OWL Intuition-lc User manual

© 2 Save Energy Limited 2013 1
Electricity consumption monitoring – three phase
for larger homes and light commercial premises
IN THE BOX:
3 x AA
alkaline battery
Getting started with
Transmitter unit
3 channel
3 x plug-in standard
Sensor clamp
(<10mm cable, <71A)
OR
3 x plug-in large
Sensor clamp
(<17mm cable, <200A)
MADE IN CHINA
MODEL : CMA1 1 6
WARNING
- RISK OF ELECTRICAL SHOCK
- Please Refer to User Manual.
x 3

2 © 2 Save Energy Limited 2013
Introduction
This Electricity Transmitter is a part of the OWL Intuition range of cloud connected moni-
toring and control products. Its operation is dependant upon being paired to the broad-
band Internet connected Network OWL (supplied separately).
This version of the Electricity Transmitter is designed for monitoring three phase electric-
ity consumption. It is suitable for use in larger homes and some smaller light commercial
premises.
Access to both live and historic energy information collected by this Transmitter is via the
OWL Intuition web dashboard, from any Internet connected computer anywhere in the
World. iPhone and Android smartphone apps are also available for free download.
For details on using your new OWL Intuition-lc system, please download the Electricity
Monitoring User Manual document by clicking on Support & Manuals on the web dashboard
(lower right).

© 2 Save Energy Limited 2013 3
Installation Instructions
Network OWL installed and online
The Network OWL should already be installed. Refer to the Network OWL Getting Started
guide for guidance if required. Check that it is powered-up and connected to the OWL
servers (the top green LED should be ashing in a “triple blip pattern”).
STEP ONE - Insert batteries into the Trans-
mitter
Slide back cover off of the Transmitter and insert the bat-
teries into the unit. Keep the Transmitter with you alongside
the Network OWL until Step Three. You should NOT t the
Sensors at this time.
INSERT 3 x AA BATTERY
PA RT NO. CMR180i
MADE IN CHINA

4 © 2 Save Energy Limited 2013
PA RT NO. CMR180i
MADE IN CHINA
STEP TWO - Pair Transmitter to the Network OWL
Ensure the Transmitter is next to the Network OWL.•
Unplug the power connector from the Network OWL for 2•
seconds and then plug it back in.
The green LED will ash rapidly. After about 30 seconds •
the blue LED will start a steady ash indicating that it is in
Pairing Mode.
Press the small “Check” button in the Transmitter battery •
compartment until the red LED on the front starts ashing.
The Transmitter is now in Pairing / Check Mode and the red•
LED on the front will start ashing every 2 seconds (for 30
seconds).
The pairing process will now take place and the blue LED•
on the Network OWL will start ashing a fraction of a sec-
ond after the red LED ashes on the Transmitter.
When the Transmitter Check Mode nishes, if the pairing •
was successful, the blue LED will ash every time it re-
ceives data from the Transmitter (every 12 to 60 seconds).
Replace battery compartment cover.•
PRESS
CHECK BUTTON

© 2 Save Energy Limited 2013 5
IMPORTANT Pairing Notes:
If you don’t complete the pairing process within 60 seconds of the Network OWL blue•
LED starting its steady ash, restart the process by removing and re-inserting the DC
power jack.
You can quickly check for correct pairing at any time by pressing the Transmitter•
“Check” button until the red LED starts ashing - if the Transmitter red LED and
Network OWL blue LED ash within a fraction of a second of each other, they are cor-
rectly paired.
If you remove / change the Transmitter batteries you will need to remove the existing•
pairing from the Network OWL and pair the Transmitter again.

