Panamax MIW-POWERKIT-PRO User manual

1
4INS00810 REV A 03/07
MIW-POWERKIT-PRO SPECIFICATIONS
AC Circuit
AC Outlets, Total: ..................................................2
Line Voltage: .........................................120V, 60Hz
Total Current Capacity: .....................................15A
AC Power Cord
Length: ...........................................................8 feet
Connectors: ..........................................NEMA 5-15
Power Inlet Faceplate
AC Connector: ....................................NEMA ML-2P
Signal Line Protection: Not Included / Modules Sold
Separately
Power Outlet Faceplate
AC Connectors: ..................................2 NEMA 5-15
Noise Filtration: .............................................Level 1
Signal Line Protection: Not Included / Modules Sold
Separately
POWER ON
PANAMAX MIW-POWERKIT-PRO INSTALLATION INSTRUCTIONS
CONTENTS CONTACTING PANAMAX
Recommended installation conguration
Features of the MIW-POWERKIT-PRO:
Provides Noise-Free AC Power to remote plasma screens, LCD’s, projectors, etc. when used with
Panamax power management components.
Includes CSA-Certied components for code-compliant installations.
Accomodates optional signal line modules for a professional nish.
Additional EMI/RFI noise ltration built into outlet receptacles.
3 Year product warranty
•
•
•
•
•
Panamax
1690 Corporate Circle
Petaluma, CA 94954
Phone - 707-283-5900 or 800-472-5555
Fax - 707-283-5901
Web - www.panamax.com
Customer Relations
7:30 AM – 4:30 PM, M-F, Pacic Time
Email - [email protected]
POWER ON
One each
MAX In-Wall
power inlet
and outlet
enclosure
Two MAX In-
Wall
signal bay
enclosures
One twistlock
power cord
(16) Mounting Screws
(6) Wire Nuts
Management Component
(2) Mounting Brackets
Specications are subject to changes due to product upgrades and improvements.
Included Installation Accessories:
