ION 3000
The Prisma SD-WAN Instant-On Network (ION) 3000, designed for the enterprise branch, transforms
legacy wide area networks (WANs), enables you to combine heterogeneous underlying transports into
a unified hybrid WAN. It establishes service-level agreements (SLAs) for security, path selection, and
application performance. It helps gain direct insight into end-user application performance for traditional,
SaaS, modern, encrypted applications.
ION 3000 participates in bi-directional communications with the Prisma SD-WAN controller, enabling
configuration of devices, applications, and WANs, providing analytics on devices and applications.
You can deploy the Prisma SD-WAN ION 300 in a standalone fashion without a data center device,
enabling granular control and visibility for direct-to-internet deployment scenarios, or in conjunction with
ION 7000 or ION 9000 in the data center, creating a secure, full-mesh fabric across the WAN.
You can deploy the ION 3000 as follows:
• Standalone Prisma SD-WAN ION 3000 (No HA)
• Prisma SD-WAN ION 3000 + Existing Router HA
• Prisma SD-WAN ION 3000 + Prisma SD-WAN ION 3000 HA

18 ION 3000 HARDWARE REFERENCE | ION 3000 Overview
© 2021 Palo Alto Networks, Inc.
ION 3000 Ports
The ports on the ION 3000 are used as follows:
Ports Description
AUX This port is an auxiliary access port intended for offline access,
configuration, and troubleshooting of a system during installation.
USB This port is reserved for future use.
Controller This port is used by the ION device to communicate with the Prisma
SD-WAN controller.
Internet This port is used to connect to internet service. By default, this port
is protected by a firewall.
Internet Bypass This port is only used in ION 3000 HA scenarios. It should not be
used in single ION device scenarios.
LAN This port is intended for private LAN network connectivity. By
default, this port is bridged to the corresponding WAN port.
WAN This port is intended for private router/MPLS connectivity. By
default, this port is bridged to the corresponding LAN port.
Fail-to-Wire Port Pair Up to 6 pairs - all ports. These ports can be configured as discrete
ports or as fail-to wire pairs.

ION 3000 HARDWARE REFERENCE | ION 3000 Overview 19
© 2021 Palo Alto Networks, Inc.
ION 3000 Front Panel with LEDs
The ION 3000 LEDs indicate the status of the disk, power, and the controller connectivity:
Icons Description
Displays disk status. Orange light (Blinking)—Disk Activity.
Displays controller connectivity status. Blue light—Connected.
Red light—Not Connected
Displays power status. Green light—Powered on.
No light—Powered off.

20 ION 3000 HARDWARE REFERENCE | ION 3000 Overview
© 2021 Palo Alto Networks, Inc.
ION 3000 Specifications
The Prisma SD-WAN ION 3000 specifications are shown below:
I/O
Controller 2 x 10/100/1000 RJ-45
WAN/LAN/Internet 6 pairs of 10/100/1000 RJ-45 with programmable inline
fail-to-wire capability.
Throughput
Throughput Up to 500 Mbps
Encrypted throughput is measured with 1400 byte HTTP
packets with all features turned on.
Power and Mechanical
Type or Watts 1 PSU 150W
Power Input AC 100~240 V @50~60 Hz
Fan cooling 1 smart fan
Certifications
Certifications CE (EMC), FCC Class A, RoHS, BIS, CCC, KCC
Environmental
Operating temperature 32°F to 104°F (0°C to 40°C)
Storage temperature -4°F to 158°F (-20°C to 70°C)
Operating humidity 5% to 90% (non-condensing)
Storage humidity 5% to 95% (non-condensing)
Physical
Weight 8.8 lbs (4 kg)
Dimensions 16.81" x 1.72" x 11.89" (431 mm x 44 mm x 305 mm)
Local network Access Typically a downstream Layer 2 (L2) or Layer 3 (L3)
Ethernet switch and/or a Wireless Access Point (WAP).
Internet connectivity This connectivity is used to reach the Cloud Registration
Service and the Network Controller. It can be in the
form of a private connection via an MPLS network
