OPERATION AND MAINTENANCE
INSTRUCTIONS FOR THE
NO CLOG
DUAL PATH"
SOLDER EXTRACTOR
MODELS
SX-20 SX-20V
SX-25 SX-25V
SX-30 SX-30V
MANUAL NO. 5050-0131
Featuring
Thermo-Drive™
HEAT CONTROL REV. C

(GENERAL INFORMATION
ASSEMBLING CHAMBER
START-UP ALL MODELS TO FRONT SEAL
To operate the Solder Extractor (all models), Look through vents to assure that the
a. place Solder Extractor in stand Chamber seats properly on the Front Seal.
b. set Temperature Control to 10 7
c. allow three (3) minutes warm-up time Chamber
d. reduce temperature. A temperature setting of ーー
712 to 8% is normal for most desoldering tasks Front
Seal _PROPERLY SEATED CHAMBER
e. use the Extractor
DESOLDERING ELECTRICALLY SENSITIVE COMPONENTS
Pace Power Sources with “Zero Power Switching” and all PED-A-VAC’S can be used with SX-20, SX-25 and
SX-30 Desoldering Handpieces for safe removal of components. Power Sources without “Zero Power
Switching’ capability can safely remove sensitive components when used with the SX-20V, SX-25V and SX-30V
Desoldering Handpieces. However, it is necessary to actuate the vacuum pump before the desoldering tip con-
tacts the component lead, and continue the pump operation until the desoldering action is complete. Vacuum
actuation is by finger tip control as described in this manual.
PROCEDURE FOR REMOVING GLASS CHAMBER
The Dual Path Solder Extractor is designed with a solder well which sits between the transfer tube and front
seal tube (see illustration below). This feature contributes to the efficient operation of the Dual Path. Under nor-
mal operation, the well is maintained at a temperature above that of solder melt and therefore any solder falling
into the well will remain molten. The following procedure should be followed before removing the Glass Chamber.
1. While the extractor is hot, hold the extractor vertical, with the desoldering tip pointing straight-up.
2. Gently tap the side of the extractor handle to loosen any molten solder that may be in the well so that gravi-
ty will flow the solder into the Glass Chamber.
3. While still holding the extractor vertically, apply two or three blasts of vacuum as to suck any loose solder
into the Glass Chamber.
You are now ready to remove the Glass Chamber from the Dual Path Solder Extractor for cleaning.
Solder
Well
Transfer
(Internal)
Tube
Front
Seal Tube
EQUIPMENT UPGRADING Table 1. OLD/NEW MODEL PACE PART NUMBERS
i Old Model Dual Path | New Pace
If you own an old model Desoldering Tool Old Model
and want to update it with a newer version, Pace Part No. | Model Part No.
use Table 1 to choose an appropriate new SX-199 7010-0017 SX-30 7010-0027
Solder Extractor Model: SX-199V 7010-0021 SX-30V | 7010-0028
ei SX-200 7010-0004 SX-20 7010-0023
8º 25 a SX-200V 7010-0013 SX-20V | 7010-0024
© SX-201 7010-0011 SX-25 7010-0025
o od SX-201V 7010-0014 SX-25V | 7010-0026
=
2

GENERAL INFORMATION >
Before using your Dual Path™ Solder Extractor, read this manual to become familiar with
it’s operation, capabilities, and maintenance. Used and maintained properly, your Dual Path
Extractor will serve you well for many years.
TABLE OF CONTENTS
Title Page
Generalinformation................................. eee 2
Theory of Operation 上 ユー ユー・ に に に に に に に に に に トト トト トト トト に トト トレ トト レレ トト トト トレ トト トレ トト ーーー て 5
ОрегаНоп......... еее еее еее наенннннь 7
Maintenance ... 14
Replacement Parts
MODELS SX-20 — SX-25 — SX-30
MODELS SX-20V — SX-25V — SX-30V
FIGURE 1. PACE DUAL PATH HANDPIECES
3

