UNITED OFFICE 304611 User manual

IAN 96272
CROSS CUT SHREDDER UAV 250 A2
CROSS CUT SHREDDER
Operating instructions
AKTENVERNICHTER
Bedienungsanleitung
IAN 304611

GB/IE/NI Operating instructions Page 1
DE/AT/CH Bedienungsanleitung Seite 13
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

B
A

GB│IE│NI │ 1 ■
UAV 250 A2
Contents
Introduction ..............................................2
Intended use ..............................................2
Package contents ..........................................2
Applicance description......................................2
Technical data.............................................3
Overheating protection ...............................................3
Safety information.........................................4
Initial start-up .............................................6
Use......................................................6
Switching the appliance on ............................................6
Inserting paper ......................................................6
Inserting credit cards .................................................7
Inserting a CD ......................................................7
Clearing a material blockage...........................................7
Turning off the appliance ..............................................7
Emptying the waste containers...............................8
Emptying the large waste container ......................................8
Emptying the small waste container ......................................8
Cleaning .................................................8
Faults ....................................................9
If the paper jams in the appliance .......................................9
If the appliance suddenly stops working ..................................9
If the appliance cannot be switched on ...................................9
Disposal.................................................10
Kompernass Handels GmbH warranty .......................11
Service ...........................................................12
Importer ..........................................................12
Read these operating instructions carefully before using the appliance
for the first time and retain them for future reference. Please pass these
operating instructions for the appliance on to any future owner(s).

■ 2 │ GB│IE│NI UAV 250 A2
Introduction
Congratulations on the purchase of your new appliance.
You have selected a high-quality product. The operating instructions are part of
this product. They contain important information about safety, use and disposal.
Before using the product, please familiarise yourself with all operating and safety
instructions. Use the product only as described and for the range of applications
specified. Please also pass these operating instructions on to any future owner.
Intended use
This appliance is designed for shredding paper, credit cards, CDs/DVDs and
small staples (sizes: 24/6 and 23/6 (11.5 x 6 mm), B-8 (11.5 x 7 mm), No10
(8.4 x 5 mm)) and paper clips (up to 25 mm) in private households. Any other
uses of the appliance are considered improper and carry the risk of serious
personal injury. This appliance is not for commercial use.
Package contents
■ Cross Cut Shredder (cutting attachment, collecting containers large/small)
■ Operating instructions
Applicance description
Figure A:
1Cutter attachment
2Small waste container
3Viewing window
4Large waste container
Figure B:
5Cutter opening for CDs/credit cards
6Cutter opening for paper
7“Power” lamp
8“Overheat” lamp
9Switch

GB│IE│NI │ 3 ■
UAV 250 A2
Technical data
Mains voltage 220 - 240 V ~ (AC), 50 Hz
Nominal current approx. 1.2 A
Rated power 250 W
Protection class II / (double insulation)
Large waste container capacity 21 litres
Cutting process for paper
Cross-cut,
5 x 18 mm particles
Safety level P‒4
Working width 220 mm
Cutting capacity 10 sheets (80 g/m2)
Overheating protection
This appliance is fitted with overheating protection. If the motor overheats due to
overloading, the appliance switches itself off automatically and the “Overheat”
lamp 8 lights up permanently red until the motor has cooled down sufficiently.
If this occurs, proceed as follows:
WARNING – RISK OF INJURY!
► Remove the power plug from the wall socket to avoid unintended starting
of the appliance.
■ Switch the appliance off by moving the switch 9to the middle position "OFF".
■ Empty the waste containers 2/4.
■ Allow the appliance to cool down.
■ Put the mains plug back into the socket.
■ Switch the appliance on, by moving the switch 9 into the "AUTO" position.
The “Power” lamp 7lights up permanently green.
The “Overheat” lamp 8is off when the appliance has cooled down suf-
ficiently.
We recommend that you let the appliance cool down for about 30 minutes after
3 minutes of operation.

