Palm Pixi Plus User manual

Quickstart
TXTNG &
DRIVNG…
IT CAN WAIT
Take the interactive
tutorial at
att.com/Tutorials
FOLD

Welcome to AT&T
Please use our interactive web tutorial
available at
att.com/tutorials
for the most complete and up-to-date
information available to set up your
device and services. Be sure to select
Manufacturer: Palm and Model: Pixi Plus
from the drop-down menus. The online
tutorials include detailed step-by-step
instructions and screenshots to assist
your learning.
Or use this simple Quickstart to quickly
get an overview of the major features and
services available with your phone.
Thanks again for choosing AT&T.
2

Insert the SIM card
You must insert an activated SIM card
before turning on the phone for the first
time. If you don’t have a SIM card,
contact AT&T.
WARNING Always remove the battery
before inserting or removing the SIM card.
NOTE: If you already turned on your
phone, you must turn it off before
inserting the SIM card. To turn the phone
off, press and hold the power button
(see p. 6) and tap Turn Off.
1 To separate the back cover from
the body of the phone: Use your
thumbnail to release the clasp at the
midpoint of the left side of the phone.
2 Run your thumbnail around the
hairline opening to release the
upper-left and top clasps (a). Repeat
to release the bottom-left and
bottom clasps (b).
3

a
b
3 Swing the body of the phone out of
the back cover as if the right side
were a hinge.
4 To remove the battery: Put your
finger in the recess to the right of the
battery; push the battery left and
then lift it up and out.
4

Notch
5 Insert the SIM card and replace the
battery.
6 To replace the back cover: Insert the
ringer switch into the hole provided
for it on the right side of the back
cover.
7 Press all clasps to fasten the cover to
the body of the phone.
5

Power button
Turn on your phone
Press and hold the power button for a
few seconds until you see the Palm logo.
Wait for setup to start (please be patient).
Can’t start setup?
If you inserted the SIM card without first
removing the battery, your phone cannot
connect to the AT&T network, and you
will not be able to complete setup. To fix
this, remove the battery, and then
remove the SIM card. Then insert the
SIM card and last, insert the battery.
6

Set up your phone
To use your phone, you must agree to
Palm’s terms and conditions, and create
and verify a Palm profile. Be sure to write
down the valid email address and the
password that you use to create your
profile; you will need them later.
If you forget your password, go to
palm.com/palmprofile to reset it. If
you forget your email address, go to
palm.com/support for assistance.
For tips on tapping the screen and
entering text, see the Navigation guide
(after p. 12) and the info on p. 15.
NOTE: Do you have a Palm profile from a
webOS™ phone that you no longer use?
During setup, just sign in to your existing
profile when prompted. All info associated
with your profile is downloaded to your
new phone. If you are still using your
other phone, however, you should create
a new profile for your new phone—you
can’t use the same profile on two
phones at the same time.
7

7
6
8
9
10
4
5
3
2
1
12
Top
11
Overview
8

1 Earpiece
2 Speaker (on back)
3Gesture area: See the Navigation
guide, after p. 12.
4 Microphone
5 Option: See p. 15.
6 Camera lens and flash (on back)
7 Ringer switch: Slide to turn the ringer
and notification sounds on and off
(red means off).
8 Volume: For call, ringer, and
music/video playback.
9 Charger/microUSB connector
10 Sym: See p. 15.
11 Power: Press to wake up and turn
off the screen. To turn the phone,
Wi-Fi, and Bluetooth® off/on, use
airplane mode (see p. 14). When you
remove the battery, shut down the
phone completely by pressing and
holding power.
12 3.5mm headset jack
9

To wirelessly sync Contacts and Calendar
info, set up online accounts with
providers like Google and Microsoft
Exchange.
If you don’t already have an account with
a provider, you must create one before
you set up the account on your phone.
For example:
• Google: Go to gmail.com.
• Exchange: Check with your company’s
IT department.
After you create an online account, set
up the account on your phone. See p. 16.
For the full list of available online sync
accounts, see the online accounts table
at the back of the User Guide (see p. 22).
A sync relationship you set up in one app
is automatically set up in other apps. For
example, by setting up a Gmail email
account, your phone is also set to sync
Google Contacts, Calendar, and IM.
Set up online Contacts
& Calendar to sync
10

Page
indicator
Launcher
Quick Launch
Phone Contacts Email Calendar
Launcher,
page 1
Open applications
Tap an icon to open an application.
Launcher: To open the Launcher, quickly
flick up twice from the gesture area to
the screen. (In Card view—described on
the next page—flick up once.) The
Launcher displays all your apps. Swipe
left and right onscreen to scroll through
Launcher pages, or up and down to see
everything on the page.
Quick Launch: To open Quick Launch
when you can’t see it onscreen, slowly
drag up from the gesture area to the
screen. Quick Launch displays up to five
icons. To customize it, drag out any icon
except Launcher and drag in another one.
11

Card view with three open cards
Move among open
applications
To use an open app, tap its card.
You can use multiple applications at the
same time. To move among them, flick
up from the gesture area to the screen
to shrink the app you’re using. You’re
now in Card view, where all open apps
appear as small windows (cards).
In Card view, swipe left or right on the
screen to scroll through open apps.
To close an app, throw the card off the
top of the screen in Card view.
12

