Ozito SSH-2440 User manual

SILENT
SHREDDER
2400W
SPECIFICATIONS
Power Rating: 2400W (S6 40%), 2000W (S1)
No Load Speed: 40/min
Max. Cutting: Ø40mm
Noise Level: 93 dB
Blades: Roller Cutting System
Collection Bag: 64 litre
Protection Class: 1 (Earthed Appliance)
Weight: 23 kg
SSH-2440
STANDARD EQUIPMENT
WARRANTY
0318
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts and included accessories, for
example: Rolling cutter head and plate, collection bag and wheels.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the
goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
ozito.com.au
INSTRUCTION MANUAL
Shredder
Housing
Support Legs x 2
Wheels x 2 Wheel Axle
Hub Caps x 2
Collection BagWheel Plug x 2
Nut & Washer x 6 Hex Key
Hex WrenchBolt x 2

3
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
After removing the silent shredder from the
carton, check that the shredder has not
been damaged. Unpack the contents.
Fitting the wheels and stand
1. Carefully place the shredder housing
upside down on a at surface.
2. Place each leg over the 2 threads
on the base of the shredder
housing. For maximum stability
ensure that the legs are facing
outwards.
3. Place a at washer followed by the
nut over each of the 4 threads. Lightly
tighten using the hex wrench supplied.
4. Fit the wheel axle to the base of the
legs ensuring that it is positioned
towards the rear of
the shredder.
1. On/off switch
2. Transport handle
3. Reset button/overload protector
4. Direction control switch
5. Hopper
6. Cutting adjustment Knob
7. Discharge chute
8. Stand
9. Wheels
10. Collection bag
11. Hex key
12. Hex wrench
SILENT SHREDDER
ACCESSORIES
KNOW YOUR PRODUCT
1. WHEELS & STAND
ASSEMBLY
2 41 3 5
10 11 12
WARNING! YOU MAY REQUIRE ASSISTANCE
LIFTING THE SHREDDER OUT OF THE CARTON.
6
7
8
9
WARNING!: ENSURE THE TOOL IS TURNED OFF
AND DISCONNECT FROM THE POWER SUPPLY
BEFORE PERFORMING ANY OF THE FOLLOWING
OPERATIONS.

9. Fit a wheel plug onto each
end of the axle to secure
the wheels on the axle.
Use a rubber mallet (not
included) and lightly tap the
plugs into position on the
axle.
10.Push the hub caps onto the
centre of the wheels so it
clicks into place.
11. Once fully assembled,
carefully lift the shredder
into its correct position
supported by the stand and
wheels..
5. Secure the axle onto the legs
using 2 bolts, nuts & washers.
a. Place the bolt through the hole
in the axle followed by the leg.
b. Fit a at washer over each bolt, attach
the nut onto the bolt and tighten using
the hex wrench and hex key (only
partially tighten at this stage).
c. Repeat for the opposite leg.
6. Securely tighten the 4 nuts on the
base of the shredder followed by
the 2 bolts & Nuts on the wheel
axle.
Ensure the stand and axle are
secure and do not wobble.
7. Fit a wheel onto each side
of the axle.