■ 4 │ GB│IE│NI UAV 250 A2
Safety information
The following safety instructions must always be followed when using electrical
appliances:
DANGER! – RISK OF ELECTRIC SHOCK!
► To prevent accidents, have defective plugs and/or power cables replaced
immediately by an authorised specialist technician or our Customer Service
department.
► Applinaces that do not work properly or have been damaged must be
checked immediately and repaired by our customer service.
► Do not expose the appliance to rain, and never use it in a humid or wet
environment.
► Ensure that the power cable does not get wet or moist during use.
► Do not place the appliance in the direct vicinity of any sources of heat or
water. There is a risk of fire or of receiving an electrical shock!
WARNING! – RISK OF INJURY!
► Only one person should operate the shredder at any time.
► Never leave the appliance unattended during operation.
Keep loose clothing, long hair, jewellery, etc. at a safe
distance from the cutter opening.
Never insert your fingers into the cutter opening.
Keep children away from the appliance. They could hurt themselves.
► Do not use the appliance close to inflammable or explosive materials and/
or ignitable gases or in dusty environments.
Explosion hazard!
► Never insert your finger into the central hole of a CD when you are feeding it
into the appliance.
► Keep pets away from the appliance. They could hurt themselves.

GB│IE│NI │ 5 ■
UAV 250 A2
WARNING! – RISK OF INJURY!
► This appliance is not intended for use by persons (including children) with
limited physical, sensory or mental capabilities or lack of experience and/
or knowledge unless they are supervised by a person who is responsible
for their safety, or receive instructions from this person on how to use the
appliance.
► The packaging material can be a source of danger for children. Dispose
of the material immediately after unpacking or keep it in a safe place not
accessible to children.
► Route the power cable in such a way that no one can tread on it or trip
over it.
CAUTION! PROPERTY DAMAGE!
► Do not use the appliance outdoors. The appliance could be irreparably
damaged!
► Do not overload the appliance. The paper shredder is designed for brief
operating periods.
► Never use the paper shredder for purposes for which it is not designed or
intended.
NOTES ON SAFE USE
► Always position the appliance close to a power socket. Do not use an
extension cable. Ensure that the appliance and the power socket are easily
and quickly accessible in the event of an emergency.
► In case of danger, remove the plug from the socket immediately.
► Remain alert at all times! Always pay attention to what you are doing and
act with common sense. Never use the appliance if you are distracted or
don't feel well.

■ 6 │ GB│IE│NI UAV 250 A2
Initial start-up
NOTE
► As every shredder is tested for functionality after manufacture, it is possible
that you may find paper residue in the cutting blades.
■ Push the small waste container 2onto the rails inside the large waste
container 4.
■ Place the cutter attachment 1onto the large waste container 4so that the
mains cable sticks out to the rear.
■ Insert the plug into a mains socket.
Use
max.
x 80g/m2
10
You can shred up to 10 sheets (80 g/m2paper) at the same time.
CAUTION! PROPERTY DAMAGE!
Never feed paper into the cutter opening if it still has paper clips larger
than 25 mm attached! These could damage the cutting blades.
Switching the appliance on
■ Set the switch 9 to "AUTO" for shredding. The “Power” lamp 7lights up
permanently green.
Inserting paper
■ Insert paper into the cutter opening for paper 6from above and in portrait
format.
The motor starts automatically and switches itself off automatically if no further
paper is inserted. You can shred up to 10 sheets (80 g/m2paper) at the same
time.
NOTE
► Regularly remove any residue left in the cutting blades with a suitable tool,
e.g. a pair of tweezers. Ensure that the appliance is unplugged before
doing this.

