PA MPU130BT MKII User manual

USER GUIDE
H11320 - Version 1 / 02-2022
MPU MKII

ENGLISH CD/USB/SD/BT player and Tuner with remote control
Page 2
1 - Please read carefully :
We strongly recommend to read carefully and understand the safety instructions before
attempting to operate this unit.
2 - Please keep this manual :
We strongly recommend to keep this manual with the unit for future reference.
3 - Operate carefully this product :
We strongly recommend to take into consideration every safety instruction.
4 - Follow the instructions:
Please carefully follow each safety instruction to avoid any physical harm or property
damage.
5 - Avoid water and wet locations :
Do not use this product in rain, or near washbasins or other wet locations.
6 - Installation :
We strongly encourage you to only use a fixation system or support recommended
by the manufacturer or supplied with this product. Carefully follow the installation
instructions and use the adequate tools.
Always ensure this unit is firmly fixed to avoid vibration and slipping while operating
as it may result in physical injury.
7 - Ceiling or wall installation :
Please contact your local dealer before attempting any ceiling or wall installation.
8 - Ventilation :
The cooling vents ensure a safe use of this product, and avoid any overheating risk.
Do not obstruct or cover these vents as it may result in overheating and potential
physical injury or product damage. This product should never been operated in a
closed non-ventilated area such as a flight case or a rack, unless cooling vents are
provided for the purpose .
9 - Heat exposure :
Sustained contact or proximity with warm surfaces may cause overheating and product
damages. Please keep this product away from any heat source such as a heaters,
amplifiers, hot plates, etc...
Sound levels
Our audio solutions deliver important sound pressure levels
(SPL) that can be harmful to human health when exposed
during long periods. Please do not stay in close proximity of
operating speakers.
1 - Safety information
Important safety information
Symbols used
Any maintenance procedure must be performed by a CONTEST
authorised technical service. Basic cleaning operations must tho-
roughly follow our safety instructions.
This product contains non-isolated electrical components. Do not
undertake any maintenance operation when it is switched on as
it may result in electric shock.
This unit is intended for indoor use only. Do not use it in a wet,
or extremely cold/hot locations. Failure to follow these safety ins-
tructions could result in fire, electric shock, injury, or damage to
this product or other property.
WARNING : This unit contains no user-serviceable parts. Do not open the housing or attempt
any maintenance by yourself. In the unlikely even your unit may require service, please contact your
nearest dealer.
In order to avoid any electrical malfunction, please do not use any multi-socket, power cord extension
or connecting system without making sure they are
perfectly isolated and present no defect.
10 - Electric power supply :
This product can only be operated according to a very specific voltage. These
information are specified on the label located at the rear of the product.
11 - Power cords protection:
Power-supply cords should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords at
lugs, convenience receptacles and the point where they exit from the fixture.
12 - Cleaning precautions :
Unplug the product before attempting any cleaning operation. This product should be
cleaned only with accessories recommended by the manufacturer. Use a damp cloth
to clean the surface. Do not wash this product.
13 - Long periods of non use :
Disconnect the unit’s main power during long periods of non use.
14 - Liquids or objects penetration :
Do not let any object penetrate this product as it may result in electric shock or fire.
Never spill any liquid on this product as it may infiltrate the electronic components
and result in electric shock or fire.
15 - This product should be serviced when :
Please contact the qualified service personnel if :
- The power cord or the plug has been damaged.
- Objects have fallen or liquid has been spilled into the appliance.
- The appliance has been exposed to rain or water.
- The product does not appear to operate normally.
- The product has been damaged.
16 - Inspection/maintenance :
Please do not attempt any inspection or maintenance by yourself. Refer all servicing
to qualified personnel.
17 - Operating environment :
Ambient temperature and humidity: +5 - +35°C, relative humidity must be less than
85% (when cooling vents are not obstructed).
Do not operate this product in a non-ventilated, very humid or warm place.
Recycling your device
• As HITMUSIC is really involved in the environmental cause,
we only commercialise clean, ROHS compliant products.
• When this product reaches its end of life, take it to
a collection point designated by local authorities. The
separate collection and recycling of your product at the time
of disposal will help conserve natural resources and ensure
that it is recycled in a manner that protects human health
and the environment.
This symbol signals an important safety precaution.
The CAUTION symbol signals a risk of product deterioration.
The WARNING symbol signals a risk to the user’s physical integrity.
The product may also be damaged.
Instructions and recommendations

