Panasonic FX-505 C2 Series User manual

4I/O CIRCUIT DIAGRAMS
<FX-505-C2>
Load
+
-
12 to 24V DC
%
Load
Load WR
Main circuit
(Brown) +V
(Pink) External input
(Black) Sensing output 1
(White) Sensing output 2
(Blue) 0V
(Gray) Monitor current output (4 to 20mA)
<FX-505P-C2>
Load
+
-
12 to 24V DC
%
Load
Load WR
(Brown) +V
(Pink) External input
(Black) Sensing output 1
(White) Sensing output 2
Main circuit
(Blue) 0V
(Gray) Monitor current output (4 to 20mA)
Note: Make sure to insulate the ends of the unused lead wires.
5OPERATION PROCEDURE
ƔThe sensing output can be switched to sensing output 1 or sensing output 2
by holding down the mode key.
ƔThe changed settings are not stored if turning the power OFF while setting.
7KHUHIRUHFRQ¿UPWKHVHWWLQJVE\SUHVVLQJWKH6(7NH\EHIRUHWXUQLQJWKH
power OFF.
ƔWhen turning ON the power, RUN mode is displayed and the digital display
shows the threshold value (green) and the incident light intensity (red).
• Displays threshold value (green) and incident light intensity (red).
• 7HDFKLQJWKUHVKROGYDOXH¿QHDGMXVWPHQW DQGNH\ ORFNIXQFWLRQ
can be set.
• For setting method of each function, refer to “ TEACHING
MODE,” “ THRESHOLD VALUE FINE ADJUSTMENT FUNC-
TION,” or “ KEY LOCK FUNCTION.”
• Select either Light-ON or Dark-ON.
• For the setting, refer to “SENSING OUTPUT OPERATION
MODE
.”
• The default setting is “ ” (Light-ON).
• An item set in CUSTOM mode (Response time setting, Emission
power setting and Hysteresis setting) is displayed.
• For details, refer to “ CUSTOM MODE.”
• The default setting is “ ” (response time setting).
• Advanced setting can be done.
• For the setting, refer to “ PRO MODE.”
<RUN mode>
<Sensing output operation mode>
<CUSTOM mode>
<PRO mode>
<RUN mode>
INSTRUCTION MANUAL
'LJLWDO)LEHU6HQVRU$PSOL¿HU FX-505Ƒ-C2
MJE-FX505C2C No.0068-85V
Thank you very much for purchasing Panasonic products.
Please read this Instruction Manual carefully and thoroughly for the correct and
optimum use of this product.
.LQGO\NHHSWKLVPDQXDOLQDFRQYHQLHQWSODFHIRUTXLFNUHIHUHQFH
WARNING
ƔNever use this product as a sensing device for personnel protection.
ƔIn case of using sensing devices for personnel protection, use products which
meet laws and standards, such as OSHA, ANSI or IEC etc., for personnel
protection applicable in each region or country.
1INTENDED PRODUCTS FOR CE MARKING
ƔThis product complies with the following standards / regulations.
(8'LUHFWLYH!
EMC Directive
<Standards in US / Canada>
ANSI/UL 60947-5-2, CAN/CSA C22.2 No.14
5HJXODWLRQVLQ.RUHD!
S1-G-1-2009, S2-W-5-2009
ƔCaution about UL recognition
,QFDVHUHTXLULQJFRQIRUPLW\RI8/OLVWLQJPDUNRU&8/OLVWLQJPDUN86HFODVV
2 power supply unit.
Ɣ&RQWDFWIRU&(
Panasonic Marketing Europe GmbH Panasonic Testing Center
Winsbergring 15, 22525 Hamburg,Germany
2PART DESCRIPTION
Digital display
(Green / Red)
UP key
• Teaching
• Threshold value
¿QHDGMXVWPHQW
• Select setting items
MODE key
• Select Modes
• Cancel during setting
• Select sensing output 1/2
by pressing long
SET key
• Teaching
• Confirm setting
contents
DOWN key
• Teaching
• 7KUHVKROGYDOXH ¿QH
DGMXVWPHQW
• Select setting items
Sensing output 2
selection indicator
(Yellow)
Sensing output 1
selection indicator
(Yellow)
Sensing output 1
operation indicator
(Orange)
Sensing output 2
operation indicator
(Orange) MODE indicator: PRO (Yellow)
MODE indicator: L / D (Yellow)
MODE indicator: CUST (Yellow)
Pressing down SET key + MODE key for 3 sec : Set key lock or Release key lock
3MOUNTING
How to connect
1. Fit the rear part of the mounting sec-
WLRQRIWKHDPSOL¿HURQD',1UDLO
2. Press down the rear part of the
mounting section of the unit on the
DIN rail and fit the front part of the
mounting section to the DIN rail.