Find it fast
In Launcher or Card view, simply begin
typing a word, name, or first and last
initials.
Your phone displays any matching
results. Tap the one you want.
Tap a phone number to dial it. Or tap
beside a phone number to send a text
message.
To search the web, tap the text you
entered and tap the search option
you want.
Tap to make
a call
13

Make a call, use
the phone
Make a call
Quick Launch > > enter the
number > . To end the call, tap .
If you need to wake up the screen,
press power and drag up.
Listen to voicemail
Quick Launch > > .
Dial a number from call history
Quick Launch > > > tap a
number.
Dial a number by contact name
Launcher or Card view > type the
first or last name or initials > tap
the number.
Turn airplane mode on/off
Drag down from the upper-right
corner of any screen > Turn on/off
Airplane Mode.
14

Enter and save info
To enter text: Tap the screen. When the
cursor appears, begin typing.
To enter uppercase letters: Press
Shift . To turn on Caps Lock, press
Shift twice.
To enter numbers and symbols that
appear at the top of the keys: Press
Option and the key for the character.
To turn on Option Lock, press Option twice.
To enter symbols like currency symbols
and accented characters: Press Sym
to open the symbols table, scroll to the
character you want, and tap to select.
To select text: You can select text in
messages, web pages, memos, and so on.
See the text selection gestures in the
Navigation guide attached to this guide.
Open the application menu to use Cut,
Copy, and Paste.
How do I save the info I entered?
Make the back gesture (see the Navigation
guide), and your information is saved
automatically. You don’t have to do
anything else. If you see a Done button,
tap it to save and move on. When you
close an app, new info is always saved
automatically.
15

Set up accounts on
your phone
The first time you open Contacts,
Calendar, and Messaging, you see a
setup screen that appears only once.
Tap Add An Account > tap an account >
enter your username and password >
Sign In.
Just want to jump to your contacts or
calendar, or send a message? Scroll
down and tap Done .
Email: See p. 18.
Later, set up accounts this way: Open the
menu by tapping the app name in the
upper-left corner of the screen >
Preferences & Accounts > Add An
Account.
Your Palm profile also has an account
associated with it. You can use it for
Contacts and Calendar info, and for
other kinds of info as well, like Memos.
This info is backed up daily on Palm’s
servers, but you can manage this info
only on your phone.
16

Messaging, Web,
Wi-Fi, and camera
Send a text or multimedia message
Launcher > . If you see
Done , tap it. Tap .
Enter a contact name or number,
or enter the number of a recipient
who is not a contact. Tap to add
an image. Enter message text > .
Browse the Web
Launcher > > enter the web page
address > press Enter .
Turn Wi-Fi on or off
Launcher > > On or Off.
When Wi-Fi is on, if your phone finds
the network you want, tap the network
name to connect to it.
Take a picture
Launcher > . If is hidden, tap
to display it. Tap . To take a picture
in landscape view, turn the phone 90°.
Record a video
Launcher >. If is hidden, tap
to display it. Tap . To stop recording,
tap .
17

Set up Email
Quick Launch > . The first time you
open Email, the address you used to
create your Palm profile is already in the
Email Address field. Enter the password >
Sign In > Done to complete setup of that
account.
Setting up email from some providers
automatically adds your contacts and
calendar data from that provider to
your phone. See p. 10 and p. 16.
Later, add other email accounts this way:
Open the application menu > Preferences
& Accounts > Add An Account.
Send an email
Quick Launch > . If you see
Done , tap it. Tap . Enter a
contact name or email address, or enter
the email address of a recipient who is
not a contact. Tap to add an
attachment. Enter email message
text > .
18
Set up and
send email

Merged views and
linked contacts
The Palm® Synergy™ feature displays
data from several sources in a single
view on your phone, but keeps the
sources of your data separate.
Let’s say you use Google calendar for
your personal appointments and your
company’s Outlook calendar for business
appointments. Your phone’s Calendar
application can display appointments
from both calendars in a single view.
Likewise, the Email application lets you
display the messages from all your
account inboxes in a single view. And
in Messaging, all your messages with
the same person show up in a single
conversation view.
The Contacts application also offers a
merged view—all your contacts from all
your accounts appear in a single list.
Contacts also lets you see all your
information for a person in a single view.
19

Transfer info to
your phone
To transfer contacts from your old
phone or SIM card: Go to
att.com/copycontacts.
To export info from a desktop organizer:
Go to palm.com/migrate-pixi.
Where can I export info from?
• Windows: Palm® Desktop v. 6.2.
Standalone Outlook® 2003 (XP only)
or 2007. You cannot export info from
Outlook if you sync Outlook with an
Exchange server.
• Mac: iCal and Address Book.
Where do I transfer the info to?
Pick the account—for example, your
Google, Exchange, or Palm profile
account—to receive the info you
exported. We recommend that you
transfer your info to an online account
(see p. 10 and p. 16). For other solutions,
see palm.com/sync-solutions.
20
