Panasonic AVCCAM AG-HSC1UE User manual

Panasonic Broadcast
Mechanical Parts List
Model No. : AG-HSC1UP/E/MC
CONTENTS
CASING PARTS ASSEMBLY (1).....................................................................................................MPL-1
CASING PARTS ASSEMBLY (2).....................................................................................................MPL-2
LCD PARTS ASSEMBLY.................................................................................................................MPL-5
LENS ASSEMBLY............................................................................................................................MPL-7
PACKING PART ASSEMBLY ..........................................................................................................MPL-9

80
79 78
B30
B31
77
B69
85
82
84
83
93
B29
81
B23
B22
B21
B24
73
72
70
75
92
B52
89
B25
B27
B26
76
88
9
74
0
B42
1
61
B68
B64
B59
B60
B47
62
63
62
B66
B58
B19
B20
62
B67
68
69
71
64
65
66
67
B18
B43
B44
B45
86
B57
B50
B56
B70
B62
94
B65
B46
B61
B28
MPL-1
CASING PARTS ASSEMBLY (1) Components identified with the mark have the special characteristics for safety.
When replacing any of these components, use only the same type.

B54
47
46
43
B55
42
B53
44
45
B11
B12
40
B36
B37
41
6
16
B40
B39
B34
B35
48
15
26
7
4
25
B63
24
3
2
5
B41
14
B38
22
20
23
21
B49
B33
11
4
4
B32
B2
B1
18
19
9
B71
10
49
B51
28
B6
B5
B4
B3
34
31
32
33
36
B10
B9
B8
35
39
B7
38
37
29
8
4
B48
27
17
30
50
CASING PARTS ASSEMBLY (2)
MPL-2

Ref.No. Part No. Part Name & Description
P
c
s
Remarks Ref.No. Part No. Part Name & Description
P
c
s
Remarks
1 VQL1N50 CAUTION LABEL A 1 FOR AG-HSC1UP
1 VQL1N51 CAUTION LABEL A 1 FOR AG-HSC1UE
1 VQL1N52 CAUTION LABEL A 1 FOR AG-HSC1UMC
2 VSC5917 SHIELD PLATE 1
3 VSC5906 HEAT SINK FRAME A 2
4 VMG1772 DUMPER RUBBER 4
5 VKF4154 JACK BOARD 1
6 VGQ9175 HEAT SINK SHEET A1 1
7 VGQ9176 HEAT SINK SHEET A2 1
8 VGQ9177 HEAT SINK SHEET A3 1
9 VGQ9180 CCD HEAT SINK SHEET 1
10 VSC5902 CCD HEAT SINK PLATE 1
11 VSC5909 LENS FRAME 1
14 VGQ9179 HEAT SINK SHEET 1
15 VEP03H10G MAIN P.C.BOARD 1
16 VGQ9337 DPR SHEET 1
17 VGQ9346 ECM DPR SHEET 1 1
18 VEP01986A SUB P.C.BOARD 1
19 VWJ1925 MAIN SUB FPC 1
20 VEP20B98B JACK P.C.BOARD 1
21 VGQ9145 CAPACITOR COVER 1 1
22 VGQ9146 CAPACITOR COVER 2 1
23 VWJ1926 JACK FPC 1
24 VEP20C00A FRONT P.C.BOARD 1
25 VGQ9147 SENSOR HOLDER 1
26 VEP23667A HDMI P.C.BOARD 1
27 VGQ9183 HDMI SPACER 1
28 VKM7160 BATTERY CASE 1
29 VMB4087 BATTERY HOLD SPRING 1
30 VMB4085 BATTERY COVER SPRING 1
31 VXA8376 BATTERY COVER HINGE (1) 1
32 VMS7798 SHAFT 1
33 VKM7179 BATTERY COVER 1
34 VGQ9459 BATTERY COVER BRIND 1
35 VEP21294A BATTERY CATCHER P.C.BOARD 1
36 VSC5911 REAR FRAME 1
37 VGU0A50 BATTERY LOCK KNOB 1
38 VMB4086 BATTERY LOCK SPRING 1
39 VMP8735 BATTERY LOCK FRAME 1
40 VSC5907 HEAT SINK FRAME B 1
41 VGQ9178 HEAT SINK SHEET B 1
42 VGQ9182 SPEAKER COVER 1
43 VGQ9263 CUSHION 1
44 L0AA02A00075 SPEAKER 1
45 VMC2023 SPEAKER SPRING 1
46 L6FAG99D0018 DC FAN MOTOR 1
47 VMG1762 DUMPER RUBBER 1
48 VYK1Z83 HEAT SINK FRAME CU 1
49 VWJ1928 SIDE R FPC 1
50 VGQ9353 ECM DPR SHEET 2 1
CASING PARTS ASSEMBLY (1),(2)
EPL-3

