Pace Technologies MEGA-M250b User manual

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
Equipment Type: 10-inch Manual Abrasive Cut-off Machine
Model: MEGA-M250b
Electrical Requirements: 208Y Volts (3-phase)
Frequency: 50/60 Hz
Motor Horsepower: 3 hp (3-phase) (2.2 KW)
Manual Revision Date: January 5, 2017
Serial Number
This instruction manual is
provided with each piece of
delivered equipment.

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
WARRANTY
Terms and Conditions applying to all PACE Technologies Products
1. LIMITED WARRANTY AND DISCLAIMER:
PACE Technologies Products are warranted for one year from the purchase date to be free from defects in material
and workmanship under correct use, normal operating conditions, and proper application. PACE Technologies
obligation under this warranty shall be limited to the repair or exchange, at PACE Technologies option, of any
PACE Technologies Product or part which proves to be defective as provided herein. PACE Technologies reserves
the right to either inspect the product at Buyer’s location or require it to be returned to the factory for inspection.
Buyer is responsible for freight to and from factory on all warranty claims. The above warranty does not extend to
goods damaged or subjected to accident, abuse or misuse after release from PACE Technologies warehouse, nor
goods altered or repaired by anyone other than specifically authorized PACE Technologies representatives. PACE
Technologies shall not in any way be responsible for the consequences of any alteration, modification or misuse
unless previously approved in writing by an officer of PACE Technologies. Note: Corrosion is considered a
maintenance issue and not a warranty issue.
PACE TECHNOLOGIES MAKES NO EXPRESS WARRANTIES OTHER THAN THOSE WHICH ARE
SPECIFICALLY DESCRIBED HEREIN. Any description of the goods sold hereunder, including any reference to
Buyer’s specifications and any description in catalogs, circulars and other written material published by PACE
Technologies, is the sole purpose of identifying such goods and shall not create an express warranty that the goods
shall conform to such description.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED.
THERE ARE NO IMPLIED WARRANTIES OF MECHANTABILITY OR FITNESS FOR PARTICULAR
PURPOSE. THIS WARRANTY STATES PACE TECHNOLOGIES ENTIRE AND EXCLUSIVE LIABILITY
AND BUYER’S EXCLUSIVE REMEDY FOR ANY CLAIM FOR DAMAGES IN CONNECTIONS WITH
PACE TECHNOLOGIES PRODUCTS. PACE TECHNOLOGIES WILL IN NO EVENT BE LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES WHATSOEVER, NOR FOR ANY SUM IN EXCESS OF
THE PURCHASE PRICE.
2. LIABILITY CAP:
PACE Technologies maximum aggregate liability for loss and damage arising under, resulting from or in
connection with the supply or use of the Equipment and Consumables provided under this purchase, or from the
performance or breach of any obligation (s) imposed hereunder, whether such liability arises from any one or more
claims or actions for breach of contract, tort, (including negligence), delayed completion, warranty, indemnity,
strict liability or otherwise, unless otherwise limited by the terms hereof, shall be limited to one hundred percent
(100%) of the purchase price.
3. DELIVERY:
Customer assumes and shall bear the risk of all loss or damage to the Products from every cause whatsoever,
whether or not insured, and title to such Products shall pass to Customer upon PACE Technologies delivery of the
Products to the common carrier of Pace Technologies choice, or the carrier specified in writing by Customer, for
shipment to Customer. Any claims for breakage, loss, delay, or damage shall be made to the carrier by the
Customer and Pace Technologies will render customer reasonable assistance in prosecuting such claims.
ii