2. ADJUSTING THE PLATE 3. STARTING
SETUP & PREPARATION OPERATION
WARNING! THE DIRECTION CONTROL SWITCH
CAN ONLY BE USED WHEN THE SHREDDER IS
TURNED OFF.
Prior to operation
The shredder operates by using a rolling cutter head, the cutter head
rotates and pulls the material past a metal plate which grinds and cuts
the material.
Prior to operation the metal plate will need to be adjusted to ensure
efcient performance. Adjust the metal plate as follows:
1. Press the rotation direction switch
so it is set to the feed position.
2. Turn on the shredder by pressing the green
ON button “I” on the on/off switch.
3. Using the cutting adjustment knob located
on the right-hand side of the shredder (when
viewed from the rear).
Note: Rotating the knob in a clockwise direction
will move the metal plate closer to the rolling
cutter head, rotating in an anti-clockwise
direction will move the metal plate away from the cutter head.
4. With the motor running slowly
adjust the cutting adjustment knob
by turning in a clockwise direction,
continue to do this until a scraping
noise is heard (metal plate making
contact with the cutter head). Fine
metal shavings will fall from the
discharge chute.
5. As soon as the scraping noise is
heard rotate the adjustment knob anti-clockwise 1/4 of a turn. Ensure
that the metal plate is not making contact with the cutter head.
Note: Do not overtighten as may lead to metal plate being cracked.
6. Once adjustment is complete check that the shredder is cutting
efciently by feeding some material into the feeding hopper. Do this
by following the instructions outlined in the “Shredding” section.
Note: When shredding hard material it may need to be put through
the shredder twice, rstly to crush the material and secondly to cut it.
In order to crush material the cutting adjustment knob will need to be
loosened by turning it anti-clockwise half a turn, this will increase the gap
between the metal plate and the rolling cutter head.
Re-adjust the metal plate once crushing is complete.
Direction control switch
1. Prior to operation the direction
control switch must be set
either to the feed or reverse
position.
2. When set to the feed position
the shredder will pull material
through the hopper, into the
rolling cutter head and shred
it.
3. When set to the reverse
position the shredder will
run in the opposite direction
and release any blocked or
clogged material. In reverse
direction, the power
button must be held
down.
Note: The direction control
switch will not start the motor, it
only sets the direction of the rolling cutter head.
Note: If the switch for selecting the direction of rotation is in its
centre position "N", the motor will not start.
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
0.50 mm
N
N
N
N
N
N
ON/OFF switch
1. To start the shredder press the
green “I” button on the on/off
switch.
2. To stop the shredder press the red
“O” button on the on/off switch.
Note: The device has a internal zero
voltage switch. This prevents the
device restarting unintentionally after
a power failure.
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK,
WE RECOMMEND THE USE OF A RESIDUAL CURRENT
DEVICE (RATED 30mA OR LESS).
N
N
N
N
N
N
N
N
N
N
N
N

Overload protection
1. The shredder is equipped with a built-in motor protection system that
prevents the motor from being overloaded. The motor will switch off
automatically in the event of overloading.
2. If overloading occurs disconnect the
shredder from the power supply and move
the direction control switch to the “O”
position.
3. Allow at least 5 minutes for the motor
to cool down.
4. Press the reset button.
5. Plug the shredder back into mains
power and switch on.
6. If the cutting blades are jammed turn off the shredder and turn the
direction control switch to the reverse position, turn on the shredder
to clear any blocked or clogged material.
No-volt release switch
1. The shredder is equipped with an internal no-volt release switch.
If there is a loss of power the machine will automatically turn-off.
2. To re-start the shredder reconnect the power
cord to the extension lead and press the
green “I” button on the on/off switch.
SSH-2440
4. OPERATING THE SHREDDER
WARNING! PRIOR TO STARTING THE MOTOR
ENSURE THAT THE SHREDDER IS EMPTY.
Shredding
The following types of material can
be used in the shredder:
• Twigs
• Branches
• Waste from cut bushes
• Waste from hedge trimming
1. Feed the material to be
shredded into the feeding
hopper.
2. The shredder will
automatically pull the
material through the rolling
cutter head, shred it and
extract it through the
discharge chute.
Shredding tips
Following the below procedures will improve operation and prolong the
life of the shredder.
¥Branches and twigs should be shredded shortly after they are cut.
They become extremely hard once dry and the maximum cutting
diameter is reduced.
¥Garden waste such as fresh foliage, creepers and vines contain a
lot of moisture, this can result in material sticking to the cutter head.
Such material should be allowed to dry for a few days before being
fed into the shredder.
¥Always check material before shredding, ensure it does not contain
any stones, or nails as this may severely damage the shredder.
¥Always store the shredder indoors in a dry place.
WARNING! DO NOT FEED MATERIAL INTO THE
SHREDDER AFTER THE SHREDDER HAS BEEN
STOPPED, THIS CAN LEAD TO MATERIAL BEING
TRAPPED IN THE SHREDDER AND MAKE IT VERY
DIFFICULT TO REMOVE.
WARNING! THE SHREDDER IS NOT RECOMMENDED
FOR MATERIALS INCLUDING GLASS, METAL,
PLASTIC BAGS, STONES, FABRIC, EARTH COVERED
ROOTS, SOFT LEAFY MATERIAL AND WASTE WITHOUT
A FIRM CONSISTENCY (EG. KITCHEN WASTE).
WARNING! TO PREVENT DAMAGE TO THE
MACHINE IT IS RECOMMENDED THAT GARDEN
MATERIAL GREATER THAN 40MM IS NOT FED INTO
THE SHREDDER.
40mm Ø
N
N
N
N
N
N
N
N
N
N
N
N
40mm Ø
MAX
N
N
N
N
N
N
WARNING! DO NOT PUT YOUR HANDS INSIDE
THE DISCHARGE CHUTE TO CLEAR SHREDDED
MATERIAL WHILE THE MACHINE IS TURNED ON OR
CONNECTED TO MAINS POWER.