Ref.No. Part No. Part Name & Description
P
c
s
Remarks Ref.No. Part No. Part Name & Description
P
c
s
Remarks
61 VKM7152 SIDE CASE R 1
62 VMG1724 LCD CUSHION 3
63 VKF4197 JACK COVER (A/V) 1
64 VKF4141 SD SLOT COVER 1
65 VMB4088 SD SLOT COVER SPRING 1
66 VMP8715 SD SLOT PLATE 1
67 VSC5913 HEAT SINK PLATE 1
68 VGU0A49 KNOB 1
69 VGQ9133 KNOB HOLDER 1
70 VMP8716 HINGE PLATE 1
71 VGL1218 ACCESS PANEL LIGHT 1
72 VEP20B99A SIDE R P.C.BOARD 1
73 VEP20C01A LCD DET P.C.BOARD 1
74 VGQ9412 BELT PAD 1
75 VYK2D35 FRONT CASE 1U 1
76 N9ZZ00000346 BARRIER MOTOR (1) 1
77 VKM7156 TOP CASE 1
78 VEP24186A ECM P.C.BOARD 1
79 VMT1784 MIC DUMPER 1
80 VYQ4060 MIC NET 1U 1
81 VSC5910 TOP FRAME 1
82 VSC5912 MIC FRAME 1
83 VEP24185A MIC P.C.BOARD 1
84 VWJ1929 MIC FPC 1
85 N9ZZ00000376 REAR COVER 1 WITH OPERATION DIAL
86 VYK2D20 SIDE CASE LU 1
87 VGQ9377 NON SLIP SHEET 1
88 VKM7157 COVER 1
89 VGL1219 PANEL LIGHT 1
90 VKW3329 SENSOR COVER 1
91 VGQ9181 EVR COVER 1
92 VYQ4059 LENS HOOD 1
93 VGQ9251 SHEET 1
94 VGQ9323 THERMAL INSULATION SHEET 1
B1-12 XQN16+BJ4FN SCREW 12
B18 XQN16+BJ4FN SCREW 1
B19,20 VHD1411 SCREW 2
B21-23 XQN16+BJ4FN SCREW 3
B24 VHD1267 SCREW 1
B25-27 XQN16+BJ4FN SCREW 3
B28 XQN16+B3FN SCREW 1
B29 XQN16+BJ4FN SCREW 1
B30 XQS16+A3FN SCREW 1
B31-41 XQN16+B3FN SCREW 11
B42-46 XQN16+B3FJK SCREW 5
B47 XQN16+B3FN SCREW 1
B48,49 VHD1667 SCREW 2
B50 XQN16+B3FJK SCREW 1
B51,52 XQN16+B4FN SCREW 2
B53-55 XQN16+B5FN SCREW 3
B56-61 XQN16+B5FJK SCREW 6
B62 VHD1904 SCREW 1
B63,64 XQN16+B6FN SCREW 2
B65-68 XQN16+BJ5FJK SCREW 4
B69 XQN16+BJ8FN SCREW 1
B70 VHD1902 SCREW 1
B71 XQN16+BJ5FN SCREW 1
EPL-4

151
168
167
160
159
163
165
164
161
158
154
155
153
157
156
152
162
B 161
B 162
LCD PARTS ASSEMBLY
MPL-5

Ref.No. Part No. Part Name & Description
P
c
s
Remarks Ref.No. Part No. Part Name & Description
P
c
s
Remarks
151 L5BDDXM00008 LCD 1
152 VEP26293A MONITOR P.C.BOARD 1
153 VGL1208 DIFFUSION SHEET 1
154 VGL1209 PRISM SHEET A 1
155 VGL1210 PRISM SHEET B 1
156 VGL1211 REFLECTION SHEET 1
157 VKW3321 LEAD LIGHT PLATE 1
158 VGQ9095 LEAD LIGHT PLATE HOLDER 1
159 VKM7153 LCD CASE (LOWER) 1
160 VSC5894 LCD SHIELD CASE 1
161 VSC5895 LCD EARTH PLATE 1
162 VKM7154 LCD CASE (UPPER) 1
163 VKM7158 HINGE COVER 1 1
164 VGQ9448 HINGE COVER 2 1
165 VXD0493 HINGE 1U 1
167 VMZ3660 BONDING TAPE A 1
168 VMZ3661 BONDING TAPE B 1
B161,62 VHD1828 SCREW 2
LCD PARTS ASSEMBLY
MPL-6

