Pace TDC770D User manual

BRINGING TECHNOLOGY HOME
www.pace.com
OPERATOR’S MANUAL
Pace TDC770D
Whistler

1
CONTENTS
This product incorporates copyright protection technology that is protected by
U.S. patents and other intellectual property rights. Use of this copyright protection
technology must be authorized by Macrovision, and is intended for home and other
limited pay-per-view uses only unless otherwise authorized by Macrovision. Reverse
engineering or disassembly is prohibited.
This manual describes some on-screen displays such as menus.
These may change in the future, if the set-top’s software is
updated over the cable. However, the way that you use the
menus will remain similar to the way described in this manual.
SAFETY INFORMATION .............................................................................................2
REAR PANEL..............................................................................................................8
CONNECTING THE EQUIPMENT .............................................................................10
Connecting your TV to the AC power supply .....................................................14
Connecting the power cord to your set-top........................................................14
Connecting equipment to the wall AC outlets ....................................................14
OPERATING YOUR SET-TOP....................................................................................15
Turning your set-top on and off..........................................................................15
Lightning storms ...............................................................................................16
Using your remote control .................................................................................16
Displaying a picture on your HDTV screen ........................................................16
Using the front-panel buttons ............................................................................17
Using your set-top’s DVR (digital video recorder) functions ..............................18
Using an external hard disk ...............................................................................19
Using RF Bypass ...............................................................................................20
Using Zoom to change the picture .....................................................................21
SETTING UP SUBTITLES .........................................................................................22
MAKING USER SETTINGS .......................................................................................23
About User Settings...........................................................................................23
About the TV Aspect Ratio .................................................................................24
About TV Display Capability (resolution settings)..............................................25
Setting Auto Pillarbox........................................................................................28
Making Closed Caption Settings .......................................................................30
Making Front-Panel Settings .............................................................................31
Setting Hard Disk Sleep Mode...........................................................................32
Making HDMI Settings ......................................................................................33
Removing the User Settings menus ...................................................................33
Restoring the factory default settings .................................................................34
USING THE SETUP MENUS.....................................................................................36
SOLVING PROBLEMS ..............................................................................................37
TERMS AND CONDITIONS FOR USE OF SOFTWARE (“TERMS”)............................41
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
Other trademarks listed herein are the property of their respective owners.
© 2009 Pace plc.
All rights reserved.
Pace and are trademarks and/or registered trademarks of Pace plc

2
SAFETY INFORMATION
This digital set-top has been manufactured and tested with your safety in
mind. However, improper use can result in potential electric shock or fire
hazards. To avoid defeating the safeguards that have been built into your
set-top, please observe the precautions discussed in this document.
To reduce the risk of fire or electric shock, do not expose this set-top to rain
or moisture.
On the rear panel of your set-top there is a tamper-evident label that states
‘Warranty void if broken or removed’.
To avoid possible damage to the internal hard disk, do not pick up or move
your set-top while it is connected to the wall AC outlet. If you want to move
your set-top, first stop any recording, then turn off your set-top and wait 60
seconds before disconnecting it. You should handle your set-top carefully, as
any damage you cause to the internal hard disk (or any other component) will
invalidate your warranty.
Installation
The installation of your set-top should be carried out by a qualified installer
and should conform to local codes.
Note to the installer
This reminder is provided to call the attention of the cable-TV-system
installer to Section 820 of the National Electrical Code (USA), which
provides guidelines for proper grounding and, in particular, specifies
that the cable ground shall be connected to the grounding system of the
building, as close to the point of cable entry as is practical.
Service address:
Pace Americas Inc.
3701 FAU Boulevard, Suite 200, Boca Raton, Florida 33431 U.S.A.
Other warnings
To reduce the risk of electric shock, do not remove the cover of your set-top.
There are no user-serviceable parts inside it.
Do not perform any servicing unless you are qualified to do so. Refer all
servicing to qualified service personnel. Servicing the set-top yourself will
invalidate the warranty.
The lightning flash with arrowhead symbol, within a triangle,
is intended to alert you to the presence of uninsulated
“dangerous” voltages within your set-top’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock
to persons.
The exclamation point within a triangle is intended to alert
you to the presence of important instructions in the literature
accompanying your set-top.
Warnings on your set-top
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
ATTENTION

3
IMPORTANT SAFETY INSTRUCTIONS
Before you install or use the apparatus, you must read and
understand these Important Safety Instructions.
At all times when using the apparatus you must follow these
Important Safety Instructions to reduce the risk of fire, electrical
shock and injury to persons.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into the outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.

