Ozoneair PURIFY GO User manual

PURIFY GO & PLUS

USER MANUAL
Ozoneair PURIFY GO & PLUS
ENGLISH
DANSK
DEUTSCH
ESPAÑOL
FRANÇAIS
ITALIANO
NEDERLANDS
NORSK
PORTUGUÊS
SUOMI
SVENSKA
4
18
32
46
60
74
88
102
116
130
144
LANGUAGES
For full warranty conditions, see each country’s respective website.
With reservation for changes.
Read the instructions carefully before use.

Introduction
Safety guidelines
Recycle
Description & Specifications
Parts
Display
Placement
Auto mode
Daily mode
Maintenance
Troubleshooting
4
5
6
6
8
9
10
10
12
13
16
TABLE OF CONTENT
EN 5
This user manual is intended to help you use
your Ozoneair Purify safely and to give you the
basic information regarding how to operate and
maintain the product. Read the instructions
carefully before use.
If you after reading the manual are not certain
you understand the risks that may be associated
with the product, do not use the product. Please
contact Ozoneair if you need further information.
The user manual only addresses the basics for safe
use of the product. It is not possible to describe
all situations which could arise while using the
product.
INTRODUCTION
Throughout this user manual the following symbols are used to indicate
when special precautions should be taken, or certain procedures should
be followed.
WARNING! - This symbol indicates a warning and should be
followed to avoid personal injury and property damage.
NOTE - This symbol indicates special instructions or notes that
will help you get the most out of your product.
Safety information
Users responsibility
02
It is the user’s responsibility to comply with all recommendations and
safety guidelines before operating the product, and to always use the
product in a sensible way.
• Do not open the UV lamp holders without unplugging the product.
• Do not look directly onto the UV lamp while running. UV light can be
damaging for skin and eyes.
• Do not use in contact with water.
• Ensure that the air intake on the back of the product is not blocked.
• Do not replace the original power adapter with an alternative power
adapter.
• Do not cover the product or place items on top of the product or the
power adapter.
• Do not touch the glass surface of the UV lamps with bare hands. Use
cotton gloves or a cloth to avoid fingerprints which can harm and
decrease the UV lamps capacity.
When using the product,certain safety precautions
must be followed to reduce the risk of personal
injury and property damage. Ozoneair warranty
only applies if the product is used according to
these instructions.
SAFETY GUIDELINES
4EN
01
01
02
03
04
05
06
07
08
09
10
11
ENGLISH

04
6
Ozoneair Purify uses a combination of dierent
cleaning techniques to achieve best possible
cleaning rate. The techniques are optimized for an
eective cleaning and combines ionisation, UV-
light with photocatalysis, photoplasma and HEPA
filter.
DESCRIPTION & SPECIFICATIONS
EN
ION
Ions play an important role in the atmosphere’s self-purifying processes,
and by increasing the amount of ions in the indoor air, one strives to
create similar purifying mechanisms indoors. Small, charged particles
are clumped together by electrostatic forces into larger particles. When
the clustered particles no longer can be kept airborne, they fall to the
floor and other horizontal surfaces and can then easily be cleaned away.
DIRECT RADIATION
When airborne microorganisms pass through UV light in a specific
spectrum the UV energy penetrates the outer cell membrane, passes
through the cell body and disrupts its DNA from reproducing, making it
an eective method for disinfection.
PHOTOCATALYSIS
A chemical reaction occurs where electromagnetic radiation in the
ultraviolet region activates a catalyst. When the UV light activates the
catalyst, it generates hydroxyl radicals which eliminates bacteria, viruses,
mold spores, reduces volatile chemical gases and neutralizes bad odors.
HEPA FILTER
A HEPA filter is a high-eciency particulate absorbent air filter; it works
by forcing air through a fine mesh that traps harmful particles such as
pollen, pet dander, dust mites, and tobacco smoke.
Operating temperature:
Storage conditions:
Operating altitude:
0 °C till 35 °C
Room temperature and
dry conditions
Tested up to 5 000 meters
Operating requirements
CE - Ozoneair are CE marked and comply with the RED
Directive (2014/53/EU), the EMC Directive (2014/30/
EU), and Low Voltage Directive (2014/35/EU) issued by
the European Commission.
RoHS – Ozoneair complies with the RoHS Directive
(2011/65 / EC) which prohibits the use of hazardous
substances in electronic equipment.
Certifications
Technical details
Model:
Line voltage:
Eect:
Size:
Sound level:
Weight:
Fan speed:
GO
DC 24 V
25 W
326 x 291 x 137mm
35-55 dB
2,9 kg
30-100 CFM
7
EN
PLUS
DC 24 V
30 W
326 x 291 x 137mm
35-55 dB
2,9 kg
30-100 CFM
RECYCLE
Electrical components. Do not dispose the product
with your regular household waste. Return the
product to your local recycling facility for proper
recycling. Recycle the UV lamps in containers
intended for lamps containing mercury. Recycle
the product packaging in applicable containers for
paper and plastic. The battery inside the remote
shall be sorted accordingly.
This symbol indicates that the product shall not
be disposed with regular household waste. The
product contains electrical components and
should be handled properly.
03

