Panamax MB850 User manual

www.panamax.com
MB850
FOR YOUR HOME THEATER SYSTEM
BATTERY BACKUP
Estimated Runtime in Minutes
DLP TV (260 Watts)
HD Gaming Console
Satellite Receiver / Cable Box
Media Player
DVR / TiVo
®
6
12
80
80
120
During power disruptions the MB850
Battery Backup provides constant
power to your equipment, such as:
LAMP BASED DISPLAY
Prevent expensive lamp burnout in
lamp based displays (cooling fan
can continue to properly cool down
lamp).
DVR
Avoid loss of DVR recorded TV
programming.
GAMING
Prevent loss of unsaved games -
during saving / loading.
HT SYSTEM
Avoid the time & hassle rebooting
home theater system.
12
6
3
9
11
10
8
7
1
2
4
5
2:00
Up to 2 Hours of
Running Time.

OUTPUT POWER
MB850 850VA / 510 WATTS with AVR
OUTPUT VOLTAGE ON UTILTY
VOLTAGE: 90V TO 140V
FREQUENCY: 57Hz TO 63Hz
AVR SMART BOOST: BOOST 10% OF INPUT VOLTAGE FOR OUTPUT
SURGE PROTECTION
DESIGN SPECIFICATION: ANSI/IEE C62.41 CAT A
SURGE ENERGY CAPACITY: 890 JOULES
MAXIMUM SURGE CURRENT: 36,000 AMPS
BATTERY
BATTERY TYPE: SEALED MAINTENANCE FREE LEAD ACID
NORMAL LIFE: 3 TO 6 YEARS
RECHARGE: 8 HOURS FROM TOTAL DISCHARGE
RUNTIME: UP TO 120 MINUTES
OUTPUT VOLTAGE ON BATTERY
VOLTAGE: 120V +/- 5%
FREQUENCY: 60Hz
SAFETY APPROVALS
UL: UL 1778 (UPS)
FCC: DoC CLASS B
cUL (CANADA) cUL 107.1
MB850 SPECIFICATIONS
Specifications subject to change due to product upgrades and improvements..
1690 Corporate Circle, Petaluma, CA. 94954 • 800-472-5555 • 707-283-5900 • Fax [phone] • www.panamax.com
L621 REV. A 12/08
© 2008 Panamax Inc. Panamax and the Panamax logo are registered US trademarks of Panamax.
MADE IN CHINA
3 Year
Product
Warranty
2 Year
Battery Warranty
3 Year $250,000
Connected
Equipment
Policy
BATTERY BACKUP FEATURES
MB850
POWER ON/OFF SWITCH
LCD DISPLAY PROVIDES:
• Input Voltage Level
• Output Voltage Level
• AVR Status Meter
• Battery Capacity
• Estimated Runtime
• Load Level
• Output Power Frequency
ICON INDICATORS INCLUDE:
• On Battery Mode
• Overload Condition
• Fault Condition
LCD DISPLAY TOGGLE
SWITCH:
Allows selection of LCD
contents to be displayed.
AVR
Automatic Voltage Regulation
stabilizes input voltage to an
appropriate level for optimal
equipment performance by
completely eliminating brown-
outs and overvoltages,
5 BATTERY POWERED AND
SURGE PROTECTED OUTLETS
Provides continuous battery
backup when power is
interrupted.
4 FULLTIME SURGE
PROTECTED OUTLETS
Provides complete surge
protection for equipment not
requiring battery backup.
USB/SERIAL PORT TO PC
Allows home theater PC to
communicate with UPS
through USB or serial port.
1 PAIR, IN / OUT COAX / CABLE
SAT SURGE PROTECTION
WIRING FAULT INDICATOR LIGHT
LED illuminates when wiring
problems exist.
ETHERNET PROTECTION PORTS
Phone / Modem / DSL / Ethernet
protection (Combination Ethernet or
phone line protection).
RESETTABLE CIRCUIT BREAKER
Provides overload protection.
REPLACEABLE BATTERY
AUTO-SHUTDOWN SOFTWARE
Panamax offers surge protection
plus battery backup. Will safely
shut down your home theater PC.
WEIGHTS & MEASUREMENTS, QUANTITIES, UPC’S
FOR ORDERING & SHIPPING
SINGLE MODEL MB850
Dimensions Weight
L 10.25” x H 8.875” x W 4.375” 16 lbs.
SINGLE UNIT CARTON
Dimensions Weight UPC
L 15 x H 11.375” x W 7.175” 17 lbs. 050616-008532
MASTER CARTON
Qty. Dimensions Weight UPC
3 L 22” x H 12.5” x W 15.5” 52 lbs. 50050616-008537
MODEL: MB850
