OXO MultiBEAM LED-Variable White-Zoom User manual

MultiBEAM LED-Variable
White-Zoom
KEEP THIS MANUAL FOR FUTURE NEEDS ( E
All manuals and user guides at all-guides.com
all-guides.com

Thank you for your patronage. We are confident that our excellent products and service can
satisfy you.
Foryour own safety,please r~ad this user manual carefullybefore installing the device.
CAUTION
Keep this device away from rain and moisture
CAUTION
Unplug mainslead bef<:>reopening the housing.
Every person involved with the installation,operation and maintenance of this device has to
- be qualified
- follow the instructions of thismanual
-consider this manual to be part of the total product
- keep this manual for the entire service life of the product
- pass this manual on to every further owner or user of the product
- download the latestversion of the user manual from theInternet
Thank you for having chosen thisprofessional LED lighting.
Youwill see you have acquiredapowerful andversatiledevice.
Unpack the device. Insidethe box you should find:
1. Thefixture device
2. Onepower cables
3. One XLR connection cable
4.One safety rope and this manual
Belows are the optional accessories, please purchase from your local dealer if needed
1.Barn-door
2.Frost filter
Please check carefullythat thereisno damage caused bytransportation. Should there beany,
consult your dealer and don't install this device .
•DMX channel: 6 channels
• Equippedwith 36x3WLEOS: 12 x Cool-White,24x Warm-White
•100 000 hoursLED life
• The LEOScan be controlled individually
• Automatic power supplyadaption between 100V and 240 Volts without power selector
•Programmable color-change speed and strobe effect
All manuals and user guides at all-guides.com

• DMX-controlled operation or stand alone operation with Master/Slave-function
• Strobe-effect with I-18 flashes per second
• Advantages ofLED-technology:Extremelylonglife,19wpowerconsumption,minimal heat emission,defact
maintenance free with brilliant light radiation
•DMX-control via everystandard DMX-controller
(1) Housing
(2)LEDS
(3) Floor-stand
(4)Menu-button
(5) Up-button
(6)Down-button
(7)Enter-button
(8) Power input
(9)DMX output
(lO)DMX-input
CAUTION
Be careful with youroperations.With a dangerous voltageyou can
Suffer a dangerous electric shockwhen touching wires
Thisdevice has left the factoryin perfect condition.In order to maintain this condition and to
ensure a safe operation,it is absolutelynecessaryfortheuser to follow the safetyinstructionsand
warning notes written in this user manual.
All manuals and user guides at all-guides.com

~.
Important:
Damages caused bythe disregard of this user manual are not subject towarranty.Thedealer
will not acceptliability foranyresultingdefects orproblems.
If the device has been exposed to temperaturechanges due to environmental changes,do not
switch it on immediately. The arising condensation could damage the device.Leave the device
switched off until it has reached room temperature.
Thisdevicefallsunder protection-class I. Thereforeit isessential that thedevice be earthed.
Theelectric connection must carryout byqualifiedperson.
Thedevice shall onlybe used with rate voltageand frequency.
Make sure that the available voltage is not higher than stated at the end of this manual.
Make sure the powercord is never crimped or damaged by sharp edges.Ifthis would be the case,
replacement of the cable must bedonebyan authorized dealer.
Always disconnect from the mains,whenthedeviceis not inuse or beforecleaningit. Only
handlethe power cord bythe plug.Never pull out the plugbytugging the power cord.
During initial start-up some smoke or smell may arise.This is a normal process and does not
necessarily mean that the device is defective,it should decrease gradually.
Fixturescannot be installed on combustible substances,keep more than30cm distance with wall
forsmooth air flow,so there should be noshelter for fans and ventilation for heat radiation.
If the external flexible cable or cord of thisluminaire is damaged, it shall beexclusively replaced
bythe manufactureror his serviceagent or a similar qualified person in order to avoid a hazard.
-. Never touch thedeviceduringoperation
Thehousingmayheat up
Never look directly into thelight source,
as sensitive personsmaysuffer an epileptic shock.
Please be aware that damages caused bymanual modifications tothe device are notsubject to
warranty. Keep awayfrom children and non-professionals.
Thisdevice is a lighting effectfor professional use on stages,in discotheques,theatres,etc.
Thisfixture is only allowed tobe operated with themax alternating current which stated in the
technicalspecificationsin the last page of thismanual,the device was designed for indoor use
only.
All manuals and user guides at all-guides.com

