OVER-EAR PARROT OE1700P Instruction manual

34SELECT CHANNEL
Press the mode button
until the display flashes
use the directional
buttons to change
channel.
2SWITCH ON
Press and hold on/ off
until the LED power
light turns on and the
display shows.
1INSERT BATTERIES
Open the front of the
transmitter and insert
2 x AA batteries.
PLAY AUDIO
Plug your device into
the Connect audio
device (i.e. headphones)
to audio input.
Parrot setup...
What’s in the box
Receiver, power cable and 3.5mm jack
WWW.OVER-EAR.COM Transmitter
3.5mm jack cable
Power cable
PARROT
Belt Pack Transmitter
Parakeet
Bob
WWW.OVER-EAR.COM
Make the most of
your Parrot...
Parrot can be used with a wide range of
OVER-EAR products, including headphones
and other transmitters.
Compatible with:
Harry
Donkey
Joe
Falcon X

MEET PARROT TECHNICAL
SPECIFICATION
SAFETY
INSTRUCTIONS
DO DON’T
NEED HELP?
TROUBLE
SHOOTING
NO AUDIO / MUSIC?
Check your music playing device is
working, connected correctly, playing
music with volume turn Parrot up full.
Try a different device and audio cable.
Ensure receivers/headphones are
switched on, connected to correct
channel and have volume up.
NB - if the mic works but no music, the
problem is likely to be your own music
device or connection.
NO MIC?
Check the mic is working and connected
properly.
Ensure receivers/headphones are
switched on, connected to correct
channel and have volume up.
Try using mic without any music.
NB - if music works but no mic, the
problem is likely to be the mic.
SIGNAL CUTS OUT, INTERFERENCE
OR REDUCED RANGE?
Ensure there is no interference caused
by other wireless equipment in the vicinity.
If using 2 or more transmitters (or
Falcon X) simultaneously make
sure each is on different channels
(frequencies). You cannot use 2
transmitters on the same channel in the
same place ever. They will cancel each
other out, resulting in little or no signal.
NO POWER?
Check the transmitter is fully charged
and switched on.
• Switch off and disconnect equipment before
cleaning.
• Do not repair or replace parts for any products.
• Do not use equipment if damaged by water, heat,
physical impact etc.
• Do not use or store equipment in or near water,
moist or hot environments.
• Keep away from radiators and heat generating
electrical equipment such as screens and amps.
• Use only the supplied power cable and
accessories with your product.
• Disconnect from power after charging and
especially when not being used for long periods
of time.
• Ensure that power connection is plugged in
properly - not damaged, working within a
comfortable temperature and not exposed to
direct sunlight.
• Do not overload wall sockets.
• Failure to comply with safety guidelines can result
in electrical shock, fire, damage to equipment and
invalidate your warranty.
• If in doubt please contact dealer or manufacturer.
Do use headphones and
systems at comfortable
and safe listening levels.
Do gently clean
equipment between
uses and users. Hygienic
wipes and ear pad covers
are available from your
supplier.
Do feel free to expand
your system. Mix and
match with a variety of
Over-Ear transmitters,
headphones and
receivers.
Do call, email or visit us
for help and advice.
Don’t use 2 or more
transmitters on the same
channel - they won’t work.
Don’t use equipment
near other wireless
apparatus including radio
mics, transmitters etc.
Frequencies can interfere
and result in distorted or
no signal.
Don’t attempt to repair
or modify equipment
yourself. At best
this invalidates your
warranty. At worst this
could seriously harm
somebody.
Don’t use headphones
for extended periods of
time.
Model Number: OE1700P
Dimensions: 8.2cm x 6.1cm x 2.7cm
Weight: 0.15g
Sound: Stereo
Frequency
Response: 30- 15,000Hz
Channel
Separation: >40dB
Modulation: UHF
S/N Ratio: >80db
Audio Input
Voltage: 500mVrms @ 1khz
Connections: 3.5mm audio; 3.5mm mic
Power Source: 2 x AA Batteries
Charge Voltage: 5v
Charge Current: 200mA
Charge Time: N/A
Battery Life: <24 hours
R F Power: 10dBm
Modulation
Frequency Offset:
50KHz/ 600mVrms
Op Distance: >150m
Working Current: 90mA±10mA
Frequencies: Custom i.e. 433MHz/
863MHz/
915MHz etc.
LED Colour Typical Frequency
EU USA
A863.1MHz 914MHz
B863.7MHz 915MHz
C864.9MHz 916MHz
D864.3MHz 917MHz
Please note frequencies and other specifications
may be changed without notice.
If in doubt please confirm with supplier.
1.
2.
3.
4.
6.
5.
1. Power button
Press and hold for on/ off (1 sec). turn the
transmitter on.
2. Auxiliary input
Connect your device by using a 3.5mm
jack.
3. Mic input
Connect your microphone via a 3.5mm
jack.
4. Mode button
Press and hold the mode button until the
frequencies on the display start flashing.
Once flashing, you can use the channel
buttons to change the channel.
5. Channel buttons
Use the [^] Channel up and [v] Channel down
to cycle through the channels.
6. Battery Cover
Flip open the battery cover to replace the
batteries within the transmitter.
Feel free to drop us a line at:
[e-mail]
