P'kolino Twin Bed with Storage Drawers PKFFBRTBSDCHY User manual

Twin Bed with
Storage Drawers
Made in Brazil.
July / 2020
20
READ ALL INSTRUCTIONS BEFORE ASSEMBLING TWIN BED.
KEEP INSTRUCTIONS FOR FUTURE USE.
THE ASSEMBLY OF THIS PRODUCT REQUIRES TWO ADULTS.

Twin

Made in Brazil.
July / 2020
20
You will need a Phillips head screwdriver and a hammer
Twin Bed Parts:
Philips screwdriver Hammer
Tools required
10
11
12
13
14
14
15 16
9
38
9
4
17
6
6
5
2
Manufacturer Label
(x2)

Hardware:
FOR MISSING PARTS OR HARDWARE:
DO NOT CONTACT THE STORE WHERE YOU MADE YOUR PURCHASE.DO NOT CONTACT THE STORE WHERE YOU MADE YOUR PURCHASE.
Please contact the manufacturer directly at [email protected] or 888-403-8992.
For customer service cases involving hardware please provide the part number.
16 Wooden dowel 10x40 (A)
06 Bolts 7 x 100 (C)
04 Bolts 1/4 x 110 (D)
08 Bolts 1/4 x 90 (E)
12 Elliptical nuts (F) 36 Screws 4 x 30 (G) 64 Screws 3.5 x 12 (H)
2 Wooden spacers 88mm (I) 1 Allen wrench (J) 8 Casters (K)
8 Plates (L)
24 Wooden dowel 8x30 (B)
04 Adhesive felt (M)

Step 1
Headboard panels
1) Insert wooden dowels (A) into the holes, as shown in the diagram.
Hammer
Qty
08
A
10x40 Wooden Dowel
10 x 40 Wood dowel
(x2)
Step 2
1)Attach parts 5, 6 and 7 on the post 1 and 2 with 2 bolts (D),
2 elliptical nuts (F) and 6 bolts (C), using the allen wrench (J).
3) Remove the paper from the adhesive felt (M) and attach to the bottom of the posts 1 and 2
Headboard
Qty
06
C
Ø17 7 x 100 Bolt
7,0 x 100 Bolt
1/4 x 110 Bolt
Qty
02
D
¹⁄" x 110 Bolt
Allen
wrench
Qty
01
J
A
A
C+J
C+J
C+J
J+C
INSIDE
F
FF
J+C
J+C
D+J
J+D
M
M
A
A
A
A
FQty
02
1/4
Elliptical Nut
J
C/D
5
6
7
5
6
6
7
1
2
Adhesive
tape
Adhesive felt
Qty
02
M

Step 3
Footboard panel
1) Insert wooden dowels (A) into the holes, as shown in the diagram.
Step 4
1)Attach footboard panel 8 on the posts 3 and 4 with 2 bolts (D) and
2 elliptical nuts (F) using the allen wrench (J).
3)Remove the paper from the adhesive felt (M) and attach to the bottom of the posts 3 and 4
Footboard
Hammer
Qty
04
A
10x40 Wooden Dowel
10 x 40 Wood dowel
1/4 x 110 Bolt
Qty
02
D
¹⁄" x 110 Bolt
Allen
wrench
Qty
01
J
FQty
02
1/4
Elliptical Nut
A
A
A
A
D+J
J+D F
F
F
J
D
8
8
4
3
M
M
Adhesive
tape
Adhesive felt
Qty
02
M

Hammer
Qty
04
A
10x40 Wooden Dowel
10 x 40 Wood dowel
Step 5
Rails
1) Insert wooden dowels (A) into the holes, as shown in the diagram.
Step 6
1)Attach rails 9 on the headboard, with 4 bolts (E),
and 4 elliptical nuts (F) using the allen wrench (J).
Rails and headboard
1/4 x 90 Bolt Qty
04
E
Ø17 ¹⁄" x 90 Bolt
FQty
04
1/4
Elliptical Nut
Allen
wrench
Qty
01
J
A
A
A
A
E+J
E+J
F
F
F
F
E+J
E+J
J
E
9
9
9
9

Step 7
Footboard
1/4 x 90 Bolt Qty
04
E
Ø17 ¹⁄" x 90 Bolt
FQty
04
1/4
Elliptical Nut
Allen
wrench
Qty
01
J
4 x 30 Screw
4,0 x 30 Screw
PN Qty
24
G
Philips screwdriver
F
J+E
J+E
J+E
F
F
F
J+E
G
G
G
G
G
G
G
G
G
G
G
G
GGGGGGGGGGGG
=0mm
10
10
G
I
I
8
3
4
10 x12
Wooden spacer
3 ⁷⁄" (88mm)
Qty
02
I
I
1)Attach slats 10 on the rails with 24 screws (G);
2)The rst slat must be xed to the end of the side rail bracket
3)After xed the rst slat use the hardware letter (I)
to help dene the space between each next slats.
Use 1-(I) on the left side rail and 1-(I) on the right side rail
1)Attach footboard on the rails 9 with 4 bolts (E) and
4 elliptical nuts (F) using the allen wrench (J).
9
9
Step 8
Slats

Hammer
Philips screwdriver
Step 9
Drawer parts
1) Insert wooden dowels (B) into the holes, as shown in the diagram.
2) Attach plate (L) with screws (H)
4 x 30 Screw
4,0 x 30 Screw
PN Qty
06
G
Philips screwdriver
(x2)
8 x 30 Wooden Dowel
Qty
24
B
8 x 30 Wood dowel
LQty
08
Plate
3.5 x 12 Screw
3,5 x 12 Screw
PN Qty
16
H
(x2)
B
B
B
B
B
B
B
B
L
LL
L
H
HH
HH
HH
H
B
B
B
B
G
G
G
11
12
13
13
12
11
Step 10
1)Attach back side 12 and support 13 on the right side 11 with screws (G)
Right side of drawer
15
Pre holes

Step 11
Step 12
Drawer bottom
1) Insert drawer bottom 14, as shown in the diagram.
(x2)
(x2)
14
14
12
13
11
4 x 30 Screw
4,0 x 30 Screw
PN Qty
06
G
Philips screwdriver
G
GG
1)Attach the right side 15 on the back side 12 and to the support 13 with screws (G)
Right side of drawer
15
12
13

Step 13 (x2)
(x2)
Step 14
Drawer bottom
1) Insert drawer bottom 14, as shown in the diagram.
14
Drawer front
1)Attach the drawer front 16 to the parts 11 and 15 with the screws (H)
3.5 x 12 Screw
3,5 x 12 Screw
PN Qty
16
H
Philips screwdriver
H
H
H
H
H
H
H
H
H
H
16

Step 15
Step 16
Step 1
Step 2
Casters
1)Turn the drawer down and attach the casters (K)
to the sides with the screws (H).
(x2)
3.5 x 12 Screw
3,5 x 12 Screw
PN Qty
32
H
Philips screwdriver
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
H
K
K
K
K
K
K
H
H
Caster
Qty
08
K
Pre holes

This product has been carefully crafted of MDF, solid pine wood and/or pine veneers. These materials derive
from plantations, a renewable and well managed forest, therefore, not endangering the environment. The highest
quality standards have been implemented to assure a sturdy and reliable product. Due to the natural variances in
the graining of wood, you may notice subtle differences in the shading and tone of the color stain, warp, holes,
wood knots and also small cracks. This is not a defect. But rather a result of the natural beauty of the wood itself.
ABOUT WOOD AND FINISH:
