PACOM PDR420 User manual

Four-Channel Digital Video Recorder
i
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING:TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert
the user to the presence of uninsulated "dangerous voltage" within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
COMPLIANCE NOTICE OF FCC:
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL
DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE
REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED
IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO
FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION
MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. OPERATION OF THIS
EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL INTERFERENCE, IN WHICH CASE
USERS WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT THEIR OWN EXPENSE.
WARNING: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE
FOR COMPLIANCE COULD VOID THE USER’SAUTHORITY TO OPERATE THE EQUIPMENT.
THIS CLASS OF DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE CANADIAN
INTERFERENCE-CAUSING EQUIPMENT REGULATIONS.
The information in this manual is believed to be accurate as of the date of publication. IDIS is not responsible for any
problems resulting from the use thereof. The information contained herein is subject to change without notice.
Revisions or new editions to this publication may be issued to incorporate such changes.

User’s Manual
ii
Important Safeguards
1. Read Instructions
All the safety and operating instructions should be read before the
appliance is operated.
2. Retain Instructions
The safety and operating instructions should be retained for future
reference.
3. Cleaning
Unplug this equipment from the wall outlet before cleaning it. Do not
use liquid aerosol cleaners. Use a damp soft cloth for cleaning.
4. Attachments
Never add any attachments and/or equipment without the approval of
the manufacturer as such additions may result in the risk of fire, electric
shock or other personal injury.
5. Water and/or Moisture
Do not use this equipment near water or in contact with water.
6. Placing and Accessories
Do not misplace this equipment other than upright position. This
equipment has an open frame SMPS (Switching Mode Power Supply),
which may cause a fire or electric shock if anything is inserted into the
unit through the ventilation holes on the side of the equipment.
Do not place this equipment on an unstable cart, stand or table. The
equipment may fall, causing serious injury to a child or adult, and
serious damage to the equipment.
This equipment and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the
equipment and cart combination to overturn.
7. Power Sources
This equipment should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power,
please consult your equipment dealer or local power company.
8. Power Cords
Operator or installer must remove power and TNT connections before
handling the equipment.
9. Lightning
For added protection for this equipment during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the antenna or cable system. This
will prevent damage to the equipment due to lightning and power-line
surges.
10. Overloading
Do not overload wall outlets and extension cords as this can result in
the risk of fire or electric shock.
11. Objects and Liquids
Never push objects of any kind through openings of this equipment as
they may touch dangerous voltage points or short out parts that could
result in a fire or electric shock. Never spill liquid of any kind on the
equipment.
12. Servicing
Do not attempt to service this equipment yourself. Refer all servicing
to qualified service personnel.
13. Damage requiring Service
Unplug this equipment from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
A. When the power-supply cord or the plug has been damaged.
B. If liquid is spilled, or objects have fallen into the equipment.
C. If the equipment has been exposed to rain or water.
D. If the equipment does not operate normally by following the
operating instructions, adjust only those controls that are covered by
the operating instructions as an improper adjustment of other
controls may result in damage and will often require extensive work
by a qualified technician to restore the equipment to its normal
operation.
E. If the equipment has been dropped, or the cabinet damaged.
F. When the equipment exhibits a distinct change in performance —
this indicates a need for service.
14. Replacement Parts
When replacement parts are required, be sure the service technician has
used replacement parts specified by the manufacturer or that have the
same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock or other hazards.
15. Safety Check
Upon completion of any service or repairs to this equipment, ask the
service technician to perform safety checks to determine that the
equipment is in proper operating condition.
16. Field Installation
This installation should be made by a qualified service person and
should conform to all local codes.
17. Correct Batteries
Warning: Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
18. Tmra
A manufacturer’s maximum recommended ambient temperature
(Tmra) for the equipment must be specified so that the customer and
installer may determine a suitable maximum operating environment
for the equipment.
19. Elevated Operating Ambient Temperature
If installed in a closed or multi-unit rack assembly, the operating
ambient temperature of the rack environment may be greater than room
ambient. Therefore, consideration should be given to installing the
equipment in an environment compatible with the manufacturer’s
maximum rated ambient temperature (Tmra).
20. Reduced Air Flow
Installation of the equipment in the rack should be such that the amount
of airflow required for safe operation of the equipment is not
compromised.
21. Mechanical Loading
Mounting of the equipment in the rack should be such that a hazardous
condition is not caused by uneven mechanical loading.
22. Circuit Overloading
Consideration should be given to connection of the equipment to
supply circuit and the effect that overloading of circuits might have on
over current protection and supply wiring. Appropriate consideration
of equipment nameplate ratings should be used when addressing this
concern.
23. Reliable Earthing (Grounding)
Reliable grounding of rack mounted equipment should be maintained.
Particular attention should be given to supply connections other than
direct connections to the branch circuit (e.g., use of power strips).