(C GENERAL INFORMATION
INTRODUCTION
Pace, Inc. is continuously improving its line of efficient and reliable instruments for the
non-destructive rework, repair and modification of electronic assemblies. This manual
describes six available Pace Solder Extractors and their uses.
Dual Path Solder Extractor Handpieces shown in Figure 1 work best with Pace Power
Sources. They can be used with other power and vacuum sources, providing they have the re-
quired outputs.
SPECIFICATIONS
All Dual Path Extractors are supplied with 3 wire grounded power cords and 35 watt Heaters, with
60 watt heat equivalent.
+ Models SX-20, SX-20V, SX-25 and SX-25V—Require 120VAC, 50/60HZ power.
® Models SX-30 and SX-30V—Require 24VAC, 50/60HZ power.
» VisiFilter—is provided with Models SX-25, SX-25V, SX-30 and SX-30V.
« Accessories— Tips, Cleaning Brushes, Hose and Instruction Manual are supplied with all
models.
PARTS IDENTIFICATION
The following breakdown identifies the major parts located on the standard and “V” Dual
Path Solder Extractors. Except for power cords and the Air Switch/Tube Assembly, the
Models SX-20, SX-25, and SX-30 are identical in construction to the SX-20V, SX-25V, and
SX-30V Models shown below.
Handle Vacuum Finger Control Air Switch/Tube Assembly
(“V" Models only) (“V" Models only)
Front
Seal Vent
Tip o
VA A E
Set
Screw Solder
Vent Transfer End Baffle
Heater
Tube
Sodr-X-Tractor
and
Cap
Assembly
"s"
Collection
Filter
Assembly
Baffle Chamber
MODELS SX-20, SX-25, AND SX-30 PARTS IDENTIFICATION
C MODELS SX-20V, SX-25V, AND SX-30V PARTS IDENTIFICATION
4

THEORY OF OPERATIONS,
DUAL PATH SOLDER EXTRACTOR
The Solder Extractor functions as a vacuum cleaning device to remove solder. Heat sup-
plied to the hollow tip (FIGURE 2) melts the solder, activating the vacuum flow which ex-
tracts the liquid solder from the joint and transfers it quickly and safely to the solder collec-
tion chamber within the handle.
== =
FIGURE 2. CUT-AWAY VIEW OF DUAL PATH SOLDER EXTRACTOR MODEL SX-25
The “V” Model Solder Extractors (FIGURE 3) have the same features as above Models, and an addi-
tional air switch/tube assembly to the handle for permitting instantaneous finger-tip-actuated
vacuum control. This vacuum control gives users “Spike Free” desoldering capabilities for CMOS
and similar static sensitive components (when used with power sources not equipped with elec-
tronic “Spike Free” Power™ output).
FIGURE 3. CUT-AWAY VIEW OF DUAL PATH SOLDER EXTRACTOR MODEL SX-25V _)
5

THEORY OF OPERATION
All Dual Solder Extractor models allow guick hand-removal of the solder collection
chamber (FIGURE 4) for maintenance. The collection chamber is removed by a guick-twist
without touching the hot chamber or of disturbing or disconnecting any heated elements or
electrical connections. Ingested volatized flux and coating are prevented from entering the
pump or vacuum source by the primary filter at the inside rear of the glass chamber. This
filter is easily visible through two inspection ports in the handpiece and should be replaced
when discolored.
RS Quick
Twist
Connector
Inspection
Port (2)
FIGURE 4. SOLDER EXTRACTOR HANDPIECE WITH
COLLECTION CHAMBER PARTIALLY REMOVED
VISIFILTER'"
An external filter (FIGURE 5) traps volatiles which are not handled by primary filter.
VisiFilters are optionally available with replaceable filter elements, (FIGURE 6). Replace
VisiFilter or Element when heavily discolored.
FIGURE 5. VISIFILTER FIGURE 6. VISIFILTER WITH
REPLACEABLE ELEMENTS

TIP SELECTION GUIDE
One of the most important aspects for successful solder extraction is the selection of the proper
size of Tip for the job. Keep several points in mind while selecting the Tips:
OPERATION ~
| Clearance
STEP 1. The Inside Diameter (1.D.) of the Tip must be large
enough to fit loosely over lead to provide clearance for air
and molten solder flow.
STEP 2. The Outside Diameter (0.D.) of the Tip must be
smaller than the pad diameter to permit contact with the
copper pad while preventing contact with the base material.
STEP 3. Match the Tip to the work. Small I.D. Tips for small
leads, larger Tips for heavier leads.
STEP 4. For desoldering terminals and solder splash
removal, use largest I.D. Tip available.
Extractor
Tip
% inch
(952cm)
Heater
Assembly
Tip Tool
에: Heater
Screwdriver us,
Extractor
Tip
NM
STEP 5. Adjust the selected Tip to extend approximately
Ye inch (952cm) beyond the heater body for all normal
desoldering tasks.
STEP 6. Tighten retaining screw approximately Ya turn after
screw contacts Tip. DO NOT overtighten.