ENGLISH
AUDIOPHONY PUBLIC ADDRESS
Page 3
• CD/Mp3 player with anti-shock memory (AVM
System)
• USB player with USB Mass Storage plug (FAT32, 16
Go max.)
• SD and SDHC player (16Go max)
• Output level adjustment
• AM and FM tuner with autoscan and 10 recordable
stations
• Browse through menus and tracks
• Supplied with an infrared remote control
• Customisable or random playlist
• RCA Unbalanced output(-10dB)
• Remote control functions:
• Source selection (CD, USB, SD, BT or Tuner)
• Play, Pause, Skip, Search
• Program, Random and Repeat functions
• Folder and track selection
• Customisable and recordable stations
• Mute
• CD Eject
3 - Main characteristics
4 - Technical specifications
• Power supply: 230 V AC - 50 Hz ou DC 13,2V
• Power consumption: 26W
2.1 - Compact disks
a - Handling precautions
Please protect the disks in order for dust, fatty deposits and fingerprints not to damage them.
However, if one of your disks is dirty please rub it gently with a dry cloth.
Do not use alcohol, any solvent, antiseptic liquids or silicone-coated clothes.
Handle your disk with precaution and protect its surface, especially while getting it out of its case.
Do not bend the disk.
Do not heat it.
Do not enlarge the hole at the center of the disk.
Do not write on the screenprinted part of the CD.
In the event of the appearance of condensation due to important temperature changes, please let your CD
dry without using any heat source.
b - Storage precautions
Always eject the disk when you are not using it.
Store your disks in the case provided for the purpose, protected from dust and shocks.
Do not store your CDs in places:
- Exposed to sunlight.
- Subject to the accumulation of dust and humid.
- Near heat sources (radiator...).
2 - Our advices
• Player dimensions: 482 x 44 x 275 mm
(19" - 1 unit)
• Weight: 3.4 kg

ENGLISH CD/USB/SD/BT player and Tuner with remote control
Page 4
5 - Preparation and installation
5.1 - Checking the contents
The package must contain the following articles:
- The MPU130BTMKII
- An infrared remote control
- The user guide
- A double RCA cable
- An antenna set (AM and FM)
- 1 power cord.
5.2 - Installing the unit
a-Set up the MPU130BTMKIIMKII over a flat surface
or within racks.
b - Please make sure the unit is installed in a properly
ventilated place, unexposed to sunlight rays, excessive
temperatures or humidity.
CAUTION:
This device can be safely operated when placed on
a flat surface not exceeding a 15° slope. Using this
player on excessively steep surfaces might result in
the ejection, deterioration or impossibility to read your
disks.
The LCD display was designed to be read easily when
you are in front of the player. Please set up the unit in
order for the display to be clearly visible.
5.3 - Connecting the unit
a - Turn the unit off (unplug it).
b - Connect the RCA cable to one of the inputs of your
mixing desk.
CAUTION:
Please use the cables supplied. Using other types of
cables might cause severe damages to the unit.
Please make sure the device is OFF before connecting
any sources in order to prevent severe damages.
6 - Compatible medias
The MPU130BTMKII is able to read several media
formats:
- MP3
- WMA
- CDA
When using the CDA format, please note that the CD
containing the CDA files cannot use any other kind of
files as CDA files cannot be mixed up with MP3 or WMA
files on the same support.
The MP3-Pro, MP4, Wave (etc.) formats are not suppor-
ted by this system.
Please only use MP3, WMA or CDA files on your disks
as other formats might damage your device.
We strongly recommend to use high-quality medias,
recorded at low speed.
Notes:
• Some CD-R/CD-RW recorded via CD writer might
not be readable for many reasons such as the disk
characteristics, scratches, stains, condensation etc.
• Some disks might also be impossible to read if
recorded via CD writer due to the parameters of the
operating systems. Please make sure to format your
disks correctly before rewriting. For more details,
please read the user guide supplied with your CD
6-1 - Compact disks
writer.
• This device cannot read partially recorded or not
finalised CD-R or CD-RW.
• For more information about handlig CD-R/CD-RW,
please consult the safety precautions supplied with
each disk.
About CD-R/RW
Due to the very particular structure of CD-R/CD-RW
disks, they should not be let in Pause mode at a precise
point, as it may result in difficulties to resume the
playing.
As a result, we strongly recommend you to use archive
desks to save your most important files.
About DualDisc
This product was designed to comply with the music
CD regulations. However, performances and flawless
reading are not guaranteed if you are using non-com-
pliant CDs.