Four-Channel Digital Video Recorder
iii
Table of Contents
Chapter 1 —Introduction................................................................ 1
Features......................................................................................... 1
Package Contents.......................................................................... 1
Rear Panel Connectors.................................................................. 2
Factory Reset................................................................................. 3
Front Panel Controls...................................................................... 3
Chapter 2 —Operation.................................................................... 4
Turning on the Power..................................................................... 4
Live Viewing................................................................................... 5
Recording....................................................................................... 5
Playback........................................................................................ 6
Searching....................................................................................... 7
PTZ Control.................................................................................... 8
Chapter 3 —Configuration........................................................... 10
Overview...................................................................................... 10
Main Setup................................................................................... 11
Appendix........................................................................................ 15
WebGuard.................................................................................... 15
Minibank self player..................................................................... 18
Factory Default Settings............................................................... 19
System Log.................................................................................. 20
Troubleshooting........................................................................... 21
Connector Pin Outs...................................................................... 21
Specifications............................................................................... 22

User’s Manual
iv

Four-Channel Digital Video Recorder
1
Chapter 1 —Introduction
FEATURES
Your color digital video recorder (DVR) provides recording capabilities for 4camera inputs. It provides
exceptional picture quality in both live and playback modes, and offers the following features:
Ÿ4 Composite Input Connectors
ŸCompatible with Color (NTSC or PAL) and B&W (CCIR and EIA-170) Video Sources
ŸRecords up to 30 NTSC Images per Second (25 PAL Images per Second)
ŸContinuous Recording in Disk Overwrite Mode
ŸContinues Recording while Playing Back and Transmitting to Remote Site
ŸVarious Record Modes: Schedule (Continuous, Event) and Manual
ŸMultiple Search Engines (Date/Time, Calendar, Event)
Ÿ“Loop-Through” Video Connectors
ŸAlarm Input and Output Connections
ŸBuilt-in Buzzer
ŸLive or Recorded Video Access via Internet Explorer Web Browser
PACKAGE CONTENTS
The package contains the following:
ŸDigital Video Recorder
ŸPower Cord
ŸUser’s Manual (This document)
CAUTION: ROUTE POWER CORDS SO THAT THEY ARE NOT A TRIPPING HAZARD.
MAKE CERTAIN THE POWER CORD WILL NOT BE PINCHED OR ABRADED BY
FURNITURE. DO NOT INSTALL POWER CORDS UNDER RUGS OR CARPET. THE
POWER CORD HAS A GROUNDING PIN. IF YOUR POWER OUTLET DOES NOT HAVE
A GROUNDING PIN RECEPTACLE, DO NOT MODIFY THE PLUG. DO NOT OVERLOAD
THE CIRCUIT BY PLUGGING TOO MANY DEVICES IN TO ONE CIRCUIT.

User’s Manual
2
REAR PANEL CONNECTORS
No special tools are required to install the DVR. Refer to the installation manuals for the other items that
make up part of your system. Your DVR should be completely installed before proceeding.
Video In: Connect the coaxial cables from the video sources.
Network: Connect a Cat5 cable with an RJ-45 jack.
RS-485 Port: Connect a PTZ camera. Refer to Appendix –Connector Pin Outs for details.
Loop: Connect the video source to another video-out device through loop BNC connectors if
necessary.
Video Out: Connect the SPOT monitor.
Alarm In: Connect alarm-in devices. The threshold voltage for NC (Normally Closed)is above
4.3Vand for NO (Normally Open)is below 0.3V, and it should be stable at least 0.5 seconds to be
detected.
GND: Connect the ground side of the alarm input to the GND connector.
Alarm Out: Connect an alarm-out device to NC (Normally Closed) and C(Common) connectors or
NO (Normally Open) and C(Common) connectors. Permitted current is up to 0.5A for 125 VAC, 1
A for 30 VDC.
Factory Reset Switch: Use this switch on rare occasions that you want to return all the settings to the
original factory settings.Refer to the Factory Reset section for details.
Power Cord: Connect the power cord to the DVR and then to the wall outlet.
NOTES:
ŸThe Loop BNC connectors are auto terminated. Do NOT connect a cable to the Loop BNC unless it is
connected to another terminated device because it will cause poor quality video.
ŸTo make connections on the Alarm Connector Strip, press and hold the button and insert the wire in
the hole below the button. After releasing the button, tug gently on the wire to make certain it is
connected. To disconnect a wire, press and hold the button above the wire and pull out the wire.
ŸThis Network Port is not connected with cables or wires intended to connect to the outdoor directly.

