OwlTech MW450 User manual
MW450 INSTALLATION MANUAL
Interface Description
Transmission Distance Reference
Item
Part
Feature
Remark
Power-On LED E On Power normal Should power supply irregular occurs, check if POE
switches are working properly, wiring is correct.
Off
Power abnormal
Microwave Signal
Strength Indicator H1 H2 H3 H4 H1 to H4 Flashing Cycle Receiving normal
Microwave Working
LED I
Flash
Microwave signal normal
If the microwave power indicate abnormal, you need
to contact the engineers, returned to factory for
repair.
Always On or OffMicrowave signal abnormal
LAN1 Working LED J
Flash LAN1 working properly
When LED is Always Off& Always On, please check if
network wiring and connectors are proper.
Always Off
LAN1 no access to network
Always On LAN1 excepon
LAN1 Working LED K
Flash
LAN2 working properly
Always OffLAN2 no access to network
Always On
LAN2 excepon
LAN1 Port M 1 x RJ-45 for 10/100 Mbps（802.3at/802.3af 48V POE）
LAN2 Port N
1
RX +
2 RX -
3
TX +
4 DC6V – 24V
5
DC6V – 24V
6 TX -
7
GND
8 GND
Reset R Reset to factory default status, default IP address is
192.168.188.253, status as MW450 mode (AP mode)
1 set MW450 Data Receiving Capability
Distance 0.8km 1.2km 2km
IPC qty. 16 1080P 8 1080P 1 1080P
Bandwidth 80M 50M 10M
1. Bandwidth and IPC quantity are reference only, above data are based on the tested data with this product and IPC at steady
operation, if there is an obstruction at site, or other microwave interference, then IPC quantity may need to be decreased in
according to the live situation.
2. 1 set of MW450R is able to receive up to 4 set MW450T data, please refer to above data table for the IPC total quantity with 4
set MW450 transmission, if there is an obstruction at site, or interference, 1 to 1 connection is recommended for stability.
3. Microwave relay is required if there is long distance, the total amount of data transferred depends on the distance in between
the last MW450T and MW450R.
H1 H2 H3 H4 I
E
M NR
J K
http://www.owltechcctv.com -1-
MW450R Setting Description
Device
Application
Connection
Device
Connection
Step 1
Step 2
MW450R Setting Connection Diagram
Log in - device default IP address is 192.168.188.253, or check with the device label for IP address.
Device reset to AP mode as shown below:
Enter the IP address of microwave device with IE, to enter the login screen.
User Name: admin
Password: admin
MW450T
MW450T MW450T
MW450T
MW450T
MW450R
MW450R
MW450R Computer
MW450R
MW450T
POE Switch
POE Switch
NVR
Router
Default IP address after reset: 192.168.188.253
Factory IP address shown at device label
Computer IP address set with the same network
segment of Microwave device: 192.168.1.188.2
Gateway set: 192.168.188.1
http://www.owltechcctv.com -2-
Step 3 Modify to fixed IP address, IP address can be self-defined, each microwave IP address must be different and in the
same network segment, it is recommended not to be in the same network segment with those network routers,
device will restart after modification, login again.
Step 4 Set up device name and password, as well as microwave frequency band.
http://www.owltechcctv.com -3-
1. Modify SSID name, set up in according to installation location and other information to facilitate future maintenance.
Each device needs to be set to a different name. Suggested name: project + location + IP address information.
2. Channel width of 10M / 20M / 40M / 80M selectable, factory default value is 40M, modification is not recommended.
3. 5G microwave analysis under device environment, recorded the surrounding 5G band status.
1
2
3
5
4
http://www.owltechcctv.com -4-
4. This device has 9 frequency bands to choose, set up the band in according to the frequency band environment
analysis, 1 band interval with existing bands is suggested.
5. Modify the encrypted password.
Note: remember the settings for 2, 3, 4 and 5 are the same to corresponding MW450R and MW450T.
Step 5 Set up AP+WDS
MW450T Setting Description
Device
Connection
Step 1
Step 2
MW450T Setting Connection Diagram
Log in - device default IP address is 192.168.188.253, or check with the device label for IP address.
Device reset to AP mode as shown in the
figure
Enter the IP address of microwave device with IE, to enter the login screen.
User Name: admin
Password: admin
MW450T
MW450R
Computer
POE Switch
Default IP address after reset: 192.168.188.253
Factory IP address shown at device label
Computer IP address set with the same network
segment of Microwave device: 192.168.1.188.2
Gateway set: 192.168.188.1
Noted that when doing MW450T setting, make sure MW450R setting
is completed and powered, Need to know the SSID and passwor of
such MW450R, but should not be at the same network segment as
MW450T.
(need to know device name and password when MW450R setting is
completed)
http://www.owltechcctv.com -5-
Step 3
Step 5
Modify to fixed IP address, IP address can be self-defined, each microwave IP address must be different and in the
same network segment, it is recommended not to be in the same network segment with those network routers,
device will restart after modification, login again.
Step 4 Set up device name and password, as well as microwave frequency band.
Set up AP+WDS
1. Modify SSID name, set up in according to installation location and other information to facilitate future maintenance.
Each device needs to be set to a different name. Suggested name: project + location + IP address information.
Note: settings 2, 3, 5 are the same as the settings of corresponding MW450R
http://www.owltechcctv.com -6-
1
2
3
5
4
MAC Binding Setup Description
http://www.owltechcctv.com -7-
Step 1
Step 3
Enter MW450R setup interface to pair with the MAC address of MW450T, max. up to 4 MW450T.
Step 2 Enter MW450T setup interface to pair with the MAC address of MW450R, note that only 1 MW450R.
Check the signal connection strength of MW450T and MW450R, this parameter can be used as reference for angle
adjustment during installation.
Network Cable Wiring Configuration
MW450R/T Microwave connection
Method 2: external power (power need to be above DC12V 2A)
Pin #
1
2
3
6
4
5
7
8
Wire Color
White/Orange
Orange
White/Green
Green
Blue
White/Blue
White/Brown
Brown
Signal
RX+
RX-
TX+
TX-
DC6-24V
DC6-24V
GND
GND
MW450R/T
MW450R/T
POE Switch
Method 1: connected to POE switch directly
1
2
3
6
4
5
7
8
DC6V-24V
GND
http://www.owltechcctv.com -8-
Switch ( Not POE )
Relay connection
Method 1: connected to POE switch directly
Method 2: external power (support 2pcs MW450 at the same time,
power need to be above DC12V 4A)
MW450T MW450R
POE Switch
Pin #
1
2
3
6
4
5
7
8
Wire Color
White/Orange
Orange
White/Green
Green
Blue
White/Blue
White/Brown
Brown
Signal
RX+
RX-
TX+
TX-
DC6-24V
DC6-24V
GND
GND
MW450T MW450R
1
2
3
6
4
5
7
8
DC6V-24V
4
5
7
8
GND
http://www.owltechcctv.com -9-
