OZTENT RX-5 User manual

ORX05TELUA AND ORX05ACLRA
OWNER’S MANUAL
RX-5 TENT
RX-5 LIVING ROOM & ZIP-IN FLOOR

Page 1 of 18
HELPFUL HINT
We recommend that you set up this
product before you leave for your trip.
Check that all parts are present and that
you familiarise yourself with the assembly
and disassembly of the product.
© Oztent Australia Pty Ltd 10/12/2021 - All rights reserved
Oztent Australia Pty Ltd
www.oztent.com
Prepared by: Michael Champ
Authorised by: Trent Fitzgibbins
Issue No. 0001
Issue date: 10/12/2021

Page 2 of 18
RX-5 Tent Owner’s Manual
Congratulations and thank you for choosing your
new Oztent product.
We are sure that you will find your new Oztent product a pleasure to use and enjoy.
Before set-up or use, we recommend that you read through this entire manual. It
provides full user instructions.
To avoid any problems that may occur when you use a new product for the first time,
it is important that the Oztent product is set up correctly. Please ensure that you read
all instructions contained in this manual carefully. We want you to have a safe and
enjoyable experience.
After unpacking your new Oztent product, please check that it is not damaged and
that all parts have been supplied. If in doubt, contact your local Oztent Customer Care
Centre or dealer.
Note that the RX Tent is sold with the Living Room by some retailers. If you have
purchased the RX Tent/Living room Combo, ensure that you have two packages - one
for the Tent, one for the Living Room. If you have purchased the RX tent only, you can
purchase the Living Room at a later date.
Don’t like reading instructions?
Scan the QR code below watch
the how to video

Page 3 of 18
Contents
Package Contents..................................................................................................................... 4
Warning....................................................................................................................................... 5
Use and Caring........................................................................................................................... 5
Important Notes ........................................................................................................................ 7
Setting Up the Oztent RX-5 ..................................................................................................... 8
Setting Up the Awning ............................................................................................................12
Setting Up Your Oztent RX-5 Fly ...........................................................................................13
Setting Up the Living Room ...................................................................................................14
Parts Identification...................................................................................................................17
Warranty ....................................................................................................................................18

Page 4 of 18
RX-5 Tent Owner’s Manual
Package Contents RX-5 Tent
Item General Part Name Qty
1 Tent 1
2 Fly 1
3 Reflective Guy Ropes 13
4 Pegs 18
5 1.9m Poles 2
6 2.3m Poles 2
7 2.6m Spreader 2
8Oversized Zippered Carry Bag 2
Package Contents RX-5 Living Room & Zip-In Floor
Item General Part Name Qty
1 Zip In Entry Floor 1
2 Complete Panel System 1
3 Reflective Guy Ropes 2
4 Tent Pegs 4
5 Oversized Zippered Carry Bag 1

Page 5 of 18
Use and Caring
Conditioning Canvas
It is important that you season your canvas when it’s new and also after long periods
of storage so it gives its best performance. Simply pitch your tent and wet it down
with a garden hose. This enables the stitching holes to shrink around the thread in
the stitch lines and the cotton in the canvas to swell. Let the canvas dry completely
before repeating this process another two times.
Due to the nature of canvas, any seam even after seasoning can still cause a drip. If
you do notice a seam has not been seasoned properly, simply rub a wax candle on
the exterior of the stitch line. This will create a waterproof barrier quickly and easily.
If cared for correctly, your tent will still be around for the next generation of campers
to enjoy.
Ventilation
Maintain adequate ventilation inside the tent at all times.
Campsite Choice
When choosing a campsite, carefully consider the possibility of falling rocks or tree
limbs, lightning, flash floods, avalanches, strong winds, and other potential hazards,
to reduce the risk of loss or injury.
Select a site that’s level, well drained, and is protected from the wind and other
elements. Clear the campsite of sharp stones, sticks, and other debris, both for
Warning
Never use any fuel-burning products (stoves, lanterns, heaters, etc.) inside
or within proximity of this tent. Use of fuel-burning products inside or within
proximity of the tent can result in the accumulation of dangerous concentrations of
carbon monoxide – a colourless, odourless and tasteless gas that is slightly denser
than air. Breathing carbon monoxide could cause serious injury or death.
Keep all flame and heat sources away from this tent. This tent is made with flame
resistant fabric but it is not fireproof. The tent fabric will burn if left in continuous
contact with an open flame or other heat source. Failure to keep all flame and heat
sources away from this tent may result in a fire that could cause serious injury or
death.
Before using this product, read and fully understand: 1) attached warnings; 2) the
instruction manual and all accompanying documentation. Failure to follow these
directions can cause an unsafe situation leading to injury.

