Overland Storage SnapServer Expansion E2000 User manual

10400283-003 07/2010 ©2010 Overland Storage, Inc. Page 1 of 5
SnapServer®Expansion E2000
Quick Start Guide
Overview
This document describes how to unpack a SnapServer
Expansion E2000 array from Overland Storage and
install it into a four-post, 32-inch depth, EIA-310 rack.
WARNING: To reduce the risk of electric shock or damage
to equipment, always remove any power cords while
working with the unit.
AVERTISSEMENT: pour réduire le risque de choc
électrique ou endommagement de l'équipement, retirez
toujours les cordons électriques en travaillant avec l'appareil.
CAUTION: While working with the unit, observe standard
Electrostatic Discharge (ESD) precautions to prevent
damage to micro-circuitry or static-sensitive devices.
Register First
Before starting, it is essential that you activate your
Overland warranty. Technical and warranty support are
not available until this is done:
1. Go to the Overland Storage web site
(http://www.overlandstorage.com/).
2. Click the Service & Support tab.
3. Select My Products tab > Register New Product.
4. At the Site Login, enter your e-mail address and
password (Figure 1).
NOTE: If you are not yet a member, click “New member?”
and follow the instructions given. It’s free and easy!
Figure 1. Support Site Login
5. Fill in the information and click Submit.
Within three business days, you will receive an e-mail
from Overland with your warranty certificate. Follow the
instructions included to complete the process.
Rack Installation
Before installing the disk drives, it is recommended that
the unit first be secured in the rack.
WARNING: Use care during rack installation or removal to
prevent accidental tipping of the rack causing damage or
personal injury.
AVERTISSEMENT: soyez prudent lors de l'installation ou
de l'enlèvement du support afin d'empêcher le
renversement accidentel de la crémaillère, pour éviter
dommages et blessures.
The rail kit included with the E2000 is adaptable for
installation in the two major types of hardware racks:
squared-holed and round-holed EIA-310 racks.
NOTE: A two-post telco-style rack or any rack that is less than
29-inches in depth will not support this appliance. Also, for
threaded-hole racks, Overland Storage recommends using a
shelf.
The rails are not universal. They are stamped LH (left)
and RH (right) and must be mounted on the appropriate
side (when facing the rack front).
Attach Inner Rails to Chassis
This procedure is required for all rack types:
1. Mark the screw holes on the rack where the rails will
be installed.
NOTE: Be sure rear holes are horizontally in line with the
front holes to ensure the unit remains level.
2. Remove the inner rail (Figure 2) from the rail set:
Figure 2. Inner Rail Release Latch
a. Fully extend the rail set.
b. Push the inner member latch down, and remove
the inner rail.
Inner Member Latch
Middle Member Latch
(Hidden)
Middle Member
Outer Member
*10400283003*

10400283-003 07/2010 ©2010 Overland Storage, Inc. Page 2 of 5
c. Release and slide the middle member back into
the outer member.
Figure 3. Inner Rail Release Latch
3. Attach the right inner member (Figure 4):
Figure 4. Attach Inner Rail Member to E2000
a. Facing the chassis, position the rail against the
right side of the appliance with the locking tabs
going through the holes on the rail.
b. Slide the rail toward the front to lock it.
This may require some force as it is a tight fit.
c. Secure the rail with its Phillips screw.
4. Repeat Step 3 to install the left inner member.
IMPORTANT: Depending on your rack type, continue with
either the “Square-Holed Rack Installation” or “Round-
Holed Rack Installation.”
Square-Holed Rack Installation
1. Attach the left outer rail to the rack (Figure 5):
Figure 5. Attaching Front of Rail
a. Position the rail against the inside of the rack front
rail with the hooks in line with the holes.
b. Insert the bracket front into the rack rail and
press down so that the hooks catch.
The spring-loaded tabs will extend into the hole to
prevent the rail from unhooking.
c. Slide the rear segment of the bracket rearward
until the hooks are in line with the correct holes.
d. Insert the bracket rear into the rack rail and press
down so that the hooks catch and the tabs lock.
2. Repeat Step 1 for the right slide rail assembly.
3. Verify that the rails are level and straight.
Continue with “Install the Unit in the Rack” on page 3.
Round-Holed Rack Installation
Before installing the rails onto an unthreaded round-
holed rack, the round-hole rail kit adaptors (Figure 6)
must be installed on the ends of the outer rails.
Figure 6. Round-Holed Rack Adaptors
1. Attach the adaptors (Figure 7) to both ends of the
rail:
Figure 7. Attach the Adaptor to the Front
a. Position the adaptor stamped “A” at the front of the
left outer rail (end with the graphic label).
NOTE: Make sure the stamp is at the top and the square
adaptor holes are aligned with the hooks on the outer rail.
b. Press the adaptor onto the hooks and slide it
upwards until it locks (clicks).
NOTE: The rail buttons will snap into the square holes.
c. Repeat Steps a–b for the left rear adaptor
(stamped “B”).
2. Facing the rack, position the left rail in the rack,
aligning the adaptor holes with the front left rack
holes being used (Figure 8 on page 3).
Middle Member Latch
Middle Member
Outer Member
Screw
Align Rear
Holes to Tabs
Hooks
Tab
A
B
(Front)
(Rear)
Adaptor
“A” Stamp

