Operation Manual
Easy Wireless Stick
TQBH0266-2
ENGLISH
Mac

– 2 –
Contents
Introduction......................................................3
WhatyoucandowiththeEasyWirelessStick.....................................3
Computer Environment Required for Connection . . . . . . . . . . . . . . . . . . . . . . .4
SupportedProjectorModels ........................................4
Software Conguration.............................................5
Explanation of Select Access Port Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ExplanationofLauncherScreen.....................................6
Connecting Computer and Projector..................................7
■Checkingtheprojector.....................................................7
■Connectingusingthesearchlist..............................................9
■Connecting using the registered projector tree. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
■Connecting using automatic connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Projecting Computer Screen from Projector ..........................14
MultiLiveMode..................................................15
■Switching from one screen style to another . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
■16-screenindexstyle.....................................................16
■Settingthesendername ..................................................16
Registering and Editing Tree Information.............................17
■Creatinggroups ........................................................ 17
■Registeringprojectors.................................................... 18
■Changingthenamesofgroups .............................................19
■Changing the registered information of projectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
■Changing the registered groups of projectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
■Deleting registered projectors and groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Copying the Tree to Another Easy Wireless Stick ......................23
■Exporting ..............................................................23
■Importing...............................................................24
Troubleshooting .................................................25
Trademarks .............................................Backcover

– 3 –
Introduction
What you can do with the Easy Wireless Stick
If you connect the Easy Wireless Stick to a computer, you can easily connect a projector and the computer and
project the screen of the computer from the projector.
Notes
• The screen images shown in this manual are examples of Mac OS X v10.7. The illustrations and screen images
may differ from the actual items and screens.
Furthermore,thespecicationsofthesoftwareofthisproductaresubjecttochangewithoutnotice.
• Do not connect this product to a computer on which WirelessManager is running. The functions may not work
properly.Furthermore,donotstartWirelessManagerwhilethisproductisbeingused.
* “WirelessManager”isanabbreviationforthePanasonic’sseparatesoftware‘WirelessManagermobileedition’for
transferring images.

– 4 –
Computer Environment Required for Connection
Check your computer.
The computer needs to meet the following requirements in order to use the software of this product.
OS :
Mac OS X v10.6
Mac OS X v10.7
Mac OS X v10.8
Mac OS X v10.9
Interface : USB 2.0
CPU : A CPU with at least the minimum specications to run the above OS.
Memory : Memory with at least the minimum specications to run the above OS.
Color quality : 32 bit
Screen resolution : Up to 2048 x 1536 dots
Notes
• InMacOSX10.9,theprojectedimagemaystoporcommunicationwiththeprojectormaybesevereddueto
the“AppNap”function.Insuchcases,disabletheAppNapfunction.Fordetailsonhowtodisableit,see“The
projectedimagestopsorcommunicationwiththeprojectorisseveredinMacOSX10.9”intheTroubleshooting
section.
• OperationviaaUSBhubisnotguaranteed.
• Note that operation is not guaranteed when the software is used with a system environment other than the
above,onanOSthatwasnotpre-installedorclean-installed.
Operationisnotguaranteedforallcomputersthatmeettheaboveconditions.
Supported Projector Models
Check your projector.
DZ570 Series : PT-DZ570, PT-DW530, PT- DX500 (with ET-WM200 installed)
FW430 Series : PT-FW430, PT-FX400 (with ET-WM200 installed)
FW300NT Series : PT-FW300NT, PT-F300NT
F200NT Series : PT-F200NT
FW100NT Series : PT-FW100NT, PT-F100NT
VW345N Series : PT-VW345N, PT-VX415N
VX400NT Series : PT-VX400NT
VW435N Series : PT-VW435N, PT-VX505N
VZ575N Series : PT-VZ575N, PT-VW535N, PT-VX605N
LB90NT Series : PT-LB90NT
LW80NT Series : PT-LW80NT, PT-LB80NT, PT-LB75NT
LB60NT Series : PT-LB60NT, PT-LB55NT, PT-LB50NT
LB51NT Series : PT-LB51NT
Current as of August 2014