4
SAFETY INFORMATION (cont.)
In addition to the Important Safety Instructions, please read the Safety
Information below.
Power sources
The model number, serial number, and electrical rating of this set-top are on
a label on its base.
You must operate your set-top only from the type of power source indicated
on the marking label. If you are not sure of the type of power supply to
your home, consult your dealer or local power company. If you move your
set-top between locations at different temperatures, allow it to reach room
temperature before you apply power to it.
Overloading
Do not overload wall AC outlets, extension cords or other power outlets as
this can result in a risk of fire or electric shock.
Lightning
For added protection for your set-top during a lightning storm, or when
it is left unattended and unused for long periods of time, disconnect the
cable system from your set-top. See also item 13 in the Important Safety
Instructions.
Ambient temperature
The operating temperature range of your set-top is 32-104°F. If the ambient
temperature around your set-top falls outside this range, you must correct
this in order for your set-top to work correctly and safely. For example, if the
temperature is too high, make sure there is sufficient ventilation (see below)
and that your set-top is not directly on top of or underneath other equipment.
Ventilation
Slots and openings in the casing of your set-top are provided for ventilation,
to ensure reliable operation of your set-top and to protect it from overheating.
• Neverblocktheventilationopeningsbyplacingyourset-toponabed,
sofa, rug, or other similar surface. Place it on a hard, flat surface.
• Nevercovertheventilationopeningswithitemssuchasnewspapers,
table-cloths, or curtains.
• Youcanplaceyourset-topnearotherconsumerelectronicsdevices,such
as stereo amplifiers or televisions, but you must not place it directly on
top or underneath them.
• Donotplaceyourset-topinabuilt-
in installation such as a bookcase
or rack unless proper ventilation is
provided and you have adhered to
the manufacturer’s instructions.
• Maintain a minimum
distance of three inches
around your set-top for
sufficient ventilation.
See also item 7 in the Important Safety
Instructions.
3 in. 3 in.3 in.

5
SAFETY INFORMATION (cont.)
Water and moisture
Do not expose your set-top to rain or moisture, dripping or splashing, and
ensure that no objects filled with liquids, such as vases, are placed on your
set-top. See also item 5 in the Important Safety Instructions.
Entry of objects and liquids
Never push objects of any kind into your set-top through openings as they
may touch dangerous voltage points or short-out parts that could result in
fire or electric shock. Never spill liquid of any kind on your set-top.
Transporting
Move the combination of set-top and cart with care. Quick stops, excessive
force and uneven surfaces may cause the combination of set-top and cart to
overturn. See also item 12 in the Important Safety Instructions.
Placement and mounting
Do not place your set-top on an unstable or uneven surface. Your set-top
may fall, causing serious injury to a child or adult and serious damage to
your set-top. If you mount your set-top, for example to a wall or ceiling,
follow the manufacturer’s instructions and use a mounting accessory
recommended by the manufacturer. See also item 12 in the Important Safety
Instructions.
Risk of re or scorching
Never place naked flame sources, such as lighted candles, on or adjacent to
your set-top.
Replacement parts
When replacement parts are required, be sure that the service technician has
used replacement parts specified by the manufacturer or that have the same
characteristics as the original part. Unauthorized substitutions may result in
fire, electric shock or other hazards. See also item 14 in the Important Safety
Instructions.
Safety check
Upon completion of any servicing or repairs to your set-top, ask the service
technician to perform safety checks to determine that your set-top is in
its proper operating condition. See also item 14 in the Important Safety
Instructions.
SAVE THIS INFORMATION FOR FUTURE REFERENCE