GB│IE│NI │ 7 ■
UAV 250 A2
Inserting credit cards
■ Insert the credit card from above into the middle of the CD/credit card cutter
opening 5. You can only shred one credit card at a time. Always insert the
card into the CD/credit card cutter opening 5with the wide side first.
Otherwise, the magnetic strip will not be destroyed.
NOTE
► Always insert the credit card into the middle of the CD/credit card cutter
opening 5. Otherwise, the shredding process will not start!
NOTE
► If the shredding process does not start when you insert the credit card, care-
fully push the credit card further into the CD/credit card cutter opening 5
with a flat object.
NOTE
► If you want to ensure that the information on the magnetic strip is irrevocably
destroyed, insert the credit card into the middle of the cutter opening for
paper 6.
Note that the residue will then fall into the large waste container 4.
If necessary, empty this beforehand in order to keep paper and plastic
waste separate.
Inserting a CD
WARNING! RISK OF INJURY!
► Never insert your finger into the central hole of a CD when you are feeding
it into the appliance.
■ Insert the CD from above into the middle of the CD/credit card cutter
opening 5. You can only shred one CD at a time.
Clearing a material blockage
1) Move the switch 9to the "REV" ("reverse") position if the paper being
shredded causes a blockage. The appliance now goes into reverse and
the paper that is being shredded is ejected.
2) Move the switch 9to the "OFF" position as soon as the jammed material
has been ejected.
Turning off the appliance
■ Switch the appliance off by moving the switch 9to the position "OFF". The
“Power” lamp 7goes out.

■ 8 │ GB│IE│NI UAV 250 A2
Emptying the waste containers
■ Empty the waste containers 2/4 regularly.
■ Empty the large waste container 4at the latest when paper is visible in the
viewing window 3.
■ Dispose of the waste material in an environmentally responsible manner.
Emptying the large waste container
WARNING! RISK OF INJURY!
► Remove the power plug from the wall socket to avoid unintended starting of
the appliance.
1) Remove the cutter attachment 1from the large waste container 4.
2) Pull the small waste container 2 upwards out of the large waste container 4
on the guide rails.
3) Empty the large waste container 4 and then reassemble the components.
Emptying the small waste container
1) Remove the cutter attachment 1from the large waste container 4.
2) Pull the small waste container 2 upwards out of the large waste container 4
on the guide rails to empty.
3) Empty the small waste container 2 and then reassemble the components.
Cleaning
DANGER! – RISK OF ELECTRIC SHOCK!
► Always pull out the plug before cleaning the appliance. There is a risk of
electric shock!
WARNING! RISK OF INJURY!
► The blades in the appliance are very sharp!
CAUTION! PROPERTY DAMAGE!
Do not spray any oil or other lubricants into the cutter opening 5/6.
These can irreparably damage the appliance.
■ Remove any residue left in the cutting openings 5/6 or cutting blades
with a suitable tool, e.g. a pair of tweezers. Ensure that the appliance is
unplugged before doing this.
■ Clean the appliance with a moist cloth. For stubborn dirt, add a little mild
detergent to the cloth.

GB│IE│NI │ 9 ■
UAV 250 A2
Faults
If the paper jams in the appliance
This means that you have attempted to feed too much paper into the appliance
(max. 10 sheets 80 g/m2paper).
1) Move the switch 9into the "REV" position if the paper causes a blockage.
The appliance now goes into reverse and the paper that is being shredded
is ejected.
2) Pull the paper out of the appliance and then set the switch 9to "AUTO".
The appliance is now ready for use again.
If the appliance suddenly stops working
This means that the appliance has overheated and the automatic safety cut-out
has activated itself. The “Overheat” lamp 8lights up permanently red.
WARNING! RISK OF INJURY!
► Remove the power plug from the wall socket to avoid unintended starting of
the appliance.
1) Place the switch 9 in the "OFF" position.
2) Allow the appliance to cool down.
3) Put the mains plug back into the socket.
4) Switch the appliance on, by moving the switch 9 into the "AUTO" position.
The “Power” lamp 7lights up permanently green. The “Overheat” lamp 8
remains off when the appliance has cooled down sufficiently.
If the appliance cannot be switched on
■ Place the switch 9 in the "OFF" position. The “Power” lamp 7goes out.
■ Try a different wall socket.
■ The appliance is possibly defective. Have the appliance checked by a qualified
technician.
■ The appliance has overheated and triggered the automatic safety cut-out.
Then proceed as described in the section “If the appliance suddenly stops
working”.
WARNING! RISK OF INJURY!
► Remove the power plug from the wall socket to avoid unintended starting of
the appliance.