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
4. ACCEPTANCE:
Customer shall inspect the Products promptly upon receipt of delivery. Unless customer objects in writing
within thirty (30) business days thereafter, customer shall be deemed to have accepted the Products. All claims
for damages, errors, or shortage in Products delivered shall be made by Customer in writing within such five
(5) business day period. Failure to make any claim timely shall constitute acceptance of the Products.
5. PAYMENT:
Customer agrees to provide timely payment for the Products in accordance with the terms of payment set forth
on the reverse side hereof or in any proposal submitted herewith. If any payment is not paid on or before its
due date, Customer shall pay interest on such late payment from the due date until paid at the lesser of 12% per
annum or the maximum rate allowed by law.
6. DEFAULT:
If Buyer is in default (including, but not limited to, the failure by Buyer to pay all amounts due and payable to
Seller) under the work or purchase order or any other agreement between Buyer and Seller, Buyer’s rights
under the warranty shall be suspended during any period of such default and the original warranty period will
not be extended beyond its original expiration date despite such suspension of warranty rights.
7. MISCELLANEOUS PROVISIONS:
This agreement has been made in and shall be governed by the laws of the State of Arizona. These terms and
conditions and the description of the Products on the reverse side hereof or in any proposal submitted herewith
constitute the entire agreement and understanding of the parties with respect to this sale and supersede all prior
and contemporaneous agreements or understandings, inducements or representations, expressed or implied,
written or oral, between the parties with respect hereto. Any term or provision of this Agreement may be
amended, and any observance of any term of this Agreement may be waived, only by a writing signed by the
party to be bounds. The waiver by a party of any breach shall not be deemed to constitute a waiver of any
other breach. Should suit be brought on this Agreement, the prevailing party shall be entitled to recover its
reasonable attorneys’ fees and other costs of suit including costs and attorneys’ fees incurred on appeal or in
collection of any judgment.
iii

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
Contents
PAGE
Nameplate i
Warranty ii
1.0 Product Description 1
2.0 Shipping, Unpacking and Installation 5
3.0 Safety Guidelines 7
4.0 Start-Up and Operation 10
5.0 Maintenance 14
6.0 Trouble Shooting 15
7.0 List of Spare Parts 16
8.0 Electrical Drawings 32
iii

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
1.0 Product Description
The MEGA-M250 is a manual abrasive
cut-off machine for cutting materials
ranging from soft aluminum metals to
hardened tool steels. It is ideal for the
metallographic laboratory, as well as for
small industrial or production
applications.
The MEGA-M250 is very robust and
durable, with its cast aluminum alloy and
stainless steel construction. Featuring a
corrosion-free T-slot table, the MEGA-
M250 is a very versatile bench-top
metallographic cutter.
1.1 General Description
1
Control
panel
Manual
wheel
feed
Cutting
chamber
Main motor
Main axle
Overload light
Motor ammeter

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
1.2 Technical Specifications
Electrical specifications: Standard 208Y (phase-phase or 120/120/120 to
ground), (380V, 400, 440, 480 optional)
Motor power: 3 hp (2.2 kW) - 3-phase unit
Power: 7.6 @208V / 4.4 amps @ 480V
Cut-off wheels: 10-inch (250 mm) diameter
Wheel arbor: 32 mm (~1.25 inch) diameter
Speed: 2895 rpm at 208-380V/50 Hz
3475 rpm at 208-380V/60 Hz
2895 rpm at 440-480V/50 Hz
3475 rpm at 440-480V/60 Hz
Maximum sample diameter: 3-inch (75 mm)
Short sample size: 2.4 inch x 5.3 inch
(60 mm x 135 mm)
Weight: Approx. 280 lbs (126 kg)
Dimensions (WxDxH): Hood Closed: 28 x 29 x 24–inches
(710 x 740 x 610- mm)
Hood Open: 28 x 35 x 31-inches
(710 x 890 x 790 mm)
Table dimensions (WxD): 8.25 x 8.9-inch
(210 mm x 230 mm)
Cabinet: Cast aluminum block construction
Hood: Fabricated steel with Lexan safety glass
Working temperature: 32° - 100°F (0 - 40°C)
Shipping temperature: 32° - 100°F (0 - 40°C)
Storage temperature: 32° - 100°F (0 - 40°C)
Recirculation system (included): 15 gallons (60 liters)
2
EU Directives: Machinery directive 2006/42/EC
Low Voltage Directive 2006/95/EC
Electromagnetic Compatibility directive 2004/108/EC
EU Harmonized Standards: EN ISO 1200:2010
EN 61010-1:2010
EN 61326-1:2006

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
1.3 Mechanical Schematic
Note: Installation of the MEGA-M250 should be on a flat sturdy surface, with easy access to
electrical connections.
3

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
1.4 Features Powerful motor
The MEGA-M250 is equipped with a
powerful direct drive motor. In addition,
the motor has an inductive brake for faster
stopping of the blade.
Manual wheel cutting
The MEGA-M250 is an easy-to-use
manual cutter with simple controls. For
control and safety the MEGA-M250 is
equipped with a trigger activated cutting
handle.
The MEGA-M250 also has a side port
window for longer samples.
4
High
leverage
cutting
handle
Side port for long samples