6
S-VIDEO
ETHERNET
VIDEO OUT
Pr
Pb
Y
COMPONENT VIDEO
TV PASS MODULE
TO TV
CABLE IN AUDIO
OUT
DIGIT A L
AUDIO OUT
OPTICAL
AUDIO OUT
IR RECEIVE
IR TRANSMIT
POWER OUTLET FOR TV ONLY
120V AC 60Hz 4.2A MAX.
POWER INPUT
120V AC 60Hz
DOUBLE INSULATED
L
R
+5V DC
500mA max.
SAT A
SAFETY INFORMATION (cont.)
Safety aspects of connections
Full details of the rear panel are on page 8.
Connecting
Do not connect your set-top (or any other equipment such as a TV or VCR)
to the power supply until you have properly connected all the other cables.
Your set-top operates with a 120 V AC, 60 Hz power supply.
Do not connect your set-top to any supply other than this.
This set-top is equipped with a two-wire power cord, with a polarized plug
at one end. The other end of the cord is fitted with a polarized connector,
which is shaped such that it can be fitted only one way into the power
input connector of your set-top. Connect this end first, before inserting the
polarized plug into the wall AC outlet.
Disconnecting
Disconnect your set-top from the power supply before you disconnect any
other equipment from its rear panel.
The only way to disconnect your set-top from the power supply is to remove
the power cord from the wall AC outlet. Therefore, you must install your set-
top near to the wall AC outlet, which should be easily accessible.
If you are in any doubt about the power cord, its plug, or its connection,
consult a qualified electrician.
The CABLE IN connector is designed for
connection to a cable network only.
You must not connect any other equipment,
such as a VCR, to this input.
POWER INPUT
The model number, serial
number and electrical
rating of this set-top are
on a label on its base.
The POWER OUTLET plug is designed only for connection to the AC
power cord for a TV. The maximum power it can supply is 500 watts.
Do not connect any equipment that uses more than 500 watts, or any non-
TV equipment such as a toaster or hair dryer.
S-VIDEO
ETHERNET
VIDEO OUT
Pr
Pb
Y
COMPONENT VIDEO
TV PASS MODULE
TO TV
CABLE IN AUDIO
OUT
DIGIT A L
AUDIO OUT
OPTICAL
AUDIO OUT
IR RECEIVE
IR TRANSMIT
POWER OUTLET FOR TV ONLY
120V AC 60Hz 4.2A MAX.
POWER INPUT
120V AC 60Hz
DOUBLE INSULATED
L
R
+5V DC
500mA max.
SAT A

7
SAFETY INFORMATION (cont.)
Regulatory information
CAUTION: Do not attempt to modify your set-top without written
authorization from the manufacturer. Unauthorized modification
could void your authority to operate your set-top.
NOTE
Your set-top has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. Your set-top generates, uses
and can radiate radio-frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a
particular installation. If your set-top does cause harmful interference to
radio or television reception, which can be determined by turning your
set-top off and on, you are encouraged to try to correct the interference by
one or more of the following measures.
•Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweenyourset-topandthereceiver.
•Connectyourset-toptoanoutletonacircuitdifferentfromthatto
which the receiver is connected.
•Consultyourdealeroranexperiencedradio/TVtechnicianforhelp.

8
S-VIDEO
ETHERNET
VIDEO OUT
Pr
Pb
Y
COMPONENT VIDEO
TV PASS MODULE
TO TV
CABLE IN AUDIO
OUT
DIGIT A L
AUDIO OUT
OPTICAL
AUDIO OUT
IR RECEIVE
IR TRANSMIT
POWER OUTLET FOR TV ONLY
120V AC 60Hz 4.2A MAX.
POWER INPUT
120V AC 60Hz
DOUBLE INSULATED
L
R
+5V DC
500mA max.
SAT A
REAR PANEL
COMPONENT VIDEO
Component video output for analog HDTV
AUDIO OUT
Audio outputs
(stereo, L and R)
CABLE IN
From cable
service-provider
TO TV
RF output to the
TV or VCR
S-VIDEO
S-video output
VIDEO OUT
Composite
video output
SATA
For connection
to an optional
external hard
disk
POWER OUTLET
For TV only
(500 W max.)
POWER INPUT
(Make this
connection
last of all)
OPTICAL AUDIO OUT
Optical S/PDIF audio output
ETHERNET
For service
use only
HDMI
Video and audio
output for digital HDTV
USB (Universal Serial Bus)
For future use
IR TRANSMIT
Infra-red output to control a
VCR (for future use)
IR RECEIVE
Infra-red input from
a remote “eye”
DIGITAL AUDIO OUT
Electrical S/PDIF audio output
TV PASS MODULE
Connector for a TV pass®
module (for installers’ use only)