+RZWRUHPRYH
1. Push the controller forward.
2. /LIWXSWKHIURQWSDUWRIWKHDPSOL¿HU
to remove it.
2. Lift up
1. Push forward
2. Press down
1. Fit
35mm width DIN rail
+RZWRFRQQHFWWKH¿EHUFDEOH
%HVXUH WR ¿W WKH DWWDFKPHQW WR WKH ¿EHUV ¿UVWEHIRUHLQVHUWLQJWKH¿EHUVWRWKH
DPSOL¿HU)RUGHWDLOVUHIHUWRWKHLQVWUXFWLRQPDQXDOHQFORVHGZLWKWKH¿EHUV
1. Snap the fiber lock lever down till it
stops completely.
2. ,QVHUWWKH¿EHUFDEOHVVORZO\LQWRWKH
inlets until they stops. (Note)
3. Return the fiber lock lever to the
original position till it stops.
Fiber lock lever
Fiber for
receiver
1. Snap
3. Return
2. Insert
Fiber for emitter
1RWH :LWKWKHFRD[LDOUHÀHFWLYHW\SH¿EHUVXFKDVFD-G4 or FD-FM2LQVHUWWKHVLQJOHFRUH¿EHUFDEOHLQWRWKH
EHDPHPLWWLQJLQOHW³3´DQGWKHPXOWLFRUH¿EHUFDEOHLQWRWKHEHDPUHFHLYLQJLQOHW
If they are inserted in reverse, the sensing performance will deteriorate.
<Reference>

1-point teaching [Window comparator mode (except sensing output 2) / Hysteresis mode]
ƔThis is method to set the shift amount to the desired value and to set the
threshold range by using the 1-point teaching.
<Hysteresis mode>
1_SL P-1 2_SL
<Window comparator mode>
1_SL P-1 2_SL
Set to de-
sired value
Set to de-
sired value
Set to de-
sired value
Set to de-
sired value
Stable sensing is possible
1. Pressing SET key down
2. 3UHVVWKH6(7NH\GRZQLQWKHVHQVLQJREMHFWSUHVHQWFRQGLWLRQ
Stable sensing is not possible
3. The threshold value (1_SL) that is 10% lower from the incident
light intensity and the threshold value (2_SL) that is 10% higher
from the incident light intensity are set. (Note 1, 2)
Notes 1) The shift amount of 10% is an initial value. The shift amount can be set in PRO mode. Furthermore, the shift value
can be set in incident light amount. For setting method, refer to <PRO6> in “PRO MODE OPERATION MANUAL.”
2) If the value after setting exceeds the maximum (minimum), the maximum (minimum) sensitivity will be set.
2-point teaching [Window comparator mode (except sensing output 2) / Hysteresis mode]
ƔThis is method to set the threshold range by conducting the 2-point teaching (P-1, P-2).
Ɣ :KHQFRQGXFWLQJWHDFKLQJXVHVHQVLQJREMHFWV3DQG3ZKRVHLQFLGHQW
OLJKWLQWHQVLWLHVDUHGLႇHUHQWIURPHDFKRWKHU
<Hysteresis mode>
1_SL (P-1) 2_SL (P-2)
<Window comparator mode>
1_SL (P-1) 2_SL (P-2)
Stable sensing is possible
1. Pressing SET key down (1st time)
2. 3UHVVGRZQWKH6(7NH\LQWKHVHQVLQJREMHFWSUHVHQWFRQGLWLRQ
(2nd time)
Stable sensing is not possible
Note: If the value after setting exceeds the maximum (minimum), the maximum (minimum) sensitivity will be set.
3-point teaching [Window comparator mode (except sensing output 2) / Hysteresis mode]
ƔThis is the method to conduct the 3-point teaching (P-1, P-2, P-3) and to set the
threshold range by setting the threshold value (1_SL) of the mid-point between “A”
and “B” and the threshold value (2_SL) of the mid-point between “B” and “C”.