Four-Channel Digital Video Recorder
3
FACTORY RESET
To reset the unit, you will need a straightened paperclip:
1. Turn the DVR off.
2. Turn it on again.
3. While the DVR is initializing, poke the straightened paperclip in the unlabeled hole to the right of
the RS-485 connector.
4. Hold the switch until the LEDs on the Front Panel flashes three times and are lit.
5. Release the reset switch. All of the DVR’s settings are now at the original settings it had when it
left the factory.
NOTE: When using the Factory Reset, you will lose any setting you have made. If you want to use the
same DVR name registered on the DVRNS server after initializing the system using the factory reset, you
need to contact the DVRNS server manager.
FRONT PANEL CONTROLS
HDD LED: The LED flickers when the DVR is recording or searching video on the hard disk drive.
ALARM LED: The LED is lit when alarm output or internal buzzer is activated.
Camera Buttons (1-4): Pressing the button displays the selected camera in full screen. In PTZ mode,
pressing the 1 or 2 button zooms in or out, and the 3 or 4 button focuses near or far.
Playback/Arrow Buttons: Pressing the button controls playback of recorded video in playback or
searching mode. Pressing the button moves to another item or changes a selected number value in
Main Setup menu. Pressing the button pans or tilts a PTZ camera in PTZ mode.
Pause/Stop Button ( ): Pressing the button pauses or stops playing video in playback or searching
mode. Pressing the button selects an item or completes the entry you have made in Main Setup menu.
Pressing the button freezes or releases the current screen in live-viewing mode.
USB Port: Connecting the USB flash drive allows you to upgrade the software and to import or export
DVR settings.
REC Button: Pressing the button toggles manual recording On and Off. The DVR continues
recording independently of the recording schedule while manual recording in On.
MENU Button: Pressing the button launches or closes the Main Setup menu in live-viewing or
recording mode, Search Menu in playback or searching mode, or PTZ menu in PTZ mode.
PTZ Button: Pressing the button enters or exits PTZ mode.
DISPLAY Button: Pressing the button toggles screen mode between quad and sequence.

User’s Manual
4
Chapter 2 —Operation
TURNING ON THE POWER
Connecting the power cord to the DVR turns on the unit. The unit will take approximately 60 seconds to
initialize.
The DVR provides five operation modes: live viewing, recording, playback, searching and PTZ mode.
When the DVR operates first, it displays quad screen and starts recording. Refer to Appendix –Factory
Default Settings for details of system setting values.
The description of OSD icons is as follows:
Recording mode
Camera title
PTZ mode
Freeze mode
Event detection (alarm input or motion)
Video loss
Sequence mode
Playback mode
How to change the password…
The default password is 4321 (camera buttons) and you can change the password.You will be asked the
password when entering Main Setup menu, clearing data, changing the system date/time and password.
Refer to Chapter 3 –ConfigurationàMain Menu àAdvanced Setup àSystem àSet
Password for changing password.
How to change the system date/time…
You can change the system date/time. Refer to Chapter 3 –Configuration àMain Menu à
Advanced Setup àSystem àDate/Time for changing the system date/time.