Page 6 of 18
RX-5 Tent Owner’s Manual
comfort and to protect the floor of the tent. If possible, avoid setting the tent on
ground that is already wet. If this is not possible keep the tent well ventilated to
minimize humidity and condensation within the tent.
Pegs and Ropes
Peg down the tent properly at all times to reduce the risk of loss or injury to tent
users.
All tents require pegging to prevent them from being blown away in strong winds.
Always anchor the tent. Tent pegs and ropes are supplied to safely setup the tent in
most situations. It may be necessary to purchase additional and/or specialized pegs
and ropes for use in extreme or varied soil conditions.
Tightly tensioning the tent with attached ropes greatly increases the tent’s strength
and stability. This will also reduce fabric sagging and wrinkles and prevent rainwater
from pooling.
Using a Floor Saver
A Floor Saver keeps the tent floor clean and dry and it minimises floor wear and tear
by protecting it from excessive abrasion. The RV5 MeshFloor Saver suits the RX5.
Condensation
When warm, moist air comes in contact with the cool tent fabric condensation can
form. In most situations condensation can be controlled by allowing air inside the
tent to vent outside. During periods of high humidity, such as during rain storms, it
may be dicult to prevent or reduce condensation. In these situations ventilation
could actually increase the condensation by drawing in more humid air.
To reduce condensation use the included Tent Fly. The Tent Fly is designed to reduce
the temperature dierence between the inside and outside of the tent. It is normal to
find the underside of the fly covered in water droplets in humid conditions.
Condensation can also collect on parts of the floor inside the tent. This is also normal
and does not indicate leaking fabric.
Zippers
Be careful when using tent zippers. Go slow when zipping. Make sure to align the
zipper tracks before sliding the zipper and don’t exert excessive force on the zipper.
If fabric gets caught in the zipper, stop and slowly reverse the zipper to remove. A
silicone based lubricant may be used to improve zipping.
When dirt gets in the zipper teeth, it can cause abrasion and damage to the zipper
sliders. You can clean the zipper teeth by rinsing them with water. The pressure from
a regular garden hose will push out small sand particles.

Page 7 of 18
Cleaning
If the tent should require cleaning, set it up and use a sponge with warm water to
clean. If further cleaning is required, a garden hose can be used to wash o any
remaining dirt. Do not use detergent, soap, bleach, or have the tent dry cleaned, as
this may remove the waterproofing and/or damage the fabric. Allow the tent to air-
dry completely before packing or storing.
Storage
Packing and storing the tent while it’s wet or damp leads to premature breakdown
of the canvas and coatings. Prolonged exposure to moisture causes the waterproof
layer to break down, becoming soft, sticky and no longer waterproof. Storing a wet
tent can cause mildew to form on the fabric. Mildew will cause the tent to stain,
smell, and may lead to the premature breakdown of the waterproof coating. Dry the
tent thoroughly after every trip.
Animals and Insects
To prevent damage from animals chewing holes in the tent fabric, never store food
or cooking equipment in the tent.
When packing away ensure that there are no insects inside the tent as they may try
to eat their way out, causing holes in the material.
Important Notes
1. If you have an Oztent Floor Saver, place it where you want to set up prior to
setting up your tent.
2. Assemble your Tent Fly before Step 6 of “Setting Up the Oztent RX” in the
following instructions.
3. Pack your tent away in the reverse order of set up. Roll up your rear window
and front awning and leave the front door open. Remove your awning poles
and take all pegs out. Lower the tent to the ground and first swing in arm “A”
followed by arm “B”. Always swing the arms low to the ground.
4. If you have an Oztent RX-5, ensure your back extension is neatly tucked inside
the tent prior to pack down.
5. Although the Oztent RX series and accessories are designed for one person
operation, a second person will make your set-up significantly easier and faster.
6. The following illustrations are artistic representations of the Oztent RX series
and may dier from the production model. However, the overall operation will
be the same.