9
REAR PANEL (cont.)
CABLE IN Connect the cable service here.
TO TV Connect to the RF/antenna input on your TV or
VCR (optional).
S-VIDEO Connect to the S-video input (if present) on your
VCR or TV.
VIDEO OUT Connect to the composite video input on your VCR
(or a standard TV).
COMPONENT
VIDEO
If your HDTV does not have an HDMITM connector,
connect your HDTV here.
AUDIO OUT Connect to the L and R audio inputs on your
stereo TV, stereo VCR, or optional stereo amplifier.
DIGITAL AUDIO
OUT
Connect to the electrical digital audio input on
optional digital audio equipment, such as an audio
decoder or home theater receiver.
OPTICAL AUDIO
OUT
Connect to the optical digital audio input on
optional digital audio equipment.
HDMI
(High Definition
Multimedia
Interface)
If your HDTV has an HDMI connector, connect
it here for a digital audio/video connection
(instead of using the AUDIO and three analog
COMPONENT VIDEO connectors).
IR RECEIVE Connect to an optional remote “eye”.
IR TRANSMIT Connect to an optional VCR controller (future use).
SATA Connect to an optional external hard disk
(if enabled by your cable service-provider).
USB
(Universal Serial
Bus)
Connect to compatible optional equipment that
supports a USB 2.0 interface (future use).
ETHERNET For service use only.
TV PASS MODULE Connect a TV pass® module, if required.
POWER OUTLET
(for TV only)
Connect your TV’s power cord here to provide AC
power to your TV.
POWER INPUT Connect your set-top’s power cord here.
Make this connection last of all.

10
CONNECTING THE EQUIPMENT
In order for you to view programs broadcast in high-definition, your set-top must be connected
to a suitable HDTV or computer monitor. Your set-top is also compatible with standard-definition
TVs and VCRs.
Your equipment should have been connected up by your installer. However, if you need to
disconnect and reconnect your equipment, read pages 10 through 14.
On pages 12 and 13, there are two typical connection setups for an HDTV, VCR, DVD player, and
home theater receiver.
These setups make efficient use of the connectors on your set-top. However, depending on
your other equipment and the connectors on it, the person who installed your system may have
chosen to connect things differently.
Both setups allow stereo recording and play-back of video tapes. You hear stereo sound from the
home theater’s loudspeakers.
Although the RF cables (shown by dashed lines in the diagrams) are not absolutely necessary,
we recommend that you connect them as a back-up and to use the RF Bypass feature. If you use
the RF cables, you must tune your TV (and VCR) to your set-top’s VHF output channel (3 or 4:
consult your cable service-provider to find which channel it is for your location).
Consult the manuals supplied with your TV and VCR for information on how to tune.
You can take advantage of the digital audio output from your set-top by connecting a suitable
cable between your home theater receiver and the OPTICAL AUDIO OUT connector (as shown in
the diagrams) or the DIGITAL AUDIO OUT connector.
WARNINGS
Do not connect your set-top (or any other
equipment such as a TV or VCR) to the AC power
supply until you have properly connected all the
other cables.
Disconnect your set-top from the AC power supply
before you disconnect any other equipment from its
rear panel.
The only way to disconnect your set-top from the
AC power supply is to remove the AC power cord
(or switch the wall AC outlet switch, if present, to
its OFF position). Your set-top must therefore be
installed near the wall AC outlet, which should be
easily accessible.
The power outlet is designed only for connection to
the AC power cord for a TV. The maximum power
it can supply is 500 watts. Do not connect any
equipment that uses more than 500 watts, or any
non-TV equipment such as a toaster or hair dryer.
The cable input is designed for connection to a
cable network only. You must not connect any other
equipment, such as a VCR, to this input.
Any cable connected to DIGITAL AUDIO OUT must
be 75 ohm coaxial cable, not regular audio cable.