ENGLISH
AUDIOPHONY PUBLIC ADDRESS
Page 5
6-2 - USB supports and SD cards
The MPU130BTMKII is able to read files stored on USB
supports such as USB keys , USB hard disks, or any
other type of devices compatible with the USB Mass
Storage norm.
Your device can read the following formats stored on
USB support:
- MP3 (VBR or CBR) up to 320kbits/s
- WMA (same characteristics)
Your disks must be FAT-formatted to be compatible with
the MPU130BT. The Mpu130 is unable to read contents
via supports with different formats (NTFS, ...).
Please note that some FAT devices might present com-
patibility issues due to specific commands or functions
they might offer.
That is why we strongly recommend to test the com-
patibility of a device with the MPU130BTMKII before
acquiring it.
The MPU130BTMKII powers up USB keys and HDD
USB-connected.
However, some disks or keys might require a power
supply unit delivering more power than the MPU130BT.
We strongly recommend to use these devices with their
external power supply unit in order to prevent any kind
of problems or damages.
The USB port of the MPU130BTMKII is a USB Mass
Storage port. It cannot be used to read audio fluxes
such as the USB Audio codec under any circums-
tances. The MPU130BT is therefore not compatible
with the devices uses such fluxes such as computers,
portable players, USB microphones, etc.
The SD card slot has the same file properties and
restrictions as the USB port. SD HC can be used with
the MPU130BT, subject to not exceed a maximum size
of 16 Gb.
6-3 - Playing MP3/WMA files
MP3 files may have two formats: Constant bitrate (CBR) and Variable bitrate (VBR). The MPU130BTMKII the reading
and DJ reading of both CBR and VBR MP3 files. However, you might notice that the super-fast search speeds are
slower for VBR files,
in comparison with CBR files. As a result, if speed is an important factor to you, we recommend to use MP3 files in
the CBR format. The MP3 files must meet the following criterias indicated below:
MP3 Format
MPEG-1 Compatible with the Audio Layer-3 sampling rate from 32 kHz, 44,1 kHz,
48 kHz; Bit rate: 32 Kbps at 320 Kbps.
MPEG-2 Compatible with the Audio Layer-3 sampling rate from 16 kHz, 22,05
kHz, 24 kHz, Bit rate: 16 Kbps (stereo) a 160 Kbps.
ID3 Label
Compatible with the ID3 Versions 1.0/1.1/2.2/2.3/2.4. Indicates the title,
album, artist, and genre. Alphanumeric characters and some symbols
only can be displayed.
File extension .mp3, .MP3, .mP3, .Mp3
WMA Format File extension .wma, .WMA

