Place and solder the buzzer.
•Pay attention to the polarity. The positive (+) lead is clearly marked on the bottom side of the buzzer.
Step 11: Place and solder the male headers (x2).
•No polarity
•Place header with longer pins facing upwards

OSEPP USA, INC.
2105 S Hardy Dr., Unit # 19
Tempe, Arizona, 85282
USA
www.osepp.com
Step 12: Place and solder the battery clips (x4)
•Please note the direction of the battery clips. Refer to the image below.
Step 12: Your two PCBs should look like the below images.