11
CONNECTING THE EQUIPMENT (cont.)
Setup A - Home theater system with HDTV
(HDMI connection)
Setup A (see page 12) uses an HDMI connector to connect to the HDTV. This displays the highest quality picture
on the HDTV and also means there will be no picture degradation on any copy-protected programs (provided the
link remains secure – see right).
Variation
S-video provides a better TV picture than composite video, therefore, if your TV and VCR have S-video connectors,
replace the composite video connection with an S-video connection to your VCR, then connect directly via an S-video
connection from your VCR to your TV (or loop through your home theater receiver if you prefer).
Setup B - Home theater system with HDTV
(Component video / YPbPr connection)
Setup B (see page 13) uses a component video connection to connect to the HDTV. This displays a high definition
picture on your TV.
NOTE
Copy protection via an HDMI
secure link
The HDMI link between your set-
top and your HDTV should be a
secure link. When your set-top is
attached via an HDMI cable to an
HDCP-compliant (High-bandwidth
Digital Content Protection) HDTV,
the HDTV and set-top negotiate
a secure link, which allows your
set-top to transmit full resolution
video (picture) to your HDTV.
Not all HDTVs support HDCP. If
your set-top is connected to an
HDTV that does not support it, the
following may be displayed:
Your HDTV does not support HDCP.
Please use the YPbPr component
connection to watch TV.
The HDMI output is then disabled,
so no picture is transmitted from
this connector. In that case, use
the component video connectors
to connect up (see Setup B).
NOTE
How you set up your equipment may depend on your home theater receiver. For example, the optical audio
input may be associated with a particular video input. Consult your home theater user guide for further details.

12
CONNECTING THE EQUIPMENT (cont.)
S-VIDEO
ETHERNET
VIDEO OUT
Pr
Pb
Y
COMPONENT VIDEO
TV PASS MODULE
TO TV
CABLE IN AUDIO
OUT
DIGIT A L
AUDIO OUT
OPTICAL
AUDIO OUT
IR RECEIVE
IR TRANSMIT
POWER OUTLET FOR TV ONLY
120V AC 60Hz 4.2A MAX.
POWER INPUT
120V AC 60Hz
DOUBLE INSULATED
L
R
+5V DC
500mA max.
SATA
ANTENNA/
RF IN
TV / RF
OUT
ANTENNA/
RF IN
LEFT
AUDIO IN
RIGHT
AUDIO IN
VIDEO IN
LEFT
AUDIO IN
RIGHT
AUDIO IN
VIDEO IN
POWER
LEFT
AUDIO OUT
RIGHT
AUDIO OUT
VIDEO OUT
CABLE INPUT
HDTV
VC R
DVD
LEFT
AUDIO IN
VCR IN
RIGHT
AUDIO IN
VIDEO IN
PB/CB
PR/CR
Y
COMPONENT
VIDEO OUT
HOME THEATER RECEIVER
OPTICAL
AUDIO IN
COAXIAL
AUDIO IN
DIGITAL AUDIO OUT
DIGITAL AUDIO IN
OPTICALCOAXIAL PB/CB IN
PR/CR IN
Y IN
COMPONENT
VIDEO IN
POWER
POWER
POWER
HDMI
W A LL AC OUTLET
W A LL AC
OUTLETS
Setup A: (HDMI)
NOTE
This diagram shows a video path from
the set-top to a VCR to allow recording
by the VCR. It shows a video path from
the VCR to the TV to allow playback of
videos. Video signals fed through a VCR
may be affected by copyright protection
systems, which can cause picture
distortion on your TV.
Do not, therefore, use a path through a
VCR to watch your set-top programs.
Use the HDMI path or an alternate direct
video path from your set-top to your TV.
Remember to select the correct input on
your TV.