B205
203
B201 B202 B203
B204 213
205
206
210
206
214
212 208 202
201-1 201
B215
B214
216
B209
B210
B208
B213
B212
B211
215
204 211
207
207
217
B206
B207
209
LENS ASSEMBLY
MPL-7

Ref.No. Part No. Part Name & Description
P
c
s
Remarks Ref.No. Part No. Part Name & Description
P
c
s
Remarks
201 VXQ1463 PRISM U 1
201-1 VEP22375A CCD FPC P.C.BOARD 1
202 VGQ9068 CCD HEAT SINK SHEET 1
203 VXW0826 LENS 1U 1
204 L6HA66NC0010 ZOOM MOTOR 1
205 VXP2687 IRIS U 1
206 VMA0S74 SIDE YOKE 2
207 VMS7778 GUIDE POLE 2
208 VDL1900 CRYSTAL OPTICAL FILTER 1
209 VEK0K40 LENS FPC 1
210 VMS7779 F GUIDE POLE 1
211 VXP2667 2ND LENS FRAME MOVE U 1
212 VXP2670 4TH LENS FRAME MOVE U 1
213 VXQ1455 OIS U 1
214 VXQ1456 MASTER FLANGE U 1
215 VDW1342 MAIN FRAME 1
216 VXQ1452 1ST LENS FRAME MOVE U 1
217 VMB4079 2ND LENS SPRING 1
B201-10 XQN16+CJ4FJR SCREW 10
B211-13 XQN16+CJ7FJ SCREW 3
B214,15 XQN16+CJ5FJ SCREW 2
LENS ASSEMBLY
MPL-8

310
302
312
313
314
304
305
306
317
316
307
308
303
309
301
311
E only
E only
Components identified with the mark have the special characteristics for safety.
When replacing any of these components, use only the same type.
PACKING PART ASSEMBLY
MPL-9

Ref.No. Part No. Part Name & Description
P
c
s
Remarks Ref.No. Part No. Part Name & Description
P
c
s
Remarks
301 VPK3208 ACCESSORY BOX 1
302 VPF1129 PROTECT BAG 1
303 K2GJYYC00001 DC CORD 1
304 K2KZ9CB00002 AV CORD 1
305 K2KZ9DB00004 COMPONENT CABLE 1
306 K2CA2CA00029 POWER CORD 1 FOR AG-HSC1UP
306 K2CQ2CA00006 POWER CODE 1 FOR AG-HSC1UE
306 K2CA2CA00020 POWER CORD 1 FOR AG-HSC1UMC
307 VFA0474 WAIRELESS REMOTO CONTROL 1
308 K2KZ4CB00011 USB CONNECTION CABLE 1
309 DE-A38BA AC ADAPTOR 1 FOR AG-HSC1UP
309 DE-A38CA AC ADAPTOR 1 FOR AG-HSC1UE
309 DE-A38DA AC ADAPTOR 1 FOR AG-HSC1UMC
310 VPN6591 PAD 1
311 VPG1N37 PACKING CASE 1
312 VPF1112 POLYETHYLENE BAG 1 FOR AG-HSC1UP/MC
312 VPF1228 POLYETHYLENE BAG 1 FOR AG-HSC1UE
313 VQT1F36 OPERATING INSTRUCTIONS 1 (ENGLISH) AG-HSC1UP
313 VQT1F37 OPERATING INSTRUCTIONS 1 (C-FRENCH) AG-HSC1UP
313 VQT1F38 OPERATING INSTRUCTIONS 1 (ENGLISH) AG-HSC1UE
313 VQT1F39 OPERATINGINSTRUCTIONS 1 (GERMAN) AG-HSC1UE
313 VQT1F40 OPERATINGINSTRUCTIONS 1 (FRENCH) AG-HSC1UE
313 VQT1F41 OPERATINGINSTRUCTIONS 1 (ITALY) AG-HSC1UE
313 VQT1F42 OPERATINGINSTRUCTIONS 1 (SPAIN) AG-HSC1UE
313 VQT1G26 OPERATINGINSTRUCTIONS 1 (RUSSIAN) AG-HSC1UE
313 VQT1F44 OPERATING INSTRUCTIONS 1 (CHINA) AG-HSC1UMC
314 VFF0354-B OPERATING INSTRUCTIONS 1 CD-R FOR AG-HSC1UP
314 VFF0355-B OPERATING INSTRUCTIONS 1 CD-R FOR AG-HSC1UE/MC
316 K2CJ2DA00008 AC CABLE (TYPE C) 1 FOR AG-HSC1UE ONLY
317 K2CT3CA00004 POWER CORD (TYPE BF) 1 FOR AG-HSC1UE ONLY
PACKING PARTS ASSEMBLY
MPL-10