■ 10 │ GB│IE│NI UAV 250 A2
Disposal
Never dispose of the appliance in your normal domestic waste.
This product is subject to the provisions of European Directive
2012/19/EU-WEEE (Waste Electrical and Electronic Equipment).
Dispose of the appliance via an approved disposal company or your municipal
waste facility. Please observe the currently applicable regulations. Please contact
your waste disposal centre if you are in any doubt.
Your local community or municipal authorities can provide information on how to
dispose of the worn-out product.
Dispose of all packaging materials in an environmentally friendly manner.
Note the labelling on the packaging and separate the packaging material
components for disposal if necessary. The packaging material is labelled with
abbreviations (a) and numbers (b) with the following meanings:
1–7: Plastics,
20–22: Paper and cardboard,
80–98: Composites.

GB│IE│NI │ 11 ■
UAV 250 A2
Kompernass Handels GmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of purchase. If this product
has any faults, you, the buyer, have certain statutory rights. Your statutory rights
are not restricted in any way by the warranty described below.
Warranty conditions
The validity period of the warranty starts from the date of purchase. Please keep
your original receipt in a safe place. This document will be required as proof of
purchase.
If any material or production fault occurs within three years of the date of purchase
of the product, we will either repair or replace the product for you at our discretion.
This warranty service is dependent on you presenting the defective appliance
and the proof of purchase (receipt) and a short written description of the fault
and its time of occurrence.
If the defect is covered by the warranty, your product will either be repaired or
replaced by us. The repair or replacement of a product does not signify the begin-
ning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the warranty.
This also applies to replaced and repaired components. Any damage and defects
present at the time of purchase must be reported immediately after unpacking.
Repairs carried out after expiry of the warranty period shall be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality guidelines
and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty does not
extend to product parts subject to normal wear and tear or fragile parts such as
switches, batteries, baking moulds or parts made of glass.
The warranty does not apply if the product has been damaged, improperly used
or improperly maintained. The directions in the operating instructions for the product
regarding proper use of the product are to be strictly followed. Uses and actions
that are discouraged in the operating instructions or which are warned against
must be avoided.
This product is intended solely for private use and not for commercial purposes.
The warranty shall be deemed void in cases of misuse or improper handling, use
of force and modifications/ repairs which have not been carried out by one of
our authorised Service centres.

■ 12 │ GB│IE│NI UAV 250 A2
Warranty claim procedure
To ensure quick processing of your case, please observe the following instructions:
■ Please have the till receipt and the item number (e.g. IAN 12345) available
as proof of purchase.
■ You will find the item number on the type plate, an engraving on the front
page of the instructions (bottom left), or as a sticker on the rear or bottom of
the appliance.
■ If functional or other defects occur, please contact the service department
listed either by telephone or by e-mail.
■ You can return a defective product to us free of charge to the service address
that will be provided to you. Ensure that you enclose the proof of purchase
(till receipt) and information about what the defect is and when it occurred.
You can download these instructions along with many other manuals,
product videos and software on www.lidl-service.com.
Service
Service Great Britain
Tel.: [phone]
E-Mail: kom[email protected]
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kom[email protected]
IAN 304611
Importer
Please note that the following address is not the service address. Please use the
service address provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
DE-44867 BOCHUM
GERMANY
www.kompernass.com

DE│AT│CH │ 13 ■
UAV 250 A2
Inhaltsverzeichnis
Einleitung................................................14
Bestimmungsgemäßer Gebrauch ............................14
Lieferumfang ............................................14
Gerätebeschreibung ......................................14
Technische Daten .........................................15
Überhitzungsschutz .................................................15
Sicherheitshinweise .......................................16
Erste Inbetriebnahme......................................18
Bedienung...............................................18
Gerät einschalten ...................................................18
Papier einführen ....................................................18
Kreditkarte einführen ................................................19
CD einführen ......................................................19
Materialstau beheben ...............................................19
Gerät ausschalten ..................................................19
Auffangbehälter leeren ....................................20
Großen Auffangbehälter leeren ........................................20
Kleinen Auffangbehälter leeren ........................................20
Reinigung ...............................................20
Im Fehlerfall .............................................21
Wenn das Schneidgut im Gerät stecken bleibt.............................21
Wenn das Gerät plötzlich stehen bleibt ..................................21
Wenn sich das Gerät nicht einschalten lässt ..............................21
Entsorgung ..............................................22
Garantie der Kompernaß Handels GmbH .....................23
Service ...........................................................24
Importeur .........................................................24
Lesen Sie die Bedienungsanleitung vor der ersten Verwendung aufmerksam
durch und heben Sie diese für den späteren Gebrauch auf. Händigen Sie
bei Weitergabe des Gerätes an Dritte auch die Anleitung aus.