Ɣ :KHQFRQGXFWLQJWHDFKLQJXVHVHQVLQJREMHFWV$%DQG&ZKRVHLQFLGHQW
OLJKWLQWHQVLWLHVDUHGLႇHUHQW
ƔAfter teaching, P-1, P-2 and P-3 will be automatically relocated in ascending order:
i.e. the lowest value is placed in “A”, the second lowest in “B” and the highest in “C”.
<Hysteresis mode>
A2_SL1_SL B C
<Window comparator mode>
A2_SL1_SL B C
Stable sensing is possible
1. 3UHVV6(7NH\GRZQLQWKHVHQVLQJREMHFWSUHVHQWFRQGLWLRQVWWLPH
2.
3UHVV6(7NH\GRZQLQWKHVHQVLQJREMHFWSUHVHQWFRQGLWLRQQGWLPH
Stable sensing is not possible
3.
3UHVV6(7NH\GRZQLQWKHVHQVLQJREMHFWSUHVHQWFRQGLWLRQUGWLPH
Note: If the value after setting exceeds the maximum (minimum), the maximum (minimum) sensitivity will be set.
6SDQDGMXVWPHQWLQULVLQJGLႇHUHQWLDOPRGHRUWUDLOLQJGLႇHUHQWLDOPRGH
ƔMove to the rising differential mode, or the trailing differential mode in the
352PRGHDQGSUHVVWKHMRJVZLWFKWRFRQ¿UPWKHVHWWLQJFor the setting
procedure, refer to <PRO6> in “PRO MODE OPERATION MANUAL.”
ƔReturn to the normal screen, press the SET key, and select Span d-01~d-08.
7KHQSUHVVWKH6(7NH\WRFRPSOHWHDGMXVWPHQW
Short span
Long span
Span
6TEACHING MODE
ƔBe sure that detection may become unstable depending on the use environ-
ment in teaching if less margin is applied.
ƔWhen teaching in Window comparator mode or Hysteresis mode, a setting
has to be made in PRO mode beforehand.
In case 1-point teaching, make sure to set the shift amount. (initial value is
10% or 100)
For the setting, refer to <PRO6> in “PRO MODE OPERATION MANUAL.”
ƔTeaching can be set in RUN mode.
2-point teaching This is basic teaching method.
5HÀHFWLYHW\SH!<Thru-beam type>
12
1
2
Stable sensing is possible
1.
3UHVVWKH6(7NH\LQWKHVHQVLQJREMHFWSUHVHQWFRQGLWLRQ
2.
3UHVVWKH6(7NH\LQWKHVHQVLQJREMHFWDEVHQWFRQGLWLRQ
Stable sensing is not possible
Limit-teaching
7KUXEHDPW\SHDQGUHIUDFWLYHW\SHDUHFRPPRQ!
or
Stable sensing is possible
1.
Press the SET key in the sensing
REMHFWSUHVHQW FRQGLWLRQRU QRQ
VHQVLQJREMHFWSUHVHQWFRQGLWLRQ
2.
The threshold level is shifted
to high value (low sensitivity)
by pressing down UP key.
The threshold level is shifted
to low value (high sensitivity)
by pressing down UP key.
Stable sensing is not possible
Note: The shift value of approx. 15% is an initial value. Display of the shift value can be changed to per-
centage [approx. 0 to 999% (unit 1 %)] or incident light intensity [0 to 9999 (unit 1)].
For setting the shift amount, refer to <PRO1> in “PRO MODE OPERATION MANUAL.”
)XOODXWRWHDFKLQJ
7KUXEHDPW\SHDQGUHIUDFWLYHW\SHDUHFRPPRQ!
Stable sensing is possible
1. Pressing SET key down
2. 5XQWKH VHQVLQJREMHFW RQWKHOLQH DQGKROGGRZQ WKH
SET key.
Stable sensing is not possible
3. “ ” is displayed on the digital display (green) and
ZKHQWKH VHQVLQJREMHFW SDVVHGWKURXJKUHOHDVH WKH
SET key.
Automatic
Pressing down long
8VHIXOZKHQVHQVLQJREMHFWFDQEHVHW
8VHIXOZKHQVHQVLQJREMHFWFDQQRWEHVHW
7KLVLV WHDFKLQJPHWKRG LQFDVHVPDOO REMHFWRUREMHFW LQEDFN
ground are existing.
7KLVLVPHWKRGWRFRQGXFWWHDFKLQJGRLQJVHQVLQJREMHFWLV
moving.