– 5 –
Software Conguration
Thissoftwareconsistsofthefollowingexecutableles.
• EWS : Software for projecting the screen of a computer from a projector. (See page 9) and ex-
porting and importing when transferring projector registration information (tree) to another
Easy Wireless Stick (See page 23)
Explanation of Select Access Port Screen
YoucanconnectacomputerandaprojectorviatwotypesofSelectAccessPortscreen:searchlistandregistered
projectortree.Fortheconnectionprocedures,see“ConnectingComputerandProjector”(page7).
Search list screen Registered projector tree screen
①
⑨
⑪
③
④⑫
⑥⑭
⑦
⑯
⑧
⑮
②
⑬
①Ends the software. ②Displays the search list screen.
③Displays the currently selected wireless LAN connection setting.
④
Allows you to select from [S] and [1] to [4] as the appropriate wireless LAN connection setting for the projector.
Select[S]ifthewirelessLANconnectionoftheprojectorissetto[SIMPLE],[S-DIRECT],or[S-MAP],andse-
lectthecorrespondingnumberifitissetto[1]to[4].
⑤Displays the currently selected projector.
⑥Displays the names of the projectors. ⑦Displays the network IDs of the projectors.
⑧Connects to the selected projector.
⑨Displays the version information. ⑩Displaysthemenuoftheconguration.
⑪
Displays the registered projector tree screeen. ⑫Displays the registered groups.
⑬Displays the names of registered projectors.
⑭Displays the currently selected projector.
⑮This menu is displayed when you select and then [Control]+click a group or projector.
⑯Saves the current tree information.
* When multiple projectors are installed, you can assign the names of conference rooms or event sites to individual
projectors,andmanageprojectorsingroupssuchasbuildingsoroors.Thismanagementmethodiscalled“Tree”.
* Whentheprojector’swirelessLANconnectionsettingis“SIMPLE”,“SIMPLE”willappearastheprojectorname.
⑤
⑩

– 6 –
Explanation of Launcher Screen
WhenyouspecifyaprojectorandconnectintheSelectAccessPortscreen,thelauncherscreenappears.For
detailsonprojectingthescreenofyourcomputer,see“ProjectingComputerScreenfromProjector”(page14).
① ② ③
④⑤ ⑥ ⑦
①Add a check to connect automatically (page 13).
②Starts or pauses projection. ③Stops projection and clears the screen.
④Minimizes the launcher to the dock. ⑤Ends the software.
⑥DisplaystheSelectAccessPortscreen. ⑦Displays the version information of the software.
Notes
• The launcher is automatically minimized to the dock when projection starts.
• The[Live]buttonchangestothe[Pause]buttonduringprojection.
• When the launcher is minimized to the dock, clicking the software in the dock redisplays the launcher screen.
• Youcandragthetitlebarofthelaunchertomovethelaunchertoanypositioninthescreen.
• [Select]isnotavailableduringprojection.

– 7 –
Connecting Computer and Projector
Verify the network ID and other information for the projector, and then perform connection of the projector.
■ Checking the projector
1. Powering up the projector
Turn on the power of the projector.
2. Setting the input
Pressthe<PanasonicAPP>button/<NETWORK>buttonontheremotecontrol(orpressthe<INPUTSE-
LECT>buttonontheprojector),andswitchtheinputto[PanasonicAPPLICATION]or[NETWORK].
Astandbyscreenisdisplayedintheimageprojectedbytheprojector.
3. Checking the projector
Checktheprojector’swirelessLANconnectionsetting,projectorname,andnetworkID.
The locations where this information is displayed may vary depending on the projector.
zFor projectors that display the standby screen (Projector image)
Thestandbyscreenmaynotappearevenforprojectorsthatdisplaythatscreenif
anotheruserisalreadyprojectinganimageorifthemultilivemode(Page15)isbe-
ing used in the 4-screen or 16-screen index style. In such cases, you can check the
networkIDbypressingtheAUTOSETUPbutton.
·Example of standby screen display.
Wireless LAN
connecton setting
Projectorname
Network ID
zFor projectors that do not display the standby screen (Projector image)
· Example of input guidance display.
Wireless LAN
connecton setting
Network ID
Projectorname
INPUT NETWORK
SIGNAL NAME XGA-A1
MEMORY NO A1
WIRELESS LAN S-DIRECT
PROJECTOR NAME NAME1234
NETWORK ID Proj1234
Wireless LAN
connecton setting
Network ID
Projectorname