1. Display 2. Air outlet 3. Product stand 4. Wall mount 5. UV lamp base 6. Power source 7. Air intake
FRONT SIDE REMOTEBACK
3
PARTS
05
1
5
4
2
7
6
8EN
DISPLAY
06
1. Auto 2. Daily 3. Eect 4. Timer 5. Display
9
EN
5

11
EN
PLACEMENT
07
Remove/
attach stand
Wall mounted/at
bookshelf.
Recommended at
180 cm
WARNING! - Do not place the product so the air
intake or outlet is blocked, this may cause the product
to shut down.
The product can either be placed on a flat
surface with its stand or mounted on the wall by
removing the stand. The product should be placed
high, for example on a table or a bookshelf.
Push silver button
to activate purifier
Push to adjust
eect
Treatment starts
automatically after
a few seconds
Auto mode and
medium eect is
preselected
AUTO MODE
08
10 EN
NOTE - Ozoneair Purify uses photocatalysis which
can generate a scent that can be compared to light
metal or electricity. The scent appears initially when the
product reacts to large quantities of contaminants but
will decrease with time.
Push timer button
to activate timer
Keep pushing timer
button to select
hours
Treatment starts
automatically after
a few seconds and
runs selected hours
Timer function
auto eect
A
4
2
timereectdaily
2h
auto
timereectdailyauto
A
A
4
4
timer
delay
eectdailyauto
Hold timer button
to activate delay
function
Push to select
hours
Treatment starts
automatically after
selected hours
have passed
To deactivate the
delay function,
hold timer button
until delay has
disappeared
Delay function
timer
delay
eectdaily
auto
timer
delay
eectdaily
auto
A
eectauto

NOTE - Push and hold timer to activate delay function.
After the delayed hours have passed, Daily mode will
start automatically. Daily mode will run every day until
another setting is selected or the machine is turned o.
09
In Daily mode the product will be active for
selected hours every day. Note that the daily mode
will start the same time following days as the first
cycle is started on day one.
DAILY MODE
Push silver button
to activate the
purifier
Push daily button
to select daily
mode
Push to adjust
eect
Push timer to
select treatment
hours each day
Treatment starts
automatically after
a few second.
eectdaily
daily eect
eectdaily
timer
timer
timer
8
MAINTENANCE
10
UV lamps
SAFETY PRECAUTIONS UV LAMPS
Remove/insert UV lamps
After approximately one year of continuous use or 5000 operating hours,
the UV lamps needs to be replaced as their power has decreased. The
“Replace UV” indicator will light up on the display when the UV lamps
needs to be replaced. Below, instructions regarding how to order and
safely change the UV lamps will follow.
• Always keep the UV lamps in the provided protective case or cover
until installation.
• Let the lamps cool at least 15 minutes before opening the lamp holders.
• Be careful not to touch the new UV lamps when placing them inside,
this will decrease the ability of the UV source.
• Use a cloth or cotton gloves as protection if needed.
• Do not stress the glass parts when tightening the electrical connections,
risk of breaking.
Ozoneair Purify only requires a small amount
of maintenance, some parts need regular
replacement for the machine to run properly and
ensure high quality purifying.
Make sure
the product is
disconnected from
power.
Open the two
hatches on the
bottom of the
product and loosen
the two screws.
Pull the lamp
holders straight
out from the
product.
Pull the lamp
straight out from
the base.
12 EN 13
EN