8VHIXOZKHQQRWZDQWWRVWRSSURGXFWLRQOLQHDQGWRNHHSWKHVHQVLQJREMHFWPRYH

11
PRO MODE
ƔWhen MODE indicator: PRO (yellow) lights up, PRO mode can be set.
ƔFor detail of PRO mode, refer to “ PRO MODE OPERATION MANUAL.”
DOWN ( - ) key (select)
MODE indicator PRO (Yellow)
MODE key
UP (+) key (select)
6(7NH\FRQ¿UP
Procedure
SET
SET
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
+, -
SET
<PRO1>
Shift amount setting
Timer setting
Responce time setting
Hysteresis setting
Emission power setting
Timer range setting
Teaching lock setting
Setting items in digital display setting
Setting of digital display turning
Time period hold setting
Data bank loading setting
Back up setting
Communication protocol setting
Display adjustment setting
Setting of threshold value tracking
Copy lock setting
Copy action setting
Data bank saving setting
<PRO3>
<PRO5>
Code setting
<PRO6>
Reset setting
CUSTOM setting
Interference prevention setting
Sensing output setting
<PRO4>
Copy setting
<PRO2>
ECO setting
SET
SET
SET
+, -
External input setting
SET
<PRO7>
Logic operation setting
+, -
+, -
+, -
+, -
+, -
Ɣ 7KHWKUHVKROGFDQEHVHWE\XVLQJWKHWKUHVKROGYDOXH¿QHDGMXVWPHQWIXQFWLRQ
)RUWKHWKUHVKROGYDOXHILQHDGMXVWPHQWIXQFWLRQUHIHUWR³ 7THRESHOLD
VALUE FINE ADJUSTMENT FUNCTION”
7THRESHOLD VALUE FINE ADJUSTMENT FUNCTION
Ɣ 6HW¿QHDGMXVWPHQWRIWKUHVKROGYDOXHLQ581PRGH
Ɣ $OVRWKHWKUHVKROGYDOXH¿QHDGMXVWPHQWIXQFWLRQFDQEHXVHGLQIRUFHG21
output mode and forced OFF output mode
ƔFor setting of the sensing output, refer to <PRO6> in “PRO MODE OPERA-
TION MANUAL.”
1RUPDOPRGH5LVLQJGLႇHUHQWLDOPRGHRU7UDLOLQJGLႇHUHQWLDOPRGH!
&RQ¿UPHG
Press down
UP / DOWN key
Press down
SET key
Automatically set without pressing
down SET key in approx. 2 sec.
<Window comparator mode or Hysteresis mode>
ƔWhen setting sensing output to the window comparator mode or hysteresis
mode, “ ” and “ ” can be changed to another by pressing down
SET key for 2 sec.
,QFDVHFRQGXFWLQJWKUHVKROGYDOXH¿QHDGMXVWPHQWRI³ ” or “ ”, press
down UP key or Down key, and “ ” or “ ” are displayed. Then, the
WKUHVKROGYDOXH¿QHDGMXVWPHQWFDQEHFRQGXFWHG
Press down
UP / DOWN key
Press down
SET key
Press down
UP / DOWN key
&RQ¿UPHG
Automatically set without pressing
down SET key in approx. 2 sec.
Note: It may not respond when values of “ ” and “ ” are close because of relation of hysteresis. Be sure
WRFRQ¿UPZLWKWKLVGHYLFH
8KEY LOCK FUNCTION
ƔThe key lock function prevents key operations so that the conditions set in
each setting mode are not inadvertently changed.
ƔIf operating key switch after key lock is set, “ ” is indicated on the
digital display.
6HWNH\ORFN!
Automatic
Press down for
3 sec. or more
5HOHDVHNH\ORFN!
,
are displayed
Press down for
3 sec. or more
Automatic
9SENSING OUTPUT OPERATION MODE
ƔWhen MODE indicator: L / D (yellow) lights up, sensing output operation can be set.
Press down
SET key
Press down
UP / DOWN key
&RQ¿UPHG
&RQ¿UPHG
10
CUSTOM MODE
ƔWhen MODE indicator: CUST (yellow) lights up,
Response time setting, Emission power setting
or Hysteresis setting can be displayed.
For the setting procedure, refer to <PRO5> in
“PRO MODE OPERATION MANUAL.”
ƔBy pressing UP key or DOWN key, the setting in
each item will be changed.
