Ozone RAGE Z90 User manual

user manual

1
1. Headphone with mic + inline controller with a USB connector.
2. Magnetic controller base.
BOX CONTENT
1. Metallic headband inner structure.
2. Premium comfort.
3. 5.1 real sound.
4. Ozone atmosphere.
5. Detachable LED microphone.
6. Advanced in-line control.
7. Driver compatible with Windows 7, 8, 8.1 and XP.
FEATURES

2
COnfiguratiOn
In the tray, click OZONE logo to pop-up the
Rage Z90 Control Panel
raGE Z90 DRIVER
Rage Z90 is compatible with PC.
1. Go to www.ozonegaming.com, search for Rage Z90 and download the
drivers and software.
2. Using the USB connector, plug the headset into any free USB port. Install
the software following all the instructions in the installation window. Please
note that the headset features an additional soundcard which must be con-
figured in the system settings as the default device for audio playback and
recording.
3. Once the installation have been finished, open the Rage Z90 software and
configure the device to suit your playback and recording preferences.
InstallatiOn GUIDE

3
Customize your own setting via adjusting the functions within control panel:
1. MAIN CONTROL: You can set up the number of speakers and adjust
the Master, Front, Rear and Center Volume and sample Rate of speakers and
microphone.

4
2. EQUALIZER: Enable the Equalizer and set it up to your personal
preference or use one of the predefined settings for the different game styles.

5
You can also save you own EQ settings and you will have them available
under the “MANUAL” drop down menu.

6
3. advanced settings: Here you can set different features like
Dynamic Bass, Audio Enhance, SoundLevel Normalization for the output
device and Incoming Voice Definition or Voice FX for the input device.

7
rage Z90 INLINE CONTROLLER
You can configure below settings through the inline controller:
1. Adjust the speaker master volume as needed. (Volume wheel).
2. Mute the playback. (Wheel center mute button).
3. Mic. mute function: mute the mic with just one click and easily turn it back
ON when required. (Side mute mic button).
4. Switch on/off the Ozone Atmosphere. (LED side switch).
5. Adjust the volume of every channel independently with the center, front, rear
and sub sliders. (Independent channel volume sliders).
4. AudiO PROFILES: You can select, modify and store up to 5 different
profiles and switch your custom settings quickly.

8
* LED indicator on controller:
RED LED blinking when POWER ON

9
* LED indicator on microphone:
LED off when MIC MUTED

10
rage Z90 mic plug & unplug
* Plug & Unplug instructions:
Insert the mic connector into the headset paying attention to the shape of
the case and plug it. Once plugged turn the mic 90º to avoid detach it by
error.
To detach the mic first turn the mic 90º in the other direction and unplug it.

WEEE NOTICE:
Symbol for Separate Collection in European Countries.
This symbol indicates that this product is to be collected separately.
The following apply only to users in European countries:
This product is designated for separate collection at an appropriate collection
point. Do not dispose of as household waste.
For more information, contact the retailer or the local authorities in charge of
waste management.
©2014 OZONE Gaming Gear. All rights reserved.

WWW.OZONEGAMING.COM