Order new UV lamp
UV lamps can be purchased directly from Ozoneair. Use of parts other
than those supplied by Ozoneair will void any warranties.
WARNING! - It is important to replace the lamps
when they reach its lifetime limit. An old lamp having a
darkened glass surface has a risk of breaking and should
be replaced at advised time. Always replace both UV
lamps at the same time to ensure proper running of the
machine.
NOTE - The UV lamps shall be disposed in containers
intended for lamps containing mercury.
Cleaning of UV lamps
It is recommended to clean the UV lamps every 3-6 months. This is to
ensure that the UV light is emitted with full eect from the lamps.
For regular maintenance or if the quartz glass of the UV lamps becomes
stained, extract the lamp holder and clean the outside of the lamp with
a soft cotton towel and alcohol. Be careful not to touch the quarts glass,
use protection gloves or a cloth if needed. Fingerprints can inhibit the
lamps disinfection eect.
To install new
lamps, reverse the
process
Reset the UV count
by pressing silver
and daily button
simultaneously
until “Replace UV”
has disappeared.
NOTE - The remote contains a CR2025 battery. New
batteries can be bought at your local hardware store.
Remove/insert HEPA filter
HEPA filter
After approximately 6 months or 5000 hours of use, the HEPA filter
needs to be replaced to maintain an accurate cleaning level and for the
machine to run optimally.
15
EN
Pull the fabric
straight out to
detach the outer
protection.
Remove the filter.
Insert a new filter,
ensure the filter is
inserted the right
way.
Order new HEPA filters
HEPA filters can be purchased directly from Ozoneair. Use of parts other
than those supplied by Ozoneair will void any warranties.
NOTE - There is a metal prefilter attached to the outer
protection to remove larger dust particles and hair.
This can be cleaned with a vacuum cleaner or by gently
washing with detergent and water.
Reset the filter
count by pressing
silver and
eect button
simultaneously
Attach the outer
protection.
14 EN
Remove/insert UV lamps

TROUBLESHOOTING
11
Problem Possible reason Solution
Product not starting The product is not turned on
The power cord is not properly connected
Electrical outlet is not working
Display does not work
Product starts but no UV light is visible
Treatment does not start
Low air flow
The product has not been activated
UV lamps are consumed
The treatment is started automatically
after a few seconds
Fan is blocked
HEPA filter is full
Push menu button to start the product
Replace UV lamps
When treatment is running the menu
button is encircled by a blue light
Make sure the fan input or output is not
blocked
Replace HEPA filter
Wait for delay function to disable or
remove by push and hold Timer button
(delay symbol disappears).
Delay function is active
16 EN
Turn on the product by pushing menu
button or on remote
Check to see that the power cord is
properly connected
Try another electrical outlet
PURIFY GO & PLUS
DANSK

Introduktion
Retningslinjer for sikkerhed
Genbruge
Beskrivelse & specifikationer
Dele
Display
Placering
Automatisk indstilling
Daglig indstilling
Vedligeholdelse
Fejlfinding
18
19
20
20
22
23
24
24
26
27
30
INDHOLDSFORTEGNELSE
DA 19
Denne brugervejledning er beregnet til at hjælpe
dig med at bruge din Ozoneair Purify sikkert og
også give dig de grundlæggende oplysninger om,
hvordan du betjener og vedligeholder produktet. Læs
instruktionerne omhyggeligt inden brug.
Hvis du efter læsning af manualen ikke er sikker på at du
forstår de risici, der kan være forbundet med produktet,
skal du ikke bruge maskinen. Kontakt Ozoneair, hvis du
har brug for yderligere informationer.
Brugsanvisningen vedrører kun grundlagene for sikker
brug af produktet. Det er ikke muligt at beskrive alle
situationer, der kan opstå, når du bruger produktet.
INTRODUKTION
I denne brugsanvisning bruges følgende symboler til at indikere, når
særlige forholdsregler eller visse procedurer skal følges.
ADVARSEL! - Dette symbol angiver en advarsel og skal
genkendes for at undgå personskader og/eller materielle skader.
BEMÆRK- Dette symbol angiver en særlig instruktion eller tip,
der hjælper dig med at få mest muligt ud af dit produkt.
Sikkerhedsoplysninger
Brugeransvar
02
Det er brugerens ansvar at overholde alle anbefalinger og
sikkerhedsretningslinjer, før produktet betjenes, og altid at bruge
produktet på en fornuftig måde.
• Åbn ikke UV-lampeholderne uden at frakoble produktet fra strømmen.
• Se ikke direkte på UV-lampen, mens den kører. UV-lys kan være
skadeligt for hud og øjne.
• Brug ikke i kontakt med vand.
• Sørg for, at luftindtaget på produktets bagside ikke er blokeret.
• Udskift ikke den originale strømadapter med en alternativ
strømadapter.
• Dæk ikke produktet eller placer genstande oven på produktet eller
strømadapteren.
• Rør ikke ved UV-lampernes glasoverflade med bare hænder. Brug
bomuldshandsker eller en klud for at undgå fingeraftryk, som kan
skade og mindske UV-lampens kapacitet.
Ved brug af produktet skal visse sikkerhedsfor-
anstaltninger følges, for at reducere risikoen for
personskade og materielle skader. Ozoneairs ga-
ranti gælder kun, hvis produktet bruges i henhold
til denne vejledning.
SIKKERHEDSRETNINGSLINJER
18 DA
01
01
02
03
04
05
06
07
08
09
10
11
DANSK