MODE indicator
CUST (Yellow)
UP key
SET key DOWN key
MODE key
Ɣ 3UHVV6(7NH\WRFRQ¿UPWKHVHWWLQJ
ƔFor setting of each item, refer to the following table.
Item Digital display Reference item
Response time setting <PRO 1: Response time setting>
Emission power setting <PRO 1: Emission power setting>
Hysteresis setting <PRO 1: Hysteresis setting>

12
OPTICAL COMMUNICATION
ƔWhen the setting of data bank loading / saving, copy setting, or copy action
VHWWLQJLVFRQGXFWHGYLDRSWLFDOFRPPXQLFDWLRQVFDVFDGHWKHVXEDPSOL¿HUV
ULJKWVLGHWRWKHPDLQDPSOL¿HUDVIROORZV
However, in case using data bank loading / saving, use FX-502ƑRUFX-505Ƒ-C2
DVPDLQDPSOL¿HU
Ɣ ,IDQDPSOL¿HULVXQGHUDQ\RIWKHIROORZLQJFRQGLWLRQVWKHVHWWLQJRIGDWDEDQN
loading / saving, or copy setting cannot be carried out.
• Copy lock setting is set to copy lock ON “ .”
• Digital display is blinking
• ([WHUQDOLQSXWVHWWLQJRIPDLQDPSOL¿HULVVHWWR“ .” (Only data-
bank loading / saving)
ƔWhen communication protocol of a
sub amplifier is set to communication
emission halt “ ” the setting
of data bank loading / saving, or copy
setting cannot be carried out to sub
DPSOL¿HUVVXEVHTXHQWWRWKHPHQWLRQHG
DPSOL¿HU
ƔMake sure to mount closely like follows
since interference prevention function is
conducted by optical communication.
Main
DPSOL¿HU 6XEDPSOL¿HUV
Communication direction
Ɣ :KHQWKLV SURGXFW DQG RWKHU SURGXFWV HJ ¿EHU VHQVRU DPSOL¿HUV SUHVVXUH
sensor controllers, etc.) are connected together in cascade, install those prod-
XFWVVRWKDWWKH\DUHLQRUGHURI*URXS$%'DQG&DVVKRZQLQWKHULJKW¿J-
ure. This product is included in Group D.
Group
A
Group
B
Group
D
Group
C
Communication direction
Group Model No.
AFX-301Ƒ&RQYHQWLRQDOYHUVLRQXQLW
FX-301BƑGƑHƑLS-401Ƒ
BFX-301Ƒ0RGL¿HGYHUVLRQXQLW
FX-305ƑFX-301Ƒ-C1
CLS-403ƑDPS series
DFX-500 series
Ɣ $VIRUWKHSURGXFWVWKDWDUHORFDWHGEHWZHHQGLႇHUHQWJURXSVDႈ[WKHDPSOL-
¿HUSURWHFWLRQVHDOFX-MB1 (optional) on the communication window of each
corresponding product.
ƔWithin each group, identical models should be connected in a lump.
ƔIn case conducting copy setting of this device and other FX-500 series togeth-
er, functions which are incorporated in this device will be copied but functions
which are not incorporated in this device will not be copied.
13
INTERFERENCE PREVENTION FUNCTION
Ɣ 7KLVGHYLFHLQFRUSRUDWHVDQLQWHUIHUHQFHSUHYHQWLRQIXQFWLRQE\VHWWLQJGLႇHUHQWHPLWWLQJ
IUHTXHQFLHVGLႇHUHQWIURPDQLQWHUIHUHQFHSUHYHQWLRQIXQFWLRQE\RSWLFDOFRPPXQLFDWLRQ
ƔFor Interference prevention function setting procedure, refer to <PRO5> in
“PRO MODE OPERATION MANUAL.”
Ɣ 3RVVLEOHQXPEHURIDPSOL¿HUVIRULQWHUIHUHQFHSUHYHQWLRQIXQFWLRQLVGLႇHUHQW
as shown in table below.