Page 8 of 18
RX-5 Tent Owner’s Manual
Setting Up the Oztent RX-5
Step 1:
Take the Tent out of the bag. Place the poles, pegs and fly away from the Tent space.
Step 2:
Swing out both arms one at a time.

Page 9 of 18
Step 3:
Pull the tent up using the swing tab found near the top frame.
Step 4:
Reach inside the tent and lock the hinges in place, pushing them up.
Before After

Page 10 of 18
RX-5 Tent Owner’s Manual
Step 5:
Adjust the tent so it sits properly.
Step 6:
Hammer in all pegs/stakes.

Page 11 of 18
Step 7:
Peg out all guy ropes at approximately a 45 degree angle to secure the tent.

Page 12 of 18
RX-5 Tent Owner’s Manual
Setting Up the Awning
Step 1:
Extend the awning. Twist to unlock awning poles and twist again to lock at desired height. Pop up the
awning and secure with guy ropes as shown.
Optional:
Lower one pole during heavy rain.

Page 13 of 18
Setting Up Your Oztent RX Fly
Step 1:
Throw the Oztent Fly over the tent. Tilt it forward and zip the Oztent Fly on the top of the tent.
Step 2:
Place the poles on each side to create spacing and secure with guy ropes as shown.

Page 14 of 18
RX-5 Tent Owner’s Manual
Setting Up the Living Room
Step 1:
Install your peak awning poles. Lock them at the height of your tent roof.
Step 2:
Install your ridge pole. Twist to lock at desired tension.
1.9m 2.2m

Page 15 of 18
Step 3:
Zip on the Living Room Panel.
Note: For easy set-up, lower down the taller poles before zipping on the panels.
Step 4:
Fully extend the peak awning poles once the Living Room Panel is zipped on.
Note: Ensure that orange pole caps placed over all pole spigots and under any guy ropes.

Page 16 of 18
RX-5 Tent Owner’s Manual
Step 5:
Place the zip-in floor inside the Living Room and spread out to all four corners making sure to align A and B
symbols on tent with A and B on the zip-in floor.
Note: Lift poles gently and slide zip-in floor section under poles. Position pole bases on reinforced panel on
zip-in floor.
Step 6:
Zip-in orange zipper to front of tent then zip-in black zipper to sides and front of tent.
Note: Ensure to align orange zipper on zip-in floor with orange zipper on front of tent section.

Page 17 of 18
Parts Identification
Item General Part Name Part No.
1 Main Extrusion OZME
2 Hinge OZH
3 Corner OZC
4 Foot Fitting OZFF
5 Foot OZF
6 M8 Nut, Washer and Slider OZS
7 Brace Extrusion with Fittings SZSA
6
5
7
2
3
3
1
4
2. Hinge
3. Corner
6. M8 Nut, Washer and Slider
4. Foot Fitting
5. Foot
7. Brace Extrusion with Fittings
1. Main Extrusion