– 8 –
Network ID
Wireless LAN
connecton setting
Projectorname
Wireless LAN
connecton setting
Network IDProjectorname
Wireless LAN
connecton setting
Network ID
Projectorname
zIftheinputguidancedoesnotappear,pressthe<MENU>buttonoftheprojector,andonthemenuthatisnow
displayed,select[DISPLAYOPTION][INPUTGUIDE]“ON” or “DETAILED”.
4. Checking the network status
Thenetworksettinginformationcanbecheckedusingtheprojector’smenu.
zPressthe<MENU>buttonoftheprojectorand,onthemenuthatisnowdisplayed,select[NETWORK]
[NETWORKSTATUS]tocheckthedetailednetworksettinginformation.
zToeasilyconnecttothecomputerwithawirelessLAN,the[SIMPLE]or[S-DIRECT]settingisuseful.
Notes
• Depending on the projector used, the network setting method differs with wireless LAN networks.
[Wireless LAN settings] in the Operating Instructions for the projector
• Depending on the model of your projector, the method for displaying the input guide and the appearance of the
input guide may differ.
• Iftheinputguidedoesnotappear,set[INPUTGUIDE]to[ON]or[DETAILED]intheprojector’s[DISPLAYOP-
TION] menu.
■ Checking the projector (cont.)

– 9 –
■ Connecting using the search list
To search for a projector and then connect, use the following procedure.
1. Connect Easy Wireless Stick.
Connect the Easy Wireless Stick to a USB port of the computer.
2. Run [EWS].
Manuallyrunthe[EWS]leinthe[EasyWS]CDdrivedisplayedintheFinder.
3. Click [List] tab.
Note
• When the software starts, [S] is selected.

– 10 –
■ Connecting using the search list (cont.)
4. Search for the projector
ClickthebuttonthatcorrespondstothewirelessLANconnectionsettingdisplayedontheprojector.
* IfthewirelessLANconnectionsettingis[SIMPLE],[S-DIRECT],or[S-MAP],click[S].IfthewirelessLAN
connectionsettingis[1],[2],[3],or[4],clickthecorrespondingnumber.
Search List Screen
Standbyscreen
Notes
• ThissoftwaresupportswirelessLANconnectionsettingsSIMPLE,S-DIRECT,S-MAP,and1to4forthepro-
jector.IfthewirelessLANconnectionsettingoftheprojectorissettoanyothersetting,setittoSIMPLE,S-DI-
RECT,orS-MAP,oranysettingfrom1to4.Fordetailsonthissetting,seetheinstructionmanualfortheprojec-
tor.
• Search results are not updated automatically. To perform the search again, click the wireless LAN connection
setting again.
5. Connect to the projector.
SelecttheprojectorthatcorrespondstotheprojectornameandnetworkIDthatappearsintheprojector’sstand-
byscreen,andclickthe[Connect]button.
Search List Screen
Standbyscreen
Notes
• Thebackgroundcolorchangeswhenaprojectorisselected.Youcanalsoconnectbydouble-clickingtheprojec-
tor’snameandnetworkIDpartinthesearchlistscreen.
• WhenthewirelessnetworkLANconnectionsettingis“SIMPLE”,“SIMPLEPrpj****”willappearinthesearchlist
screen.
6. Project the screen of the computer. (See page 14)

– 11 –
■ Connecting using the registered projector tree
To connect using the registered projector tree, use the following procedure. Register the tree (group, projector) in
EasyWirelessStickbeforehand.(Seepage17)
1. Connect Easy Wireless Stick.
Connect the Easy Wireless Stick to a USB port of the computer.
2. Run [EWS].
Manuallyrunthe[EWS]leinthe[EasyWS]CDdriveofFinder.
3. Click [Tree] tab.