10400283-003 07/2010 ©2010 Overland Storage, Inc. Page 3 of 5
Figure 8. Using the Early Round-Hole Adaptors
3. Using the screws from the kit, secure the front of the
rail to the rack.
4. Slide the rear rail segment rearward until the rear
adaptor holes are in line with holes being used.
5. Using the screws from the kit, secure the rear of the
rail to the rack.
6. Repeat Steps 1–5 for the right rail.
7. Verify that the rails are level and straight.
Continue the installation with “Install the Unit in the
Rack.”
Install the Unit in the Rack
WARNING: It is recommended that a mechanical lifter (or
at least two people) be used during rack installation or
removal to prevent injury.
AVERTISSEMENT: pour éviter toute blessure il est
recommande qu'un monte-charge (ou deux personnes
au moins) soit utilisé lors de l'installation ou de l'enlèvement
du support.
1. At the front, extend the middle rail members until
they lock (click).
2. Confirm that the ball-bearing shuttles are at the
front (Figure 9).
Figure 9. Inserting Expansion Array Into Rack
3. Using a mechanical lifter or two people, insert the
appliance into the rack rails.
Lift the appliance to its install height and engage the
inner members on the appliance with the middle
members protruding from the rack, and slide the
appliance into the rack until it stops.
4. Slide the unit in and out a few times to ensure that
the expansion array does not bind.
If binding occurs, verify that the front and rear flanges
are mounted in the correct holes, readjusting the slide
positioning as necessary.
5. Using the two screws provided, secure the expansion
array flanges to the rack (Figure 10).
Figure 10. Secure the Expansion Array to Rack
Disk Drives
The E2000 comes without disk drives (they are sold
separately in singles and 4-packs) and can be configured
as noted here:
Recommended Drive Configurations
(SnapServer S2000 and N2000 only)
Before installing or adding drives to an E2000 array that
is used with either an N2000 or an S2000, the following
must be observed:
•Different capacity drives can be installed in the same
expansion array. However, they should not be
included in the same RAID array, because capacity
usage for all drives in the RAID is limited to the
capacity of the smallest drive member.
•Drives of different rotational speed (such as, SAS and
SATA drives) can be installed in the same expansion
array
(Figure 11) , but they should not be installed in
the same column or be separated from each other by a
column of different rotational speed drives
(Figure 12
on page 4)
. If you are combining drives with different
rotational speeds, use the figures below to plan where
to place the disk drives.
•Overland recommends grouping columns of drives of
the same speed next to each other when possible.
Bearing Shuttle
Server Drives Supported
SnapServer NAS N2000 A combination of 4 to 12 SAS
and/or SATA drives with blank
drive carriers filling in the
empty slots.
SnapServer SAN S2000
REO®4600 (VTL) 12 SATA drives*
* The REO 4600 does not support blank drive carriers.