Lighting effects are not designed for permanent operation. Consistent operation breaks may
ensure that the device will serveyou for a long time without defects.Do not shake the device.
Avoid brute force when installing or operating the device.
The device shall only be used complete with its protective shield.
While choosing the installation-spot,please make sure that the device isnot exposed to extreme
heat,moisture or dust. The minimum distancebetween light-output from the projector and the
illuminatedsurface must be more than 0.1 meter.
Operate the device onlyafter having familiarized with its functions. Do not permit operation by
persons not qualified for operating the device.Most damages are the result of unprofessional
operation.
Please use the original packaging if the device is tobe transported.
For safetyreasons,please be aware that all modifications on thedevice are forbidden.
If this device will be operated in any way different to the one described in this manual,the
product may suffer damages and the guarantee becomes void. Furthermore,any other operation
maylead to short-circuit,burns,electric shock,lamp explosion,crash,etc.
CAlJTIO~
Please consider the GB7000.15 EN60598-2-17 and the other respectivenational noID1S during
theinstallation. The installation must only be carried out by aqualified person.
The applicable temperature for the lignting is between _25
0
C to 45
0
C. Do notuse the lighting
under or above the temperature.
The installation of the effect has to be built and constructed in a way that it can hold 10 times the
weight for 1 hour without anyharmingdeformation.
The installation must always be secured with a secondarysafetyattachment,e.g. an appropriate
safety rope.
The operator has to make sure the safety relating and machine technical installations are approved
byan expert beforetakingthe device into operation for the first time.
These installationshaveto be approved by a skilled person onceayear.
All manuals and user guides at all-guides.com

CAUTION
Before takinginto operation for the first time,
the installation has to be approved by an expert.
Cautions:
The effect should beinstalledoutsideareas where personsmay reach it,walk by or be seated.
CAUTION
When installing the device,make sure there isno highly
inflammable material within adistance ofmin. O,3m.
Overhead mounting requires extensive experience,including amongst others calculating working
loadlimits,installation material beingused, and periodic safety inspection of all installation
materialand the device. If youlack these qualifications,do not attempt the installationyourself.
Improper installation can result in bodilyinjury.
Beforemounting make sure that the installationarea can hold a minimum point load of 10 times
the device's weight.
Connect the fixture to themains with the power plug.
Screw the bolt ofthe clamp intothehold ofthebracket,and tighten the screw underneath.
Pull the safety-ropethrough theholes on the bracket of thebase and over the trussing system or a
safefixation spot. Insert the endin thecarabine and tighten the safety screw.
All manuals and user guides at all-guides.com
all-guides.com

Connect the provided XLR c;able to the female 3-pin XLR output of your controller and the other
side to the male 3-pin XLR input of the LED lighting. You can chain multiple LED lighting
together through serial linking.The cable needed should be two core, screened cablewith XLR
input and output connectors. Please refer to thediagram below.
DMXoutput
3-Pin XLR Socket DMX Input
3-Pin XLR Socket
~
2 1: Ground
•i. 2: Signal (-)
3: Signal (+)
DMX-512connection with DMX terminator
For installationswhere the DMXcablehasto run a longdistance or isin an electricallynoisy
environment,such as in a discotheque,it is recommended touse aDMXterminator. This helpsin
preventing corruption of the digital control signal by electrical noise. The DMX terminator is
simplyan XLR plug with a 120 Q resistor connected between pins 2 and 3,which isthen plugged
into theoutput XLR socketof thelast fixturein the chain.Please see illustrationsbelow.
120 Q
~
PIN 3
PIN 2
Projector DMX starting address selection
All fixtures should begivenaDMX startingaddress when using a DMXsignal,sothat the
correct fixtureresponds tothe correct control signals. Thisdigital starting address isthe channel
number from which the fixturestarts to"listen"to the digital control information sent out from
the DMX controller. The allocation of thisstarting address is achieved by setting the correct
number on the displaylocatedon the base of the device.
All manuals and user guides at all-guides.com

