PAJ ALLROUND Finder User manual

ALLROUND
FINDER
4G

LANGUAGES
2

Table of contents
HABEN SIE FRAGEN?
23
NOTE!
We update our user manuals on a regular basis, in order to keep them up to
date. The latest version can be viewed at any time at
www.paj-gps.de/finder.
Thank you for purchasing our FINDER!
Before starting: Read the instructions carefully,
before using the FINDER for the rst time. Please keep this user manual
in a safe place in case you may need it in the future.
ALLROUND Finder 4G von PAJ V.2.0 EN
© PAJ UG (haftungsbeschränkt)
2.1 Scope of delivery .....................................................................................24
2.2 Product description..................................................................................25
2.3 Instructions for charging ........................................................................25
2.4 Activation ..................................................................................................26
2.5 Switch on/off ...........................................................................................26
2.6 Use .............................................................................................................27
2.7 Meaning of the LED lights .......................................................................30
2.8 Operating the SOS button .......................................................................31
2.9 Technical details ......................................................................................32
2.10 Safety instructions ................................................................................33
2.11 Disposal of used batteries ....................................................................38
2.12 Disposal of electrical devices................................................................39

24
2.1 Scope of delivery
*the M2M SIM card is already inside your
FINDER and is not replaceable
Your delivery will include:
• ALLROUND Finder 4G
• charging cable
• USB wall plug
• protective case
• M2M SIM card*

25
2.2 Product description
2.3 Instructions for charging
NOTE!
The ALLROUND Finder 4G has a battery duration of approximately 20 days,
needless of charging it in between! However, beware that this duration will
depend on how much you use your device. The more the ALLROUND Finder 4G
is in motion and thus sending data to the portal, the greater the battery usage.
Before using the FINDER for the rst time you must charge it. Connect the magnetic
part of the charging cable to the FINDER's magnetic contact. Connect the USB
connector to the wall-plug adapter and plug it into a power socket. If the FINDER is
connected to the power source, it will switch on automatically. Please charge the
FINDER until the red LED goes off.
SOS button
On/off switch

2.4 Activation
2.5 Switch on/off
26
right = on
left = off
In order to use your ALLROUND Finder 4G, you will need to previously
activate it online. Enter the following link and follow the instructions:
www.start.nder-portal.com
When activation is successful, turn on
the GPS tracker by sliding the switch
located under the protective rubber to
the right. The LED lights then activate.
To switch off, move the
switch to the left.

27
2.6 Use
As soon as your device has been successfully activated, started up and has sent and
logged data for the rst time, you can place it wherever you choose and use your phone,
tablet or PC to start tracking it! You will be able to do this in our App or enter the following
link to the desktop version:
www.v2.nder-portal.com

7.
8.
9.
10.
11.
1. 2.
3.
4.
5.
6.
28

2. Notifications
1. Menu
3. Devices menu
4. Device position
5. 2D / 3D setting
6. Own location
7. Map adjustment
8. Alarms / Stops on the route
9. Route points
10. Heat map
11. Routes
29

30
2.7 Meaning of the LED lights
Orange LED - GSM status
Blue LED - GPS status
Red LED - battery status
Signal Meaning
The red LED is off
(when charging cable is plugged in) The GPS Tracker is fully charged
The red LED is fixed
(when charging cable is plugged in) The GPS Tracker is charging
Signal Meaning
The blue LED is blinking There is no available GPS signal
The blue LED is off The GPS Tracker is in standby mode or
switched off
The blue LED is fixed A GPS signal is available
Signal Meaning
The orange LED is blinking There is no available GSM signal
The orange LED is off The GPS Tracker is in standby mode or
switched off
The orange LED is fixed A GSM signal is available

31
5 sec.
Press and hold the SOS button for 5 se-
conds and the FINDER will send an alarm.
You can see whether an alarm has been
sent by the orange and blue LEDs ashing
alternately for 12 seconds.
2.8 Operating the SOS button
The LEDs ash alternately for
12 seconds
The SOS button has been pressed
for 5 seconds and an SOS signal has
been sent.

32
2.9 Technical Details
Dimensions 105,5mm x 63mm x 22,7mm
GPS accuracy under 10 meters
Standby time approximately 60 days
Battery 3,7 V 5.000 mAH Li-ion
Weight 170g
Start time Cold start: 30 s
Standby: 30 s / running: 1 s
Network GSM/GPRS/EDGE/FDD-LTE/TDD-LTE
Bandwidth
LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/
B18/B19/B20/B25/B26/B28/B66/
LTE-TDD :B34/B38/B39/B40/B41
GSM/GPRS/EDGE: 850/900/1800/1900 MHz
GPS-Chip AT6558R
GSM-/GPRS-Module SIMCOM A7670G
GPS reception -162 dBm
Charger 110-220V, AC 50 Hz input
5V/1A, DC output
Storage temperature from -30°C to +80°C
Operating environment from -20°C to +75°C
Humidity 10%-85%
Water protection IP64