Response time
Interference
prevention function setting
H-SP FAST STD LONG U-LG HYPR
0248812
Ɣ ,QFDVHSXWWLQJLQPRUHDPSOL¿HUVWKDQOLPLWRILQWHUIHUHQFHSUHYHQWLRQIXQFWLRQ
SXWWKHDPSOL¿HUSURWHFWLRQVHDOWRDPSOL¿HUZKLFKLVDGMDFHQWRIHQGRIDQDPSOL-
¿HUWKDWWKHLQWHUIHUHQFHIXQFWLRQLVYDOLGRUVHW2))LQFRPPXQLFDWLRQSURWRFRO
VHWWLQJRIWKHHQGRIDPSOL¿HUWKDWWKHLQWHUIHUHQFHSUHYHQWLRQIXQFWLRQLVYDOLG
([DPSOH3XWWLQJLQRIWKLVGHYLFHDQGVHW67'RIUHVSRQVHWLPHVHWWLQJ
• Possible number of interference prevention is 4.
3XWWKH DPSOL¿HU SURWHFWLRQ VHDOV WK DQGWKDPSOL¿HUVDQGEHWZHHQ WK
DQGWKDPSOL¿HUVRUFKDQJHWKHFRPPXQLFDWLRQSURWRFROVHWWLQJRIWKDQG
8th to OFF since interference prevention works from 1st to 4th, from 5th to
8th and 9th to 12th.
Communication direction
Interference
prevention
possible
range
Put a protection seal between
WKDQGWKDPSOL¿HU
Or set communication protocol
setting in 4th to OFF.
Put a protection seal between
WKDQGWKDPSOL¿HU
Or set communication protocol
setting in 8th to OFF.
Interference prevention
possible range
Interference prevention
possible range
Ɣ ,QFDVHPRXQWLQJPRUHDPSOL¿HUVZKRVHUHVSRQVHWLPHVHWWLQJDUHGLႇHUHQW
SXWSURWHFWLRQVHDOEHWZHHQDPSOL¿HUVWKDWKDYHGLႇHUHQWUHVSRQVHWLPHVHWWLQJ
RUVHWFRPPXQLFDWLRQSURWRFROVHWWLQJRIWKHXSSHUDPSOL¿HUWR2))
ƔFor communication protocol setting procedure, refer to <PRO4> in “PRO
MODE OPERATION MANUAL.”
14
ERROR INDICATION
ƔIn case of errors, attempt the following measures.
Error
indication Description Remedy
EEPROM is broken or reached the end of its
working life. 3OHDVHFRQWDFWRXURႈFH
EEPROM writing error
Load of the sensing output 1 is short-circuited
FDXVLQJDQRYHUFXUUHQWWRÀRZ Turn OFF the power and check the load.
Load of the sensing output 2 is short-circuited
FDXVLQJDQRYHUFXUUHQWWRÀRZ
&RPPXQLFDWLRQHUURUZKHQ WKH DPSOL¿HUVDUH
mounted in cascade.
Verify that there is no loose or clearance between
DPSOL¿HUV
Communication error between the upper com-
PXQLFDWLRQXQLWDQGDPSOL¿HUV
Verify that there is no loose or clearance between
WKHXSSHUFRPPXQLFDWLRQXQLWDQGDPSOL¿HUV
15
SPECIFICATIONS
Type Cable type
NPN output PNP output
Model No. FX-505-C2 FX-505P-C2
Supply voltage 12 to 24V DC % Ripple P-P10% or less
Power consumption
(Note 1)
Normal operation: 960mW or less (current consumption 40mA or less at 24V supply voltage)
Eco mode: 680mW or less (current consumption 28mA or less at 24V supply voltage)
Sensing output
(Sensing output 1 / 2)
NPN open-collector transistor
• Maximum sink current: 50mA
• Applied voltage: 30V DC or less
(Between sensing output and 0V)
• Residual voltage: 2V or less
(At 50mA sink current)
PNP open-collector transistor
• Maximum source current: 50mA
• Applied voltage: 30V DC or less
(Between sensing output and +V )
• Residual voltage: 2V or less
(At 50mA source current)
Output operation Switchable either Light-ON or Dark-ON
Short-circuit protection Incorporated
Response time +63ȝVRUOHVV)$67ȝVRUOHVV67'ȝVRUOHVV/21*PVRUOHVV
U-LG: 4ms or less, HYPR: 24ms or less, Selectable
Monitor current output
• Output current: approx. 4 to 20mA
[Display in H-SP, FAST, STD: 0 to 4,000, Display in LONG: 0 to 8,000 (Note 2) ]
• Response time: 2ms or less
• Zero-point: Within 4mA ±1%F.S.
• Span: Within 16mA ±5%F.S.
• Linearity: Within ±3%F.S.