6 © 2 Save Energy Limited 2013
STEP THREE - Install Transmitter and attach Sensors
Locate the supply cables between your electricity meter and mains distribution board•
(fuse box). See diagram on next page.
Using the latch, clamp the 3 Sensors around the insulated Live cables going into the•
meter as per the table below – Live cables either side of meter is acceptable.
The Sensors must be a loose t onto the cables.•
Plug the Sensors into the associated Transmitter socket.•
The Transmitter should be hung on the wall in a free area as far from large metal•
objects as possible.
Phase (Line)
Number
IEC 60446
Wire Colour
Pre 2004
IEE Colour
OWL Transmitter
Socket
1 Brown Red 1 - Left
2 Black Yellow 2 - Centre
3 Grey Blue 3 - Right

© 2 Save Energy Limited 2013 7
Electricity Grid
Fuse Box /
Distribution Board
Industrial
Loads
Ring Mains,
Lights,
Machines
etc
WARNING
- RISK OF ELECTRICAL SHOCK
- Please Refer to User Manual.
Alternative
Sensor
Locations
Utility Meter
WARNING
- RISK OF ELECTRICAL SHOCK
- Please Refer to User Manual.
WARNING
- RISK OF ELECTRICAL SHOCK
- Please Refer to User Manual.
Transmitter
P1 / L1
Sensor
P2 / L2
Sensor P3 / L3
Sensor
Neutral
Blue
P1 / L1
Brown Black
P2 / L2 P3 / L3
Grey
Intuition-lc
Transmitter & Sensor Installation

8 © 2 Save Energy Limited 2013
STEP FOUR - Update your OWL Intuition system type
Using the web browser on your computer open up the following page:• https://
www.owlintuition.com (this is a secure connection).
You should have previously created your account however you now need to repeat the•
process to update the system type.
Click “Create Account” •
Set the System Type as Intuition-lc•
Reuse your existing username and password. Ensure you tick the Account Exists box.•
Now enter the remaining information again, as requested (refer to the Network OWL•
Getting Started guide if you need an explanation of the information required).
Ensure your Network OWL is still online (the top green LED should be ashing in a •
“triple blip pattern”)
Press the “Create Account” button. •
Successful updating of your account conguration will be conrmed.•
Press the “Finish” button.•

© 2 Save Energy Limited 2013 9
STEP FIVE - Log in to your OWL Intuition account
Please now log in to your OWL Intuition account with your username and password at:
https://www.owlintuition.com
You should now have an Electricity and 3 Phase widget within your web dashboard.
•
If you watch these new widgets, you should see the live total consumption in the Elec-•
tricity widget and live individual phase consumption in the 3 Phase widget, updating
every 12 to 60 seconds.
Check the signal strength of the radio signal between your Transmitter and Network
•
Signal strength indicator Settings icon

10 © 2 Save Energy Limited 2013
OWL:
If the signal strength is only 1 or 2 bars, to reduce the chance of intermittent /•
inconsistent data reception it is suggested that you reposition the Network OWL
so that it is physically closer to the Transmitter.
The Network OWL should ideally be hung on the wall in a free area as far from•
large metal objects as possible. Position the antenna in a vertical orientation.
If necessary you can replace the Ethernet cable with a longer cable (up to 100•
meters long). If installing a long Ethernet cable is a problem, you can use a
“Powerline Range Extender” or “Wireless Range Extender” - please search for
these common products online.
For details on using your new OWL Intuition-lc system, please now download the
•
Electricity Monitoring User Manual document by clicking on Support & Manuals on the
web dashboard (lower right).
Please ensure you retain this document for future reference.
•

© 2 Save Energy Limited 2013 11
INFORMATION & TROUBLE SHOOTING TIPS
Unless the Transmitter is in Check Mode, the red LED does not ash, in order to pro-•
long battery life.
Check that the blue LED on the Network OWL ashes at least every 12 seconds if the
•
monitored electricity supply consumption is varying, or every 60 seconds when at a
steady state.
If the blue LED does not ash then the Transmitter signal is not being received or the
•
Transmitter Pairing has been lost. Undo the Transmitter’s Sensor and move them so
they are near to the Network OWL to conrm radio range is not an issue.
For wireless range testing you can make the Transmitter send its signal every 2 sec-
•
onds (for 30 seconds) by pressing the “Check” button in the battery compartment for
10 seconds. The red LED will ash with each transmission, the Network OWL blue LED
will ash to conrm the signal has been received.