Four-Channel Digital Video Recorder
5
LIVE VIEWING
To Change Screen Mode
ŸFull-screen
Pressing a camera button in quad
screen mode displays that camera in
full screen.
ŸQuad screen
Pressing the DISPLAY button in full
screen mode displays four cameras at
once.
ŸSequence screen
Pressing the DISPLAY button in quad
screen mode displays four cameras in
sequence. Pressing the DISPLAY
button again in sequence screen mode
returns to the quad screen mode.
ŸFreeze screen
Pressing the (Pause/Stop) button
freezes the current screen. Pressing
the button again releases the freeze
screen mode.
RECORDING
When you turn the DVR on, it starts recording according to the default recording schedule. Recording
can also be made manually regardless of the recording schedule by pressing the REC button on the front
panel.

User’s Manual
6
To Enter Recording Mode
ŸSchedule recording (Main Menu àSchedule)
On: Enables schedule recording.
Setup: Sets up the recording mode for each hour.
C(Continuous Record: Records continuously.)
E(Event Record: Records when detecting events.)
- (Off: Does not record.)
ŸManual recording
Pressing the REC button toggles
manual recording On and Off. The
DVR continues recording
independently of the recording
schedule while manual recording in
On.
NOTES:
ŸSchedule recording and Manual recording works independently each other.
ŸRefer to Chapter 3 –Configuration àMain Setup àSchedule for further information on setting
schedule recording.
PLAYBACK
Once video has been recorded, you can view it. When playing video for the first time, the DVR will
display the most recent image. When playing video subsequent times, the DVR will start playing video
from the last recalled image.
To Enter Playback Mode
Pressing the playback buttons ( ,
, or ) in live-viewing mode
enter playback mode and play
recorded video.
Playback buttons on the front panel perform the following functions as described below:
Step Forward
Forward Play (toggles the playback speed from , , and )
Step Backward
Backward Play (toggles the playback speed from ,,and )
Pause or Stop

Four-Channel Digital Video Recorder
7
SEARCHING
The DVR provides various search engines: Date/Time, Calendar and Event, and also supports clip
copying a video segment.
To Enter Searching Mode
Pressing the MENU button in playback
mode enters Search mode and displays
the Search Menu. Select the desired
search mode in the search menu.
Selecting Go To First/Go To Last
goes to the first/last recorded image.
ŸDate/Time search
Changing the desired date and time to search for and clicking the
OK button displays the recorded image of that date and time.
Pressing the playback button plays the recorded video.
ŸCalendar search
Days with recorded video on the calendar and hours in which video
was recorded on the timetable will be highlighted. Selecting the
desired date or time and clicking the GO button display the recorded
image of that date or time. Pressing the playback button plays the
recorded video.
ŸEvent search
Selecting the event log to search for displays the recorded image of
that event. Pressing the playback button plays the recorded video.
Refer to Chapter 3 –Configuration àMain Setup àAdvanced
Setup for further information on setting event recording.
ŸClip Copy
Define the period of video to copy by selecting FROM and TO and
adjusting the date and time. Selecting FIRST copies video from the
first recorded image, and LAST copies video to the last recorded
image. Select a camera to copy video, and designate a file name for
the video. Entering a file name and selecting the START button
starts copying. The video will be automatically saved in an .exe file
in a USB flash drive. The copied images can be viewed on
computers. Refer to the Appendix –Minibank Self Player for
instructions on how to review the images you have copied

User’s Manual
8
PTZ CONTROL
PTZ control is available for only PTZ cameras that allow pan, tilt, zoom, focus or preset etc.
To Enter PTZ Mode
Connect a PTZ device to the
DVR and select the PTZ model at
Main Menu àAdvanced
Setup àPTZ Setup. When the
PTZ model is selected, the PTZ
icon appears on the screen.
Pressing the PTZ button enters PTZ
mode.
To Control PTZ Cameras
ŸPan and tilt
Selecting the PTZ camera to control
and pressing the arrow buttons in
PTZ mode pans or tilts the selected
camera.
ŸZoom
Selecting the PTZ camera to control
and pressing the camera button 1 in
PTZ mode zooms in and pressing the
camera button 2 zooms out.
ŸFocus
Selecting the PTZ camera to control
and pressing the camera button 3 in
PTZ mode focuses near and pressing
the camera button 4 focuses far.