13
S-VIDEO
ETHERNET
VIDEO OUT
Pr
Pb
Y
COMPONENT VIDEO
TV PASS MODULE
TO TV
CABLE IN AUDIO
OUT
DIGIT A L
AUDIO OUT
OPTICAL
AUDIO OUT
IR RECEIVE
IR TRANSMIT
POWER OUTLET FOR TV ONLY
120V AC 60Hz 4.2A MAX.
POWER INPUT
120V AC 60Hz
DOUBLE INSULATED
L
R
+5V DC
500mA max.
SATA
ANTENNA/
RF IN
TV / RF
OUT
ANTENNA/
RF IN
LEFT
AUDIO IN
RIGHT
AUDIO IN
VIDEO IN
LEFT
AUDIO IN
RIGHT
AUDIO IN
VIDEO IN
POWER
LEFT
AUDIO OUT
RIGHT
AUDIO OUT
VIDEO OUT
CABLE INPUT
HDTV
VC R
DVD
LEFT
AUDIO IN
VCR IN
RIGHT
AUDIO IN
VIDEO IN
HOME THEATER RECEIVER
OPTICAL
AUDIO IN
COAXIAL
AUDIO IN
DIGITAL AUDIO OUT
DIGITAL AUDIO IN
OPTICALCOAXIAL
POWER
POWER
POWER
W A LL AC OUTLET
W A LL AC
OUTLETS
PB/CB IN
PR/CR IN
Y IN
COMPONENT
VIDEO IN
S-VIDEO OUT S-VIDEO
IN
Setup B: (Component video)
CONNECTING THE EQUIPMENT (cont.)
NOTE
This diagram shows a video path from
the set-top to a VCR to allow recording
by the VCR. It shows a video path from
the VCR to the TV to allow playback of
videos. Video signals fed through a VCR
may be affected by copyright protection
systems, which can cause picture distortion
on your TV.
Do not, therefore, use a path through a
VCR to watch your set-top programs. Use
the component video path or an alternate
direct video path from your set-top to your
TV. Remember to select the correct input
on your TV.

14
WARNINGS
Do not connect your set-top (or any other equipment such as a TV or VCR) to the AC power supply until you
have properly connected all the other cables.
Do not defeat the safety purpose of the polarized plugs on power cords. A polarized plug has two blades with
one wider than the other. This plug fits into the AC outlet in only one way; match the wide blade of the plug
to the wide slot of the AC outlet.
Connecting your TV to the AC power supply
If your TV has a rating of up to 500 W, connect the power cord from your TV into the POWER OUTLET connector
on the rear panel of your set-top. This saves a wall AC outlet (although, if your TV has a rating of more than
500 W, you must connect it to a wall AC outlet).
Connecting the power cord to your set-top
Before you connect your set-top to a wall AC outlet, connect the polarized socket on the set-top’s power cord into
the POWER INPUT connector on your set-top’s rear panel.
Connecting equipment to the wall AC outlets
Connect the polarized plugs on the power cords from your set-top, VCR, and any other equipment into wall AC
outlets. If these outlets have switches, switch them ON.
CONNECTING THE EQUIPMENT (cont.)

15
TDC770D
HDTV BYPASS
IR RECEIVE MESSAGE
OPERATING YOUR SET-TOP
Turning your set-top on and off
After you have connected your set-top to the wall AC outlet (and switched this outlet ON, if it has a switch), the
light next to the power button on your set-top’s front panel should be red.
Wait for a few seconds, then press the power button on the front panel of your set-top to turn it on. The light next
to the power button goes green, to show that your set-top is on.
If the light next to the power button is neither red nor green, there is a problem (see page 37).
To turn your set-top on or off at any time, press the power button on its front panel or the POWER button on
your remote control (first making sure your remote control is set to control your set-top).
Never turn off your set-top by simply disconnecting it from the power supply. If you need to disconnect your set-
top, first stop any recording. Then turn off your set-top by pressing the power button on its front panel or on your
remote control, so that the light next to the power button goes red. Then wait 60 seconds before disconnecting
your set-top from the wall AC outlet.
Power Saving: To save power and money, and to reduce greenhouse gas emissions, turn off your
set-top, using the power button, when it is not in use.
NOTES
IMPORTANT: Unless there is a lightning storm or you will be away from your home for a long time, do not
unplug your set-top from the wall AC outlet (or do not switch it off there, if the outlet has a switch). Your set-
top cannot be updated with new features, through the cable, if it is disconnected from the AC power supply.
Depending on your set-top’s settings, if you switch your set-top off, any TV that is attached to your set-top’s
POWER OUTLET may also turn off. For more details, see page 36.
The light next to the button
changes from red to green.
To turn your set-top on,
press the power button.
Front panel display, showing
the time (see page 36)