5. GENERAL MAINTENANCE 4. OPERATING THE SHREDDER (cont.)
MAINTENANCEOPERATION cont.
Composting tips
The shredded material can be composted in many various ways:
¥The material can be placed in a heap directly on the ground (cold
composting).
¥The material can be placed in a plastic container, wooden crate,
skeleton container or similar (cold composting).
¥The material can be placed in an insulated compost holder. The
heat is then maintained for longer periods and the rotting process
continues during the winter. This method produces faster results
(warm composting).
¥The material can be spread directly onto the garden (surface
composting).
WARNING!: ALWAYS DISCONNECT THE
SHREDDER FROM THE POWER SUPPLY BEFORE
PERFORMING ANY MAINTENANCE.
WARNING!: NEVER USE A HIGH-PRESSURE
WASHER OR RUNNING WATER WHEN CLEANING
THE SHREDDER!
WARNING!: ALWAYS USE A DUST MASK AND
SAFETY GLOVES WHEN HANDLING COMPOSTED
MATERIAL TO PREVENT CONTAMINATION FROM
MICRO ORGANISMS.
The shredder requires very little maintenance. In order to maintain the
efciency of the machine and achieve a long service life observe the
following:
¥Keep the air openings clean and free of obstructing material.
¥Periodically check that all nuts and screws are secure.
¥Spray the rolling cutter head after each use with a spray lubricant to
protect against corrosion.
¥Always clean the shredder after each use. Brush away dirt and plant
residue which may be caught in the roller cutter. Wipe clean the
outside of the shredder with a cloth which has been moistened with a
mild detergent and water.
¥Store the shredder upright in a dry place.
Note: Ozito Industries will not be responsible for any damage or injuries
caused by the repair of the tool by an unauthorised person or by
mishandling of the tool.
Cleaning
Always clean the shredder after each use.
Brush away dirt and plant residue which may be caught in the rolling
cutter blade. Wipe clean the outside of the shredder with a cloth which
has been moistened with a mild detergent and water.
Mulching palm fronds
The shredder can shred palm
fronds, reducing them to an easily
disposable waste.
If the head of the palm frond is
particularly large or hard it will
need to be removed before being
inserted into the shredder.
If the material is very hard the
cutting adjustment bolt may need to
be adjusted as described in “Prior
to operation” and run through
the shredder once to soften it.
Retighten the cutting adjustment
bolt and insert the material a
second time to effectively shred it.
40mm Ø

DESCRIPTION OF SYMBOLS
SPARE PARTS
Read instructions
VVolts Hz Hertz
~Alternating current WWatts
/min Revolutions or
reciprocation per minute no No load speed
Warning
Do not expose to rain
Disconnect and discontinue use should the power cord be damaged
93
dB Decibel (noise) rating
Beware of debris being
ejected from the shredder
Keep by standers away
Wear eye protection Wear safety gloves
Sound power level
Danger - Rotating blades. Keep hands and feet out
of openings while machine is running
Ø
Do not expose to rain
Diameter
N
Direction control switch - Reverse
Cutting adjustment knob - Rotating clockwise Ò Ð Ówill move
the metal plate closer to the cutting head, rotating
anti-clockwise Ò+Ò will move the metal plate away from the
cutting head.
- Neutral
- Feed
CAUTION! ONLY CHANGE THE DIRECTION OF
ROTATION AFTER THE SHREDDER HAS COME TO
A COMPLETE STOP AND THE CUTTER HEAD HAS
STOPPED ROTATING.
Problem Remedy
The motor does
not run
Set the direction control switch to position “0” and
press the reset button.
Turn the direction control switch to either the feed
or reverse position and turn on the shredder.
Possible power failure, check the power supply/
cord and house fuse box.
The material to
be shredded
is not pulling
through the unit
The cutting blade is running in reverse. Turn off
the shredder and change the direction control
switch to the feed position.
The material is jammed in the roller blade. Set the
control switch to the “O” position and switch the
shredder on. Pull the material from the hopper.
Carefully refeed thick branched material making
sure the blade does not immediately grasp the
pre-cut notches again.
The rolling cutter head is blocked. Set the
direction switch to the reverse position and switch
the shredder on. The cutter head will now run
backwards and release the blocked material.
Material is not
being shredded
sufciently
Ensure the metal plate is correctly adjusted
in relation to the rolling cutter head. Refer to
the “Prior to operation” section for detailed
instructions.
Tripping circuit
breaker
Use shorter extension lead.
Maximum length 25m.
TROUBLESHOOTING
CARING FOR THE ENVIRONMENT
Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority
for recycling advice.
Recycling packaging reduces the need for landll and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your local
council authority for recycling advice.
Read the operating instructions.
Wear safety goggles.
Safety class II
Never expose the
device to rain
Wear ear protection
If the cable is damaged or cut, disconnect the power plug from
the mains immediately.
Maximum cutting length / chain speed vu: 13.5 m/s
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]