ENGLISH CD/USB/SD/BT player and Tuner with remote control
Page 6
7 - Description of the front and rear panels
[1] POWER switch
Turns the unit ON/OFF.
[2] SD Port
This SD port allows you to insert your SD or SDHC
card. Please only use FAT32-formatted, compatible
devices.
[3] 1 to 10 memory buttons
Allows you to directly access one of the CD player
(or current folder) track. In Tuner mode, allows you to
quickly access the preset frequencies.
To save one of these frequencies, press and hold the
corresponding button until the button number appears
at the top right of the screen.
[4] CD / CARD MEMORY Button
Allows you to create playlists. Press the PROG button
of your player or remote control.
The display will indicate "PROG". Select the files you
want to insert wit hthe FOLDER and SKIP buttons.
Once the files have been chosen, press CD/CARD
MEMORY. Repeat these steps for each file you want to
add to your playlist.
Press PLAY to launch a playlist.
[5] CD Slot
Allows you to insert/eject your CD.
[6] LCD Screen
Displays information about tracks or the current status
of the player.
[7] Infrared sensor
Allows you to receive informations sent via the remote
control.
[8] USB Port
This USB port allows you to insert a Mass Storage
device (key or HDD). Please only use FAT32-
formatted, compatible devices.
[9] PROG MEMORY Button
In SD/USB/CD mode:
This button allows you to create your playback
programs. To create your playlist, press the PROG
button on your player or remote control. PROG will
appear on the screen. Select your files to play with the
FOLDER and SKIP buttons. Once you've selected a
file, press the ENTER button. Repeat for each file you
want to add to the list.
Press PLAY to begin program playback.
In RADIO mode:
This button is used to store radio stations. Select a
station using the ▼TUNNING ▲buttons, then press
the MEMORY button and then press one of the
memory buttons M1 to M10.
7.1 - Front panel
1 2 3 4
5 7 14 15 16 17 18
86 9 10 11 12 13

ENGLISH
AUDIOPHONY PUBLIC ADDRESS
Page 7
[10] REP/RAN Button
This key is used to switch between the different repeat
playback modes. These modes are shown on the
display:
- REPEAT ONE: The current song is repeated infinitely
- REPEAT ALL : The current media content is repeated
infinitely
- RANDOM ON : The content of the current folder is
played randomly
- RANDOM OFF : Playback returns to normal mode
[11] PREV/NEXT/ ▼MEMORY ▲keys
In SD/USB/CD mode:
These keys allow you to move from one song to
another.
With an audio CD, by holding these keys to fast
forward/backward through the current song.
In RADIO mode:
These keys allow you to move from one stored station
to another.
[12] STOP/EJECT Button
Allows you to stop the current track and eject the CD
from the player. When using a USB key or SD card,
please always press this button before removing the
media from its slot.
[13] Source selection
Allows you to switch from a source to another:
- USB
- SD
- CD
- Tuner
- Bluetooth
Press this button several times to switch from a source
to another.
To connect a Bluetooth source, switch to Bluetooth
mode and search your Bluetooth device for a device
named BLUE. Then connect this device. Playback
controls are performed from your Bluetooth source
device.
[14] INFO / SINGLE Button
In SD/USB/CD mode:
Allows you to limit playback to a single song.
In RADIO mode:
Allows you to view information about the operation of
the radio.
[15] TUNNING / FOLDER Button
In SD/USB/CD mode:
Allows you to move from one directory to another.
In RADIO mode:
Use these keys in TUNING (radio) mode to change the
reception frequency. Press and hold for fast scrolling
and automatic stop at the next reception.
[16] BAND / PLAY/PAUSE Button
In SD/USB/CD mode:
Use this button to play or pause the unit.
In RADIO mode:
Use this button to switch between AM and FM bands.
[17] A→BButtons
This key is used to create loops. A first press defines
the start of the loop, the next press gives the end of
the loop.
[17] SKIP Buttons
Allow you to select a file within a folder, or select a track
on an Audio CD.
[18] Volume control knob
Allows you to increase/decrease the volume of your
device.

