Outland Living ROSEDALE OLVG-329 User manual

FMI BRANDS INC. 101 – 3570 194 Street, Surrey, BC, Canada V3Z 1A5
USA, Canada Toll Free: 1-888-514-1663 | Tel: [phone] | Email: [e-mail]
Hours of Operation 8:30 AM - 4:00 PM (Pacific Time)
D.329.000.V0
Trellis Garden ROSEDALE
Model number OLVG-329
® Registered trademark of FMI Brands Inc.
OWNER’S MANUAL
ROSEDALE
TRELLIS GARDEN

Owner & Safety Manual
En-1 D.329.000.V0
OUTLAND LIVING®- ROSEDALE TRELLIS GARDEN OWNER & SAFETY MANUAL
Model number OLVG-329
NOTE TO INSTALLER:
Leave this guide with the consumer.
NOTE TO CONSUMER:
Please retain this guide for future use.
WARNING:
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Read the
installation, operating and maintenance instructions thoroughly
before installing or servicing this equipment.
DANGER:
Do not let children climb on
garden, or serious injury may
occur!
CAUTION:
Watch for sharp edges.
Wear protective gloves if necessary.
SUPPLIED PARTS & HARDWARE LIST:
PART # DESCRIPTION PICTURE
1 PLANTER BASE
(x1)
2
BASE LEG
WITH WHEELS
(x1)
3 BASE LEG
WITH FEET (X1)
4
BOTTOM
FRAME POSTS
(x2)

En-2
1-888-514-1663 | WWW.OUTLANDLIVING.COM
SUPPLIED PARTS & HARDWARE LIST (continued):
PART # DESCRIPTION PICTURE
5
MIDDLE
VERTICAL
SUPPORT
TUBES (x2)
6
TOP VERTICAL
SUPPORT
TUBES (x2)
7 TOP CROSS
BAR (x1)
8
TUBE
CROSSBARS
(x2)
9
WIRE
CROSSBARS
(x3)
PART # DESCRIPTION PICTURE
10 FELT GROW
BAG (x1)
11 M5x50
SCREWS (x4)
12 M5x40
SCREWS (x8)
13 GARDEN TWINE
(x1)
REQUIRED TOOLS (Not Supplied):
• Philips (cross) screw driver (PH2)

Owner & Safety Manual
En-3 D.329.000.V0
OUTLAND LIVING®- ROSEDALE TRELLIS GARDEN OWNER & SAFETY MANUAL
SECTION 1: ASSEMBLY
Side View Off-Center
Configuration
(Suggested next to a wall).
Side View Center
Configuration
(Suggested in an open area).
Left or right side wheels for moving
the garden.
ATTENTION! ASSEMBLY DECISIONS.
CHOOSE YOUR SET-UP CONFIGURATION STYLE:
i. Do you want a center-mounted frame, or off-center mounted frame? Note that an off-center mounted frame is designed
to look best when set next to a wall.
ii. Which side do you prefer the wheels to be on? Left or right? Envision yourself maneuvering the garden around in your
space.
iii. Adjust the assembly instructions to suit.

En-4
1-888-514-1663 | WWW.OUTLANDLIVING.COM
SECTION 1: ASSEMBLY (continued)
Center Frame Configuration
Off-center Frame Configuration
STEP 1
Align the Planter Base (part 1), the Base Legs (parts 2 and 3) and Bottom Frame Posts (part 4) and fasten using the (4x) four
long M5x50mm screws (part 11).
a) Placing the Base Leg with Wheels on the left side or right side is optional.
b) Utilize the same sets of holes on each side. The off-center or center hole configuration is optional.

Owner & Safety Manual
En-5 D.329.000.V0
OUTLAND LIVING®- ROSEDALE TRELLIS GARDEN OWNER & SAFETY MANUAL
SECTION 1: ASSEMBLY (continued)
STEP 2
Insert the Middle Vertical Support
Tubes (part 5) in the Bottom Frame
Posts. Note, the single top holes should
be facing in towards the sides.
STEP 3
Insert the Top Vertical Support Tubes
(part 6) in the Middle Vertical Support
Tubes. Note, the two top holes should
be facing in towards the sides.
STEP 4
Fasten the Top Crossbar (part 7) to
the Top Vertical Support Tubes using
(4x) four M5x40mm screws (part 12).
Note, the OUTLAND logo should face
forward.
Single hole up
& side facing
Two holes up
& side facing Logo facing
forward

En-6
1-888-514-1663 | WWW.OUTLANDLIVING.COM
SECTION 1: ASSEMBLY (continued)
STEP 5
Fasten the (2x) Tube Crossbars to the frame using (4x) four
M5x40mm screws (part 12).
STEP 6
Insert the (3x) Wire Crossbars with hook-ends up.
Insert hook-end up

Owner & Safety Manual
En -7 D.329.000.V0
OUTLAND LIVING®- ROSEDALE TRELLIS GARDEN OWNER & SAFETY MANUAL
SECTION 1: ASSEMBLY (continued)
STEP 8
Place the Felt Grow Bag on the Planter Base with the
OUTLAND logo facing forward.
TIP: Locate the garden where it will be displayed BEFORE
filling with dirt. Make sure the garden is standing level. Then,
fill with dirt. Plant. Enjoy. Harvest!
a) Unpack the Felt
Grow Bag.
b) Fold Side A up.
c) Fold Side B up.
d) Fold ends through
lower slot holes.
e) Fold ends through
upper slot holes.
Logo facing
forward
IMPORTANT:
Ensure all screws are fastened tightly. If the screws are loose,
the frame will be loose.
STEP 7
Construct the Felt Grow Bag.

En-8
1-888-514-1663 | WWW.OUTLANDLIVING.COM
STRING TRAINING YOUR CROP
We have provided a roll of starter twine in the garden kit. You may
use string, or twine, to lift and guide your plants, as they grow.
Although you may discover many ways to use this twine, one way
we recommend is to tie one end at the top, weave the twine over-
under-over-under the wires and tie at the bottom wire. Plants will
naturally grasp and grow up the lines. See the image here.
SECTION 2: PLANTER GARDENING
Tie at top.
Cut to length.
Weave over-
under-over-
under.
Tie at bottom.
Repeat.
MOVING THE GARDEN
The garden has two wheels on one side of the frame to enable
movement. To move your garden:
• Ensure the screws are fastened tight and the frame is not
wobbly. If wobbly, tighten the screws.
• Lift the side opposite to the wheels and push, or pull, the frame
and guide it to where you would like to position it.

Owner & Safety Manual
En-9 D.329.000.V0
OUTLAND LIVING®- ROSEDALE TRELLIS GARDEN OWNER & SAFETY MANUAL
SECTION 2: PLANTER GARDENING (continued)
SOIL BUDGET
ASSUMPTION
Add your preferred type and
volume of potting soil mix. (Soil
not included). Plan your soil
budget for 42L (11 Gal) of soil
mix and/or adjust the volume of
soil to suit your need.
SOIL BUDGET
42 Litres (L)
11 US Gallon
1.5 cubic foot (ft3)
.055 cubic yard (yd3)
.042 cubic meter (m3)
USES FOR THE ROSEDALE TRELLIS GARDEN
Determinate Tomatoes
Generally, the ‘determinate’ tomato plant, or ‘bush’ tomato plant,
will only grow to a maximum height of about 4ft. They have a
short growing season, with one harvest. One example is ‘Cherry’
tomatoes. Check other varieties with your local nursery.
Indeterminate Tomatoes
The indeterminate tomato plant keeps on growing and producing
all summer long. These tomato varieties are usually the larger type
like ‘Beefsteak’ tomatoes. Check other varieties with your local
nursery.
For best results, consult your local nursery for gardening tips
when purchasing your garden materials.
OK, so what other types of fruit and vegetables could you grow in
this garden if you wanted to? How about:
• Cucumbers • Squash • Melons • Peas • Beans
Order more gardens from outlandliving.com
APPROXIMATE DIMENSIONS
FRONT VIEW
FRONT VIEW
TOP VIEW
[30.2 in]
766.0 mm
[26.4 in]
671.4 mm
[31.3 in]
794.0 mm
(1x) Felt Grow Bag
Dimensions LxWxH (Approx.)
671 x 250 x 254 mm
(26.4 x 9.8 x 10 in)
Capacity: 42L / 11 US Gallons
[66.0 in]
1675.5 mm
[17. 9 in]
454.3 mm
[9.8 in]
250.0 mm
[10.0 in]
254.0 mm
TOP VIEW
Frame Dimensions (Approx.):
HEIGHT: 1676 mm / 66 in
WIDTH: 794 mm / 31.3 in
DEPTH: 454 mm / 17.9 in