Four-Channel Digital Video Recorder
9
To Run Preset
Pressing the MENU button in PTZ
mode displays the PTZ menu.
Move to SET PRESET in the PTZ menu and select it by pressing
the button. Pressing the button displays the preset name box.
Pressing the button again displays a virtual keyboard. Enter the
preset name by pressing the arrow buttons and button, and then
press the OK button.
Move to PRESET RUN in the PTZ menu and select it by pressing
the button. Pressing the button displays the preset name box.
Selecting the desired preset name by
pressing the button moves to the
selected preset number view.
NOTE: Depending on the camera specifications, some features on the PTZ menu may not be
supported. Refer to the camera manufacturer’s instructions for the proper settings.

User’s Manual
10
Chapter 3 —Configuration
OVERVIEW
How to Enter Main Setup Menu
Pressing the MENU button in
live-viewing mode enters a Main
Setup menu. Entering a Main Setup
menu is password protected.
Enter the password by pressing the
camera buttons 1 to 4, and a Main
Setup screen appears. The default
password is 4321.
How to Select Items
Move to the desired item by pressing the
arrow buttons (, , and ).
Pressing the (Pause/Stop) button
selects the item.
How to Change Values
Select the desired item and press the
arrow buttons ( and ) to increase or
decrease the value. Pressing the
button completes the entry.

Four-Channel Digital Video Recorder
11
How to Enter Characters
Select the desired item and press
the button, and a virtual
keyboard displays.
Move to the desired character by
pressing the arrow buttons, and
enter the selected character by
pressing the button. Pressing
the OK button saves the characters
you entered. Selecting SB makes a
space, SHIFT toggles between the
upper and lower case keyboards,
BS backspaces, and DEL deletes
entered characters.
MAIN SETUP
NOTE: Refer to the Appendix –Factory Default Settingsfor the furtherinformation about system default
settings.
Schedule
ŸOn/Off: Enables or disables schedule recording.
ŸSetup: Sets schedule mode. Select the desired time to set up
schedule and change the schedule mode value. The schedule
modes are as follow:
C(Continuous Record): Records continuously.
E(Event Record): Records when detecting motion or alarm
events if each event is set to ON.
-(Off): Does not record.

User’s Manual
12
NOTES:
ŸSchedule recording and Manual recording work independently each other.
ŸRefer to the following Advanced Setup section for the further information on setting event recording.
Record Quality/Speed
ŸRecord Quality: Sets the same record quality for all camera channels.
ŸRecord Speed: Sets the same record speed for all camera channels. The higher ips (images per
second) is,the faster recording speed is. You can set the record speed for each camera channel
separately at the following Advanced Setup. If the record speed is different from each channel,
Record Speed displays –––.
Advanced Setup
ŸSystem
Date/Time: Sets the system date and time.
OSD: Enables or disables OSD (On Screen Display).
Set Password: Changes password.
ŸStorage
Overwrite: When it is set to Yes,it overwrites over the oldest
recorded image when the disk is full.
Clear Data: Erases all data including recorded video.
ŸRecord: Sets recording ips for each camera channel.
ŸMotion
Detect: When it is set to ON and detects motions, the DVR alertsyou to the event by activating an
internal buzzer or external alarm. It also records the motion detection image while in the
recording mode.
Sens: Adjusts sensitivity to motion. The higher the number is, more images it detects as events.
Zone: Sets the motion detection zone by using the arrow buttons and (Pause/Stop) button.
ŸAlarm
In: Sets alarm-in device type (Off: inactivate, NO: Normally Open, NC: Normally Closed).
Out: When it is set to ON, alerts by activating alarm during 10 seconds when any event occurs.
ŸBuzzer: When it is set to ON, alerts by activating an internal buzzer when any event occurs.
NOTES:
ŸIf you set a date and time that is older than some of your recorded images, any images with dates and
times later than the new setting will be deleted. The clock will not start running until you have restarted
the unit, so you may wish to set the time last.
ŸThe total RECORD IPS of all channels cannot be over 30 ips (25 for PAL).
TIP: If you want to be alerted by activating an alarm and make the DVR to record the image when
someone opens a front door, set as follows:
1. Main Setup àSchedule
ŸSet the Schedule to ON.
Ÿ[Setup] Set the schedule mode to C(Continuous Record) or E(Event Record) for the desired time.
2. Main Setup àAdvanced Setup àAlarm or Motion
Ÿ[Alarm –In] Set to NC or NO.
Ÿ[Motion –Detect] Set to ON.
[Motion –Zone] Set the detection zone around the front door activated by selecting the blocks.
3. Main Setup àAdvanced Setup àBuzzer or Alarm
Ÿ[Buzzer –Beep] or [Alarm –Out] Set to ON.

