Pacific hydrostar 94639 User manual

12 VOLT UTILITY PUMP
Models 9576, 94639
OPERATING INSTRUCTIONS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright©2006 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Manual Revised 10a

Page 2 For technical questions, please call 1-800-444-3353. SKU 9576,
94639
SAVE THIS MANUAL
Keep this manual for the safety warnings
and precautions, assembly, operating,
inspection, maintenance and cleaning
procedures. Write the product’s serial number
in the back of the manual near the assembly
diagram (or month and year of purchase if
product has no number). Keep this manual
and the receipt in a safe and dry place for
future reference.
IMPORTANT SAFETY
INFORMATION
In this manual, on the labeling, and
all other information provided with
this product:
This is the safety alert
symbol. It is used to alert
you to potential personal
injury hazards. Obey all
safety messages that follow
this symbol to avoid possible
injury or death.
DANGER indicates a
hazardous situation
which, if not avoided, will result
in death or serious injury.
WARNING indicates a
hazardous situation
which, if not avoided, could
result in death or serious injury.
CAUTION, used with
the safety alert
symbol, indicates a hazardous
situation which, if not avoided,
could result in minor or moderate
injury.
NOTICE is used to
address practices not
related to personal injury.
CAUTION, without the
safety alert symbol, is
used to address practices not
related to personal injury.
General Safety Warnings
WARNING Read all safety warnings
and instructions. Failure to follow the
warnings and instructions may result
in electric shock, re and/or serious
injury.
Save all warnings and instructions
for future reference.
Keep work area clean and dry. Cluttered,1. damp, or wet work areas invite injuries.
Keep children away from work area. Do2. not allow children to handle this product.
Store idle equipment. When not in use,3. tools and equipment should be stored in
a dry location to inhibit rust. Always lock
up tools and equipment, and keep out of
reach of children.
Do not use this product if under the4.

warning labels on prescriptions to

are impaired while taking drugs. If there
is any doubt, do not attempt to use this
product.
Wear eye protection. Wear ANSI5. approved safety impact eye goggles
when assembling this product.
Dress safely. Do not wear loose clothing6. or jewelry, as they can become caught
in moving parts. Wear a protective
hair covering to prevent long hair from
becoming caught in moving parts. If
REV 06g; 07i

Page 3For technical questions, please call 1-800-444-3353.SKU 9576,
94639
wearing a long-sleeve shirt, roll sleeves
up above elbows.
Do not overreach. Keep proper footing7. and balance at all times to prevent
tripping, falling, back injury, etcetera.
Industrial applications must follow OSHA8. requirements.
Stay alert. Watch what you are doing at9. all times. Use common sense. Do not
use this product when you are tired or
distracted from the job at hand.
Check for damaged parts. Before using10. this product, carefully check that it
will operate properly and perform its
intended function. Check for damaged
parts and any other conditions that may
affect the operation of this product.

immediately.
11. when servicing, use only identical
replacement parts. Only use
accessories intended for use with this
product. Approved accessories are
available from harbor freight tools.
Maintain this product with care. Keep12. this product clean and dry for better and
safer performance.
For your safety, service and maintenance13. should be performed regularly by a

Use the right tool for the job. Do14. not attempt to force a small tool or
attachment to do the work of a larger
industrial tool. There are certain
applications for which this tool was
designed. It will do the job better and
more safely at the rate for which it was
intended. Do not modify this tool, and do
not use this tool for a purpose for which it
was not intended.
The warnings, precautions, and15. instructions discussed in this manual
cannot cover all possible conditions and
situations that may occur. The operator
must understand that common sense
and caution are factors, which cannot
be built into this product, but must be
supplied by the operator.
SPECIFIC PRODUCT WARNINGS
AND PRECAUTIONS
1.

DO NOT ATTEMPT TO USE THIS
PRODUCT TO PUMP FLAMMABLE,
EXPLOSIVE, OR CORROSIVE
LIQUIDS.
USE ONLY A2. 12 VOLT DC
ELECTRICAL SYSTEM TO POWER
THIS PUMP.
Maintain a safe working environment.3. Keep the work area well lit. Make
sure there is adequate surrounding
workspace. Keep the work area free
of obstructions, sawdust, grease, oil,
standing water, trash, and other debris.
Avoid electrical shock. Use caution4. when connecting the utility pump to
a 12 volt, DC electrical system. Use
caution when working with uninsulated
conductors or bus bars. Prevent body
contact with grounded surfaces. Avoid
stepping in standing water or other
liquids.
This utility pump is designed for5. intermittent use only. Do not use the
utility pump over excessive lengths of
time, as premature wearing will result.
Secure the discharge hose (not included)6. before starting the utility pump. An
unsecured hose may whip, causing
personal injury and/or property damage.