– 12 –
■ Connecting using the registered projector tree (cont.)
4. Connect to the projector.
Selectaprojectordisplayedintheregisteredprojectortree,andclick[Connect]button.
Example: If the name of the connection destination projector is “Name1244”, select the projector indicated as
“Name1244”,andthenclick[Connect]button.
Notes
• Thebackgroundcolorchangeswhenaprojectorisselected.Youcanalsoconnectbydouble-clickingtheicon
for the projector in the registered projector tree screen.
• IfthecorrespondingprojectorcouldnotbefoundusingtheregisteredwirelessLANconnectionsetting,usean-
other wireless LAN connection setting to search for the corresponding projector.
• Iftheprojectoryouwanttoconnecttoisnotdisplayedbelowthegroupitbelongsto,click[ ].
5. Project the screen of the computer. (See page 14)

– 13 –
■ Connecting using automatic connection
If you connect once, you can store the information for connecting to Easy Wireless Stick.
Addacheckto[AutomaticConnectionSetting]inthelaunchertoenableconnectingtotheprojectorandstarting
projection.
1. Connect Easy Wireless Stick.
Connect the Easy Wireless Stick to a USB port of the computer.
2. Run [EWS].
Manuallyrunthe[EWS]leinthe[EasyWS]CDdriveofFinder.
Thesoftwarestarts,andautomaticallyestablishesaconnectiontotheprojectorforwhichtheautomaticconnec-
tionsettingiscongured.
Notes
• Tocanceltheautomaticconnectionsetting,clearthecheckfromthecheckbox.
• Connectionmaynotbepossibleiftheprojector’swirelessLANconnectionsettingischangedafterselectingthe
[Automatic Connection Setting].
If [Failed to connect.] is displayed, connect using the search list again. (See page 9)
• Whiletheprojectorisconnectedandnotperformingprojection(Live/Pause),youcansettheautomaticconnec-
tion setting in the launcher screen.

– 14 –
Projecting Computer Screen from Projector
Whentheconnectionisestablished,thelauncherappears.Ifyouclickthe[Live]button,thecomputerscreenis
projected from the projector. See “Explanation of Launcher Screen” (page 6).
Notes
• The launcher is minimized to the dock after live mode starts.
• Audioisnotsenttotheprojector,soaudioisnotoutputfromtheprojector’sinternalspeakersoraudiodevice
connected to the projector.
• Projectionisnotpossiblewhiletheprojectorisinthestandbystate.Makesuretoturnontheprojector.
• The Easy Wireless Stick may cause delay when putting your computer into sleep mode. Before putting your
computerintosleepmode,rstdisconnecttheEasyWirelessStick.
• If the Easy Wireless Stick is disconnected during image projection, the software is force ended and the com-
puterscreenwillremaindisplayedontheprojector’sprojectionscreen.Ifyoudonotwantthescreentoremain
displayed,clickthe[Stop]buttontostopprojectionandthendisconnecttheEasyWirelessStick.

– 15 –
Multi Live Mode
■ Switching from one screen style to another
Multi live mode has “4-screen multi style”, “4-screen index style” and “16-screen index style”.
■How to operate
Ifyourstpressthe[Stop]buttononthelaunchertostopprojectionandthenselect[MULTI-LIVE]fromthe
[NETWORK]menuoftheprojectorandpressthe<ENTER>button,youcanchangethestyle.
• 4-screen multi style
Assign an area of one quarter of the projector screen to each of
up to four computers, and project images on the projector screen.
This is the style to use for screen display using WirelessManager.
ItcannotbeusedwiththeEasyWirelessStick.
• 4-screen index style
Display the indexes (small screens) of up to four computer
screens, and make one of these screens an enlarged display. You
can also temporarily switch over to a full screen display.
This is the style to use for screen display using WirelessManager.
ItcannotbeusedwiththeEasyWirelessStick.
• 16-screen index style (See page 16)
Display the indexes (small screens) of up to 16 computer screens.
You can also temporarily switch over one of these screens to a full
screen display.
Notes
• When the projector starts up, it resumes in the current style the last time the projector was turned off.
• Whenswitchingfrommultilivemodetoliveoffullscreendisplay,rstselectthe4-screenmultistyle,andthen
clickthe[Live]buttononthecomputer.
• If you switch over to a 4-screen multi style while computers are connected in a 16-screen index style, the con-
nectionstothecomputerswillbenullied.
• You cannot use the [MULTI-LIVE] menu in full screen display or when not connected.
[MULTI-LIVE]
[MULTI-LIVE]
[MULTI-LIVE]