■ 14 │ DE│AT│CH UAV 250 A2
Einleitung
Herzlichen Glückwunsch zum Kauf Ihres neuen Gerätes.
Sie haben sich damit für ein hochwertiges Produkt entschieden. Die Bedienungsan-
leitung ist Bestandteil dieses Produkts. Sie enthält wichtige Hinweise für Sicherheit,
Gebrauch und Entsorgung. Machen Sie sich vor der Benutzung des Produkts mit
allen Bedien- und Sicherheitshinweisen vertraut. Benutzen Sie das Produkt nur
wie beschrieben und für die angegebenen Einsatzbereiche. Händigen Sie alle
Unterlagen bei Weitergabe des Produkts an Dritte mit aus.
Bestimmungsgemäßer Gebrauch
Dieses Gerät ist ausschließlich zum Zerkleinern von Papier, Kreditkarten, CDs / DVDs
sowie kleinen Heftklammern (Größen: 24/6 und 23/6 (11,5 x 6 mm), B-8
(11,5 x 7mm), No10 (8,4 x 5 mm)) und Büroklammern (bis 25 mm) in privaten
Haushalten geeignet. Jede andere Verwendung oder Veränderung gilt als nicht
bestimmungsgemäß und birgt erhebliche Unfallgefahren. Verwenden Sie dieses
Gerät nicht gewerblich.
Lieferumfang
■ Aktenvernichter (Schneidaufsatz, Auffangbehälter groß / klein)
■ Bedienungsanleitung
Gerätebeschreibung
Abbildung A:
1Schneidaufsatz
2Kleiner Auffangbehälter
3Sichtfenster
4Großer Auffangbehälter
Abbildung B:
5Schneidöffnung CD / Kreditkarte
6Schneidöffnung Papier
7Leuchte „Power“
8Leuchte „Overheat“
9 Schalter

DE│AT│CH │ 15 ■
UAV 250 A2
Technische Daten
Netzspannung 220 - 240 V ~ (Wechselstrom), 50 Hz
Nennstrom ca. 1,2 A
Nennleistung 250 W
Schutzklasse II/ (Doppelisolierung)
Kapazität großer
Auffangbehälter 21 Liter
Schnittverfahren für Papier
Kreuzschnitt,
5 x 18 mm-Partikel
Sicherheitsstufe P‒4
Arbeitsbreite 220 mm
Schneidekapazität 10 Blatt (80g/m2)
Überhitzungsschutz
Dieses Gerät ist mit einem Überhitzungsschutz ausgestattet. Wenn der Motor
aufgrund von Überlastung zu heiß wird, schaltet sich das Gerät automatisch aus
und die Leuchte „Overheat“ 8 leuchtet durchgehend rot, bis sich der Motor
ausreichend abgekühlt hat.
Gehen Sie in diesem Fall folgendermaßen vor:
WARNUNG! VERLETZUNGSGEFAHR!
► Ziehen Sie den Netzstecker aus der Netzsteckdose, um ein unbeabsichtig-
tes Einschalten zu vermeiden.
■ Schalten Sie das Gerät aus, indem Sie den Schalter 9 in die mittlere Position
„OFF” stellen.
■ Leeren Sie die Auffangbehälter 2/4.
■ Lassen Sie das Gerät abkühlen.
■ Stecken Sie den Netzstecker wieder in die Netzsteckdose.
■ Schalten Sie das Gerät ein, indem Sie den Schalter 9 in die Position
„AUTO” stellen.
Die Leuchte „Power“ 7 leuchtet durchgehend grün.
Die Leuchte „Overheat“ 8 ist erloschen, wenn das Gerät ausreichend
abgekühlt ist.
Wir empfehlen nach 3 Minuten Betrieb das Gerät für ca. 30 Minuten abkühlen
zu lassen.