ENGLISH CD/USB/SD/BT player and Tuner with remote control
Page 8
7.2 - Rear panel
[19] AUTO PLAY switch
When it is set to ON, it automatically starts the playback
when the power is turned on.
[20] Unbalanced outputs
These RCA send an analogue, unbalanced signal (-10
dB) to your sound system.
[21] Bluetooth antenna
[22] FM Antenna connector
Connect your FM antenna cable here.
[23] AM Antenna connector
Connect your AM loop antenna here.
[24] 13.2 V DC power supply
The MPU130BT can use a 12 V DC power supply unit
connected to this socket.
[25] 220 V AC power supply
Connect here the supplied 220V power cord.
Note: this connector contains a fuse. If need to replace
the fuse, please only replace it by a new one with the
exact same characteristics.
MADE IN TAIWAN
Distributed by HITMUSIC S.A.S
Zone Cahors Sud
46230 FONTANES - FRANCE
BT ANTOUTPUT
AUTO PLAY
RADIO POWER
SUPPLY
DC 13.2V
ON
OFF
FUSE :
T1A - 250V
5 x 20 mm
AC 230V - 50Hz
45W
21
20 22 23 24 2519
7.3 - Remote control
1
9
10
19
20
16
15
6
8
5
13
12
11
7
2
3
4
17
18
14
[1] 1 to 10 memory buttons
Allows you to directly access one of the CD player
(or current folder) track. In Tuner mode, allows you to
quickly access the preset frequencies.
[2] FOLDER Buttons
Allow you to move from a folder to another. Folders are
numbered by alphabetical order.
When using an Audio CD, these buttons allow you to
search a specific time within the current track.
[3] A→BButtons
This key is used to create loops. A first press defines
the start of the loop, the next press gives the end of
the loop.
[4] Source selection
Allows you to switch from a source to another:
- USB
- SD
- CD
- Bluetooth
- Tuner
[5] MEMORY Button
Allows you to add a frequency to the customisable
frequencies of your device (M1-M10). Press the
MEMORY button then the corresponding M button to
save the current frequency.

ENGLISH
AUDIOPHONY PUBLIC ADDRESS
Page 9
6] POWER Button
Turns the MPU130BT MKII on and off.
[6] EJECT Button
Press here to eject the CD.
[7] MEM buttons
In SD/USB/CD mode:
This button allows you to create your playback
programs. To create your playlist, press the PROG
button on your player or remote control. PROG will
appear on the screen. Select your files to play with the
FOLDER and SKIP buttons. Once you've selected a
file, press the ENTER button. Repeat for each file you
want to add to the list.
Press PLAY to start program playback.
In RADIO mode:
This button is used to store radio stations. Select a
station using the ▼TUNNING ▲buttons, then press
the MEMORY button and then press one of the
memory buttons M1 to M10.
[8] BAND Button
Use this button to switch between AM and FM bands.
[9] EJECT Button
Use this button to eject the CD from the player.
[10] PROG Button
Allows you to create playlists. Press the PROG button
of your player or remote control.
The display will indicate "PROG". Select the files you
want to insert wit hthe FOLDER and SKIP buttons.
Once the files have been chosen, press ENTER.
Repeat these steps for each file you want to add to
your playlist.
Press PLAY to launch a playlist.
[11] SINGLE Button
Allows you to limit playback to a single song.
[12] REPEAT / RANDOM button
This key is used to switch between the different repeat
playback modes. These modes are shown on the
display:
- REPEAT ONE: The current song is repeated infinitely
- REPEAT ALL : The current media content is repeated
infinitely
- RANDOM ON : The content of the current folder is
played randomly
- RANDOM OFF : Playback returns to normal mode
[13] PLAY/PAUSE Button
Allows you to play/pause the current track.
[14] STOP Button
Allows you to stop the current track and eject the CD
from the player. When using a USB key or SD card,
please always press this button before removing the
media from its slot.
[15] SKIP Buttons
Allow you to select a file within a folder, or select a
track on an Audio CD.
[16] MUTE Button
Allows you to interrupt the audio output without
pausing the current track. Press this button to
activate/deactivate this function.
[17] ENTER Button
Allows you to confirm your choice.
[18] INFO Buttons
In radio mode, this key displays information on the
operation of the radio.
[19] TUNING Buttons
In Tuning mode (radio), use these buttons to modify the
receiving frequency. Hold this button to automatically
jump to the next available station.
[20] VOLUME Buttons
These keys are used to increase or decrease the
output volume.

Because AUDIOPHONY®takes the utmost care in its products to make sure you only get the best possible quality, our products are subjects to modifications without
prior notice. That is why technical specifications and the products physical configuration might differ from the illustrations.
Make sure you get the latest news and updates about the AUDIOPHONY®products on www.audiophony-pa.com
AUDIOPHONY®is a trademark of HITMUSIC S.A.S - Zone Cahors sud - 46230 FONTANES - FRANCE
