Pacific AM-3 User manual
PLEASE READ THIS BOOK
This operator’s book has important informaon for the use and safe operaon of this machine. Read this
book carefully before starng the machine. Keep this book and tell all operators to read the book. If you
do not follow the instrucons, you can cause an injury or damage equipment, furniture or buildings.
For new books, please download your copy from our website www.pacicoorcare.com or write to:
Pacic Floorcare
2259 S. Sheridan Drive
Muskegon, MI 49442-6252
Carefully inspect all components to ensure that there is no concealed freight damage. If such damage is
discovered, le a “CONCEALED DAMAGE REPORT” immediately with the delivering carrier.
The contents of this manual are based on the latest product informaon available at the me of
publicaon. Pacic reserves the right to make changes or improvements without noce.
Thank you for purchasing a Pacic Floorcare product. Warranty registraon will allow us to beer
serve you over the lifeme of the product. For quick and easy registraon, go to:
www.pacicoorcare.com/Register Product.
PARTS & OPERATING MANUAL
AM-3 THREE SPEED
AIR MOVER
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
When using an electrical appliance, basic precautions should always be followed.
WARNING- To reduce the risk of fire, electric shock or injury:
• Use only as described in this manual. Use only manufacturer’s recommended components and attachments.
• Use only indoors. Do not use outdoors or expose to rain.
• Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors, or
dropped into water, return it to your Authorized dealer.
• Do not pull or carry by cord, use cord as a handle, close door on cord, or pull cord around sharp edges or corners. Keep cord
away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into openings. Do not use with any opening blocked; keep free of dust, hair and anything that may
reduce air flow.
• Turn off all controls before unplugging.
• Do not attempt to service the unit while appliance is plugged in.
• Appliance may cause a fire when operating near flammable vapors or materials. Do not operate this machine near
flammable fluids, dust or vapors.
• Connect to a properly grounded outlet.
• Use only on GFCI protected receptacles.
• To reduce the risk of electric shock, connect only to an outlet provided with a ground fault circuit interrupting device.
• Do not use an extension cord with this fan.
• This unit is thermally protected.
• Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
• Do not use this dryer with any solid-state speed control device.
• Always operate dryer on a stable flat surface such as the floor.
• Do not operate dryer without safety devices in place.
• Do not allow to be used as toy. Close attention is necessary when used near children.
• All repairs must be performed by a qualified service person.
• Do not modify the machine from its original design.
2
IMPORTANT SAFETY INSTRUCTIONS
Operang Instrucons
WARNING- To reduce the risk of fire, electric shock or injury; only use dryer as described in this manual.
Plug in to a standard outlet with the correct voltage and amperage for the unit.
Place the dryer in the desired operating position.
Set the switch at the desired speed: low, medium or high.
Check for proper operation before leaving the unit unattended. Do not move or carry the dryer when it is running.
3
For Best Performance
• Keep machine clean and in good operang condion.
• Have machine checked periodically by your Authorized Dealer.
• Use only authorized service centers for parts or service.
• Store machine carefully in dry area.
• For opmum drying performance and safety, study and follow your
operators manual.
3 postion switch
Unit in vertical position CAUTION: Do not stack dry-
ers more than two units high
without tie-downs
Grounding Instrucons
This appliance must be grounded. If it should malfunction or break down,
grounding provides a path of least resistance for electric current to reduce
the risk of electric shock. This appliance is equipped with a cord having an
equipment-grounding conductor and grounding plug. The plug must be
plugged into an appropriate outlet that is properly installed and grounded
in accordance with all local codes and ordinances.
This appliance is for use on a nominal 120 volt circuit and has a ground
plug (see illustration, right). Make sure that the appliance is connected to
an outlet having the same configuration as the plug. No adaptor should be
used with this appliance.
WARNING- Improper connection of the equipment-grounding
conductor can result in a risk of electric shock. Check with a qualified
electrician or service person if you are in doubt as to whether the outlet is
properly grounded. Do not modify the plug provided with the appliance
– if it will not fit the outlet, have a proper outlet installed by a qualified
electrician.