Four-Channel Digital Video Recorder
13
Network Setup
ŸType
Manual: When using a static IP address for network connection,
select Manual, and enter the network parameters
manually.
DHCP: When the DVR is networked through DHCP, select
DHCP. The DVR reads the IP address from DHCP
(Dynamic Host Configuration Protocol) network.
ADSL: When the DVR is networked through ADSL, select
ADSL. Enter the ID and password for network
connection, and the DVR receives the IP address.
ŸDVRNS: When set to ON, DVRNS (DVR Name Service) function is available and allows you to
connect to the DVR with the dynamic IP address or the domain name at the remote site.
Server/Port: Enters the IP address (or domain name) and port number of the DVRNS server obtained
from your network administrator.
NAT: Uses the NAT (Network Address Translation) Device.Refer to the NAT manufacturer’
instructions for the proper network settings using NAT.
DVR Name: Enters the DVR name to register on the DVRNS server, and check if the name is
available by selecting DVRNS NAME CHECK.
NOTES:
ŸAsk your network provider for your network connection type.
ŸIf the DVR is configured for DHCP or ADSL network, the IP address of the DVR might change
whenever the unit is turned on.
ŸYou can use the domain name instead of IP address of the DVRNS server if you already set up the
DNS server during the Network setup.
ŸThe DVRNS server settings on your DVR should match the settings on the registered DVRNS server.
Any changes on the DVRNS server might cause improper operation.
ŸWhen entering no name or a name already registered on the DVRNS server during the DVRNS setup,
an error message displays.
ŸIf you want to use the same DVR name registered on the DVRNS server after initializing the system
using the factory reset, you need to contact the DVRNS server manager.
ŸThe DVR name you entered should be checked by selecting DVRNS NAME CHECK during the
DVRNS setup, otherwise the DVRNS changes will not be saved.
ŸThe DVRNS registration will be limited to one DVRNS server. The DVR cannot be registered to
multiple DVRNS servers. Please contact your network administrator when you want to register the
DVR to another DVRNS server.
PTZ Setup
ŸID: Sets PTZ camera ID.
ŸProtocol: Selects a PTZ device.
ŸBaud rate/Data bit/Stop bit/Parity: Sets port speed, data bit,
stop bit and parity of the connected device. Refer to the PTZ
device manufacturer’s instructions for the proper settings.

User’s Manual
14
System Information
ŸSystem
Version: Displays the system version.
Language: Displays the system language.
ŸUpgrade: Connecting the USB flash drive containing the
upgrade package file (.rui) to the USB port on the front panel and
selecting the desired file upgrades the software.
ŸStorage
Recorded: Displays the time information of recorded data.
Status: Displays the storage status.
S.M.A.R.T.: Displays the storage condition if the installed hard
disk drive supports S.M.A.R.T. (Self-Monitoring, Analysis and
Reporting Technology) monitoring program.
ŸImport Setup: Connecting the USB flash drive containing the setup file to the USB port on the front
panel and selecting the desired file loads the DVR settings.
ŸExport Setup: Connecting the USB flash drive to the USB port on the front panel and naming the
settings saves the current DVR settings in .cfg file format.
ŸSystem Log: Displays the system logs. Refer to Appendix –System Log for the details of system log
information.
NOTES:
ŸYou cannot upgrade the software while HDD is not installed.
ŸIf the file system on the USB flash drive is not FAT16 or FAT32 format, format device using FAT16 or
FAT32 format.
ŸIf the DVR senses S.M.A.R.T. Alert, the S.M.A.R.T. Alert popup message will appear. Once the
S.M.A.R.T. Alert popup message displays, replacing the hard disk drive is recommended, usually
within 24 hours.
ŸEven after changing the DVR settings by loading saved settings, the DATE/TIME setting will NOT be
changed.
ŸIf you want to change the network settings when loading the saved settings, check INCLUDE
NETWORK SETUP. Otherwise, the network settings will NOT be changed.
Shutdown
Selecting SHUTDOWNin the Main Setup screen shuts the system down. You need to confirm that
you want to shut the system down.