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
2.0 Unpacking, Shipping and Installation
2.1 Unpacking Unit is delivered in a box. Unpack and check for completeness of
parts.
Measures WxHxD: Approx. 28” x 30” x 26”
Weight: Approximately 280 lbs.
2.2 Shipping When moving box, lift from bottom.
The MEGA-M250 is constructed of sensitive electronic and
mechanical components. Do not drop.
! Caution: Heavy equipment. Take care to avoid bodily injury.
5
2.3 Installation
!
Install unit carefully! Improper installation voids
warranty.
!
The MEGA-M250 should be placed on a flat stable
surface.
TO OPEN HOOD, CUTTER IS SHIPPED WITH THE
LOCKOUT SWITCH TURNED TO UNLOCK. AFTER
CONNECTING POWER, TURN SWITCH TO
LOCK TO OPEN HOOD AND TO USE CUTTER
Connect coolant tank supply, drain and
electrical connections.
!
Electrical connections—The saw is designed to
operate at 208-220V 3-phase (can be converted to
380V 3-phase by rewiring the motor and pump)
!
Verify the direction of rotation of the cut-off wheel.
The wheel should turn from top to bottom as viewed
from the front of the machine.
(Installation continued on next page)
CAUTION
Before installation or when there
is no power to the machine, the
hood cannot be opened with the
interlocking safety device in the
LOCK position. To open the
hood without power hook-up,
turn the interlocking device with
key to the UNLOCK position
(used for service and shipping).
Turn to Lock position
to operate saw
Shipped in the
Unlock position

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
Recirculating tank connections
6
(Installation continued on next page)
Drain into
screen
Pump
Tank
drain
External coolant supply: Attach 1/2-inch tube between pump and cutter.
Drain: 1.5-inch (38 mm) tube.
Electrical connections: Connect six-foot electrical power cable to source.
Note: Inspect the operating voltage on the name plate.
Electrical connection for
external coolant supply:
Power for recirculation system comes from the MEGA-M250,
Recommended Coolant: To minimize corrosion a coolant with a anti-corrosion additive or an oil
emulsion coolant is recommended. Note: It is recommended that the
coolant be changed every 50 cuts or every week, whichever occurs
first.

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
3.0 Safety Guidelines
3.1 Warning Sign
!This sign points to special safety features on the machine.
The MEGA-M250 abrasive cutter has been designed for cutting metallographic specimens.
DO NOT CUT oversize samples. Always follow proper operational guidelines and avoid
contact with moving parts, lubricants and abrasives. Seek appropriate medical care for
cutting injuries.
3.3 Emergency Statement
!
Before operating, cutting chamber hood must be closed. After cutting, the safety latch
will not open for approximately 5 seconds after pressing the stop (red) button.
!
Use only certified cut-off wheels from a professional supplier. Improper blades selection
voids warranty. (For appropriate blade selection, refer to the Abrasive Blade Selection
Guidelines Chart in Section 4.3)
!Disconnect power before opening the main unit.
!Replacement parts should be installed only by qualified personnel.
!Securely clamp the part / sample to the working table. During cutting, consider that the
part may pinch and cause jamming of the cut-off wheel. Use the appropriate clamping
devices to avoid this occurrence.
!Never start a cut under load.
!Make sure that the cut-off blade is rotating down and into the sample.
3.2 Safety Precautions
7
Careful attention to this instruction manual and the recommended safety guidelines is
essential for the safe operation of the MEGA-M250.
Proper operator training is required for the safe operation of the MEGA-M250. Any
unauthorized mechanical and electrical change, as well as improper operation, voids all
warranty claims. All service issues need to be reported to the manufacturer / supplier.