33
Dimensions 105,5mm x 63mm x 22,7mm
GPS accuracy under 10 meters
Standby time approximately 60 days
Battery 3,7 V 5.000 mAH Li-ion
Weight 170g
Start time Cold start: 30 s
Standby: 30 s / running: 1 s
Network GSM/GPRS/EDGE/FDD-LTE/TDD-LTE
Bandwidth
LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/
B18/B19/B20/B25/B26/B28/B66/
LTE-TDD :B34/B38/B39/B40/B41
GSM/GPRS/EDGE: 850/900/1800/1900 MHz
GPS-Chip AT6558R
GSM-/GPRS-Module SIMCOM A7670G
GPS reception -162 dBm
Charger 110-220V, AC 50 Hz input
5V/1A, DC output
Storage temperature from -30°C to +80°C
Operating environment from -20°C to +75°C
Humidity 10%-85%
Water protection IP64
2.10 Safety Instructions
Signal words
The following signal words are used in these operating instructions:
NOTE!
This is a warning about possible damage to property.
WARNING!
This classies a hazard of medium risk level. Failure to comply with the warning
may result in serious injury.
Proper use
Please read the safety instructions for this PAJ FINDER, hereinafter only
referred to as GPS tracker, carefully before use in order to be able to deploy it
properly. The intended use is to employ the GPS tracker only as described in
this manual to locate an object or a living being. Please bear in mind that it is
a criminal offence to monitor third parties using a GPS tracker without their
consent. If you use it in any other way, this is considered improper use and
can lead to damage to property or even personal injury. Please note that the
GPS tracker is not a toy for
children.
In other countries and regions there are different laws on digital positioning
an d l o c aliza t i o n o f p e o pl e , a n i m als a nd /or o b je c ts. PA J U G i s n o t r esp o n s i ble i f
such laws or regulations are violated, this is the sole responsibility of the user.
NOTE!
The manufacturer and dealer accept no liability for damage caused by
improper or incorrect use.

34
A faulty electrical installation or a mains voltage that is too high can lead to
an electric shock.
• Before use, make sure that the mains voltage of the socket corresponds
with the information on the type plate.
• To be able to disconnect the charging cable from the mains as quickly as
possible in the event of a failure, connect the power supply unit where it
is easily accessible.
• If you notice any visible damage to your GPS tracker or charging cable, do
not use it.
• Use only the original parts supplied to charge the GPS tracker. If the char-
ging cable is damaged, replace it only with original accessories from the
manufacturer.
• Never place the GPS tracker near an open re or hot surfaces.
• The GPS tracker is not protected against humidity and water. Please use
and store it only in a dry environment.
• The charging cable should only be used indoors. Keep it away from humidity
and do not kink it.
• Do not open the housing of the GPS tracker. Leave the repair to qualied
specialists. However, if you carry out repairs yourself, connect the GPS tracker
incorrectly or operate it incorrectly, liability and warranty claims are excluded.
Hazards for children and vulnerable people
Safety
WARNING! RISK OF ELECTRIC SHOCK!
WARNING! DANGER OF SUFFOCATION!
Please do not let people (including children) with limited physical, sensory or
mental abilities use the GPS tracker. It is considered an exception if they have
previously received instructions from a person responsible for their safety on
how to use the device. Please be sure that they not play with small parts (e.g.
accessories, etc.). These may be swallowed, leading to suffocation.

35
Batteries that leak due to damage can cause burns if they come into contact
with the skin. Therefore, never open the battery. However, if the battery leaks,
please wear protective gloves.
Below you will nd information and instructions on how to use the battery:
• The GPS tracker runs by a lithium ions battery. It is not exchangeable and
must not be removed or opened.
• Make sure that the GPS tracker (also when charging the battery) is kept
away from heat sources and high temperatures, such as direct sunlight in a
vehicle. Disregard of this instruction may result in destruction of the battery
and overheating, explosion and re.
• Only use the original accessories for the charging process. If the battery is
charged otherwise, this may result in overheating, explosion or re.
• Do not burn or pierce the GPS tracker. Protect it from mechanical damage.
• If a child swallows the battery, seek medical aid immediately!
Removing or replacing the battery
• Contact our support if the battery needs to be removed or replaced.
• Send the machine to us to remove or replace the battery.
• For safety reasons, do not attempt to remove the battery. Failure to re-
move the battery properly may result in damage to the battery and unit,
personal injury and/or compromise the safety of the unit.
• PAJ GPS shall not be liable for any damage or loss (whether in contract or
tort, including negligence) arising from your failure to comply with these
warnings and instructions.
WARNING! EXPLOSION AND FIRE HAZARD!
The battery
WARNING! RISK OF CHEMICAL BURNS!
NOTE!
Inform your child about the dangers and use of the GPS tracker.