OPERATION
SET-UP
STEP 1.Attach vacuum hose to SX-20/SX-25/SX-30
handpiece.
uret
STEP 3. Attach hose to cord with retainer clamps.
STEP 5. Select and attach the tip with a screw driver.
Refer to Tip Selection Guide (page 14).
outlet. Model SX-25 uses 120VAC 50-60HZ supply;
Model SX-30 uses 24VAC 50-60 HZ supply.
X
STEP 2. Attach hoses to the “V" Model handpiece as
shown. Assemble the separate 12” piece of hose in-
cluded.
STEP 4. Attach VisiFilter with raised lettering towards
handpiece. Connect short hose between Power Source
and VisiFilter. NOTE: VisiFilter is not used with the
SX-20(V) models.
αι
ad LA
STEP 6. Attach air/vacuum hose to Power Source. Use
maximum vacuum available. Optional air hose fittings
are available to fit all Pace Power Sources.
STEP 8. Solder Extractor vents may be replaced
without removing heater assembly

INITIAL START-UP ALL MODELS
To operate the Solder Extractor (all models),
a. place Solder Extractor in stand
b. set Temperature Control to 10
c. allow three (3) minutes warm-up time
d. reduce temperature. A temperature setting of 7% to 8% is normal for most
desoldering tasks
e. use the Extractor
V-MODEL OPERATION
To operate the “V” Model SX-20V, SX-25V and SX-30V Handpiece controlled vacuum
Extractors:
a. Hold the handpiece as you would hold a pencil (FIGURE 7). Hold your index
finger bent, with the tip of the finger resting firmly on the flat portion of the
Vacuum Control Bar, and just behind the orifice.
b. On the Power Source, turn Pump switch to the “ON” position (Refer to Opera-
tion and Maintenance Instructions for your Power Source).
c. To actuate the vacuum, slide your finger tip firmly forward to completely seal the
orifice. As long as the orifice is closed, the vacuum is actuated through the Sodr-X-
Tractor tip. Keep moving the component lead with the Solder Extractor tip during
full vacuum operation. Continue stirring lead to cool down the joint.
d. After extracting the solder, remove the extractor tip from the joint, then slide
your finger tip back off the orifice to terminate the vacuum. (If operation is
completed, turn off pump. See Operation and Maintenance instruction for
your Power Source).
OPERATION >
Vacuum
Control Bar
FIGURE 7. CORRECT POSITION FOR HOLDING THE HANDPIECE 2)
9

(OPERATION
VACUUM EXTRACTION
When performing a desoldering operation, the following steps should be followed for best results.
STEP 1. Position the Tip over the lead making contact with
solder. As the solder melts, allow the Tip to gently rest on
a film of solder between solder and Tip.
STEP 2. Move Tip with a stirring motion, dwelling until lead
moves freely within the board hole. Free movement of the
lead indicates complete solder melt.
STEP 3. Apply vacuum and continue stirring action dur-
ing vacuum application. To remove solder, maintain light
contact. (NOTE: Pressure can damage or lift the pad).
STEP 4. Continue stirring action and vacuum flow to cool
joint area.
STEP 5. Continue vacuum flow one or two additional
seconds after removing Tip from the board to assure com-
plete transfer of the solder to Chamber.
STEP 6. Check your work. If any solder remains in a plated-
thru hole (PTH) after extraction, resolder and extract again
Allow
cool down between resoldering and extraction
10

VACUUM EXTRACTION (continued)
OPERATION >
HOT-AIR PRESSURES. HOT—AIR PRESSURES
こき
STEP 7. Hot-air pressure mode removes solder from blind
of thru-hole joints.
STEP 8. Hot-air jet mode melts planar component leads,
solder connections and shrinks tubing.
CLINCHED LEADS
CLINCHED LEADS
STEP 9. To unclinched leads, place Tip on lead until solder
melts.
STEP 10. Move Tip to end of lead and lift to straighten.
(WARNING: Lift, dont pry!). Extract solder as described
in Steps 3 through 6.
TERMINALS
AUXILIARY HEATING
STEP 11. For solder extraction on terminals, increase heat
setting. Place Tip in contact with wire and solder. Watch
for complete melt. Wiggle wire and apply vacuum to ex-
tract solder. Keep wire moving during cool down.
STEP 12. Solder extraction on multilayer boards may re-
quire application of a second heat source at the joint on
the convenient side. Use a PACE Conductive Heating
System or hot soldering iron tip for auxiliary heat.
11