■ 16 │ DE│AT│CH UAV 250 A2
Sicherheitshinweise
Die folgenden Sicherheitshinweise müssen beim Einsatz von elektrischen Geräten
in jedem Fall berücksichtigt werden:
GEFAHR! ELEKTRISCHER SCHLAG!
► Lassen Sie beschädigte Netzstecker oder Netzkabel sofort von autorisiertem
Fachpersonal oder dem Kundendienst austauschen, um Gefährdungen zu
vermeiden.
► Lassen Sie Geräte, die nicht einwandfrei funktionieren oder beschädigt
wurden, sofort von autorisiertem Fachpersonal oder vom Kundendienst
untersuchen und reparieren.
► Setzen Sie das Gerät nicht dem Regen aus und benutzen Sie es auch
niemals in feuchter oder nasser Umgebung.
► Achten Sie darauf, dass das Netzkabel während des Betriebs niemals nass
oder feucht wird.
► Stellen Sie das Gerät nicht in der Nähe von Wärme- oder Wasserquellen
auf. Es besteht Brandgefahr und die Gefahr eines elektrischen Schlages!
WARNUNG! VERLETZUNGSGEFAHR!
► Den Aktenvernichter jeweils nur durch eine Person bedienen.
► Das Gerät während des Betriebs niemals unbeaufsichtigt lassen.
Halten Sie lose Kleidung, lange Haare, Schmuck u. Ä. von
der Schneidöffnung fern.
Stecken Sie nie die Finger in die Schneidöffnung.
Halten Sie Kinder vom Gerät fern. Diese können sich verletzen.
► Benutzen Sie das Gerät nicht in staubigen oder explosionsgefährdeten
Umgebungen (entzündliche Gase, Dämpfe, Dämpfe von organischen
Lösungsmitteln). Explosionsgefahr!
► Stecken Sie nicht Ihre Finger in das zentrale Loch der CD, wenn Sie diese
in das Gerät einführen.
► Halten Sie Tiere vom Gerät fern. Diese können sich verletzen.

DE│AT│CH │ 17 ■
UAV 250 A2
WARNUNG! VERLETZUNGSGEFAHR!
► Dieses Gerät ist nicht dafür bestimmt, durch Personen (einschließlich
Kinder) mit eingeschränkten physischen, sensorischen oder geistigen Fä-
higkeiten oder mangels Erfahrung und / oder mangels Wissen benutzt zu
werden, es sei denn, sie werden durch eine für ihre Sicherheit zuständige
Person beaufsichtigt oder erhielten von ihr Anweisungen, wie das Gerät zu
benutzen ist.
► Das Verpackungsmaterial stellt eine Gefahr für Kinder dar. Entsorgen Sie
das Verpackungsmaterial nach dem Auspacken sofort oder bewahren Sie
es für Kinder unzugänglich auf.
► Verlegen Sie das Netzkabel so, dass niemand darauf treten oder darüber
stolpern kann.
ACHTUNG! SACHSCHADEN!
► Benutzen Sie das Gerät nicht im Freien. Das Gerät kann irreparabel beschä-
digt werden!
► Überlasten Sie das Gerät nicht. Der Aktenvernichter ist für kurze Betriebszei-
ten ausgelegt.
► Verwenden Sie den Aktenvernichter niemals zweckentfremdet.
HINWEISE ZUM SICHEREN VERHALTEN
► Stellen Sie das Gerät in unmittelbarer Nähe zur Netzsteckdose auf. Benut-
zen Sie kein Verlängerungskabel. Sorgen Sie dafür, dass das Gerät und der
Netzstecker leicht zugänglich und im Notfall problemlos erreichbar sind.
► Ziehen Sie bei Gefahr sofort den Netzstecker aus der Netzsteckdose.
► Seien Sie stets aufmerksam! Achten Sie immer darauf, was Sie tun und gehen
Sie stets mit Vernunft vor. Benutzen Sie das Gerät in keinem Fall, wenn Sie
unkonzentriert sind oder sich unwohl fühlen.