36
Below you will nd information and instructions on how to clean the GPS tracker:
• Do not use aggressive cleaning agents or brushes for cleaning. Do not
clean the GPS tracker with metallic cleaning objects (e.g. knife, metal
sponge). This may damage the surface.
• Never put the GPS tracker in water, in a dishwasher (or the like) and do not
use a steam cleaner.
Correct cleaning:
• The surface may be wiped clean with a slightly damped cloth.
• The GPS tracker should then be wiped dry completely.
WARNING! RISK OF DAMAGE!
Cleaning
Electromagnetic compatibility
Please observe all rules and prohibitions and switch off the GPS tracker immediately
in danger areas and if it might cause interference. Furthermore, it should not be
used in the vicinity of, for example, medical equipment, fuels and chemicals, or in
blasting areas. With mobile devices, malfunction due to interference may occur
and affect performance. Transformers and very strong magnetic elds must be
avoided. Otherwise there may be deviations in the transmission.
NOTE!
Failure to observe these recommendations may result in malfunctions or
damage to the GPS tracker.
Storage
If you are not using the GPS tracker for a lengthy period of time, turn it off. Place
the tracker in its original packaging or in a carton of the same size. Protect the
tracker from dirt and humidity.

37
Declaration of conformity
Hereby, PAJ UG (haftungsbeschränkt) declares that the tracker, ALLROUND
Finder 4G, is in conformity with the Directive 2014/53/EU. The complete text
of the EU Declaration of Conformity can be found at the following Internet
address: paj-gps.de/konformitaetserklaerung/
Packaging disposal
Dispose of the packaging according to type. Throw cardboard and paper
to the corresponding container. Foil belongs in the recyclables collection.
NOTE!
Keep the FINDER away of children’s reach in order to avoid possible damage
to property or personal injury.

38
The following note is addressed to those who use batteries or products with
products with built-in batteries and who will not resell them in the form in which
they were supplied to them (end users).
Free recall of used batteries.
Batteries must not be disposed of with waste. You are legally obliged to return
used batteries so that proper disposal can be guaranteed. You can return used
batteries to a local collection point or to your local retailer. As a distributor of
batteries, we are also to take back used batteries, although our obligation to take
back used is limited to the type which we carry or have carried as batteries in our
range. Used batteries of the aforementioned type can therefore either be returned
to us with sucient postage or handed in directly to our dispatch warehouse at
the following address free of charge:
PAJ UG (haftungsbeschränkt)
Hohe Straße 61
51570 Windeck
Germany
E-Mail: [email protected]
Meaning of the battery symbols
Batteries are marked with the symbol of a crossed-out dustbin (see illustration).
This symbol indicates that batteries must not be disposed of in household waste.
Batteries containing more than 0.0005% mercury by mass, more than 0.002%
cadmium by mass or more than 0.004% lead by mass are also marked with the
chemical name of the pollutant below the dustbin symbol. The abbreviation „Cd“
stands for cadmium, „Pb“ for lead and „Hg“ for mercury.
2.11 Disposal of used batteries

2.12 Disposal of electrical devices
The Electrical and Electronic Equipment Act (ElektroG) contains a large number of requi-
rements for the handling of electrical and electronic equipment. The most important ones
are summarised here.
1. Separate collection of WEEE:
Waste Electrical and Electronic Equipment that has become waste is referred to as WEEE.
Owners of WEEE must dispose of it separately from unsorted local waste. In particular,
WEEE does not belong in household waste, but in special collection and return systems.
2. Batteries and accumulators:
As a rule, owners of WEEE must separate spent batteries and accumulators that are not
enclosed in the WEEE before handing them over at a collection point. This does not apply
if the WEEE is handed over to public waste management authorities and separated from
other WEEE there for the purpose of preparation for reuse.
3. Options for returning old appliances (WEEE):
Owners of WEEE from private households can hand it in to public waste management
authorities or at the collection points set up by manufacturers or distributors as dened
by the ElektroG. An online directory of collection and collection points can be found here:
https://www.ear-system.de/ear-verzeichnis/sammel-und-ruecknahmestellen.jsf
4. Data Protection:
Old equipment often contains sensitive personal data. This applies in particular to infor-
mation and telecommunication technology devices such as computers and smartphones.
For your own sake, please note that each end-user is responsible for deleting the data on
the old equipment to be disposed of.
5. Meaning of the „crossed-out dustbin“ symbol:
The symbol of a crossed-out dustbin regularly displayed on electrical and elec-
tronic equipment indicates that the respective device must be separated from
unsorted local waste at the end of its service life.
6. Manufacturer registration number
As a manufacturer, within the meaning of the ElektroG, we are registered with the respon-
sible foundation Elektro-Altgeräte Register (Benno-Strauß-Str. 1, 90763 Fürth) under the
following registration number: DE33887550.
39

In this case, please contact us
and we will be delighted to help you!
PAJ UG (haftungsbeschränkt)
Hohe Straße 61
51570 Windeck
Germany
Mail: [email protected]
Telefon: [phone]
Web: www.paj-gps.de
The PAJ GPS Team
wishes you to enjoy your ALLROUND Finder 4G!
DO YOU HAVE ANY QUESTIONS?
40
ALLROUND Finder 4G von PAJ V.2.0 FR
© PAJ UG (haftungsbeschränkt)