• ORDGUHVLVWDQFHWRȍ
External input
• Signal condition
High: +8V to +V DC or Open
Low: 0 to +1.2V DC (at 0.5mA source current)
• ,QSXWLPSHGDQFH$SSUR[Nȍ
• Signal condition
High: +4V to +V DC (at 3mA sink current)
Low: 0 to +0.6V DC or Open
• ,QSXWLPSHGDQFH$SSUR[Nȍ
Protection IP40 (IEC)
Ambient temperature
WR&,IWRXQLWVDUHPRXQWHGDGMDFHQWO\LQFDVFDGHWR&RULIWRXQLWV
DUHPRXQWHGDGMDFHQWO\LQFDVFDGHWR&1RGHZFRQGHQVDWLRQRULFLQJDOORZHG
Storage: -20 to +70°C
Ambient humidity 35 to 85% RH, Storage: 35 to 85% RH
Material Enclosure: Polycarbonate, Key: Polyacetal, Protective cover: Polycarbonate
Cable 0.2mm26-core cabtyre cable, 2m long
Weight (Main body only) Approx. 60g
Accessory FX-MB1 $PSOL¿HUSURWHFWLRQVHDOVHW
Note: 1)Excluding power consumption of the monitor current output
,IWKHGLVSOD\DGMXVWPHQWZDVFRQGXFWHGLWLVQRWLQWKLVUDQJH
16
CAUTIONS
ƔThis product has been developed / produced for industrial use only.
Ɣ 0DNHVXUHWKDWWKHSRZHUVXSSO\LV2))ZKLOHDGGLQJRUUHPRYLQJWKHDPSOL¿HUV
ƔTake care that if a voltage exceeding the rated range is applied, or if an AC
power supply is directly connected, the product may get burnt or be damaged.
ƔTake care that short-circuit of the load or wrong wiring may burn or damage the product.
ƔDo not run the wires together with high-voltage lines or power lines, or put
them in the same raceway.This can cause malfunction due to induction.
Ɣ 7KHVSHFL¿FDWLRQPD\QRWEHVDWLV¿HGLQDVWURQJPDJQHWLF¿HOG
ƔVerify that the supply voltage variation is within the rating.
ƔIf power is supplied from a commercial switching regulator, ensure that the frame
ground (F.G.) terminal of the power supply is connected to an actual ground.
Ɣ ,QFDVHQRLVHJHQHUDWLQJHTXLSPHQWVZLWFKLQJUHJXODWRULQYHUWHUPRWRUHWF
is used in the vicinity of this product, connect the frame ground (F.G.) terminal
RIWKHHTXLSPHQWWRDQDFWXDOJURXQG
Ɣ 7KHXOWUDORQJGLVWDQFH8/* +<35 PRGH LV PRUH OLNHO\ WR EHDႇHFWHGE\
extraneous noise since the sensitivity of that is higher than the other modes.
Make sure to check the environment before use.
ƔDo not use during the initial transient time (H-SP, FAST, STD: 0.5 sec., LONG,
U-LG, HYPR: 1 sec.) after the power supply is switched ON.
Ɣ 8VHVDPHSRZHUVXSSO\ZKHQPRXQWLQJDGMDFHQWO\
ƔExtension up to total 100m is possible. When you extend the cable, be sure the power sup-
ply voltage is 12V DC or more and use cables which have 0.3mm2or more of conductor
cross-section area. However, in order to reduce noise, make the wiring as short as possible.
ƔMake sure that stress by forcible bend or pulling is not applied to the sensor
FDEOHMRLQWDQG¿EHUFDEOH
ƔThis product is suitable for indoor use only.
ƔAvoid dust, dirt, and steam.
ƔTake care that the product does not come in contact with oil, grease, organic
solvents such as thinner, etc., strong acid or alkaline.
Ɣ 7KLVSURGXFWFDQQRWEHXVHGLQDQHQYLURQPHQWFRQWDLQLQJLQÀDPPDEOHRUH[-
plosive gasses.
ƔNever disassemble or modify the product.
ƔThis product adopts EEPROM. Settings cannot be done 100 thousand times
or more because of the EEPROM’s lifetime.
Panasonic Industrial Devices SUNX Co., Ltd.
https://panasonic.net/id/pidsx/global
3OHDVHYLVLWRXUZHEVLWHIRULQTXLULHVDQGDERXWRXUVDOHVQHWZRUN
PRINTED IN JAPAN © Panasonic Industrial Devices SUNX Co., Ltd. 2019