En-10
1-888-514-1663 | WWW.OUTLANDLIVING.COM
SECTION 3: SET UP INSPECTION SEQUENCE
The garden should be inspected before use and at least annually. More frequent cleaning and/or adjustments may be required as
necessary.
Prior to each use:
Ensure the garden is placed on a level and firm surface able to hold the fully loaded weight of the frame and harvest. The actual weight
will vary, depending on the type of soil used, how moist the soil is and how much crop weight is present. A reasonable forecast is
approximately 22 - 44 kg (50 - 100 lbs).
• Ensure no parts are missing and all fasteners are firmly tightened.
• If the frame structure seems wobbly, tighten the screws.
SECTION 4: MAINTENANCE
Your garden is meant for indoor or outdoor use and requires periodic maintenance to keep it in good condition.
Do not over-water. Too much water can drown your plants or promote root and stem rot. Consult your local plant nursery for specific
information about your garden’s needs.
The felt grow bag material is breathable, which is healthy for your garden root structure. If the soil becomes oversaturated with water, the
felt bag may leak brown water. This is normal. Oversaturating is not healthy for the plants. Try not to oversaturate.
To control rainwater exposure, we recommend locating the garden under eaves, or awnings. If there is a chance that the garden may
become over saturated with water, or rainwater, we recommend placing a drip tray, or mat, under the base.
Should any part of this appliance become soiled or dirty, wipe down with a damp wet cloth.
IMPORTANT: Do not use petroleum based, flammable or corrosive cleaning products on or near this unit.
This appliance is NOT a toy.
SECTION 5: STORAGE
We recommend to store your garden under cover during winter, or
when not in use.
Follow these instructions to ready for storage:
• Use the wheels to guide the garden to shelter.
• Optional: Remove the grow bag from frame.
• Store conveniently. See you next season.
WARNING:
Do not climb on the garden or use it as a ladder or serious
injury, property damage and/or death may occur.
ATTENTION:
Children should be supervised at all times when using this unit,
without exception.

Owner & Safety Manual
E n -11 D.329.000.V0
OUTLAND LIVING®- ROSEDALE TRELLIS GARDEN OWNER & SAFETY MANUAL
STOP:
Do not return this product to the store.
If you need help or parts, call the OUTLAND Hotline:
1-888-514-1663
Get help for:
• Missing/damaged parts • Assembly • Troubleshooting
• Warranty Assistance • Product Information
1 YEAR LIMITED WARRANTY
Customers in Canada and USA
All components are warranted by the manufacturer for a period of 1 year after date of purchase by the original
owner against defects in materials and workmanship under normal use. This warranty does NOT cover normal wear
and weathering, assembly and/or maintenance OR use in a commercial application. At FMI Brands’ sole discretion,
products under warranty will be repaired and/or replaced at no charge to the customer. Any returns sent back to FMI
Brands must be sent via prepaid freight and in the original retail packaging.
Please register your OUTLAND Living product for proof of purchase and warranty at
https://outlandliving.com/register-products/
For more warranty information and details please contact FMI Brands Inc. at [e-mail]
FOR REPLACEMENT PARTS AND ACCESSORIES PLEASE VISIT
WWW.OUTLANDLIVING.COM
The owner’s manual is available as a free download from www.outlandliving.com
Should you have any questions or comments regarding this product, please do not hesitate to contact FMI Brands Inc. at [phone] or
E-Mail to [email protected].
