OWNER'S MANUAL
RAPTOR / RAVEN SERIES
RAPTOR 14 RAVEN 14 RAVEN 10RAPTOR 10
S19 - UPDATED 12/18
Welcome to Osprey. We pride ourselves on creating the most functional,
durable and innovative carrying products for your adventures. Please
refer to this owner’s manual for information on product features, use,
maintenance, customer service and warranty.

RAPTOR / RAVEN SERIES 2
OVERVIEW
SHARED FEATURES
1 Scratch-free, heat-embossed zippered slash pocket for
sunglasses and electronics
2 Stretch mesh zippered hipbelt pockets provide on-trail
access for small items
3 Hydration sleeve with direct-zip access and hose path for
easy loading
4 LidLock bike helmet attachment
5 Stretch mesh front pocket for quickly stashing extra gear
6 Blinker light attachment and reflective patch for safety
7 Removable bike tool roll keeps tools handy and organized
8 Lightweight sternum strap magnet for easy access to water
+ Bike tool organization in main compartment
+ Hydraulics®LT 2.5L reservoir included
2
1
3
4
5
6
7
8
FABRIC
MAIN 210D Nylon Double Diamond Ripstop
ACCENT 420HD Nylon Packcloth
BOTTOM 420HD Nylon Packcloth
RAPTOR 14
SPECS ONE SIZE
Cubic Inches 854
Liters 14
Pounds* 1.75
Kilograms* 0.80
Inches 19h x 9w x 10d
Centimeters 48h x 22w x 25d
RAPTOR 10
SPECS ONE SIZE
Cubic Inches 610
Liters 10
Pounds* 1.59
Kilograms* 0.72
Inches 19h x 9w x9d
Centimeters 48h x 22w x 23d
RAVEN 14
SPECS ONE SIZE
Cubic Inches 854
Liters 14
Pounds* 1.63
Kilograms* 0.74
Inches 17h x 8w x 10d
Centimeters 43h x 21w x 25d
RAVEN 10
SPECS ONE SIZE
Cubic Inches 610
Liters 10
Pounds* 1.50
Kilograms* 0.68
Inches 17h x 8w x 9d
Centimeters 43h x 21w x 22d
UNIQUE FEATURES
1 Front panel zippered stash pocket
2 Side compression straps also carry full face helmets
* Pack weight does not include reservoir

RAPTOR / RAVEN SERIES 3
CARRY
SIZING / FIT
1
2
3
STERNUM STRAP
HARNESS
HIPBELT
BACKPANEL
1 AIRSCAPE BACKPANEL
+ Mesh-covered, extra deep ridged foam allows maximum
ventilation while keeping the load close to the body
2 BIOSTRETCH HARNESS
+ Bike-specific winged shoulder strap shape provides
comfort and stability
+ Soft, breathable spacermesh contact surfaces and
die-cut foam ventilation
3HIPBELT
+ Airmesh wrap hipbelt with zippered pockets provide
stability and breathability
WOMEN'S-SPECIFIC FIT
+ Narrower and shorter torso length
+ Narrower, shorter harness with curves designed to accommodate most
women's necks, shoulders and chests
+ A hipbelt designed to wrap naturally around the curve of a woman's hips,
offering better load stabilization and support
BACKPANEL
The backpanel and harness straps should wrap fully
around your shoulders with no gaps between the
pack and your back.
HARNESS
The padded part of the harness straps should end
1"/2.5 cm- 2"/5 cm below the armpits.
RAPTOR - MEN'S
TORSO O/S 17-21¨/ 43-53 cm
RAVEN - WOMEN'S
TORSO O/S 14-18¨ / 35.5-46 cm
STERNUM STRAP
The sternum strap adjusted to approximately
2"/5 cm below the collarbone.
FIT

RAPTOR / RAVEN SERIES 4
FEATURES
RESERVOIR SLEEVE
14L / 10L
The dedicated internal reservoir sleeve's direct-zip access and hose path allows
for easy loading/ unloading of the included Hydraulics® 2.5L LT reservoir. An
internal hanging loop with buckle ensures proper vertical orientation and stability.
Compatible with any reservoir up to 3L.
For more information on Osprey's full line of reservoirs and reservoir care,
visit osprey.com.
LIDLOCK HELMET ATTACHMENT
14L / 10L
Osprey’s LidLock easily and securely carries bicycle helmets.
1 Locate the LidLock helmet attachment clip near the top of the
pack ’s front panel and pull away from the pack.
2 In the vertical position, pass LidLock through helmet vent from
the bottom and engage in horizontal position.
3 Inside the pack's front slash pocket is a cord loop to increase
or decrease the LidLock's tension.
FULL FACE HELMET CARRY
14L
To attach a full face helmet;
1 Unclip the two upper compression straps.
2 Place the helmet face opening up on the front panel of the pack and thread
the two compression straps through the helmet’s face opening.
3 Re-clip the compression strap buckles and tension them to hold the helmet
securely to the pack.
4 Clip the helmet’s chinstrap through the blinker light attachment near the
base of the front panel for extra carrying stability
BIKE TOOL ROLL
14L / 10L
A removable roll-out tool pouch is integrated into its own zippered lower
pocket for quick access. It provides tool organization for bike essentials.
RESERVOIR BITE VALVE MAGNET
14L / 10L
The sternum strap magnet allows for quick access to the reservoir bite valve.

RAPTOR / RAVEN SERIES 5
FEATURES
UPPER COMPRESSION STRAPS
AND SHOVE-IT POCKET
14L
A front panel shove-it pocket is
designed to stash essential biking
gear on the go. The pocket's upper
quick-release compression straps
secure a full face or allow for pack
compression for added stability.
SCRATCH-FREE SLASH POCKET
14L / 10L
Scratch-free, heat-embossed
zippered slash pocket for sunglasses
or electronics.
INTERNAL ORGANIZATION
14L / 10L
Organization for your essentials and
pocketing sized for bike-specific tools
and gear.
BLINKER LIGHT ATTACHMENT
14L / 10L
Blinker light attachment and reflective patch
for safety.
FRONT STRETCH MESH POCKET
14L / 10L
For quickly stashing gear.
ZIPPERED HIPBELT POCKET
14L / 10L
On-trail access for small items.