12 © 2 Save Energy Limited 2013
SAFETY INFORMATION
To ensure that you use your product safely and correctly please read the warnings & safety
precautions below before installing your OWL Intuition Transmitter & Sensor.
This product uses a Type C current Sensor. Do not apply around or remove from haz-•
ardous LIVE conductors.
When tting the Sensor if in any doubt always contact a qualied electrician.•
Do not immerse the unit in water or other liquids. If you spill liquid over it, dry it im-•
mediately with a soft cloth.
Do not use or store the product in conditions that could adversely affect the product•
such as rain, snow, desert and magnetic elds.
Do not subject the product to excessive force, shock, dust, temperature or humidity.•
Keep the product away from heat sources - radiators, stoves, heaters etc.•
Do not use the product in or near water or in high moisture areas such as bathrooms.•
Do not tamper with the product’s internal components. This invalidates the warranty.•
Do not attempt to repair the product yourself.•
Contact the retailer or Customer Services if your product requires servicing.•
If the equipment is used in a manner not specied in this manual, the protection pro-•
vided by the equipment may be impaired.
Take care when handling all battery types. Batteries can cause injuries, burns or dam-•
age to property if they come into contact with conducting materials, heat, corrosive

© 2 Save Energy Limited 2013 13
materials or explosives.
Remove the batteries before storing the product for extended periods.•
Only use fresh batteries. Do not mix new and old batteries.•
Do not dispose of old batteries as unsorted municipal waste, only do so in accordance•
with your local waste disposal regulations.
When disposing of this product do so in accordance with your local waste disposal•
regulations.
CARING FOR YOUR PRODUCT
Before cleaning, disconnect the Sensor and remove the batteries from the Transmitter.•
Use a lightly dampened cloth. Do not use liquid or aerosol cleaning agents, benzene,•
thinners, abrasive or corrosive materials.
Do not scratch hard objects against the product.•
Do not leave discharged batteries in the product.•

14 © 2 Save Energy Limited 2013
SPECIFICATIONS
Transmitter dimensions 64mm x 95mm x 40mm
Sensor dimensions (max when closed) 50mm x 50mm x 30mm
Radio frequency band 433MHz unlicenced ISM band
Operating range Up to 30m (in free space)
Power source 3 x 1.5V Alkaline AA batteries
Operating temperature range 0°C to +40°C
Storage temperature range -25°C to +65°C
Relative humidity 25% to 95% non-condensing
COMPLIANCE
The CE marking certies that this product meets the main requirements of the European
Parliament and Council Directive 1999/5/EC. A copy of the signed and dated Declaration of
Conformity is available on request. OWL Intuition products are manufactured to ISO-9001
Quality Assurance Standards.

© 2 Save Energy Limited 2013 15
WARRANTY INFORMATION
2 Save Energy Limited guarantees that OWL Intuition products will work for a minimum
period of 24 months from date of purchase and that it will be free from defects in
materials, workmanship or design. If during this limited 2 year period of guarantee, from
date of purchase, you nd that the equipment is not working properly, you may return it to
us and we will replace, or, (at our discretion) repair it, free of charge.
2 Save Energy Limited will not accept any liability for defects arising from fair wear and
tear, accidental or wilful damage, misuse or failure to follow product or safety instructions
If you return any equipment as faulty, 2 Save Energy Limited reserves the right to test the
equipment and if found to be in perfect working order, to return it to you. In this event, 2
Save Energy Limited reserves the right to charge for any testing or postage costs incurred.
This does not affect your legal rights relating to equipment, which is faulty. Warranty
conditions only apply where Proof of Purchase is provided.
To return OWL Intuition product contact customer[email protected] to report the issue
and reason for returning your product. 2 Save Energy Limited will issue you a form and
reference number. Once we have received the completed form and proof of purchase we
will commence the returns process.

16 © 2 Save Energy Limited 2013
Customer Support
If you have any further questions please check our frequently asked questions at:
http://www.theowl.com/faqs.html
You can also email us at: [email protected]
(please ensure you state your Network OWL MAC ID)
2 Save Energy Limited operate a policy of continuous development and improvement,
therefore the content of this document is subject to change without notice.
Document Version 2.0 - February 2013
For details on using your new OWL Intuition-lc system, please download
the Electricity Monitoring User Manual document by clicking on Support &
Manuals on the web dashboard (lower right).