You can set the same starting address for all fixtures or a group of fixtures,or make different
addressfor each fixture individually.
[fyou set the same address,all the units will start to "li.sten"to the same control signal from the
same channel number.In other words,changing the settings of one channel will affect all the
fixtures simultaneously.
If you set a different address,each unit will start to "listen"to the channel number you have set,
based on the quantityof control channels of the unit.That means changing the settings of one
channelwill affect onlythe selected fixture.
[n the case of the led lighting,which is 6 channelsfixture when you select the standard channel
mode,you should set the startingaddress of the first unit to 1,the second unit to 7 (6+ 1),the
third unit to 13(6+ 7),and so on.
The Control Board offersseveral features: youcansimply set thestartingaddress,switch on and off thelamp,
run thepre-programmed program or makea reset.
The main menu is accessed bypressing the Menu-button until thedisplaystarts flashing.Browse through the
menu bypressingtheUp-button or Down-button.Press the Enter-button in order to select thedesired menu.
You can change the selection bypressingthe Up-button or Down-button. Confirm every selection by pressing
the Enter-button.You can leaveeverymodebypressing the Menu-button.The functions provided are
described in thefollowingsections.
Locked keys as default setting when starting up, press Meun key for 3 seconds to unlock.
The displaywill be locked automaticallywithout anyoperations in 15 seconds.
All manuals and user guides at all-guides.com

VALU
liJIII-xxx
(AXXX) DMX address setting
SLAV ONlI_(SLAV) Slave setting
ADDR
II/OFF C,hange DMX address via
RDMX external controller
Automatic Run III Stand
ALON (AU-A)
RUN AUTO Alone
0MODE MAST (AU-M) Automatic Run as Master
1~'I\j(DXXX) Display the DMX
512 value
VALU D-XX of each channel
DISP FLIP ON/III Reverse display
DON II/oFF Shut off LED display
LOCK Ill/OFF Key lock
,w ,r
iiiZ ik1~iiZ4i
FAIL OFFII.II/AUTO No DMX Status
REST Reset
1
SET DFSE
ONIIII
Restore factory settings
PO'vver on to preservethe
POHOMANL data
VER V-l.O~ V-9.9Software version
<COOL II XXX (000-255)
WARM XXX
(000-255)
TEMP I XXX (000-255)
2 MANL
I XXX (000-255)
Manual adjust intensity
STRB
DIMM 14 XXX (000-255)
ZOOM> I XXX (000-255)
LIFE OOOO~9999(hours) Fixture running time
3
TIME Clear fixture time *code is
CLFE "838"
STEP S-Ol ~.~
Steps of Program Run
REC. RE.XX Auto Save Scene
COOL I XXX (000-255)
WARM XXX (000-255)
TEMP XXX
(000-255)
4EDIT ~XXX
(000-255)
Edit the internal scenes
SCOl STRB
~SC48 DIMM
I XXX (000-255)
ZOOM I XXX (000-255)
TIME LXXX(OO 1 ~999) Time for each scene
CEDT /lli\1ili SJEdit program via controller
,,,,,,,,m,,
All manuals and user guides at all-guides.com

lEd 11:1
I. Press [MODEIESC] to enterthemain menu "MODE " (displayflashing)
2.Press [ENTER] and select "ADDR","RUN" or "DISP" bypressing [UP] or [DOWN]button.
3.Press[ENTER] for selecting the desired sub menu.
With this function, you can adjust the desired DMX-addressvia the Control Board.
l. Select "VALU" by pressing[UP] or [DOWN] button.
2. Press[ENTER], adjust theDMX address bypressing[UP] or [DOWN]button.
3.Press [ENTER] to confirm or-pressing [MODE/ESC] toreturn to main menu.
l
ei ell I
_/1 I II_ _ Slave setting
With this function, you can define the device as slave.
l. Select "SLAV" bypressing[UP] or [DOWN]button.
2.Press [E~TER], the display shows "ON" or"OFF"_
3. Press[UP)toselect "0"ifyou wish to enable this functionor press [DOWN] to select "OFF" if you
don't.
4.Press [ENTER] to confirm orpress [MODEIESC] to return tomain menu.
All manuals and user guides at all-guides.com