OPERATION
PRESSURE MODE
(USE OF AIR PRESSURE)
The following procedures apply when the extractor is used with Power Sources equipped with a
controlled air pressure outlet.
Circumstances may occur when the Vacuum Mode of operation will not completely remove a
solder joint. This is most often the case when a “Blind-Sided Solder Joint” is found. The “Blind-
Sided Solder Joint” is so named because of its inaccessibility, usually on the component side of
the board. This is common when a terminals flanged end (on opposite side of board) blocks air
flow. In this case the vacuum method is not applicable since no cooling air can be pulled through
the hole thus causing a sweat joint. So in this case (see Step 7 on page 11; and steps below).
The “Pressure Mode” is now required to break up this Blind-Sided Solder Joint. The “Pressure Mode”
uses the following steps:
a. Connect the air line to the Pressure Flow control valve and adjust Pressure control
to “maximum”.
b. Place the tip of the Extractor into the “Solder Dump” between the two “Hot
Cubbies”, and use a burst of pressure to clear any molten solder which might be in
the heater tube.
c. Heat must be transmitted through the lead to melt the Blind-Sided Solder Joint.
Place the heated tip over and in contact with the lead.
WARNING—ALLOW THE TIP TO COME INTO LIGHT CONTACT WITH THE PAD
AREA.
d. When the Blind-Sided Solder Joint is heated sufficiently, actuate the airflow to pro-
vide continuous burst of pressure. Stir the lead to prevent reformation of sweat
joints caused by the continuing flow of air.
If conformal coating is blocking air flow, the coating must be removed before the vacuum
desoldering operation. Try hot air jet to decure coatings; or thermo-plating tool to remove coatings
(See hot air jet page 13.)
ς
12

OPERATIONS
HOT AIR JET MODE
The hot air mode of operation is used for several different applications:
+ SURFACE SOLDERED JOINTS
Surface solder joints are removed with the “Hot Air Jet Mode” of operation. The follow-
ing steps should be taken for the succesful removal of surface mounted components.
a. With the air line connected to the Pressure Flow Control Valve on the Power
Source, set Pressure valve and power to “MAX” and blow out excess molten
solder.
b. Reduce the Pressure valve setting to “MIN” and use .036 1.D. Tip.
c. A carefully-directed Hot Air Jet will melt the solder joint when the tip is held
approximately Ys” from the surface. When you see the solder melt, lift the
lead with a soldering aid or tweezer. Do not lift before melting is observed, or
you might lift the pads from the substrate.
d. Repeat this process for each individual lead until all leads are removed and
the component is free.
GENERAL NOTE
If surface joints are heavily mounded with solder, it may be
desirable to use the Vacuum Mode to remove excess solder
prior to using Hot Air Jet Method.
¢ HEAT SHRINKABLE TUBING
To use Hot Air Jet Mode of Operation for shrinking tubing, apply the properly adjusted
jet slowly along the entire length of the tubing. Do not play the hot air at one point, but
evenly distribute heat to shrink tubing. Be sure all tubing has shrunk completely before
allowing it to cool.
¢ CONFORMAL COATING REMOVAL (Epoxy and Polyurethane)
Apply Hot Air Jet to the conformal coating to be removed. Remove the softened coating
with an orange stick so you won't damage the board.
* REMOVAL OF BONDED COMPONENTS
Apply Hot Air Jet to the component body and surrounding area to soften the bonding
material. Then twist the component to be removed with pliers or tweezers. Heating may
be required for 2 or 3 minutes, depending upon the size of the component and the
thickness of the coating.
13