16
Lightning storms
Disconnect your set-top’s power cord during lightning storms. A lightning storm may affect your set-top, if it is on
during the storm. It may appear that it has stopped working, but you can easily restore its operation as follows:
Unplug your set-top’s power cord from the wall AC outlet. Then plug this power cord in again at the wall AC outlet
(and, if there is a switch by this outlet, switch it to its ON position).
Using your remote control
Your cable TV service-provider determines the digital channels, services, and screen information that you see on
your TV when you use your set-top and its remote control.
Consult the information supplied by your cable service-provider for details on how to make the most of the digital
cable services. Also read the operating instructions that are supplied with your remote control.
Displaying a picture on your HDTV screen
If your set-top is connected to your HDTV’s component video or HDMI™ input and is turned on (the power light
is green), but your HDTV does not initially display a picture from your set-top, your HDTV may not support your
set-top’s current output resolution (for further details on resolutions, see page 25). You therefore need to change
your set-top’s output resolution as follows:
1. First press the POWER button on your remote control (power light goes red), then press the MENU button.
2. Next, press the ZOOM button on your remote control (the button could be labeled ASPECT) until a picture
appears.
Each button-press changes your set-top’s output resolution, which also appears on the TV screen.
After a few seconds, you should see the PACE USER SETTINGS menu.
3. Press the POWER button to remove this menu and return to normal viewing.
OPERATING YOUR SET-TOP (cont.)
PACE USER SETTINGS
TV Aspect Ratio
TV Display Capability
Auto Pillarbox
Closed Captions
Front Panel Settings
Hard Disk Sleep Mode
HDMI Settings
Restore Defaults
Select[OK] Exit[POWER]
Video Format : 1080i
Current output resolution from your
set-top (1080i, 720p, 480p, or 480i)

17
OPERATING YOUR SET-TOP (cont.)
Using the front-panel buttons
TDC770D
HDTV BYPASS
IR RECEIVE MESSAGE
BYPASS light
Lights when RF Bypass is on
guide
To display an on-screen guide
bypass
To turn the RF Bypass feature on/off
menu
To display on-screen menus
info
To display on-screen
information
channel Uand D
To change channel up
or down
power button
To turn your set-top on/off
power light (next to button)
Lights green when your set-top is on;
red when your set-top is off; not lighted
when your set-top is disconnected from
the power supply
IR RECEIVE light
Lights when your
set-top is receiving
a signal from your
remote control
HDTV light
Lights when your set-top outputs
High Definition TV (HDTV) content
MESSAGE light
Lights when there is an
unread message and when
you make user settings
front-panel display
Appears when your set-top is turned on
Shows the program channel number or the time
Also displays HDTV settings (see page 26)
play/record lights
Indicate the play or record state
of each display channel
Lights green to signify playback;
lights red to signify record
L, R, U, and D
To move left/right/
up/down in an on-
screen menu/guide
select button
To select items in
menus/guides

18
Using your set-top’s DVR (digital video recorder) functions
Your set-top has an internal hard disk that you can use to record and play back television programs, giving you
much more control of your viewing experience. For example, you can pause live television and resume viewing
from the point at which you left off. You can record many more hours than you can by using a VCR or DVD
recorder. There are red lights on your set-top’s front panel to show when recording is taking place.
With your set-top you can:
• pauseliveTV;
• instantlyreplayliveTV;
• fast-forwarduptothepointofliveTV;
• watchasceneinslowmotion;
• rewindthroughaprogramyouhavebeenwatching;
• recordhighdenitiondigitalpictures(aswellastheregularstandarddenition);
• recordoneprogramwhilewatchinganother;
• recordtwoprogramswhilewatchingapreviouslyrecordedprogram;
• scheduleyourset-toptorecordaprogramorawholeseries;
• fullymanageyourstoredrecordings;
• backupyourdigitalrecordingstoaVCRorDVDrecorder;
• retainfullcontroloveranyparentalviewingrestrictionsyouhavesetup.
Youcontrolyourset-top’sDVRfunctionsusingyourremotecontrol;consulttheinformationsuppliedbyyour
cable service-provider for more details. Also read the operating instructions that are supplied with your remote
control.
NOTES
The exact functionality of the
DVR in your set-top depends on
your on-screen program guide.
For more details, consult the
information supplied by your cable
service-provider.
Do not confuse recording to the
hard disk with recording to a
separate VCR or DVD recorder, as
mentioned on page 20.
The DVR functions will not work if
your set-top becomes overheated.
The internal hard disk will be
temporarily disabled. Refer to the
set-top’s ventilation requirements
on page 4.
OPERATING YOUR SET-TOP (cont.)