With this function, you can adjust the desired DMX-addressvia an exte\TIal controller.
Thisfunction canonlybe activated when the DMX-valueof all other channels is set to "0"on the
controller.
Select "RDMX"bypressing [UP] or [DOWN].
Press [ENTER], the display shows "ON" or "OFF".
Press [UP] to select "ON"if you wish to enable this function or [DOWN] to select "OFF"if you don't.
Press [MODE/ESC) to confirm.
Press [ENTER] in order to return to the main menu.
[,-unl_ Program Run, Master setting
With the function "RUN",you can run the internal program. You can set thenumber ofsteps under Step. You
can edit the individual scenes under Edit. You can run theindividualscenes either automatically (AUTO),i.e.
with theadjusted Step-Time.The selection "ALON" means Stand Alone-modeand "MAST" that the device is
defined as master.
1. Select "AUTO" bypressing [UP] or[DOWN] button.
2.Press [ENTER] for selecting the desired extension menu.
3.Select "ALON" or "MAST" bypressing[UP] or [DOWN] button.
4.Press [ENTER] to confirm or Press [MODEIESC) to return to the main menu.
I' '501
o ,-' _ Display the DMX-value,Reverse display, Shut off LED display
With this function you can displaythe DMX 512 value of each channel.
1. Select "VALU" by pressing [UP] or [DOWN] button.
2. Press [ENTER] to confirm;the display shows"D-OO".In this setting,the DMX-adjustment of every
channel will be displayed.
3. Press [UP] or [DOWN] button in order to select the desired channel. If you select "D-12" the display will
onlyshow the DMX-value of theI t
hchannel.
4. Press [ENTER] to confirm or Press [MODE/ESC) to return to the main menu.
5.Thedisplay shows "D- XX", "X"stands for the DMX-value of the selected channel.
All manuals and user guides at all-guides.com
all-guides.com

I
F' , °1
,- I I _ Reverse display
With thisfunction you ~an rotate thedisplay by180
0
I.Select "FLIP" bypressing[UP] or [DOWN] button.
2. Press [ENTER], the displayshows "ON" or "OFF".
3.Press [UP] to select "ON" if you wish to enable this function or press [DOWN] button to "OFF" if you
don't;the display will rotate by180
0•
4.Press [ENTER) to confirm or Press [MODE/ESC] to return to the main menu.
Id 0111_ Shut off LED display
With this function you can shut off the LED display after 2 minutes.
I.Select "D ON" by pressing [UP] or [DOWN] button.
2. Press [ENTER], the display shows "ON" or "OFF".
3.Press [UP] to select "ON" if you wish to enable this function or press [DOWN] button to "OFF" if you
don't.
4.Press [ENTER] to conflfm or Press [MODE/ESC] to return to the main menu.
Withthisfunction youcan locked keys the display.
I. Select" LOCK" by pressing [PIor[DOWNIbutton.
2.Press [ENTERI. the display shows "0;\'''or "OFF".
3. Press [UP] toselect "O:\'''ifyouwishto enable this functionor press[DOWNI button to "OFF" ifyou don't.
4. Press [ENTERI toconfirm or Press [MODEIESq to return to themain menu.
,-,-, I
:J C C _Main menu 1
I
I I ',E-,-1
,_,
I' , ", I I C10I
,_,- I.U -u--,._,
1.Press [MODE/ESC] to enter the main menu (display flashing).
2. Press [UP) or [DOWN] button.to select "SET".
With thisfunction you can automatic run the device byno DMX.
I.Select "FAIL"by pressing [UP] or [DOWN] button.
2.Press [ENTER], thedisplay shows "OFF","HOLD"or "AUTO".
3.Press [UP] or [DOWN] button to select"OFF", "HOLD"or "AUTO", the default is "HOLD".
4. Press [ENTER] to confirm or Press [MODE/ESC] to return to the main menu.
All manuals and user guides at all-guides.com

