Pac-Dent HSD-01 Operational manual

Passion for Excellence
Automatic
Non-Contact
Hand Sanitizer
Dispenser
Please read the manual carefully
before using this product.
Product User Manual
REF HSD-01

Passion for Excellence
670 Endeavor Circle, Brea, CA 92821 USA
909.839.0888
[email protected]
www.pac-dent.com
909.839.0881
Rev.073020 Made in China

PRODUCT INFORMATION
This innovate hand sanitizer dispenser allows fast non-contact
delivery of sanitizing solution while simultaneously providing a
flash of UV light for additional disinfection. The dispenser can be
easily mounted to any wall or installed on the included stand. The
stainless steel stand is sturdy, height adjustable, and comes in a
stylish black finish. Includes refillable bottle for sanitizing solution.
• Non-contact hand sanitizer dispenser
• UV light for additional disinfection
• Includes stylish height-adjustable stand
• Works with both sanitizing spray and gel
Adjustable Floor Stand
Automatic Dispenser
Drip Tray
(Hand Sanitizer Gel or Spray)
Dispenser Material ABS Plastic
Stand Material Stainless Steel
Dispenser Dimensions 4.1” x 4.5” x 10.1”
Stand Height (adjustable) 46” - 64”
Reservoir Capacity 1000 ml
Power AC Adapter or 4 x C Batteries
PRODUCT CONTENTS:
21
• 1 x Dispenser unit with reservoir tank
• 1 x Telescopic pole with base
• 2 x M10 screws, 3 x M5 screws,
3 x M4 screws, 3 x M4 Nuts
• 1 x Back plate
• 1 x Support plate
• 4 x C batteries
• 1 x AC adapter
• 1 x U-shaped key
• 1 x User manual

PRODUCT INFORMATION
RELATED PRODUCTS
Hand Sanitizer
Advanced MoisturizingGel
WithAloe Vera
Powerful&Long Lasting
Leaves Hands Feeling Soft
99.999% of Germs*
NET CONTENTS: 1 Gallon (3.78L)
70%v/v
Ethyl Alcohol
82128
REF
Kills
82102 82108 82116 82128
(2 fl. oz.) (8.4 fl. oz.) (16 fl. oz.) ( 1 Gallon )
ProGuard™70%
Hand Sanitizer Advanced
Moisturizing Gel
ProGuard™80%
Hand Sanitizer Spray
83027
(27.05 fl. oz.)
83004
(4 fl. oz.)
83002
（2 fl. oz.)
43
ProGuard™
Dry Wipes
RELATED PRODUCTS
PDW-50
(4” x 4” 50 wipes)
ProGuard™
Compressed Dry Wipes
PCDW-50
(50 compressed wipes)
WARNING
Use the dispenser only as directed. Do not use in areas where
dispenser may be exposed to wet environments such as showers
or outdoors. Do not install or use in extreme hot or cold locations.
Dispensed product intended for external use only. Refer to refill for
actions in case of ingestion.
CLEANING & MAINTENANCE
Clean exterior surfaces of the dispenser using warm water and
mild soap. Do not use abrasive cleaners. Dry with a soft cloth.

USER INSTRUCTIONS
STEP ONE: Pole/Base Assembly
A. Locate the Base, Telescopic
Pole, and M10 Screw.
B. Secure the Pole to the Base by
screwing the M10 Screw into the
bottom of the Base. When
installed correctly, the Pole should
be able to extend upwards.
Telescopic Pole
Base
Screw M10
STEP TWO: Back/Support Plate Assembly
A. Locate the Support Plate, Back
Plate, and three M5 Screws.
B. Connect the Back Plate and
Support Plate together with the
three M5 Screws and screw them
into the designated holes from the
front of the Back Plate. When
installed correctly, the Support
Plate’s L-shaped lip and Back
Plate’s J-shaped lip should be
facing in opposite directions away
from one another.
Back Plate
Support Plate
Screw M5
(3pcs)
STEP THREE: Pole/Stand Assemly
Screw M10
2. Snap Ring
1.
Elastic Ball
3.
Adjustment Hole
(4 pcs)
A. Locate the Pole/Base assembly,
Back/Support Plate assembly, and
the last M10 Screw.
B. Extend the Telescopic Pole until
the metal elastic ball snaps into
place at the desired height. Lock
it in place using the Snap Ring.
C. Line up the hole on the Support
Plate’s L-shaped lip with the top
of the Pole and screw in the M10
Screw.
65

STEP FOUR: Installing Dispenser Unit (CONTINUED)
Nut M4
(3 pcs) Screw M4
(3 pcs)
E. Reinstall the Reservoir
Tank and close the
Dispenser. Find the on/o
switch located on the lower
right side of the Dispenser
and turn it on. Plug in the
A/C converter into the
nearest outlet. (For
portable use, slide open
the bottom right side panel
of the Dispenser while
opened and install four C
batteries.)
F. Place hand under the
Dispenser, and a 0.5oz
dose with UV light will be
automatically dispensed.
USER INSTRUCTIONS
STEP FOUR: Installing Dispenser Unit
STEP THREE: Pole/Stand Assemly
Nut M4
(3 pcs) Screw M4
(3 pcs)
A. Locate the unit
assembled in Steps 1-3,
Dispenser, three M4
screws, three M4 Nuts, and
U-shaped Key.
B. Take the U-shaped key
and open the Dispenser by
inserting the key into the
two holes on top of it.
Press down until the
Dispenser opens in half.
C. Gently remove the
Reservoir Tank.
D. With the Dispenser
open, hold it to the Back
Plate and line up the holes
on the backside of the
Dispenser to the front of
the Back Plate. Insert the
three M4 screws into the
holes to secure the
Dispenser and apply the
M4 nuts to the end of each
screw. Tighten the screws.
CONTINUED
87

OPTIONAL: Stand-Less Installation
OPTION ONE: The Dispenser may
be mounted directly on the wall
using screw anchors. These
screws can be inserted through
the back panel of the Dispenser
while it is opened as shown.
OPTION TWO: It may also be
mounted on the wall with
double-sided adhesive tape and
then sealing the edges with
silicone sealant. Tape and sealant
not included.
2. Silicone sealant*
1. Double-sided adhesive*
ADDITIONAL INFORMATION
• Keep the U-shaped key in a safe place.
• Turn o the Dispenser before any maintenance or refilling.
• The drip tray should be wiped down periodically.
USER INSTRUCTIONS
109
STEP FIVE: Refilling The Reservoir Tank
A. Turn o the Dispenser
using the on/o switch
located on the lower right
side of the Dispenser.
B. Insert the U-Shaped Key
into the key holes on top of
the Dispenser to open it.
C. Remove the Reservoir
Tank’s top cap.
D. Fill the tank with hand
sanitizer gel or spray.
E. Replace the cap, close
the Dispenser, and turn it
back on.