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
Recirculation tank
The MEGA-M250 is equipped with a mobile
three-chamber counter-current coolant tank.
The first chamber contains a coarse strainer
for removing larger debris.
Replacement of the coolant is accomplished
by rolling out the tank and removing the
water pump.
Note: Dispose of the old coolant in
accordance with federal, state and
local regulations.
Water
pump
Electrical
connection
Pressure
line
Pump valve closed
After cutting, it is recommended that the cutting
chamber be rinsed to prevent debris and
corrosion build-up.
Water flow
regulating valve
Rinse line
8
Drain
line
Three Chamber tank
with counter-current
flow Coarse
strainer
Pump valve open
Tank
drain

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
3.4 Safety Tests
!
Examine and verify that the MEGA-M250 safety
devices and operating performance are in good working
condition prior to use. The following safety checks are
considered important:
Emergency stop switch
Magnetic Safety switch
9
Test: Activate main switch and close hood;
depress emergency stop switch.
Proper
Response: Machine powers down.
Malfunction: Machine does not lose power.
Corrective
measure:
If system does not power down,
disconnect power supply cord and call
service technician.
Magnetic safety lock out switch
Test: Activate main switch and close hood;
turn cut-off wheel ON then OFF;
Try to open the hood.
Proper
Response:
Hood does not open for approximately 5
seconds.
Malfunction: Hood opens.
Corrective
measure:
If cut-off wheel does not power down,
disconnect power supply cord and call
service technician.
Emergency stop switch

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
4.0 Start-up and Operation
4.1 General
The MEGA-M250 is a manual wheel feed cutter.
10
4.2 Control Panel
Emergency
Shut off
Coolant
ON/OFF
Emergency Shut off: Cuts power to machine.
Cutting wheel ON/: Starts the cutting wheel.
Cutting wheel OFF/: Stops the cutting wheel (inductive brake engages to slow
wheel). Hood cannot be opened until safety lock releases in
approximately 5 seconds after pressing the stop button.
Coolant ON/OFF: Operates the coolant pump in Auto or Manual mode.
Cutting
wheel (ON)
Light
ON/OFF
Cutting
wheel (OFF)

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
1. Remove blade locking bolt (reverse threaded).
2. Position new 10-inch abrasive cut-off wheel into position.
Use only certified abrasive cut-off wheels.
3. Gently tighten blade locking bolt (Note: locking bolt is reverse
threaded).
4.3 Changing abrasive cut-off wheels
11
!
Changing Blade
Remove: Loosen by
turning clockwise
Tighten: Turn counter-
clockwise
To prevent
shaft from
turning use
locking rod to
hold in place

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
Abrasive Cung Fluids
Pace Product Name Catalog Number Packaging
MAXCUT™ Abrasive Cung Fluid (32 oz) MAXCUT 1000-32 32 oz
MAXCUT™ Abrasive Cung Fluid (128 oz) MAXCUT 1000-128 1 gallon
MAXCUT™ 2 Cung Fluid with Ancorrosion Addive (32 oz) MAXCUT2 1000-32 32 oz
MAXCUT™ 2 Cung Fluid with Ancorrosion Addive (128 oz) MAXCUT2 1000-128 1 gallon
10 MAXCUT™ Abrasive Blades 32mm (1¼) Arbor
Pace Product Name Catalog Number Packaging
So Non-ferrous Materials (Aluminum, Brass, Zinc, Etc.) MAX-E250 10
Hard Non-ferrous Materials MAX-C250 10
So Steels MAX-E250 10
Case Hardened Steels MAX-D250 10
Hard Steels MAX-D250 10
General Purpose Industrial Blade MAX-I250 10
Universal Thin Blade MAX-A250 10
ABRASIVE Cutting CONSUMABLES SELECTION GUIDELINES CHART
12

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
For proper clamping, use the appropriate clamping vises to securely hold the sample in
place. It is recommended that both sides of the part be clamped to avoid pinching of the
blade (possibly breaking the blade) and to minimize burning of the workpiece during
cutting.
For proper fixturing, take into account the initial stress on the samples.
!
Fixture examples
4.5 Fixturing sample
17
Fast clamping
Clamping diameter 3 inches (76 mm)
Left lever (Cat. No. QCL-1000)
Right lever (Cat. No. QCR-1000)
Note: vises have a slot in them so
that the face does not rotate
UNIVERSAL Clamping vise
UNIVERSAL (Cat. No. MIG-01)
Clamping height (45 mm arm)
Height adapter (65 mm) attachment for MIG-01
(Cat. No. MG-H)
.
13
4.4 Manual cutting (step-by-step procedure)
1. Connect electrical power and turn on master power switch on the back panel
before opening the hood.
2. Position fixtures and sample near to cut-off wheel.
3. Close hood.
4. Turn on coolant and cutter motor.
5. Hand feed the cutting wheel into the sample.
6. Turn off cutter and allow blade to completely stop before opening cover.
Note magnetic safety switch has approximately a 5 second delay. Cutter
hood can be opened until safety switch is deactivated.