– 16 –
■ 16-screen index style
When the projector is set to “16-screen index style,” connect up to 16 computers to one projector, and
simultaneously display the screens for the 16 computers.
1. Connect the projector and computer (See page 10) in the search list screen or registered tree screen and
open the launcher screen (See page 14).
2. Select [MULTI-LIVE] from the [NETWORK] menu of the projector, press the <ENTER> button, and set the
projection screen to “16-screen index style”. (See page 15)
3. Click [Live] button on the launcher.
The computer images are projected on the empty small screens on the 16-screen display.
The projector determines the display position.
■ Enlarged display
• Usethe< >buttonsontheremotecontroltoselect(movetheyellowboxto)theimagetobeenlarged
andpress<ENTER>toexpandthatimagetollthedisplay.
• Press<ENTER>againtoreturntothe16-screenindexstyle.
Toggle between
these with the
<ENTER> button.
Note
• If a connection error occurs during projection, the message [“Live Mode” is deactivated] will appear. Check the
communicationenvironment,thenclickthe[Live]buttonagainonthelauncher.
■ Quitting 16-screen index style
Clickthe[Stop]buttononthelaunchertoquitprojection,select[MULTI-LIVE]fromtheprojector[NETWORK]
menu,pressthe<ENTER>buttonandsetthe4-screenmultistyle.
■ Setting the sender name
Clickingthe[Conguration]buttonintheSelectAccessPortscreendisplaysthe[UserSetting]screen.
• Youcanconguretextuptoeightalphanumericcharacterslong.
• Theconguredtextappearsatthebottomofeachsmallscreenofthe16-screenindexstyle.

– 17 –
Registering and Editing Tree Information
■ Creating groups
1. Display the edit menu.
Selectthe[Tree]tab,and[Control]+click[Root]todisplaythemenu.Select[CreateNewGroup].
2. Enter the name of the group.
Enterthenameofthegroup,andthenclick[OK]button.
Example: Assign the name [3T-3F] to the group for managing projectors.
3. Save the registration information.
Clickthe[Save]buttontosavetheenteredgroupnametotheEasyWirelessStick.Thechangedinformationwill
notbestoredif[Save]buttonisnotclicked.
Notes
• Registeredgroupsandprojectorsaredisplayedinascendingorder.Theordercannotbechanged.
• Agroupcanonlybecreatedonelevelbelow[Root].
• Youcanconguretextupto64alphanumericcharacterslong.

– 18 –
■ Registering projectors
1. Display the edit menu.
Select the group of the projector registration destination, and then [Control]+click to display the menu.
Select[CreateNewProjector].
2. Enter the information of the projector.
Enter the wireless LAN connection setting in ①of the projector registration screen, and enter the network ID in ②.
For details on how to verify the wireless LAN connection setting and network ID of the projector, see “Checking
the projector” (page 7).
IfthewirelessLANconnectionsettingoftheprojectorissetto[SIMPLE],[S-DIRECT],or[S-MAP],select[S]for
①in the projector registration screen.
①
②
Standbyscreen ProjectorRegistrationScreen
①
②
* The projector search is performed using the wireless LAN connection setting and network ID. The registered
nameisusedforitemdisplayinthetree,soenteranamethatwillbeeasytomanage.
3. Click [OK] button.
4. Save the registration information.
Clickthe[Save]buttontosavetheenteredprojectorinformationtotheEasyWirelessStick.Whenstoringthe
changedinformation,besuretoclick[Save]button.

– 19 –
■ Changing the names of groups
1. Display the edit menu.
Selectthegroupforwhichyouwanttochangethename,and[Control]+clicktodisplaythemenu.Select[Prop-
erty].
2. Enter a new name.
Enteranewname,andthenclick[OK]button.
3. Save the changed information.
Clickthe[Save]buttontosavethechangedgroupnametotheEasyWirelessStick.Whenstoringthechanged
information,besuretoclick[Save]button.

– 20 –
■ Changing the registered information of projectors
1. Display the edit menu.
Select the icon of the projector you want to change, and [Control]+click to display the menu. Select and click
[Property].
2. Enter a new information.
Enterthechanges,andthenclick[OK]button.
3. Save the registration information.
Clickthe[Save]buttontosavethechangedinformationtotheEasyWirelessStick.Whenstoringthechanged
information,besuretoclick[Save]button.