1,- E S,= 1_ Reset
With thisfunction.you can reset the device viathe Control Board.
. Select "REST"by pressing[UP] or [DOWN]button.
I.Press [ENTER] to reset or Press [MODE/ESC] toreturn tothemain menu.
I"5-'-1
0'- - C - Restore factory settings
With this functionyou can restore thefactorysettings of the device. All settings will be set back to thedefault
values (shaded).Any editedscenes will belost.
1.Select"DFSE"bypressing[UP] or [DOWN] button.
2. Press [ENTER], the display shows "ON" or "OFF".
3.Press [UP] to select "ON" if you wish to enablethisfunction or press [DOWN] button to"OFF" if you
don't.
4.Press [ENTER] to confIrm or Press [MODEIESC] to returnto the main menu.
-PowerontopreservetheMANLdata
With this function Power on to preserve the MANL data.
1.Select "POHO" by pressing [UP] or[DOW~] button.
") Press [ENTER],the display shows "ON" or "OFF".
3.Press [UP] toselect"OFF" if you don·t.or press [DOWN] button to "ON" if you wish to enable this
function.
4.Press [ENTER] to confirm orPress [YIEND]to return to the main menu.
I III.: -I
'-"- '- Software version
With thisfunctionyou can display the software version ofthe device.
I. Select "VER" bypressing [UP] or [DOWN] button.
2.Press [ENTER], Thedisplay will show "V-XX", "XX"stands for the ersion number,suchas thedisplay
mayalso show,"V-l.O","V-9.9"etc.
3.Press [ENTER] to confIrm or Press [MODEIESC] toreturnto the main menu.
Withthisfunctionyoucan Manualadjust intensity
I.Select "MANL"bypressing[UPI orIDOWNIbutton.
2.Press [ENTER , thedisplayshows"COOL", "WARM","TEMP", "STRB","D[\[\I", "ZOOM" .
3.Press[UPI or[DOWNIbutton toselect"COOL","WARM", "TEMP" , "STRB","01\[\1","ZOOM" .
4. Press[ENTER] to confirm or Press IMODE/ESq to return to the mainmenu.
All manuals and user guides at all-guides.com

1
1- lIiE-1 I' ',,-CI_/l,,/I/I QOOCI
'- "' _ -,_, ,- L '-' L"_"_' - ~ _, _Cf
1
- '-E-I- /I,i / "F-F-
L L ,- . LII' ,_,
I.Press [MODEIESC] to enter the main menu (display flashing).
2.Press [UP] or [DOWN] button to select "TIME".
I'
"-CI
L' ,- L _ Fixture running time
With this function you can display the running time of the device.
I.Select "LIFE" bypressing [UP] or [DOWN] button.
2. Press [ENTER], the display shows "XXXX","X"stands for the number of hours.
3.Press [ENTER] to confirmor Press [MODE/ESC] to return to themain menu.
1'-'
'-CI
L L ,- L _Clear fixture time
With thisfunction youcanclear the runningtime of the device.
I.Select"CLFE"bypressing[UP] or [DOWN] button.
2. Press[ENTER], the displayshows"ON"or "OFF",The code is"838".
3.Press[UP] toselect "ON" ifyouwishto enable this function or press[DOWN] button to"OFF"if you
don't.
4.Press [ENTER] to confirm or Press [MODE/ESC] to return to the main menu.
11::- , '1-1-ISLcPI-ls-1' '-S-'-J':ll
0'_ _'_L _ u, _ 0
,
~lc""1
~-""_"_"
le"-I,, '1- [- n,"l, -In, 11"1 - ='''i SI
=,_ '-" UUl.. ULll-l , _
I,~ d : '= 1- Main menu 4
I. Press[MODE/ESC] to enter the main menu (display flashing).
2.Press[UP] or [DOWN] button to select "EDIT".
I
'-LCP
.:I L L _Define the number of steps in Run
With this function you can define the number of steps in theProgram
Run.
I.Select"STEP" bypressing[UP] or [DOWN] button.
2.Press[ENTER], thedisplayshows"S-XX","X"standsfor the
total amount of stepsyou want to save,soyoucan call up to 48
scenesin "RUN".For exampleif the "XX"is05,itmeansthat
"RUN" will run the first 5 scenes you saved in "EDfT".
3.Press [ENTER] toconfirm or Press[MODEIESC] toreturn to
themain menu.
All manuals and user guides at all-guides.com