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
14
5.0 Maintenance
5.1 Introduction
5.2 Cleaning outside cabinet
The cabinet and front shield should be cleaned occasionally with a moistened cloth. Do not
use any chemicals or cleaning abrasives. We recommend an anti-condensation gel be used
on the front panel.
The recommended maintenance for the MEGA-M250 includes the following:
1. Use an anti-corrosion cutting fluid such as the MAXCUT 2 or an oil-emulsion cutting fluid
such as the MAXCUT OL-1000. It is recommended that the cutting fluid be changed every
50 cuts or weekly for maximum effectiveness.
2. Rinse and dry the table and vises after use.
3. When the cutter is not in use, OPEN the HOOD to prevent humidity and corrosion build-up
inside the cutting chamber.
4. If cutter will not be used for an extended period of time, coat the table and vises with a
water displacement oil such as WD-40.
5. Use only recommended abrasive blades to minimize overheating the bearings and motor.
Do not exceed the recommend amp rating of the motor.
6. Grease the appropriate fittings periodically (minimally after every 200 cuts or every other
month, whichever occurs first).
7. Immediately replace any broken or damaged parts.
Note: corrosion is considered a maintenance issue and not a warranty issue

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
15
Turn to Lock position
to operate saw
6.0 Trouble Shooting
Problem Cause Solution
No power or
function
a. Unit is disconnected from main
electrical power supply.
b. Main power switch is off.
c. Emergency stop button engaged.
a. Verify electrical source and
connection.
b. Turn on main power switch.
c. Release by turning clockwise.
Main motor does
not operate
a. Interlocking safety switch is in
Unlock position (for shipping)
b. Hood not closed.
c. Overload relays activated
a. Turn safety switch to Lock position to operate
cutter.
b. Close hood
c. Restart after resetting Q1 relay.
Pump motor does
not operate
a. Plug is disconnected
b. Overload relay activated
a. Check plug.
b. Restart after resetting Q2 relay.
Excessive
vibration during
cutting
a. Not cutting with enough force
b. Specimen locked too far back on
cutting table
c. Incorrect blade selection
a. Increase cutting force.
b. Move specimen forward.
c. Use correct blade.
Corrosion of table
of vises
a. Improper cleaning and drying
b. Incorrect or old cutting fluid.
c. Cutting chamber has become a
humidity / corrosion chamber
d. Long term storage oxidation
a. Rinse and dry table and vises.
b. Use an anti-corrosion cutting fluid such as the
MAXCUT 2 or an oil-emulsion cutting fluid
such as the MAXCUT OL-1000. It is
recommended that the cutting fluid be
changed every 50 cuts or weekly for
maximum effectiveness.
c. Open hood when not being used
d. If cutter will not be used for an extended
period of time, coat the table and vises with a
water displacement oil such as WD-40.
If motor or pump
does not turn on
check Q1 - motor
and Q2– pump
relays
Shipped in the
Unlock position
More extensive trouble shooting, repair guides, video’s, parts list are provided
online at www.metallographic.com or
http://www.metallographic.com/PACE-service/MEGA-M250-service.html

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
MEGA-M250b
Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. [phone] Fax [phone] email: [e-mail] Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
7.0 List of Spare Parts
16
Part no. Descripon Image
Electrical
M2-E-CB-001 MEGA M250 Full control board
replacement for MEGA M250
M2-QF1 MEGA M250 QF1 overlaod switch
(motor) (Schneider GV2-ME14C/6-10A)
M2-QF2
MEGA M250 QF2 overload switch
(pump) (Schneider GV2-ME05C/0.63-
1A)
MEG-RCMU RCMU timer (blade)
MEG-RAMU RAMU timer (safety switch)
LC1D12B7C KM1, KM3 AC contactor (MEGA-
M250) (Schneider LC1D12B7C)
LC1D09B7C KM2 AC contactor (MEGA-M250)
(Schneider LC1D09B7C)