10400283-003 07/2010 ©2010 Overland Storage, Inc. Page 4 of 5
Figure 11. Supported Drive Configurations
Figure 12. Unsupported Drive Configurations
Installing Drives
NOTE: Do not remove the disk drives from their carriers. Doing
so voids the drive warranty.
Once the unit is in the rack, install the drives. Initially,
the top row is empty and the other two rows are filled
with drive blanks. Remove as many blanks as needed:
1. If a drive blank is in the slot where you are about to
install a disk drive, remove the blank by pressing the
lever release button and pulling it out.
2. Remove a drive assembly from the packaging.
3. Press the button to release the lever.
4. With the button on the right, position the drive
assembly in front of the appropriate bay and slide it
in (Figure 13) until resistance is felt.
Figure 13. Inserting Drive Carriers
5. Push the lever in to lock the assembly in the bay.
6. Repeat Steps 1–5 for each remaining drive carriers.
IMPORTANT: To maintain proper airflow and cooling, a
drive assembly or a blank drive carrier must be installed
in every slot. No empty slots are allowed.
Attach the Bezel
Once the drives and blanks are installed, attach the front
bezel (Figure 14):
Figure 14. Attaching the Bezel
1. Insert the bezel tabs into the flange holes.
2. Push the other side in until it latches (clicks).
3. If desired, lock the bezel.
Cable Attachment
All cabling and power connections are located on the rear
panel of the E2000 expansion array (Figure 15). All
cooling exhaust is handled through the rear panel.
Figure 15. E2000 Rear Panel Connections
1. Plug the supplied SAS cable into the bottom SAS
Port (HOST) of the expansion array.
2. Plug the other end of the SAS cable into the SAS port
on the server or the top SAS Port (EXP) of another
existing E2000.
NOTE: If you are connecting additional E2000 arrays, the
SAS cable from a HOST port of the first array always
connects to the upper SAS Port (EXP) of the next array.
3. Attach the power cords to the AC Power sockets.
4. Plug the power cords into a UPS appliance or AC
power source.
Power Up the E2000
IMPORTANT: Always power up your E2000 expansion
arrays before powering up your head unit (if the head unit
is running, shut it down first). This enables the head unit to
discover all the attached expansion arrays.
Rotational Speed X
Rotational Speed Y
Do not include drives with
different RPMs in the
same column.
Drive Blanks
12
SAS Port
“EXP”
SAS Port
“HOST”

10400283-003 07/2010 ©2010 Overland Storage, Inc. Page 5 of 5
To turn the expansion array ON, press and hold the
Power button (Figure 16) for no more than one (1) second.
Figure 16. Power Button on Left Flange
After you turn the power ON, the system performs a
self-test process, which takes about a minute. When all
expansion arrays are ON and running, power up the
SnapServer or REO appliance.
You must leave all the expansion arrays ON while you
complete any additional configuration processes for your
application and backup media servers.
Verifying that the E2000 is Online
1. Launch a Web browser and enter the Server name
(or IP address) of the SnapServer or REO 4600 to
which the E2000 is connected.
2. Depending on your server, use the instructions in the
following table to verify that your server recognizes
the E2000 expansion array.
Your E2000 appears in the GUI as a 12-disk drive
chassis. Disk drives installed in the E2000 appear as
online disk drives in the correct physical position.
Unpopulated drive slots appear as offline disk drives
(N2000 and S2000 only).
Additional Configuration
Because the SnapServer Expansion E2000 array works
with different Overland disk products, you need to refer
to the appropriate user guide that comes with your
SnapServer or REO system for any special configuration
steps, the total number of expansion arrays that can be
attached, and for instructions on creating RAID arrays
and drive pools.
The SAN S2000 user guide is available online at:
http://support.overlandstorage.com/support/
snapserver-san.htm
The REO 4600 user guide is available online at:
http://support.overlandstorage.com/support/
reo-series.htm
The NAS N2000 user guide is available online at:
http://support.overlandstorage.com/support/
snapserver-nas.htm
Warranty & Service
Detailed Warranty Information
To view detailed warranty information for Overland
products, click Service > Warranty or follow this link:
http://support.overlandstorage.com/support/service-
coverage.html
Access Product Information
For detailed information about your products including
entitlement, under Support Home, select My Products >
View Products. Log in if you haven’t already done so.
For the answers to the most commonly asked questions,
select the appropriate product family page under
Downloads and FAQ’s tab.
General Help
For warranty and technical support information, see our
Contact Us web page:
http://www.overlandstorage.com/company/contact-us/
index.aspx
To search for more service information, visit our Expert
Knowledge Base System:
http://support.overlandstorage.com/kb
TIP: If you want to be notified whenever a change is made,
click Watch Category in the Tools box on the upper right
on the Knowledge Base sub-category pages.
Server Perform These Steps
SnapServer
NAS N2000
1. Click the Administration link and log in as
admin with your administrator password.
2. Navigate to the Storage > Disks/Units
screen.
SnapServer
SAN S2000
1. Log into the GUI as admin.
2. Navigate to the Devices screen.
REO®4600
(VTL)
1. Log into the GUI as Administrator.
2. Navigate to the System > Disk
Management screen.
Power
Button
You can get additional technical support on the Internet at http://support.overlandstorage.com, or by contacting
Overland Storage using the information found on the Contact Us page on our web site.