„MAINTENANCE
TIP CARE
The Extractor Tips should be cared for in the same manner as soldering iron tips. The
following suggestions will prevent damage to the handpiece assembly:
* Remove excess solder, burned flux, and conformal coatings by lightly wiping the tip on
a non-contaminating material.
+ The Solder Extractor Tip is expendable; washout (thinning) of the inside bore occurs
during normal use. The Tip must be replaced before it becomes so thin that it breaks off
in the heater assembly.
* Charred coating of flux can cause blockage in the tip bore. Clear the residue from inside
the tip with a length of small-diameter stiff wire.
BROKEN TIP REMOVAL
If the tip breaks off in the Heater assembly, remove power cord from power source. Use a
steel rod, slightly less than 1/8 inch in diameter, to ram the broken tip out of the Heater tube
while the Extractor is still hot. With set screw removed, insert ram from handle end while the
front face of the heater is supported and drive the broken tip out. (FIGURE 8)
FIGURE 8. BROKEN TIP REMOVAL
14

MAINTENANCE.
TIP REPLACEMENT PROCEDURE
a. While the unit is idling hot, loosen set screw to free the tip.
. Remove the Tip from the Heater.
. Clean Heater with small wire brush to remove oxide buildup.
. Place new Tip in Heater with hangout of 1% to %.
. Tighten set screw 1/8 turn past the point of contact to secure Tip in place. 200
NOTE
Although set screws are permanently lubricated, it is essential
that the screw be loosened and the tip be removed at least
once every eight operating hours.
CLEANING SOLDER COLLECTION CHAMBER
Solder and flux buildup in Chamber depends upon use. Clean Chamber and “S” Baffle as
often as necessary with a large bristle brush. Apply mineral oil to the brush and lightly coat
inside of Chamber and “S” Baffle.
REPLACING PRIMARY VISIBLE FILTER
The white, primary Sodr-X-Tractor Filter located within the rear of the Glass Chamber
(FIGURE 9) should be changed whenever heavy deposits of contaminants are noticeable. It is
very important that this filter be kept clean; this assures optimum air flow and minimum flow
restriction, and keeps contaminants from reaching the vacuum source.
Sodr-X-Tractor
Filter
Baffle and
End Cap
Assembly
Rear
Seal
FIGURE 9. SODR-X-TRACTOR FILTER LOCATION.
15

tion to each:
(MAINTENANCE
CORRECTIVE MAINTENANCE
Table (2) outlines the most common deficiencies which might occur and the easiest solu-
TABLE 2. CORRECTIVE ACTION FOR MOST COMMON MALFUNCTIONS
SYMPTOMS
CAUSE
SOLUTION
The operator notices that solder
joints are not being completely
removed on a consistent basis.
Loss of Vacuum
A. Clean Tip bore.
B. Clean Heater solder transfer with
wire
bristle brush.
C. Check “S” Baffle. If the “S” Baffle
has shifted within the Glass Tube to
a position where it blocks the
Transfer Tube, the vacuum could be
reduced. It is important that the “S"
Baffle have enough tension so that it
maintains a constant position in the
Chamber. This may be adjusted by
bending the “S" Baffle between your
fingers. DO NOT ATTEMPT TO BEND
THE “S” BAFFLE WHILE IT IS IN THE
GLASS CHAMBER. The Baffle should
be seated just in front of the End Cap
Baffle Assembly, leaving sufficient
room for the Filter (refer to FIGURE
9).
D. Front Seal—Assure that Chamber
is properly seated on the front seal.
Е. Sodr-X-Tractor Visible Filter—A
contaminant loaded filter will reduce
air flow. Replace.
F. Damaged Air Hose—A damaged
air hose can cause partial or full loss
of vacuum. Examine hose and
replace if necessary.
G. Clogged VisiFilter—Replace filter
or filter
element when filter is loaded.
Dark discoloration indicates time for
replacement.
H. Clogged, Damaged Pump or
Vacuum Transducer—Refer to your
“Operation Maintenance Power
Source or Vacuum Transducer”
manual.
16