Page 18 of 18
RX-5 Tent Owner’s Manual
Warranty
FOR SALES IN AUSTRALIA USA AND INTERNATIONAL MARKETS.
TENTS, FURNITURE AND ACCESSORIES: [OZTENT, MALAMOO,
AND FOXWING]
This document sets out the terms and conditions of product
warranties for Oztent, Malamoo and Foxwing branded products. It is
an important document. Please keep it with your proof of purchase
documents in a safe place for future reference should you require
service for your Oztent, Malamoo, or Foxwing branded product.
General Terms and Conditions
1. In this warranty
(a) ‘Oztent’ means Oztent Australia Pty Limited ABN 19 050
035 964 in respect of products purchased in Australia,
USA and International markets;
(b) ‘Product’ means any Oztent product purchased by you
accompanied by this document;
(c) ‘Warranty Period’ means
(i) where you use the Product for personal, domestic
or household purposes in Australia the period of ‘12’
months and in USA and International markets the
period of ‘12’ months;
(ii) for Tents and Tent Accessories used for personal,
domestic or household purposes (e.g. Peaked Side
Panel) the period of ‘24’ months;
(iii) for Furniture (e.g. Chairs) and Furniture Accessories
used for personal, domestic or household purposes
the period of ‘60’ months;
following the date of original purchase of the Product;
(d) ‘you’ means the purchaser of the Product not having
purchased the appliance for re-sale, and ‘your’ has a
corresponding meaning.
2. This warranty only applies to Products purchased and used
in Australia, USA or International markets and is in addition
to (and does not exclude, restrict, or modify in any way)
any non-excludable statutory warranties in Australia, USA or
International markets.
3. Oztent warrants that, when dispatched from an Oztent
warehouse, the Product is free from defects in materials and
workmanship for the Warranty Period.
4. During the Warranty Period Oztent or its Authorised Service
Centre will, at no extra charge if your product is readily
accessible without special equipment, and subject to these
terms and conditions, repair or replace any parts which it
considers to be defective. You agree that any replaced Product
or parts become the property of Oztent. This warranty does not
apply to guy ropes, tent pegs, or similar perishable parts.
5. Parts and Products not supplied by Oztent are not covered by
this warranty.
6. Where you are within an Oztent service area, this warranty
covers the cost of transport of the Product only to and from
Authorised Service Centres of Oztent (“ASC”) and travelling
costs for representatives of the ASC to and from your home
or business. If you are outside an Oztent service area, or you
are claiming for an accessory you will bear these costs. For
information about whether you are within an Oztent service
area, or information on your nearest ASC please phone 1800
OZTENT or 1800 698368 in Australia, +8555 OZTENT or
[phone] in the USA or [phone] in International
markets.
7. Proof of purchase is required before you can make a claim
under this warranty.
8. You may not make a claim under this warranty unless the defect
claimed is due to faulty or defective parts or workmanship.
Oztent is not liable in the following situations (which are not
exhaustive):
(a) The Product is damaged by:
(i) accident
(ii) misuse or abuse, including failure to properly
maintain or service
(iii) normal wear and tear
(iv) storm damage or improper storage
(v) incomplete or improper installation
(vi) incorrect, improper or inappropriate operation
(vii) insect or vermin infestation.
(b) The Product is modified without authority from Oztent
in writing.
(c) The Products model number, serial number or warranty
seal has been removed or defaced.
(d) The Product was serviced or repaired by anyone other
than Oztent or its Authorised Service Centres.
9. This warranty, the contract to which it relates and the relationship
between you and Oztent are governed by the law applicable in
the Australian State where the Product was purchased or the
law applicable in the USA or International markets if the Product
was purchased in the USA or International markets. Where the
Product was purchased in the USA or International markets for
business purposes the Consumer Guarantee Act does not apply.
Limitation of Liability
10. To the extent permitted by law:
(a) Oztent excludes all warranties other than as contained in
this document;
(b) Oztent shall not be liable for any loss or damage whether
direct or indirect or consequential arising from your
purchase, use or non-use of the Product.
11. Provisions of the Trade Practices Act and State consumer
legislation in Australia, and the Consumer Guarantees Act, the
Sale of Goods Act and the Fair Trading Act in New Zealand
or any Act or State consumer legislation in the USA or
International markets, imply warranties or conditions, or impose
obligations, upon Oztent which cannot be excluded, restricted
or modified. To the extent permitted by law, the liability of
Oztent (if any) arising out of or in relation to the Product or any
services supplied by Oztent shall be limited (where it is fair and
reasonable to do so),:
(a) in the case of Products, at its option, to the replacement
or repair of the Product or the supply of equivalent
products or the payment of the cost of replacing the
Product or having the Product repaired or of acquiring
equivalent Product. Upon being replaced, parts and
Products become the property of Oztent; or
(b) in the case of services, at its option, to the supply of the
services again or the payment of the cost of having the
services re-supplied;
and in the case of Products or services supplied in the USA or
International markets, loss or damage whether direct or indirect
or consequential that is reasonably foreseeable.
Privacy
You acknowledge that if you make a warranty claim it will be
necessary for Oztent and its Authorised Service Centres to exchange
information in relation to you to enable Oztent to meet its obligations
under this warranty.
Important Notice
Before calling for service please check carefully the owner’s manual,
use and care instructions and the warranty terms and conditions.
Product Registration
To assist in validating warranty, we kindly ask that you register your
product purchase online with Oztent in your country of origin or
alternatively complete the warranty card provided with your product
(if applicable) and return it to Oztent care of the nominated address.
Please visit our website
for more warranty
information & to register
your Oztent product
oztent.com.au/product-rego

Oztent Australia Pty Ltd
PO Box Q1700 Sydney NSW 2000
Australia Ph: 02 8706 5100
USA Ph: 855 569 8368
International Ph: [phone]
www.oztent.com