I,- E [I-Auto.Save
With thisfunctionyou can automatic save thenumber of stepsin theProgram Run.
1. Select "REC"bypressing [UP] or [DOWN] button.
2.Press [ENTER], thedisplayshows "RE.XX","XX" stands for thenumber from I to 400.
3.Press [ENTER] to confmn or Press [MODEIESC] to return tothemain menu.
a) Editing via the Control Board
1. Select "SCOt" bypressing[UP] or [DOWN] button.
2. Press[ENTER], the display shows "SCXX","X"stands forthe sceneno.to be edited.
3.Select the channel no.you would like toedit bypressing[UP] or [DOWN] button.
4.Adjust the desired DMX valuebypressing [UP] or [DOWN] button.
5.Press [ENTER] in order to edit other channels of thisscene.
6.Repeat steps 3-5 until you finish setting all the DMX valuesfor all channels of this scene.
7. Once all thechannels completed,the displaywill flash"TIME"
8.Press [ENTER] toedit thetimeneeded,thedisplayshows "TXXX" ,"XXX" standsfor thetimeneeded
to run thecurrent scene,value "001-999".E.g.,"002"meansyou need OAms (002*O.2ms) to run thecurrent
scene.Adjust the desired timebypressing [UP] or [DOWN] button.
9.Press [ENTER] to save the settings for thescene you are editing,the displaywill change to the nextscene
automatically.
10.Repeat step3-8 to edit and otherscenes,youcanedit and save a maximumof 48scenes.
II. Press[MODEIESC] to exit. The numberof stepscan be defmed under"STEP"and thescenescan be
called up under "RUN".
b) Editing via the external controller
Call up the first scene in your controller now.
1. Select "SCOt" bypressing[UP] or [DOWN)button.
2.Press [ENTER], thedisplay shows "SCOt".
3.Press [ENTER], the display shows "COOL".
4.Select "CEDT" bypressing [UP) or [DOWN) button.
5.Press [ENTER], thedisplayshows "OFF".
6.Press [UP) or [DOWN) button.the displayshows"ON".
7.Press [ENTER], the displayshows "SC02". You successfullydownloaded the firstscene.
8. Adjust theStep-time as described above under point 12.
9. Call up the second scene in your controller now.
I O.Repeat steps5-11 until all desiredscenesaredownloaded.
11. Press [MODE/ESC] to exit.Thenumberof stepscan bedefined under"STEP"and the scenes can be
called up under"RUN".
All manuals and user guides at all-guides.com

DMX channel's functions and their values (6 DMX channels):
Channel Value Function
St
Cool White
10-255 CoolWhite (O-Black,255-100% Cool White)
Warm White
20-255 Warm White (O-Black,255-100% Warm White)
Color temperature:
0-10 NoFunction
II-50 NoFunction
51-90Co lor_temperature(3200K)
391-130Color temperature( 4300K)
131-170 Color temperature(5600K)
171-210 Color temperature(6500K)
211-250 Color_temperature(7200K)
251-255 No Function
Shutter, strobe:
0-31 Led trun off
32-63Led turnon
64-95 Strobeeffect slowto fast
4
96-127 Led turn on
128-159 Pulse-effect in sequences
160- 191Ledturn on
192-223 Randomstrobe effectslow to fast
224-255Led turn on
General Dimming
50-255 Dimming( O-Black,255- 100% )
Zoom
60-255 Continuous adjustment from nearto far
All manuals and user guides at all-guides.com
all-guides.com

Instructions for installing the barn-door and frost filter:
For thisdevice,the bar door and the frost filtercan beinstalledseparatelyor together.
I. Whenonly installthe frostfilter,use the rotating clips on thelenscover tofixit.
2.Whenonlyinstall thebar door,loose the 2 M4 screws onthe lens cover,put on thebar door and tighten the
screws.
3.When install the bar doorand frostfilter together,loose the 2 M4 screws,put on the frostfilterand the bar
door onebyone,then tighten the screws.
CLEANINGANDMAINTENANCE
We recommend a frequent cleaning of thedevice. Please use asoft lint-free and moistened cloth.
Never use alcoholorsolvents
CAUTION
Disconnect from mains before startingmaintenance operation.
There are no servicable parts inside the device. Maintenance and service operations areonlyto be
carried out by authorized dealers.
Should you need any sparepat1s,please use genuineparts.
Ifthe power supplycable of thisdevice becomes damaged,it hastobe replaced byauthorized
dealers onlyin orderto avoid hazards.
Should you have furtherquestions,please contact yourdealer.
INSTALLATION
Thisdevice is only constructedfor a standinginstallation.The device mustonlybeinstalled
absolutelyplanar at a vibration-free,oscilation-free and fire-resistant location. Make sure that the
device isinstalled absolutelyplanar byusing a water-level.
All manuals and user guides at all-guides.com

TECHNICAL SPECIFICATIONS
Power supply:AC 100Y-240Y-,50/60Hz
Power consumption: max. 120 W
Packing dimensions: 40x 30x48 CM
Flight case dimensions:79x76.5x60 cm
Net weight: 7 KGS
Gross weight: 10KGS (carton packing)75.5 KGS(flight case packing/6pcs)
Remark: errors and omissions for everyinformation given in this manual except. All information
is subject to change without prior notice.
All manuals and user guides at all-guides.com