MAINTENANCE ~
CORRECTIVE MAINTENANCE
TABLE 2. CORRECTIVE ACTION FOR MOST COMMON MALFUNCTIONS (cont.)
SYMPTOMS CAUSE SOLUTION
Heater does not heat. No electrical powerto | A. Check power cords, is Power
heater. Source and Extractor plugged in
power outlet?
B. Turn “ON” power.
C. Check Power Source Fuse,
replace if blown.
Heater does not heat. Defective Heater A. Replace Heater Assembly
(refer to FIGURE 10)
1. DISCONNECT POWER-
CORD from outlet. Remove
three screws in flange
holding heater assembly to
handle.
2. Loosen stress relief screw
at rear of handle.
3. Slowly remove the heater
by pushing the cord through
the handle from the back end.
Remove vent. Do not pull the
heater assembly.
4. Remove the screw and nut-
which attaches the ground
wire to the heater flange.
5. Remove the rear seal and
insulating washer.
6. Use pliers to grasp the con-
nector pins attached to the
heater wires. Ease each pin
from its connector since pins
are tightly fitted.
7. Remove front seal from re-
placement heater, assemble
insulating washer over seal
retainer tube, replace seal.
8. Attach ground wire firmly to
heater flange.
9. Mount heater to handpiece.
Clearance cutout is provided in in-
sulating washer for ground screw.
17

REPLACEMENT PARTS
q FIGURE 10. DIAGRAM OF REPLACEMENT PARTS
18

REPLACEMENT PARTS.
TABLE 3. LIST OF REPLACEMENT PARTS FOR SOLDER EXTRACTOR
(Refer to FIGURE 10 for Item No.)
ITEM NO. DESCRIPTION PACE PART NO.
1 Extractor Handle, SX-20, SX-25, SX-30 1119-0039
1A Extractor Handle, SX-20V, SX-25V, SX-30V 1119-0050
2 Vents (2) 1119-0041
2A Vent (1) 1119-0042
3 Super Tip See Tip Chart
4 Glass Chamber 1265-0003
5 “S” Baffle 4010-0033
6 Sodr-X-Tractor Filter (Pk/10) 1309-0018
7 Heater and Seal Assembly, Dual Path 120VAC,35W 6010-0034
Heater and Seal Assembly, Dual Path 24VAC,35W 6010-0035
8 Heater Washer 1213-0030
9 Screw, Nylon 1405-0341
10 Screw w/Lockwasher #4-40 x 5/16” SST (4)
11 Set Screw (Pk/10) 1348-0285
12 Nut #4-40, Hex Head (1)
13 Line Cord Assembly (VDE) 1332-0090
14 Line Cord Assembly, Standard (120VAC) 1332-0009
15 Line Cord Assembly (24VAC) 1332-0032
16 VisiFilter 1309-0020
17 VisiFilter, Replaceable Element Type 1309-0028
18 Filter Element, VisiFilter 1309-0027
19 Twist Lock Fitting 1263-0004
20 Tubing Assembly w/VisiFilter 1325-0017
21 Tubing Assembly w/Twist Lock Fitting 1325-0006
22 Tubing 12” 1342-0001
23 Clamp, Flat Cord Type 1211-0002
24 Clamp, Round Cord Type 1321-0085-02
25 Tubing, 6° Length 1325-0003
26 Baffle and End Cap Assembly, Dual Path 4010-0071
27 Bristle Brush 1127-0002
28 Wire Brush 1127-0006
29 Cushion Grip (fits standard handpiece only) 1346-0042
30 Front Seal 1213-0033
31 Rear Seal 1213-0001
REPLACEMENT TIPS FOR SOLDER EXTRACTOR
Table 4 lists replacement Tips used for the Solder Extractor. Use FIGURE 11 to determine
the Outside Diameter (O.D.) and Inside Diameter (I.D.), then select the Tip part from Table 4.
TABLE 4. REPLACEMENT PART NUMBER FOR TIPS
1.D. NOMINAL | O.D. REFERENCE | PACE PART
in. | mm in. mm NUMBER
018 | 0.45 059 1.34 1121-0213
SUPER .025 | 0.63 .060 1.52 1121-0214
TIPS 036 | 0.91 072 1.83 1121-0215
050 | 1.27 „085 2.16 1121-0216
061 1.55 .104 2.64 1121-0217
.095 | 2.43 125 3.17 1121-0091
Outside Diameter Super tips
(0.D.) Ref. have two
1.D. marks
+ (Trademark)
Inside Diameter
(1.D.) Nom.
FIGURE 11. MEASUREMENT OF REPLACEMENT TIPS ノ
19

| INCORPORATED |
9893 a COURT
LAUREL, MARYLAND 20723-1990 USA
[phone]
FAX [phone]
©1982 PACE INCORPORATED ALL RIGHTS RESERVED PRINTED IN U.S.A.
ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