Page 4 For technical questions, please call 1-800-444-3353. SKU 9576,
94639
Do not allow the utility pump to run7. dry. Fill the pump (23) chamber with
liquid before operation. Failing to do so
may damage the seal ring (22), which
depends on the liquid for its lubrication.
In cold weather, when the utility pump8. is not in use, protect the interior of the
pump from freezing by draining the
liquid and pumping a permanent type
automobile antifreeze containing a rust
inhibitor through the system. A 50%
mixture with water is recommended. Be

a neutralizing liquid prior to reuse of the
unit.
If used on a boat, read and understand9. all instructions and safety precautions as
outlined in the manufacturer’s manual for
the boat on which the utility pump will be
used.
Lead-acid batteries generate10. hydrogen gas during normal
operation. Hydrogen gas is:
explosive and highly ammable.
If connecting the utility pump temporarily11. to a lead-acid battery, wear ANSI
approved, safety impact eye goggles.
Avoid contact with battery acid. If12. splashed, immediately wash affected
area with clean water. Continue washing
area until medical help is available.
If the utility pump is used on a boat, turn13. off the boat ignition before making power
cord (1) connections.
If used on a boat, always connect the14. red
power cord (1) on the utility pump to the
positive (+) side of the boat’s 12 volt DC
electrical system.
Connect the15. black power cord (1) on the
utility pump to the negative (--) side of
the boat’s 12 volt electrical system.
When connecting the power cords (1) to16. the boat’s 12 volt DC electrical system,
connect the red power cord . Then,
connect the black power cord. When
disconnecting the power cords from
the electrical system, disconnect
the black power cord rst. Then,
disconnect the red power cord.
Turn the boat’s ignition switch to its “off”17. position and disconnect the utility pump
from the boat’s 12 volt DC electrical
system before performing any inspection,
adjustments, maintenance, or cleaning
procedures on the pump.
18.
.
People with pacemakers should consult19. their physician(s) before using this

proximity to a heart pacemaker could
cause interference to or failure of the
pacemaker.

Page 5For technical questions, please call 1-800-444-3353.SKU 9576,
94639
REV 08e, 10a
SPECIFICATIONS
Model 9576 94639
Motor 12 VDC / 50 W

12 VDC / 110 W

Application
Utility Water
Pumping,
including
marine
applications
Utility Water
Pumping
Power Wires 
Discharge
Height* 23 ft.
  
Self Priming 
Construction Stainless Steel Pump Housing
Steel Motor Housing
Dual Threaded
Inlet 3/8”-18 NPT Female I.D. 3/4” Male O.D.
Dimensions 
*Note: For optimal performance, the
suction hose (not included) I.D.
must be at least the same size as the
suction ange and free of air leaks.
All joints and connections of the suction
hose should be securely tightened to
prevent air from entering the suction
side. Use a good grade suction hose
that will not collapse.
In addition, the height from the inlet
to the pump and then the height from
the outlet to the discharge will greatly
impact pump performance.
UNPACKING
When unpacking, make sure the item
is intact and undamaged. If any parts are
missing or broken, please call Harbor Freight
Tools at 1-800-444-3353 as soon as possible.
OPERATING INSTRUCTIONS
NOTE: For additional reference to the parts
mentioned in the following pages, refer
to the Assembly Diagram at the end of
this manual.
NOTE: Mount the pump permanently to
a at surface only. Do not mount the
Pump on a rounded surface. (Hardware
for permanently mounting the Utility
Pump is not included.)
CONNECT
SUCTION HOSE
(NOT INCLUDED)
HERE.
CONNECT
DISCHARGE HOSE
(NOT INCLUDED)
HERE.
FIGURE A
1. The Inlet and Outlet Ports on the Utility
Pump are both dual threaded with an
Inside Diameter of 3/8” NPT and an
Outside Diameter of 3/4”. This allows
for more versatility in selecting a suction
hose and discharge hose (not included)
with the proper threaded male or female
connector. (See Figure A.)
If you are connecting a suction hose2. having a threaded male connector,
wrap about 4” of pipe seal tape (not
included) around the threads of the
male
male connector into the threaded female