This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
Recommendations for the use of a residual current device with a rated residual current of
30mA or less.
• Only operate the machine in open space (eg. not close to a wall or other xed object)
and on a rm, level surface.
• Do not operate the machine on a paved or gravel surface where ejected material could
cause injury.
• Before starting the machine, look into the feeding chamber to make certain that it is empty.
• Keep your face and body away from the feed intake opening.
• Always stand clear of the discharge zone when operating this machine.
• Do not transport this machine while the power source is running.
• Do not tilt the machine while the power source is running.
• When the machine is stopped for servicing, inspection, or storage, or to change an
accessory, shut off the power source, disconnect the spark plug wire from the spark plug
(electric unit disconnect from supply), make sure that all moving parts have come to a
complete stop and, where a key is tted remove the key. Allow the machine to cool before
making any inspections, adjustments, etc.
• Only use the shredder in dry conditions and never outdoors when it is raining.
• Do not allow children or any person who has not read this instruction manual or who is not
familiar with the shredder operate the product.
• Remember that the operator may be held responsible for accidents or hazards occurring to
other people and/or their property.
• Ensure the shredder is placed on a rm and level surface prior to using.
• Never use the shredder with damaged safety devices or without protection.
• Wear ear protection when operating the shredder.
• Do not allow processed material to build up in the discharge chute. This may prevent proper
discharge and can result in kickback of material through the feeding hopper.
• If the machine becomes clogged, switch off the machine and disconnect from the power.
Allow the cutter to come to a stop. Clear debris from the cutter assembly.
• Never attempt to shred bones, stone, glass, metals, plastic or rags.
• Wear protective gloves, safety glasses and avoid loose clothing.
WARNING! Rotating cutter head. Keep hands and feet out of openings
• Store shredder upright in a dry place when not in use.
• Never put your hands in the cutter area while the cutter assembly is running or the shredder
is plugged in. The cutter continues to run for a few seconds after the shredder has been
switched off.
• If the cutter strikes any foreign objects or if the shredder starts making any unusual noise or
vibration, switch off the shredder immediately and disconnect the power.
Allow the cutter to come to a stop and take the following steps:
- Inspect for damage.
- Check and tighten any loose parts.
- Have any damaged parts replaced and /or repaired by an electrician or power tool
repairer.
• Always switch off the shredder and disconnect the power whenever you leave the work area.
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools create sparks which may ignite the dust or
fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching
outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is earthed
or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the inuence of drugs,
alcohol or medication. A moment of inattention while operating power tools may result in
serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch or energising power tools that have the
switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a
key left attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-
related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents are caused by poorly maintained
power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be performed.
Use of the power tool for operations different from those intended could result in a hazardous
situation.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
b. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualied persons in order to avoid a hazard.
GENERAL POWER TOOL SAFETY WARNINGS
ADDITIONAL SAFETY INSTRUCTIONS FOR SHREDDERS
ELECTRICAL SAFETY
WARNING! When using mains-powered tools, basic safety precautions, including
the following, should always be followed to reduce risk of re, electric shock,
personal injury and material damage.
Read and understand the manual prior to operating this tool.
Save these instructions and other documents supplied with this tool for future reference.
Before you connect the equipment to mains supply make sure that the data on the rating plate are
identical to the mains data.
If the supply cord is damaged, it must be replaced by a qualied electrician or a power tool repairer
in order to avoid a hazard.
If operating a power tool in a damp location is unavoidable use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect
the extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged
or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension
lead not suitable for the power input of the tool or which is damaged or defective may result in a risk
of re and electric shock.