NOTE: Do not use adapters shown in
gures B & C in Canada
WARNING- To reduce the risk of fire, electric shock or injury; Do not attempt to service the unit while appliance is
plugged in.
Periodic Maintenance
1. Check power cord for any breaks, separations or cuts.
2. Make sure the ground pin or grounding prong is intact or the machine will be unsafe to operate.
Trouble Shooting (if the dryer will not run)
1. Check electrical cord; is it firmly seated in wall outlet
2. Check GFCI and reset if tripped
3. Check to see if building circuit breaker is tripped. If circuit is overloaded, move cord to different GFCI outlet.
4. If using an extension cord, make sure it is in good condition, proper gauge and firmly connected.
MAINTENANCE / TROUBLE SHOOTING
4
5
AM-3 AIR MOVER
15
Item # Part # Description
1 224291 Dryer Housing, Black , Regrind
2 223091 Squirrel Cage, Plastic
3 228540 Intake Panel
4 W358D Screw, #6 x 1/2”, Black
5 225003 Handle/Wheel Assembly (OPTIONAL)
6 962221 Screw, 1/4-20 x 1 Hex Head (OPTIONAL)
7 225201 Dryer Motor
8 227003 Motor Control Panel
9 964012 Screw M4x6 Flat Head Phillips
10 225045 Knob, Switch
11 W358D Screw, #6 x 1/2”, Black
12 920015 Nut, Lock, 1/2” Steel Conduit
13 228504 Strain Relief
14 908062 20’ HD 3 Wire Cord 16/3
15 228001 Switch, 3 Speed
16 962017 Screw 3/8-16 x 1/2” Hex Head
17 227491 Grill, Dryer Discharge
18 920031 Nut 8-32 KEPS
19 962337 Screw, 8-32 x 1 PHIL PAN
20 223304 Foot, Left Dryer Kickstand
21 W358D Screw, #6 x 1/2”, Black
22 225046 Kickstand, Dryer
23 223305 Foot, Right Dryer Kickstand
24 223306 Foot, Black Rubber
25 930015 Rivet, 3/16 Black
26 920009 Nut, Kep 1/4-20 Zinc (OPTIONAL)
WARRANTY POLICY
AIR MOVER, MODEL AM-3
The Pacic Floorcare AM-3 Air Mover has been manufactured, tested and inspected in accordance with specic engineering
requirements and is WARRANTED to be free from defects in workmanship and materials as follows:
Five (5) years - Rotomold housing
One (1) year parts and labor – All other components unless excluded below.
This warranty extends to the original user/purchaser and only when used, operated and maintained in accordance with Pacic
Operang and Maintenance instrucons.
This warranty does not apply to the following wear parts and accessories of the machine including:
Part Number
908062
228001
Nor does it apply to damage or failure caused by improper use, abuse or neglect. Warranty credit or replacement of return
parts including motors, etc., is subject to incoming inspecon of those items.
To secure repair under this warranty, the following procedure should be taken:
• The inoperave machine or warranted parts must be delivered to the authorized dealer with shipping and delivery charges
prepaid. If unable to locate the Dealer, you may contact Pacic at the address listed herein for the locaon of the nearest
Pacic repair center or agent or for other instrucons pertaining to your warranty diculty.
• Upon compliance with the above warranty procedure, all warranted repairs would be completed at no addional charge
or cost to the user.
• Only Pacic or its authorized dealers and agents may make no charge warranty repairs on this product. All others do so
at their own risk.
This warranty limits Pacic liability to the repair of the product and/or warranted parts replacement and does not include
incidental or consequenal damages arising from the use of a Pacic machine whether defecve or not.
This warranty is in lieu of all other expressed or implied warranes and is extended to the original purchaser/user.
2259 S. SHERIDAN DRIVE
MUSKEGON, MICHIGAN 49442-6252
800-968-1332
FAX 800-863-9536
12/13
Part Name
Cord Assembly
Switch