Page 6 For technical questions, please call 1-800-444-3353. SKU 9576,
94639
this process for the discharge hose
having a threaded male connector.
If you are connecting a suction hose3. having a threaded female connector,
wrap about 4” of pipe seal tape (not
included) around the threads of the male
connector of the Utility Pump. Then,
female connector of the
suction hose onto the threaded male

this process for the discharge hose
having a threaded female connector.
Note: Depending on the make/model of
boat on which the Utility Pump will be
used, there are many variations as to
connecting the Utility Pump to the boat’s
12 Volt DC electrical system. Therefore,
it is recommended that only a qualied
technician perform this procedure.
Note: It is highly recommended that a circuit
protection device and control switch be
used when permanently installing this
“Specic
Product Warnings and Precautions” in
this manual for further instructions.
INSPECTION, MAINTENANCE,
AND CLEANING
TO PREVENT INJURY
AND FIRE FROM
ACCIDENTAL OPERATION OR
SPARKING:
Turn the Boat’s Ignition Switch to
its “OFF” position and
disconnect the Power Cords (1)
from the boat’s 12 Volt DC
electrical system before
performing any inspection,
maintenance, or cleaning.
BEFORE EACH USE,1. inspect the
general condition of the Utility Pump.
Check for loose screws, misalignment
or binding of moving parts, cracked or
broken parts, damaged electrical wiring,
loose or leaking suction and discharge
hoses, and any other condition that may

of the Utility Pump. If abnormal noise
or vibration occurs, have the problem
corrected before further use. Do not
use damaged equipment.
WHEN NECESSARY:2. With a clean, dry
cloth, or vacuum, remove all dirt and
debris from the Utility Pump.
PLEASE READ THE
FOLLOWING CAREFULLY
   
      
      
      
   



        

     

    
 
      
      




Page 7For technical questions, please call 1-800-444-3353.SKU 9576,
94639
PARTS LIST AND ASSEMBLY DIAGRAM
Note: When ordering parts, specify the model number the parts are being ordered for.
REV 05i;06k; 10a
Part Description
1 Power Cord 2 Insulator 3 Back Cover
4a Sealed Ball Bearing
5 Battery Clip 7 Brush Holder 8 Brush 9 Stator
10 Flat Washer
11 C-Clip
12 Armature 13 C-Clip 14 Flat Washer
17a Sealed Ball Bearing
18 Front Cover 19  20 Sealed Spring Washer
Part Description
21  22  23 Pump Housing 24 Cross Head Screw
25a Impeller Blade (94639) 25b Impeller Blade (9576) 26a Impeller
27  28 Pump Cover 29 Cross Head Screw 30 Handle 31 Cross Head Screw 32 Bolt 33 Base Plate 34 Cross Head Screw 35 
Record Product’s Serial Number Here: Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts.
25

Page 8 For technical questions, please call 1-800-444-3353. SKU 9576,
94639
LIMITED 1 YEAR / 90 DAY
WARRANTY
Harbor Freight Tools Co. makes every
effort to assure that its products meet high
quality and durability standards, and warrants
to the original purchaser that for a period
of ninety days from date of purchase that
the engine/motor, the belts (if so equipped),
and the blades (if so equipped) are free
of defects in materials and workmanship.
Harbor Freight Tools also warrants to the
original purchaser, for a period of one year
from date of purchase, that all other parts
and components of the product are free from
defects in materials and workmanship (90
days if used by a professional contractor or
if used as rental equipment). This warranty
does not apply to damage due directly or
indirectly, to misuse, abuse, negligence or
accidents, repairs or alterations outside
our facilities, normal wear and tear, or to
lack of maintenance. We shall in no event
be liable for death, injuries to persons
or property, or for incidental, contingent,
special or consequential damages arising
from the use of our product. Some states
do not allow the exclusion or limitation of
incidental or consequential damages, so the
above limitation of exclusion may not apply
to you.



FITNESS.
To take advantage of this warranty,
the product or part must be returned to us
with transportation charges prepaid. Proof
of purchase date and an explanation of the
complaint must accompany the merchandise.

will either repair or replace the product at
our election or we may elect to refund the
purchase price if we cannot readily and
quickly provide you with a replacement. We
will return repaired products at our expense,
but if we determine there is no defect, or that
the defect resulted from causes not within the
scope of our warranty, then you must bear the
cost of returning the product.

rights and you may also have other rights
which vary from state to state.
3491 Mission Oaks Blvd. • PO Box 6009
Camarillo, CA 93011 • [phone]
